L.B. White Therma Grow HW120 Owner's Manual And Instructions

Greenhouse heater
Hide thumbs Also See for Therma Grow HW120:
Table of Contents

Advertisement

Quick Links

Download this manual
SCAN THIS QR CODE
with your smartphone or
visit http://goo.gl/ny7ua to
view maintenance videos
for L.B.White heaters.*
*Requires an app like QR Droid for Android or
QR Reader for iPhone.
Owner's Manual and Instructions
Congratulations!
You have purchased the finest direct fired greenhouse heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and
welcome any suggestions or comments you may have...call us, toll-free,
at 1-800-345-7200.
ATTENTION ALL USERS
This heater has been tested and evaluated by C.S.A. International, in accordance
with CSA International Requirement 1.95 U.S.- Greenhouse Heaters for use as a
direct gas-fired circulating heater for the heating of greenhouses. If you are
considering using this product for any application other than its intended use, then
please contact your fuel gas supplier, or the L.B. White Co., Inc.
Therma Grow
™
View this manual online at www.lbwhite.com
MODELS
OUTPUT (Btuh)
HW120
120,000
Greenhouse Heaters
FUEL
Available in either
L.P. Gas Vapor
Withdrawal or
Natural Gas
Configurations.
150-27698 REV.A
