HW-F350 HW-F355 Crystal Surround Air Track (Active Speaker System) user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
Multi-function Remote Control The supplied remote control can be used to control the TV connected to this unit. (Works only for Samsung TVs) The remote control has a TV hotkey that enables you to perform various operations with the simple press of a button.
safety information SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of CAUTION electric shock or personal injury.
PRECAUTIONS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inch- es).
contents FEATURES Features License SAFETY INFORMATION Safety warnings Precautions GETTING STARTED Before reading the user’s manual What’s included DESCRIPTIONS Front Panel Rear Panel Installing the ferrite core on the Subwoofer speaker cable REMOTE CONTROL Tour of the remote control CONNECTIONS Installing the wall mount Connecting an external device using Audio (Analog) cable or Optical (Digital) cable...
descriptions FRONT PANEL POWER BUTTON Turns the Crystal Surround Air Track on and off. Selects the D.IN, AUX, BT, TV, USB input. - While the unit is powered, pressing the ( ) button for more than FUNCTION 3 seconds sets the button to act as MUTE button. BUTTON To cancel MUTE button setup, press ( ) button for more than 3 seconds again.
descriptions REAR PANEL AUX IN OPTICAL IN SUBWOOFER CONNECTOR Connects the connector jack of the Subwoofer. TERMINAL POWER SUPPLY Connect the AC power adaptor jack to the power supply in jack, and then connect the AC power adaptor plug to a wall outlet. Connect USB devices such as MP3 players here to the play files on the devices.
TOUR OF THE REMOTE CONTROL HW-F350 POWER BUTTON TV POWER BUTTON Turns your Samsung TV on and off. Turns the Crystal Surround Air Track POWER on and off. TV POWER Press the USB mode. Press the AUX mode.
Page 10
Press again to restore the sound to the previous volume level. SAT stands for Surround Air Track, which is Samsung’s proprietary name. The remote control can operate TVs made by SAMSUNG only. Depending on the TV you are using, you may not be able to operate your TV with this remote...
connections INSTALLING THE WALL MOUNT You can use the wall mount bracket to mount this unit on a wall. Installation Precautions • Install on a vertical wall only. • For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the weight of the set.
connections CONNECTING AN EXTERNAL DEVICE USING AUDIO (ANALOG) CABLE OR OPTICAL (DIGITAL) CABLE This unit comes equipped with one optical in digital jack and one audio analog in jack, giving you two ways to connect it to a TV. AUX IN OPTICAL IN Audio Cable Optical Cable...
Optical Digital input D.IN AUX input BLUETOOTH mode BT (HW-F355 model only) TV mode TV (HW-F355 model only) USB mode HW-F350 OPTICAL OPTICAL OPTICAL USB TV SOURCE USB TV SOURCE The unit turns off automatically in the following situations: POWER...
• When the Air Track is connected to the Bluetooth device, it will display BT CONNECTED ➡ BT on the front display. • If the Bluetooth device has failed to pair with the Air Track, delete the previous “[Samsung] AirTrack” found by the Bluetooth device and have it search for the Air Track again.
The Air Track automatically turns off after 20 minutes in the Ready state. SOUNDSHARE (HW-F355 MODEL ONLY) This section explains how to connect the Crystal Surround Air Track to a Bluetooth compatible SAMSUNG TV. To connect the Crystal Surround Air Track to a Bluetooth compatible...
- recommended operation range: within 16.25 ft. (5m) If the distance between the Air Track and Samsung TV is over 16.25 ft. (5m), the connection or the sound can be cut off. If this occurs, connect to the Bluetooth device again within the operational range.
Play/Pause/Stop TV MUTE TV MUTE TV INFO TV INFO TV PRE-CH TV EXIT TV PRE-CH TV EXIT HW-F350 During playback, press the ►, button. HW-F355 SOUND EFFECT SOUND EFFECT SMART VOLUME SMART VOLUME • Press the ► button again to stop playing the file temporarily.
Page 18
TV MUTE TV MUTE TV MUTE TV INFO TV INFO TV PRE-CH TV EXIT TV PRE-CH TV EXIT HW-F350 This is useful when answering a doorbell or telephone call. HW-F355 SOUND EFFECT SOUND EFFECT SMART VOLUME SMART VOLUME 1. To mute the sound of this unit, press the MUTE button on the remote control.
Page 19
Using the AUTO POWER LINK function AUTO POWER AUTO POWER AUTO POWER HW-F350 REPEAT REPEAT DIMMER DIMMER The Crystal Surround Air Track is automatically turned on when you turn on the TV or any device connected to the Air Track with the optical cable.
