Low-Frequency Electronic Pulse Massager P01
User's Manual
HCM-P01 Series
Thank you for purchasing the ELECOM ECLEAR refree.
This manual describes the operating instructions and safety precautions for using the
device.
Please be sure to read this manual carefully before using the device. After reading,
keep the manual safe for future reference.
Safety Precautions
The following precautions provide instructions that must be followed in order to
prevent personal injury to, or damage to property of you or any other person.
The symbols shown classify and explain the seriousness of possible hazards or
damage if you ignore the precautions and use the device incorrectly.
2nd edition, August, 2016
(Please be sure to follow the precautions)
Failure to observe Dangers will result in serious personal
Danger
injury or death.
Failure to observe Warnings may result in serious personal
Warning
injury or death.
Failure to observe Cautions may result in personal injury or
Caution
property damage.
This symbol indicates a prohibited action.
This symbol indicates a mandatory action.
Danger
Do NOT use this device if you are using a medical device such as:
• A pacemaker or any other implanted electronic medical device;
• A heart-lung machine or any other life-support electronic medical device; or
• An electrocardiograph or any other wearable electronic medical device.
Such use could cause a malfunction of these medical devices, and
severely impair your life.
Warning
Do not use this device around the heart, on the head, face, mouth,
pudendum or any blemished skin areas.
Such use could cause an accident, injury or ill health.
Do not use for any other purpose than treatment.
Such use could cause an accident, problem or device failure.
Do not use this device simultaneously with any other therapeutic device.
Such use could cause discomfort or ill health.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the refree HCM-P01 series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elecom refree HCM-P01 series

  • Page 1 Do not use this device around the heart, on the head, face, mouth, pudendum or any blemished skin areas. Thank you for purchasing the ELECOM ECLEAR refree. Such use could cause an accident, injury or ill health. This manual describes the operating instructions and safety precautions for using the device.
  • Page 2 Warning Warning Do not allow children to use this device, or play on or ride on the main Do not disassemble, repair or modify the device. unit or gel pad. Otherwise, fire or electric shock may be caused. Do Not Disassemble Such use could cause an accident or injury.
  • Page 3 Caution Caution Make sure the dedicated USB cable is connected securely when Please make sure the device works properly by testing the device as per the User’s Manual before using for the first time, or when it has not charging. been used for a long period of time.
  • Page 4: Product Features

    Product Features Package Contents Intended Use or Indications Please make sure all components are included. Although we aim to ensure that This product is a low-frequency electronic pulse massager designed to prevent all our products are carefully packaged. atrophy of numb muscles and provide massage benefits. This product is intended for home use.
  • Page 5: Part Names

    Part Names Optional Parts Main Unit Power button (mode selection button) The following optional parts are available: [+] (Strong) button LED indicator Trade name: Gel pad P01 Main unit [-] (Weak) button Medical device submission No.: 27B2X00293000001 USB port (for charging) 1 Point Pads (pair) 2 Point Pads (pair) Connectors (on the main unit)
  • Page 6: Charging The Device

    Preparation Be sure to fully charge the device before using (for the first time after purchase, or when it has not been used for a long time), or when the battery has run out during use. Connecting the gel pad to the main unit. Charging the device.
  • Page 7: Placement Of The Gel Pad

    Placement of the Gel Pad Pull the tab on the gel pad, and remove it from the protective film. Replacement of Gel Pads Disconnect the main unit from the gel pad. Take the gel pad from the bag. (Do not remove the protective film from the gel pad yet.) Note: For the second or subsequent use of the device, remove the gel pad from the storage sheet.
  • Page 8: Turn On The Device

    Gel Pad Placement Guide Treatment Shoulder -trapezius muscles- Upper arm -brachial muscle- Arm -flexor muscles of forearm- Turn ON the device. Place on stiff muscles. Place on stiff muscles in Place on stiff muscles in Press and hold the Power button for about two seconds. You will hear the upper arm.
  • Page 9: Turn Off The Device

    Adjust the intensity level. Store the device. Select one of 10 intensity levels, as you prefer. Remove the gel pad from the skin. Note: When the device is turned on, or when modes are changed, Pull the tab to remove the gel the intensity is set at level 1.
  • Page 10: Maintenance

    Maintenance Storage Store the product in an environment with the following conditions: Remove the main unit from the gel pad when cleaning. Storage temperature: - 10°C - 60°C How to Clean a Gel pad Storage humidity: 20 - 85% RH (Recommended maintenance interval: once per 30 times of use) Clean the gel pad when: Precautions for Cleaning and Storage...
  • Page 11 Disposal Recycling of Lithium-Ion Battery How to Remove Lithium-ion Battery Do NOT disassemble other than to dispose of the product. This product contains a lithium-ion battery. Since lithium-ion batteries are recyclable, valuable resources, we strongly The following procedures are to dispose of the product; not to encourage customers to recycle.
  • Page 12: Troubleshooting

    Troubleshooting Problem Cause Solution  The battery is not charged enough, or is dead. Turn off and charge the device. P .11 The device does not turn on.  The battery is being charged. After finishing charging the battery, disconnect the dedicated USB cable, and use the device. P .11 ...
  • Page 13: Product Specifications

    Machinery and equipment 78: Electronic Classification Therapeutic Device for Home Use ELECOM Co., Ltd will have no liability for any loss of data, damages, or any other Low-Frequency Electronic Pulse Massager for problems that may occur to any devices connected to this product.
  • Page 14 August 2016, Ver. 2 ELECOM Co., Ltd. • The copyright of this manual is owned by ELECOM Co., Ltd. • Unauthorized reproduction/reprint of all or part of this manual is prohibited. • The specifications and appearance of this product may be changed without prior notice for product improvement purposes.
