USER MANUAL
G-SERIES CUTTERS
EN | Original RESQTEC user manual
WWW.RESQTEC.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G Series and is the answer not in the manual?

Questions and answers

Related Manuals for RESQTEC G Series

Summary of Contents for RESQTEC G Series

  • Page 1 USER MANUAL G-SERIES CUTTERS EN | Original RESQTEC user manual WWW.RESQTEC.COM...

  • Page 2: Table Of Contents

    Preparation before use 4.3. Operation 4.4. Optimized 350 bar 4.5. Quick action couplers 4.6. Connecting the Resqtec NEO1 coupler 4.7. Disconnecting the Resqtec NEO1 coupler 4.8. Connecting the Resqtec STD coupler 4.9. Disconnecting the Resqtec STD coupler 4.10. Using the pressure release 4.11.

  • Page 3: Introduction: Safety First

    1.2 GENERAL SAFETY INFORMATION The Resqtec equipment is designed to provide safe operation. All users should read and be thoroughly familiar with the operating instructions and safety precautions stated in this manual. Operator safety depends on users being properly trained by the Authority having jurisdiction and using the equipment for its intended purposes only.

  • Page 4: Safety Information

    Failing to do so may result in damage to the hose assembly and malfunction of your Resqtec system. • Make sure no one on site is in danger or might get, when using Resqtec equipment. Be aware of your surroundings, the situation you and the people around you are in, and what the consequences of the use of the Resqtec system are.

  • Page 5: Applicable Types

    USER MANUAL CUTTER G-SERIES 1.5 APPLICABLE TYPES This manual covers the following product types: Article number Item description 4120.0000.** 5141.0100.** 5143.0200.** 5161.0100.** 5162.0100.** 5163.0300.** 5182.0100.** 5183.0100.** RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 6: Product Summary

    Read all the instructions before using the product to assure safe and optimal use of the product. These instructions contain aspects relevant to safe and optimal use of the product. The product has been manufactured by Resqtec Zumro. For addresses, please refer to the last page of this manual or to our internet site at www.resqtec.com.

  • Page 7: G4A/W, G6A/C/W, G8C/W

    USER MANUAL CUTTER G-SERIES 2.3.2 G4a/w, G6a/c/w, G8c/w CONTROL HANDLE NEO1 (MALE) COUPLER CARRYING HANDLE PROTECTION COVERS CUTTER BLADE SPREADING TEETH RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 8: Product Range

    USER MANUAL CUTTER G-SERIES 3. PRODUCT RANGE IMAGES AS DISPLAYED IN THIS MANUAL MAY DIVERGE FROM ACTUAL PRODUCT APPEARANCE. 3.1 PRODUCTS & ACCESSORIES Article number Item description Picture Usage & Restrictions 4120.0000.** 5141.0100.** 5143.0200.** 5161.0100.** 5162.0100.** RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 9 USER MANUAL CUTTER G-SERIES Article number Item description Picture Usage & Restrictions 5163.0300.** 5182.0100.** 5183.0100.** RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 10: General Operating Instructions

    DAMAGE IS FOUND. DO NOT USE DAMAGED EQUIPMENT UNDER ANY CIRCUMSTANCE! In general we distinguish a couple of different types of operations; • Connecting the Resqtec NEO1 coupler • Disconnecting the Resqtec NEO1 coupler • Connecting the Resqtec STD coupler •...

  • Page 11: Operation

    In this manual the Resqtec NEO1 couplers and the Resqtec STD couplers are described; follow the instructions of your current couplers only. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 12: Quick Action Couplers

    • If couplers do not have auto lock mechanism on the product, rotate collar of female coupler to lock and prevent accidental release. • Unroll hose reels to their full extend. Make sure that no pressure is applied before unrolling. 4.6 CONNECTING THE RESQTEC NEO1 COUPLER Make sure the dust caps are removed from both the coupler (male &...