The remote control can operate TVs made by SAMSUNG only. SOFTWARE UPGRADE Samsung may offer upgrades for the Crystal Surround Air Track's system firmware in the future. If an upgrade is offered, you can upgrade the firmware by connecting a USB drive with the firmware upgrade stored on it to the USB port on your Air Track.
The SoundShare (TV pairing) failed. • Does your TV support • SoundShare is supported by SoundShare? some Samsung TVs released after 2012. Check your TV to • Is your TV firmware the latest see if it supports SoundShare. version? •...
Engineering Society) guidelines. *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - For the power supply and Power Consumption, refer to the label attached to the product.
Page 23
All warranty repairs must be performed by a SECA Authorized Service Center. (The name and address of the location nearest you can be obtained by calling toll free: 1- 800- SAMSUNG) LABOR PARTS...
Page 24
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site www.samsung.com/ca/support (English) CANADA 1-800-SAMSUNG (726-7864) www.samsung.com/ca_fr/support (French) U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support MEXICO 01-800-SAMSUNG (726-7864) www.samsung.com/mx/support...
Page 25
HW-F350 HW-F355 Ensemble Crystal Surround Air Track (Système avec enceintes actives) manuel d'utilisation imaginez les possibilités Merci d’avoir choisi un appareil Samsung. Pour recevoir une assistance plus complète, veuillez enregistrer votre produit sur www.samsung.com/register...
Page 27
informations relatives à la sécurité AVERTISSEMENTS POUR ÉVITER LES RISQUES DE CHOC ÉLECTRIQUE, NE DÉMONTEZ PAS LE CAPOT. L’APPAREIL NE CONTIENT PAS DE PIÈCES RÉPARABLES PAR L’UTILISATEUR ; S’ADRESSER À UN SERVICE APRÈS-VENTE QUALIFIÉ. Ce symbole avertit l’utilisateur de la présence d’une tension dangereuse à...
Page 28
PRÉCAUTIONS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Assurez-vous que l'alimentation c.a. de votre domicile satisfait aux normes inscrites sur l'étiquette d'identification située à l'arrière du produit. Installez votre produit horizontalement, sur un socle approprié (meuble), en laissant un espace suffisant pour la ventilation sur le pourtour (3~4 inches).
Page 29
sommaire CARACTÉRISTIQUES Caractéristiques Licence INFORMATIONS RELATIVES À LA Avertissements SÉCURITÉ Précautions DÉMARRAGE Avant de lire le manuel d'utilisation Contenu Panneau avant DESCRIPTIONS Panneau arrière Installation du noyau en ferrite sur le câble d'enceinte du caisson des basses TÉLÉCOMMANDE Présentation de la télécommande Installation de la fixation murale BRANCHEMENTS Branchement d’un périphérique externe...
descriptions PANNEAU AVANT BOUTON POWER Permet d'allumer/d'éteindre l'ensemble Crystal Surround Air Track. Sélection des entrées D.IN, AUX, BT, TV, USB. Pendant que l’unité est alimentée en tension, si vous appuyez sur la TOUCHE DE touche pendant plus de 3 secondes celle-ci pourrait être utilisée FONCTIONS pour la MISE EN SOURDINE.
descriptions PANNEAU ARRIÈRE AUX IN OPTICAL IN BORNE DE CONNECTEUR DU Branche la prise du connecteur du caisson des basses. CAISSON DES BASSES ENTRÉE DE Branchez correctement la prise de l'adaptateur CA au secteur, puis L’ALIMENTATION branchez la fiche de l'adaptateur CA dans la prise murale. Branchez les périphériques USB comme les lecteurs MP3 ici pour lire les fichiers des périphériques.
PRÉSENTATION DE LA TÉLÉCOMMANDE HW-F350 TOUCHE TV POWER Permet d'allumer/d'éteindre le téléviseur TOUCHE POWER Samsung. Permet d'allumer/d'éteindre l'ensemble Air Track. POWER TV POWER AUX (AUXILIAIRE) Appuyez sur le mode USB. Appuyez sur le mode AUX (AUXILIAIRE). TV SOURCE OPTICAL (OPTIQUE) Sélection d'une source vidéo sur un...
