Base View - Acer Aspire 3410T Quick Manual

Base view

# Icon Item
1 Battery bay
2 Battery lock
3 Memory compartment
4 Hard disk bay
5 Ventilation slots and
cooling fan
6 Battery release latch
Description
Houses the computer's battery pack.
Locks the battery in position.
Houses the computer's main memory.
Houses the computer's hard disk
(secured with screws).
Enable the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the
opening of the fan.
Releases the battery for removal.
9
