AudioControl Digital Equalizer Owner's Manual page 15

select a frequency, apply the proper amount of
boost or cut, and change the bandwidth or "Q" of
the filter.
Para EQ1 mode allows you set the controls for
one of the parametric equalizers.
Para EQ2 lets you change the settings for the
second parametric EQ band.
Freq (uency): This corner of the screen shows
which frequency you are boosting and cutting. If
you wish to select another frequency, just tap the
left or right arrow buttons until the cursor is
flashing on the number next to "Freq. Then use
the + or - controls allows to select the frequency
you wish to apply boost or cut.
Lvl: When the cursor highlights on this screen,
you can now apply boost or cut to both channels,
using the "+ and -" controls. You will note that
you cannot use the parametric equalizers on the
left and right channels individually.
Width: This control lets you select how wide of
an area the DQT's parametric equalizer affects.
You can choose a real narrow bandwidth, like 1/
12th of an octave or go as wide as three full oc-
taves.
MODE: Memories
using one of the eight memory locations. Using
the Left and Right navigation arrows will cause
the cursor to highlight one of the following
functions:
to move the cursor next to the word Recall. Push
the "+" or "-" button to change the memory to
which you are listening. All the stored settings are
automatically recalled as you change the memory
number.
parametric equalization settings, you will want to
store them in one of the eight memory locations.
To save a memory, you need to use the left/right
navigation arrows to move the cursor until it is
Owner's Enjoyment Manual
Memories
Figure 10: EQ Recall Memories screen
Memories
N (-) Y(+)
Figure 11: EQ Save Memories screen
This screen allows you to save or recall settings
Recall: Use the left or right navigation arrows
Save: Once you have made your graphic and
Digital
Fusion
Recall #7
Save
Recall
Save #5
11
™
