- Page 2 Voltage See nameplate Power Output 1400W Turbine 3 stage Airflow 2800 L/min Max Working Pressure 0.41 bar (6 psi) Turbine Dimensions (LxWxH) 325mm x 250mm x 325mm Net Weight 8.5 kgs ( 18.7 Lbs) Material Applications: * Automotive refinish * Architectural * Marine * Industrial * Aerospace...
- Page 3 GENERAL SAFETY RULES outlet properly installed and grounded in accordance with all codes and ordinances. W A R N I N G ! R e a d a n d u n d e r s t a n d a l l Never remove the grounding prong or instructions.
- Page 4 a power tool. Do not use tool while you b) Do not use the power tool if the switch are tired or under the influence of drugs, does not turn it on and off. Any power tool alcohol, or medication. A moment of that cannot be controlled with the switch is inattention while operating power tools dangerous and must be repaired.
- Page 5 5) Service Tethrachloethane. H a v e y o u r p o w e r t o o l s e r v i c e d b y a qualified repair person using only identical PREVENT STATIC SPARKING FIRE/EXPLOSIONS replacement parts.
- Page 6 • ALWAYS ensure fire extinguishing hot surfaces. equipment is readily available and • NEVER use a damaged hose. Before properly maintained. each use, check entire hose for cuts, leaks, abrasions, or bulging. If any of ALWAYS INSPECT SPRAYING AREA these conditions exist, replace the hose immediately.
- Page 7 next heavier gauge. absolutely minimizes air pollution emissions Hose: use only grounded hoses. associated with paint spraying. Media Spray gun: grounding is obtained which are traditionally sprayed by high through connection to a properly pressure compressor driven paint sprayers grounded hose and turbine. can be sprayed by this new technology.
- Page 8 the proper consistency is found. Droplets off Fluid flow control knob the stir stick should be about one second apart. WARNING: Universal motors, like the one used in this turbine, by their nature create sparks at the commutator. Whenever spraying flammable media, keep the turbine at least 6 meters (20 Test the spray pattern and atomization feet) away from the spraying area.
- Page 9 Speed control knob Air cap Nozzle Trigger Retaining ring On-off switch Choosing Fluid Sets: Fluid flow control knob The fluid set includes a Needle, a Nozzle and an Air Cap. These parts are a matched set. Do not mix parts from other sizes. The standard fluid set which comes with the Needle gun is a 1.3mm, which will work well for most...
- Page 10 that is necessary is to convert the gun. To convert: Use an appropriate wrench to loosen the nut to remove the paint cup. Connect the hose from the pressure pot. Use an appropriate wrench to unscrew the nipple for the vent tube from the gun body.
- Page 11 WIRING...
- Page 12 HVLP TURBINE EXPLODED VIEW...
- Page 13 HVLP TURBINE PARTS LIST Parts Name Q'TY Parts Name Q'TY HEX NUT-LEFT HAND THREAD SOUND DEADENING-LOWER FAN 70 x 6 BOTTOM PLATE MOTOR HOUSING POWER SUPPLY CORD BRUSH HOLDER SCREW M4 x 16 CARBON BRUSH 7 x 12 CORD CLIP SCREW M4 x 12 SUN WASHER...
- Page 14 HVLP GUN EXPLODED VIEW...
- Page 15 HVLP GUN PARTS LIST Parts Name Q'TY G1-1 AIR CAP RETAINING RING G1-2 AIR CAP NOZZLE BAFFLE GUN BODY SOCKET CAP SCREW PATTERN ADJUSTOR O-RING SEAT ADJUSTOR SUPPORT ADJUSTOR KNOB BUSHING NEEDLE SPINDLE SPRING SEAL O-RING O-RING SPINDLE HOUSING NEEDLE ASSEMBLY NEEDLE SPRING FLUID CONTROL KNOB GRIP...