  • Page 13: Disconnecting The Resqtec Neo1 Coupler

    USER MANUAL CUTTER G-SERIES 4.7 DISCONNECTING THE RESQTEC NEO1 COUPLER Rotate the NEO1 female coupler unlock ring in the direction of the arrow and pull backwards. Make sure the control handle of the tool is not engaged when disconnecting (neutral position).

  • Page 14: Connecting The Resqtec Std Coupler

    USER MANUAL CUTTER G-SERIES 4.8 CONNECTING THE RESQTEC STD COUPLER Check whether the pump relief valve is in its neutral/release pressure relief position (with exception of NEO1). NEVER TRY TO CONNECT THE COUPLERS IF THE PUMP IS SWITCHED TO OPERATION.

  • Page 15: Using The Pressure Release

    NOTE THAT A SLIGHT AMOUNT OF HYDRAULIC FLUID WILL EJECT AT THIS POINT! MAKE SURE TO WEAR PROTECTIVE CLOTHING. For STD couplers a separate pressure release tool is available. Contact your distributor/supplier for details. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 16: Operating The Product

    Rotate the control handle rightwards to close the blades. Keep the handle rightwards. BEFORE STORING THE PRODUCT IT IS RECOMMENDED TO DEPRESSURIZE THE CYLINDER. TO DO THIS, OPEN THE BLADES TO THE POINT WHERE ONLY THE TIPS TOUCH EACH OTHER. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 17: Specifications

    EN 13204 cutting capability 1H 2G 3G 4F 5G (F-class) NFPA 1936 cutting capability A6 B6 C6 D7 E6 Round bar capability (S235 acc. to EN 13204) 30mm EN 13204 classification BC 154F-10.3 BC 154F-11.5 RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 18 EN 13204 cutting capability 1I 2K 3I 4J 5J (I-class) NFPA 1936 cutting capability A7 B8 C6 D7 E9 Round bar capability (S235 acc. to EN 13204) 38mm EN 13204 classification BC 187I-14.3 BC 187I-15.5 RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 19 EN 13204 cutting capability 1J 2K 3K 4K 5K (J-class) NFPA 1936 cutting capability A8 B9 C8 D9 E9 Round bar capability (S235 acc. to EN 13204) 43 mm EN 13204 classification CC 200J-20.0 CC 200J-21.2 RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 20: Imperial System Data

    EN 13204 cutting capability 1H 2G 3G 4F 5G (F-class) NFPA 1936 cutting capability A6 B6 C6 D7 E6 Round bar capability (S235 acc. to EN 13204) 1 3/16” EN 13204 classification BC 154F-10.3 BC 154F-11.5 RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 21 EN 13204 cutting capability 1I 2K 3I 4J 5J (I-class) NFPA 1936 cutting capability A7 B8 C6 D7 E9 Round bar capability (S235 acc. to EN 13204) 1 ½” EN 13204 classification BC 187I-14.3 BC 187I-15.5 RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 22 EN 13204 cutting capability 1J 2K 3K 4K 5K (J-class) NFPA 1936 cutting capability A8 B9 C8 D9 E9 Round bar capability (S235 acc. to EN 13204) 1 11/16” EN 13204 classification CC 200J-20.0 CC 200J-21.2 RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 23: Cutting Capabilities

    USER MANUAL CUTTER G-SERIES 5.1.3 CUTTING CAPABILITIES Resqtec cutting tools are designed and manufactured in accordance with EN- and NFPA-certifications and classifications. The following tables represent the EN- and NFPA-classification system: Categorizing according to EN 13204 – Metric system ROUND HOT...

