IMPORTANT:
Do not attempt to install this equipment if it appears to be damaged in any way. See
the Troubleshooting Section for instructions on how to return the equipment if it is
damaged or suspected to be damaged.
Personal Safety
WARNING: Personal Injury
This equipment weighs in excess of 49 lbs (22 kg). Use safe lifting techniques when
Use standard safety equipment such as safety glasses, ear protection, steel-toed
Use standard safety practices when working with electrical equipment (e.g., remove
Never work alone when installing or servicing this equipment. Have someone
Inverter Safety
WARNING: Lethal Voltage
WARNING: Burn Hazard
Internal parts can become hot during operation. Do not remove the cover during
operation or touch any internal parts. Be sure to allow sufficient time for internal parts
to cool down before attempting to perform any maintenance.
WARNING: Fire Hazard
900-0113-01-00 Rev A
lifting this equipment as prescribed by local codes.
safety boots, safety hard hats, etc., as prescribed by local codes when working on
this equipment.
all jewelry, use insulated tools, wear cotton clothing, etc.).
nearby that can assist if necessary.
Review the system configuration to identify all possible sources of energy. Ensure
ALL sources of power are disconnected before performing any installation or
maintenance on this equipment. Confirm that the terminals are de-energized using
a validated voltmeter (rated for a minimum 1000 Vac and 1000 Vdc) to verify the
de-energized condition.
Do not perform any servicing other than that specified in the installation
instructions unless qualified to do so, or have been instructed to do so by OutBack
Power Technologies Technical Support personnel.
Do not place combustible or flammable materials within 12 feet (3.7 m) of
the equipment.
This product contains relays with moving parts and is not ignition-protected.
Ensure AC, DC, and ground cable sizes conform to local codes. See pages 18
through 21 for minimum size requirements. Ensure all conductors are in good
condition. Do not operate the unit with damaged or substandard cabling.
Important Safety Instructions
3
