Back:
1. Power Connection—The bar power cable connects here.
2. Audio Inputs (Source 1 Optical, 2 AUX/Bluetooth, or 3
Wi-Fi)— Where you connect your TV (or other sources) to
the sound bar. Source 3 (Wi-Fi) is a wireless connection. For
"wired" connections, use the 6' optical cable (Source 1) pro-
vided or 1/8" analog cable (also used by Bluetooth adapter)
(Source 2) provided. Use the USB charging port for any USB
powered device (ex. Bluetooth adapter,
smartphone, tablet, iPod, etc.), for manual firmware updates
via a USB flash drive, or to create a hard-wired Ethernet
connection using a USB Ethernet adapter.
3. IR Input— Use for a wired IR pass-through
(cable sold separately)
4. Sub Out— Hard wire sub connection
5. SYNC—The SYNC button ensures the subwoofer and bar
are communicating with each other.
Note: If the SB1 Plus system ever loses power, the system will
default to "Standby" when power is restored.

Subwoofer Controls

1. Power Switch—Turns the wireless subwoofer on or off,
but you can leave it on all the time if you wish.
2. Power Connection—The subwoofer power cord
connects here.
The status light on the wireless subwoofer indicates
the following:
a. Green Steady—The bar and subwoofer are connected.
b. Green Slow Blinking—The subwoofer is searching
for the bar.
c. Green Fast Blinking—The subwoofer is in the process of
connecting with the bar.
a. Red Steady—The subwoofer is in standby mode.
b. Red Blinking—The subwoofer is in protection mode.
Remote Control
1. www.polkaudio.com
Power— Turns on the bar or puts it in
standby mode.
Mute— Mutes and unmutes the sound
coming from the sound bar.
Source 1, 2, WiFI — Changes which
input source you are listening to.
Master Volume Up and Down ( + / – )
Adjusts the master volume of the system.
Center Volume Up and Down ( + / – )
Adjusts the volume of the center channel.
SUB Volume Up and Down ( + / – )
Adjusts the volume of the subwoofer.
Movie/Music Select—Tailors the audio
for either movies or music.
VoiceAdjust Technology
™
Your SB1 Plus Sound Bar Sound bar has a dedicated center
channel, which you control from either the bar or the remote
control. By controlling the volume of the center channel, you can
make movie or television dialogue louder and more intelligible.
Wireless Rear Surround Speaker Technology
The SB1 Plus comes with built-in wireless rear surround
speaker technology. Just connect the sound bar to any pair of
Play-Fi speakers and enjoy a true 5.1 home theater experience.
(App and firmware update required).
Included Bluetooth Adapter
The SB1 Plus comes with a separate Bluetooth adapter (must
be plugged into both USB and Aux IN ports) so you can switch
between Wi-Fi and Bluetooth in seconds—play audio from even
more online sources from your phone, tablet or computer without
having to use the Polk Omni app and restream it to any Play-Fi
speaker on your network.
IR Remote Learning
Set Up Your TV's IR Remote Control For SmartBar™ Learning
Note: For your sound bar to respond to your remote control, you
MUST FIRST program the bar to respond to your television's
original IR (Infra-Red) remote. An RF (Radio Frequency) remote
will not work. Other remotes (cable, satellite) will work only after
you have programmed the bar to respond to the TV's IR remote.
Programming Instructions:
Your sound bar is currently programmed to respond to the remote
control that is included with the product. However, we strongly
recommend programming the sound bar to also respond to your
existing remote control using the steps illustrated below. This will
enable you to operate all of your components using a single re-
mote control. While programming the sound bar, ignore anything
that may be displayed on the TV screen.
Example: To teach your bar the "Volume Up" command of your
remote control.
1. The Sound Bar is turned on and the LED is dim red, and
you have sound coming from the bar.
2. Press and hold the "SOURCE/LEARN" button (on either
the bar or the included remote) for 5 seconds. LEDs 3, 5,
7, 9, 11 pulse.
