This publication is a Service Manual covering the specifications, construction, theory of operation,
and m aintenance of the Brother facsim ile equipm ent. I t includes inform ation required for field
troubleshooting and repair--disassembly, reassem bly, and lubrication- -so that serv ice personnel
will be able to understand equipm ent function, to rapidly repair the equipm ent and order any
necessary spare parts.
To perform appropriate m aintenance so that the facsim ile equipment is alw ays in best condition
for the customer, the service personnel must adequately understand and apply this manual.
This manual is made up of eight chapters and appendices.
SAFETY INSTRUCTIONS
CHAPTER 1 PARTS NAMES & FUNCTIONS
CHAPTER 2 SPECIFICATIONS
CHAPTER 3 INSTALLATION
CHAPTER 4 THEORY OF OPERATION
CHAPTER 5 MAINTENANCE
CHAPTER 6 DISASSEMBLY/REASSEMBLY, LUBRICATION, AND ADJUSTMENT
CHAPTER 7 MAINTENANCE MODE
CHAPTER 8 TROUBLESHOOTING
Appendix 1. Serial No. Descriptions
Appendix 2. Installation
Appendix 3. EEPROM Customizing Codes
Appendix 4. Firmware Switches (WSW)
Appendix 5. Re-packing Instructions
Appendix 6. Wiring Diagram
Appendix 7. Circuit Diagrams
This manual d escribes th e models an d th eir v ersions to b e d estined f or major co untries. T he sp ecifications
and functions are subject to change depending upon each destination.
PREFACE