Page 34
Permet de mettre l'appareil en sourdine. Appuyez de nouveau sur cette touche pour restaurer le volume initial. SAT est l'acronyme de Surround Air Track, une dénomination propriété de Samsung. La télécommande n'est opérationnelle que sur les téléviseurs Samsung. Il se peut que cette télécommande ne soit pas compatible avec le type de téléviseur que vous...
branchements INSTALLATION DE LA FIXATION MURALE Vous pouvez utiliser le support de fixation mural pour fixer l’unité au mur. Précautions d’installation • Ne procédez pas à l'installation sur un autre emplacement qu’un mur vertical. • Pour l’installation, évitez les températures extrêmes et l’humidité ou encore un mur pas assez solide pour supporter le poids de l’appareil.
branchements BRANCHEMENT D’UN PÉRIPHÉRIQUE EXTERNE EN UTILISANT UN CÂBLE AUDIO (ANALOGIQUE) OU OPTIQUE (NUMÉRIQUE) Cette section présente les deux méthodes (numérique et analogique) de connexion de l’unité au téléviseur. Cet appareil est doté d'une prise numérique optique et d'une prise analogique audio pour connecter un téléviseur.
Entrée optique numérique D.IN Entrée AUXILIAIRE Mode BLUETOOTH BT (Modèle HW-F355 seulement) Mode TV TV (Modèle HW-F355 seulement) Mode USB HW-F350 OPTICAL OPTICAL OPTICAL USB TV SOURCE USB TV SOURCE L'appareil s'éteint automatiquement dans les conditions suivantes : POWER TV POWER...
Page 38
• Si l'appariement du périphérique Bluetooth avec le système Air Track a échoué, supprimez l'appareil “ [Samsung] AirTrack” précédent qui a été trouvé par le périphérique Bluetooth et, à partir de ce dernier, relancez la recherche du système Air Track.
Le périphérique s'éteint automatiquement (Auto Power Off) au bout de 20 minutes dans l'état Prêt (Ready). SOUNDSHARE (MODÈLE HW-F355 SEULEMENT) Cette section explique comment brancher le système Crystal Surround Air Track aux téléviseurs SAMSUNG compatibles Bluetooth. Pour connecter Le Crystal Surround Air Track à un téléviseur Samsung compatible avec le Bluetooth.
- Portée de fonctionnement recommandée : moins de 5 m Si la distance entre le SAT et le téléviseur Samsung est supérieure à 5 mètres, la connexion ou le son pourrait être coupé. Si cela se produit, branchez de nouveau le dispositif Bluetooth dans la portée de fonctionnement.
Lecture/Pause/Arrêt TV MUTE TV MUTE TV INFO TV INFO TV PRE-CH TV EXIT TV PRE-CH TV EXIT HW-F350 Pendant la lecture, appuyez sur la touche ►,. HW-F355 SOUND EFFECT SOUND EFFECT SMART VOLUME SMART VOLUME • Appuyez sur la touche ► à nouveau pour arrêter temporairement la lecture du fichier.
Page 42
TV MUTE TV INFO TV INFO TV PRE-CH TV EXIT TV PRE-CH TV EXIT HW-F350 Cette fonction se révèle particulièrement utile lorsqu’il vous faut aller ouvrir HW-F355 votre porte d’entrée ou répondre à un appel téléphonique. SOUND EFFECT SOUND EFFECT...
Page 43
Utilisation de la fonction AUTO POWER LINK AUTO POWER AUTO POWER AUTO POWER HW-F350 REPEAT REPEAT DIMMER DIMMER Le système Crystal Surround Air Track est automatiquement mis sous tension lorsque vous allumez le téléviseur ou tout autre appareil connecté au...
La télécommande n'est opérationnelle que sur les téléviseurs Samsung. MISE À JOUR DU LOGICIEL Samsung peut offrir des mises à niveau du micrologiciel du système Crystal Surround Air Track dans le futur. Si la mise à niveau du micrologiciel est offerte, il s'agit de la télécharger dans une clé...
• La fonction SoundShare est prise charge la fonction SoundShare? en charge par les modèles de (appariement du téléviseur) a téléviseurs Samsung mis sur le échoué. • La version du micrologiciel du marché après 2012. Assurez-vous téléviseur est-elle la plus récente? que votre téléviseur prend cette...
à l'aide des directives AES (Audio Engineering Society). *: Caractéristiques nominales - Samsung Electronics Co., Ltd se réserve le droit de modifier les caractéristiques sans préavis. - Le poids et les dimensions sont approximatifs. - Pour obtenir de l'information sur la source d'alimentation et la consommation électrique, veuillez vous...
Page 47
GARANTIE LIMITÉE À L’ACHETEUR INITIAL Samsung Electronics Canada Inc. (SECA) garantit ce produit contre tout défaut de fabrication. SECA garantit aussi que si cet appareil ne fonctionne pas convenablement durant la période de garantie SECA se réservera le droit de réparer ou de remplacer l’appareil défectueux.
Page 48
Comment contacter Samsung dans le monde Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service Consommateurs Samsung. Pays Centre de contact Site Web www.samsung.com/ca/support (English) CANADA 1-800-SAMSUNG (726-7864) www.samsung.com/ca_fr/support (French) U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support...
