Summary of Contents for RESQTEC Q1
- Page 1 USER MANUAL Q1 CUTTER ENGLISH ORIGINAL RESQTEC USER MANUAL WWW.RESQTEC.COM...
-
Page 2: Table Of Contents
Maintenance after use 6.2. Regular maintenance 6.3. Annual maintenance 6.4. Recommended storage 6.5. Decomissioning & recycling 7. WARNINGS & LIMITATIONS 7.1. General instructions 7.2. Twisting of blades 8. TROUBLESHOOTING 9. WARRANTY 10. DISCLOSURE 11. CONTACT RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 3: Introduction: Safety First
USER MANUAL CUTTER Q1 1. INTORDUCTION: SAFETY FIRST! 1.1. SAFETY MESSAGES RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 4: Safety Information
USER MANUAL CUTTER Q1 1.3. SAFETY INFORMATION RESQTEC OPTI-GREEN HF-15 BIODEGRADABLE With serial number: Hydraulic fluid used in product: RESQTEC OPTI-GREEN HF-46 BIODEGRADABLE SKYDROL (PHOSPHATE ESTER MCS 2361) Distributor/Supplier information: RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 5: Applicable Types
USER MANUAL CUTTER Q1 1.5. APPLICABLE TYPES ARTICLE NUMBER ITEM DESCRIPTION 4310.0000.** RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 6: Product Summary
USER MANUAL CUTTER Q1 2. PRODUCT SUMMARY 2.1. INTRODUCTION PROTECTED HOSES NEO1 (MALE) COUPLER CONTROL HANDLE POSITIONING HANDLE PROTECTION COVER 180° ROTATIONAL BLADES RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 7: Product Range
USER MANUAL CUTTER Q1 3. PRODUCT RANGE 3.1. PRODUCTS & ACCESSORIES ARTICLE NUMBER ITEM DESCRIPTION PICTURE USAGE & RESTRICTIONS 4310.0000.** See chapter 4 to 7 for detailed usage & restrictions descriptions. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 8: General Operating Instructions
• See chapter 6 for further information. neutral position when released. • Check the carrying handle. It must be firmly fixed. • See chapter 6 for further information. • Check the protection covers. They must be present and undamaged. • See chapter 6 for further information. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 9: Operation
USER MANUAL CUTTER Q1 4.3. OPERATION NEUTRAL LEFT RIGHT RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 10: Quick Action Couplers
Female dust cap releases when female coupler is released (rotate and pull back). b. Male dust cap releases by simply pulling it. Align the NEO1 female coupler located on the hose with the NEO1 male coupler located on the product. Push to connect in one swift motion (if difficult to connect refer to chapter 4.10 for pressure release). RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 11: Disconnecting The Resqtec Neo1 Coupler
USER MANUAL CUTTER Q1 4.7. DISCONNECTING THE RESQTEC NEO1 COUPLER Rotate the NEO1 female coupler unlock ring in the direction of the arrow and pull backwards. Make sure the control handle of the product is not engaged when disconnecting (neutral position). -
Page 12: Connecting The Resqtec Std Coupler
USER MANUAL CUTTER Q1 4.8. CONNECTING THE RESQTEC STD COUPLER Check whether the pump relief valve is in its neutral/release pressure relief position (with exception of NEO1). NEVER TRY TO CONNECT THE COUPLERS IF THE PUMP IS SWITCHED TO OPERATION. -
Page 13: Using The Pressure Release
Push the pressure release activator pin, located on the backside of the NEO1 male dust cap, onto the NEO1 male coupler which contains the pressure release valve. NOTE THAT A SLIGHT AMOUNT OF HYDRAULIC FLUID WILL EJECT AT THIS POINT! MAKE SURE TO WEAR PROTECTIVE CLOTHING. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 14: Operating The Product
Please refer to the power unit’s user manual for additional information. (and open the valve). Rotate the control handle leftwards to open the blades. Keep the handle leftwards. Rotate the control handle rightwards to close the blades. Keep the handle rightwards. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 15: Adjusting The Blades' Angle
USER MANUAL CUTTER Q1 4.12. ADJUSTING THE BLADES’ ANGLE Manually push the blades in the desired angle. Make sure the blades are not pressurized in the most open position. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 16: Specifications
Max. spreading force 40.6 kN / 9,127 lbs Cutting head Rotatable 180 degrees EN 13204 AC60-B-7.7 EN 13204 cutting capability 1C 2D 3C 4- 5- (B-class) NFPA 1936 cutting capability A4 B4 C3 D3 E3 RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 17: Cutting Capabilities
1 1/2 x 3/8 Ø 1 1/2 3/8 x 5 3.50 x 0.22 2 1/2 x 0.19 2 x 3/8 Ø 1 3/4 3/8 x 6 3 1/2 4.00 x 0.23 3 x 0.19 2 1/2 x 3/8 RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 18: Technical Drawings
USER MANUAL CUTTER Q1 5.2. TECHNICAL DRAWINGS RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 19: Maintenance & Storage
• Mild soapy water can be used if Do NOT use any oil. necessary. Dry thoroughly after using water. Check the couplers and dust caps for dirt. Do NOT use any oil. • Use dry, paper cloth. Clean if necessary. RESQTEC Manual Q1 CUTTER (DM068K06) - Page 20 USER MANUAL CUTTER Q1 RESQTEC Manual Q1 CUTTER (DM068K06)
-
Page 21: Regular Maintenance
Check and clean couplers thoroughly. Do not use any additional means of lubrication, as some products might • Verify smooth operation by connecting have a negative effect on the and disconnecting al couplers at least connector. three times. RESQTEC Manual Q1 CUTTER (DM068K06) - Page 22 • Check the hose assemblies for oil be subjected to further inspection by leakage. an authorized person. When in doubt ALWAYS replace the hose. Connect all components and test all • All products should make at least two functions. complete cycles. RESQTEC Manual Q1 CUTTER (DM068K06)
-
Page 23: Annual Maintenance
USER MANUAL CUTTER Q1 6.3. ANNUAL MAINTENANCE Recommended storage temperature range 10 ˚C – 30 ˚C / 50 °F – 86 °F Recommended storage relative humidity 0 – 60% RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 24: Warnings & Limitations
USER MANUAL CUTTER Q1 7. WARNINGS & LIMITATIONS 7.1. GENERAL INSTRUCTIONS 90º RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 25: Troubleshooting
The product is connected to a power unit, but the blades will not open - Make sure the right valves on the power unit are opened. or close. - Make sure there is enough hydraulic oil and gasoline in the power unit. RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 26: Warranty
USER MANUAL CUTTER Q1 9. WARRANTY RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 27: Disclosure
USER MANUAL CUTTER Q1 10. DISCLOSURE RESQTEC Manual Q1 CUTTER (DM068K06) -
Page 28: Contact
USER MANUAL CUTTER Q1 11. CONTACT RESQTEC Manual Q1 CUTTER (DM068K06) - Page 29 RESQTEC Zumro B.V. Meer en Duin 82 2163 HC Lisse, the Netherlands +31 (0)252 419002 +31 (0)252 411794 info@resqtec.com WWW.RESQTEC.COM...
