Stancor LX Instruction Manual

Submersible sewage pumps
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model LX
Submersible Sewage Pumps
Instruction Manual
This operational instruction manual
shall be handed to the user.
Thank you for selecting the Stancor submersible sewage pumps Model LX. Stancor takes very caution in
manufacturing the product for safe use by the customer. However unsuitable handling may reduce the
performance and result in accident.
Please read this instruction manual before starting operation. We ask for appropriate utilization in
accordance with this manual.
Therefore keep this one in safe place where it can be consulted by pump operator any time.
Be sure to hand over this manual to the customer's operation, maintenance and inspection personnel.
CONTENTS
(1) Warnings........................................
(2) Safety Cautions.............................
(3) Delivery Check..............................
2. Nameplate.................................
(4) Specifications................................
(5) Installation....................................
1. Before installation.....................
2. Installation..................................
3. Electrical wiring........................
(6) Operation......................................
2. Test operation............................
3. Operation...................................
(7) Maintenance................................
50HZ
Caution
To installation personnel
(Page)
1. Daily inspections................................
2
2. Regular inspections...........................
2
3
For long period...................................
3
3
5. Consumable parts..............................
4
(8) Trouble shooting..................................
5
(9) Construction.........................................
5
1. Section drawing.................................
5
2. Accessory............................................
6
(10) Dimensions...........................................
7
(11) Performance curve............................
7
(12) Disassembly and reassembly............
7
(13) Limited Warranty................................
7
(14) Repairing and after-service...............
8
(Page)
8
8
9
9
9
10
11
11
11
12
15
15
16
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LX and is the answer not in the manual?

Questions and answers

Related Manuals for Stancor LX

Summary of Contents for Stancor LX

  • Page 1: Table Of Contents

    Caution Thank you for selecting the Stancor submersible sewage pumps Model LX. Stancor takes very caution in manufacturing the product for safe use by the customer. However unsuitable handling may reduce the performance and result in accident.

  • Page 2: Warnings

    (1) Warnings Warnings in this manual provide information required for safe operation of the pump, and instructions for preventing danger or injury to you or other people. So that you will know the degree and imminence of danger that warnings signify, they are divided into two grades, WARNING and CAUTION, according to the seriousness of what will happen if their instructions are not heeded.

  • Page 3: The Pump And Accessories

    Do not operate the pump with 50 Hz specifications at 60 Hz. Otherwise motor should be burnt out. Do not operate the pump with 60 Hz specifications at 50 Hz. It will cause the pump to perform poorly. If you have purchased a standard pump, refer to Section (4) “Specification”. The optional specifications pump is made to meet the needs of some customers.

  • Page 4: Specifications

    Fig. 1 -Data of pump nameplate (4) Specifications For the head, capacity, speed and other major specification of your pump, see the nameplate. The standard specifications and optional specifications are given in the tables below. If you have purchased a standard pump, refer to the standard specifications shown below. The optional specifications pump is made meet the needs of some customers.

  • Page 5: Before Installation

    (5) Installation Before lifting the pump, confirm the mass on catalogue or outline drawing. Use appropriate crane (or hoist) and check position and tightness of lift system so that mass of the pump is not unbalanced. Failure to observe this precaution can result in serious accidents. On the condition of suspended pump, do not attach a part and use.

  • Page 6: Electrical Wiring

    Warning accidents or electric leakage. To prevent danger of electric shock, use short circuit breakers as exclusive use. Fig.4 3PH/50HZ LX pump Full Load AMP Chart 230V 380V All electrical wiring work should be performed Model correctly by a qualified electrician. And all 80 LX52.2...

  • Page 7: Before Starting The Pump

    When temperature of the winding raises and reaches the thermal protector acting point, the motor protection circuit is activated to protect motor from over heat. Connect to the control panel in accordance with the following specifications. Be sure to install a thermal relay on the control panel, since the thermal protector is not capable of detecting sudden temperature rises caused by single phase or locked rotor.

  • Page 8: Daily Inspections

    Output The number of starting times per hour Up to 10HP From 15 to 30HP c) Do not operate a pump in the outside of the specified range. Run the pump at a discharge capacity that is suitable for the equipment. NOTE (Capacity that is too large or small will cause noise and vibration, and vibration, and also waste power.)

  • Page 9: Cautions When The Pump Is Out For Long Period

    Once a year Replace mechanical seal at an interval of one year or 6000 hours of total operating hours, either shorter one. By the replacement, the pump life extends. Once every two to five years Overhaul of the pump assures safe and long period of operation. For the case of high frequency of operations, early overhaul is requested.

  • Page 10: (8) Trouble Shooting

    (8) Trouble shooting Trouble Cause Remedy  Obstacle inhibits the float movement.  Remove the obstacle. The pump does not start.  Power is failed.  Request the electric power company for The pump starts, but it immediately stops. action. ...

  • Page 11: Section Drawing

    (9) Construction 1. Section drawing Typical Model: 100LX57.5 Name Quantity BEARING COVER LIFTING HANGER 2※3 THERMAL PROTECTOR 849-2 BALL BEARING 849-1 BALL BEARING SHAFT OPPOSITE SIDE BRACKET POWER SIDE BRACKET MOTOR FRAME 1※2 811-2 SUBMERSIBLE CABLE 811-1 SUBMERSIBLE CABLE 2※1 STATOR ROTOR IMPELLER BOLT...

  • Page 12: Dimensions

    (10) Dimensions -12-...
  • Page 13 -13-...
  • Page 14 -14-...

  • Page 15: Performance Curve

    (11) Performance curve (12) Disassembly and reassembly Refer to the cross sectional drawing. 1. Disassembly a) Unscrew and remove the bolts (120-2), and lift up the motor part. Then lay it down carefully. b) Unscrew and remove the impeller bolt (275), Pull the impeller (021) out. c) Unscrew and remove the oil plug (193), Withdraw oil d) Unscrew and remove the bolts (120-1), and remove the mechanical seal cover (016) carefully.

  • Page 16: Limited Warranty

    2. During the said period, STANCOR will repair the pump free of charge provided that: The trouble is due to shortcomings in design, workmanship, etc., that can be attributed to STANCOR, and that the pump was being operated correctly and in a normal manner in accordance with the Instruction Manual when the trouble occurred.
