Salto XS4 Mini Installation Manual

Installation guide
Eng
Guide d'installation
F
Guía de instalación
E
4-57/64"
(124,5 mm)
TUBULAR LATCH
ONLY WITH SALTO TUBULAR LATCH.
TORX 20 x1
AA - LR6
TORX 20 x2
SP01077-10
i
+
PH 2
TX 20
(*) Only for door thickness > 2-3/8" (60mm).
(*) Seulement pour portes de épaisseur > 2-3/8" (60mm).
(*) Solo para grosor de puerta > 2-3/8" (60mm).
For door preparation, see: 4DS00022 or 4DS00023.
Pour préparation de la porte, voir: 4DS00022 or 4DS00023.
Para mecanizado de puerta, ver: 4DS00022 or 4DS00023.
Select handing
Eng
OPTION 1: Ti 250 xx series
L
R
1
All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
Installation Guide
Installation guide
XS4 Mini ANSI With Tubular Latch
XS4 Mini ANSI with cylindrical latch
1-35/64" 1-35/64"
(39 mm) (39 mm)
1-1/16" 1-1/16"
(27 mm) (27 mm)
OUTSIDE INSIDE
3-23/64"
(85mm)
TORX 20 x4
Self tapping screws
*
Spindle
SFIC
Cylinder
(Not included)
Outside lever
Choisir le sens de la bèquille
F
click!
2
2-43/64"
(68 mm)
4-57/64"
(124,5 mm)
54°
Mounting screws
Inside assembly
2 - 1/8"
(54 mm)
2-3/4"
(70 mm)
*
Outside assembly
Seleccione mano
E
E
1x5
3
© 2023 SALTO Systems S.L.
T i 2
T i 2
2-43/64"
(68mm)
CLUTCH + OVERRIDE MOD.
Inside lever
Inside cover
Fixing screw
Tubular latch SALTO LT2Lxx
Strike
To be used only with SALTO compatible
escutcheons!
A utiliser uniquement avec les ensembles
plaques-béquilles SALTO compatibles!
¡Utilizar solamente con escudos SALTO
compatibles!
Atention!
a
Attention!
¡Atención!
b
4
1/4
xx.. series
50
70 xx..
1"
(25,4mm)
Real size
click!
TORX 20
Real size
227228-ED. - 19/10/2023
