Salto XS4 Mini Installation Manual

Installation guide XS4
For mortise locks with DIN door holes (38 mm) for handle fastening
Installation guide
Eng
Guía de instalación
E
Montageanleitung
D
Guide d'installation
F
Handleiding
NL
Guida all'installazione
I
M5
38
Eng
E
INSTALLATION GUIDE EI5XX...
221495-ED. 10/06/2014
22.5
20 MIN.
O
*
Required only for
doors that exceed
60mm thickness
*
Sólo para puertas de
espesor mayor de
60mm
MINI
58.5
38
*
SALTO recomends the use of a mortise lock,
Eng
with a maximum 4º pre-turn
E SALTO no garantiza el correcto funcionamiento del
ensamblaje, si se utilizan cerraduras con pregiro
superior a 4º
1/4
E i 1 m d ffc t s h r series
50
Mortise Lock not
included
Cerradura de embutir
no incluida
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