  • Page 24: Technical Drawings

    USER MANUAL CUTTER G-SERIES 5.2 TECHNICAL DRAWINGS The technical drawings in this chapter only present actual product dimensions. Coupler dimensions are excluded from these drawings. 5.2.1 SI-SYSTEM DATA RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 25 USER MANUAL CUTTER G-SERIES RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 26: Imperial System Data

    USER MANUAL CUTTER G-SERIES 5.2.2 IMPERIAL SYSTEM DATA RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 27 USER MANUAL CUTTER G-SERIES RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 28: Maintenance & Storage

    • Mild soapy water can be used if necessary. Dry thoroughly after using water. Check the couplers and dust caps for • Use dry, paper cloth. Do NOT use any oil. dirt. Clean if necessary. RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 29 PURPOSES, ONLY USE CRC SP 400. OTHER PRODUCTS ARE KNOWN TO HAVE NEGATIVE EFFECTS ON THE LUBRICANT USED IN YOUR EQUIPMENT. OTHER PRODUCTS ALSO DO NOT HAVE THE HIGH PROTECTION GRADE THAT CRC SP 400 PROVIDES. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 30: Regular Maintenance

    Connect all components and test all functions. • All products should make at least two complete cycles. DO NOT TAKE UNNECESSARY RISK BY UTILIZING FAULTY HOSES. WORN OR DAMAGED HOSES CAN CAUSE SERIOUS INJURY AND/OR DAMAGE TO THE RESQTEC SYSTEM AND OTHER PROPERTY. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 31: Annual Maintenance

    Many years of safe use is guaranteed if the product is properly cared for and maintained. To this end the product must be inspected at least once a year. This must be carried out by a service technician trained by Resqtec who possesses the necessary tools and testing equipment.

  • Page 32: Warnings & Limitations

    • Seat-belt mounting bolts; • Hinge pins; • Track rod ends. MISUSE OF RESQTEC EQUIPMENT IN THIS WAY MAY RESULT IN SERIOUS INJURY AND/ OR DAMAGE TO THE SYSTEM AND/OR PROPERTY. The warranty will void if these restrictions are disregarded.

  • Page 33: Troubleshooting

    • Make sure there is enough hydraulic oil and gasoline in the power unit. IF YOU CANNOT FIND THE PROBLEM THAT OCCURRED, OR IF THE PROVIDED SOLUTION DID NOT RESOLVE THE PROBLEM, STOP USING THE PRODUCT IMMEDIATELY AND CONTACT A CERTIFIED DISTRIBUTOR/SUPPLIER OR ONE OF THE RESQTEC OFFICES. RESQTEC USER MANUAL G-SERIES (DM065K09)

  • Page 34: Warranty

    USER MANUAL CUTTER G-SERIES 9. WARRANTY Resqtec offers two years warranty upon the purchase of this tool. For extending your warranty or information about the Resqtec service program, please contact your Resqtec distributor/supplier. WARRANTY IS ONLY VALID IF THE REGULATIONS AND RESTRICTIONS, AS DESCRIBED IN THE USER MANUAL APPLICABLE ON THE USED TOOL(S), ARE UNDERSTOOD AND FOLLOWED, AND IF THE MAINTENANCE AS ADVISED IN THE USER MANUAL IS DONE BY AN AUTHORIZED RESQTEC TECHNICIAN.

  • Page 35: Disclosure

    All information herein was carefully gathered and examined. However, we cannot be held responsible for eventual mistakes or incompleteness. Resqtec may exercise the right to change or modify parts of the equipment at any time without notification. This manual may be subject to error, revision and technical modifications.

  • Page 36: Contact

    Subang Hi-Tech Industrial Park T +31 (0)252 419002 T: +1 973 627 4646 47 500 Selangor, Malaysia F +31 (0)252 411794 F: +1 973 627 4622 T +603 5621 5298 F +603 5621 2895 info@resqtec.com www.resqtec.com RESQTEC USER MANUAL G-SERIES (DM065K09)
  • Page 37 RESQTEC Zumro B.V. Meer en Duin 82 2163 HC Lisse, the Netherlands +31 (0)252 419002 +31 (0)252 411794 info@resqtec.com...
