Colour television

Contents
1
Technical Specifications, Connection Facilities, 2
and Chassis Overview
2
3
4
5
6
2
7
LSP: Main Supply
LSP: Standby Supply
LSP: Line Deflection
LSP: Frame Deflection E/W Drive(Diagram A4) 45
LSP: Rotation Circuitry
LSP: Audio Amplifier
LSP: Headphone Amplifier
LSP: Tuner, SIMM Conn.(Fem.) (Diagram A8) 48
LSP: Receiver
LSP: Front
LSP: Inputs/Outputs
LSP: Mapping PWB Layouts
SSB: SIMM Connector (Male)
SSB: IF, I/O, Video Processing
SSB: Featurebox
©
Copyright 2003 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by RB 0370 Service PaCE
Page
4
6
22
33
34
35
36
37
38
39
40
(Diagram A1A) 41
51-57
(Diagram A1B) 42
51-57
(Diagram A2) 43
51-57
(Diagram A3) 44
51-57
51-57
(Diagram A5) 46
51-57
(Diagram A6) 47
51-57
(Diagram A7) 46
51-57
51-57
(Diagram A9) 49
51-57
(Diagram A10) 49
51-57
(Diagram A11) 50
51-57
52
(Diagram B1) 58
64-73
(Diagram B2) 59
64-73
(Diagram B3) 60
64-73
Printed in the Netherlands
Contents
SSB: HOP
SSB: Audio Demodulator
CRT Panel
DC-Shift Panel
VDAF + 2nd Orders
Mains Switch FL9 Styling
Mains Switch PV2 Styling)
HD Jack Panel: Control
HD Jack Panel: Inputs/Outputs
HD Jack Panel: Sync Slicer
HD Jack Panel: Matrix
Side I/O Panel
Top Control Panel PV2 Styling
Top Control Panel PV0 Styling
8
9
List of Abbreviations
10 Spare Parts List
11 Revision List
Subject to modification
Chassis
EM1.1A
AA
CL 36532061_000.eps
280803
Page
(Diagram B4) 61
64-73
(Diagram B6) 62
64-73
(Diagram B7) 63
64-73
(Diagram D)
74
75
(Diagram F)
76
77
(Diagram G)
78
78
(Diagram I)
79
80
(Diagram J)
81
82
(Diagram J)
83
83
(Diagram N1) 84
87-89
(Diagram N2) 85
87-89
(Diagram N3) 86
87-89
(Diagram N4) 86
87-89
(Diagram O)
90
91
(Diagram P)
92
93
(Diagram P)
92
94
95
100
114
116
118
126
EN 3122 785 13870
