QUICK INSTALLATION
INFORMATION -
For those of you short on time, but high on
ambition, we offer the following section to speed
up your installation of the DQT:
1. The DQT needs to be installed in the signal path
between your source unit and your external
amplifier(s). If this is not obvious to you,
quickly pack up your DQT and run to your
nearest authorized AudioControl dealer to have
them perform the installation. You will thank
us later.
2. Physically mount the DQT in a location that
keeps it away from soda spills, food crumbs, and
curious fingers. However you will want to select
Note:
You will want to turn the gains on
your amplifiers DOWN to maximize
your systems performance.
3. Hook up +12 volt power, ground, and remote
4. Adjust the "Input Level" control on your DQT
5. Now comes the fun part. Set your equalization
Figure 1: Basic DQT System
Owner's Enjoyment Manual
a location that allows you to see the display and
access the equalization controls.
turn-on. If you need to know more, then read
on. Heck if you don't think you need to know
more, you should still read on, because you can
never know too much.
to match the source unit's and then adjust the
"Output" to match with your amplifier inputs.
controls to where your system sounds the most
balanced yet dynamic. More about this in the
section titled "Adjusting Your Equalizer"...and
you thought you would not have to read the
rest on the manual. Hah!
