- Page 1 Installation and Operating Instructions Models: AR 600 AR 600-LEG AR 600-CER AR 600-OBS AR 600-WHT AR 900 AR 900-LEG AR 900-CER AR 900-OBS FS9S-5-2 For your convenience, we recommend to attach the serial number label HERE. 727626032016...
- Page 2 Dear Valued Customer, Thank you and congratulations on purchasing your new Parmco appliance. All Parmco products are made to the highest quality and design standards. We are sure you will enjoy your new appliance. As a note, please read through these instructions carefully. These will assist you in gaining a complete understanding of the functions and features o ered by your appliance.
-
Page 3: Table Of Contents
Requirements with particular reference to the New Zealand Electrical and Gas Installation Standards. Any attempt to install this or any other Parmco product without an authorized person could result in damage to the product and a possible health hazard. Not having an authorized person install this appliance may result in all associated warranties from Parmco Appliances being null and void. -
Page 4: Before Using This Appliance
IMPORTANT SAFETY INFORMATION For best performance and to extend the life of your appliance, we recommend that you read the instructions in this owner's manual thoroughly before using your new appliance. It will provide you with all the information you need to ensure its safe installation, proper use and maintenance. Keep this owner's manual for future reference. - Page 5 Do not spray aerosols in the vicinity of this appliance while it is in operation. DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE OR NEAR THIS APPLIANCE. For any enquiries please contact Parmco Appliances (09) 573 5678.
-
Page 6: Use And Care
USE AND CARE USE AND CARE How to use your oven We recommend that you read the instructions in this owner's manual carefully before use. It will provide you with all the instructions you require to ensure safe installation, use and maintenance. Always keep this owner's manual close to hand since you may need to refer to it in the future. -
Page 7: Product Description
PRODUCT DESCRIPTION Description of appliance 900mm AR 900s AR 600s... - Page 8 FS9S-5-2 1. Electronic clock 8. Auxiliary burner (small) 2. Control knobs (cooktop burners) 9. Small cooktop element 3. Cooking temperature selection knob 10. Medium cooktop element 4. Cooking mode selection knob 11. Large cooktop element 5. Semi-rapid burner (medium) 12. Oval cooktop element 6.
- Page 9 Controls (Ceramic models) (Gas models) The symbols on the gas control knob means the following: No gas, or “Off”. Maximum gas flow or ‘high’ flame and lighting position. Minimum gas flow or ‘low’ flame. When using the appliance, the knobs should be positioned between the maximum and minimum flow settings.
- Page 10 Igniting the Gas Cooktop Oven and Half Freestander (FS9S-5-2) This symbol above the control knob selects the controls for the larger multifunction oven. This symbol above the control knob selects the controls for the smaller conventional oven Half Oven control (FS9S-5-2) Turn off anti-clockwise When selecting a temperature between 60°C and MAX the half oven will automatically be set to conventional oven mode.
-
Page 11: Using The Cooktop
USING THE COOKTOP USING THE GAS COOKTOP Lighting the Cooktop Burners A - Burner cap B - Burner body C - Burner base D - Flame failure thermocouple (where fitted) E - Ignition candle To light the burner, press the control knob down and continue to hold the knob down before rotating the knob anti-clockwise to the high flame position. - Page 12 Correct Use of the Cooktop For lower gas consumption and better heating performance, use only flat bottom pots and pans of suitable dimensions for the burners. Please refer to the table below. As soon as liquid comes to boil, ensure that the flame is turned down to a level that keeps the liquid just boiling. It is important that pots are placed centrally over the burners.
- Page 13 Single cooking zones Turn the control knob to the desired position (low to high). Adjustment is continuous so the cooking zone will operate at any intermediate knob setting between low and high. Once the cooking zone is hot, the LED corresponding to the zone illuminates. You can switch off the cooking zone by turning the knob, in either direction, to the off position.
-
Page 14: Using The Oven
USING THE OVEN This multi-function oven combines the advantages of traditional conventional ovens with a modern fan assisted oven, all in a single appliance. It is extremely versatile, and allows you to choose easily and safely between different modes. The various cooking modes are selected using the cooking mode selection knob, located on the control panel. - Page 15 SETTING THE ELECTRONIC TIMER General instructions The oven only operates when the time has been set This appliance has a digital display 24 hour clock with six control buttons. When the power is connected, the screen displays 3 flashing numbers and “AUTO”. Adjusting the Digital Clock To set the correct time, press the button first and then the + or –...
- Page 16 For Example: If cooking time takes 45 minutes and you want it to finish at 14:00: 1. Press button, set the cooking time to 45 minutes with the + and – buttons. 2. Press button, set finish time to 14:00 with + and – buttons. 3.
- Page 17 The Oven Light Set the cooking mode selection knob to switch on the oven light/s. The oven light/s will stay on while the oven is operating. Cooling / Ventilation In order to keep the exterior of the appliance cool, the appliance is fitted with a cooling fan that operates automatically.
-
Page 18: Cooking Modes
COOKING MODES Symbol Function description Defrost: When Defrost is selected, the fan located at the back of the oven circulates room temperature air around the oven. This is recommended for defrosting all types of food, but is particularly effective at defrosting delicate food items. It is possible to accelerate the defrosting process by selecting a multi-cooking mode and setting the temperature between C and 100 Conventional Bake: When set to Conventional mode, the top and bottom heating elements... - Page 19 PRACTICAL COOKING ADVICE FOR THE COOKTOP For best results and energy efficiency, only use pans suitable for electric cooking. The bottom of the pan must be thick and flat. Before placing it on the hotplate, make sure that the pan and the hotplate are clean and dry. ...
-
Page 20: Cooking Guide
COOKING GUIDE Selector Knob Food to be Cooked Level from below Temperature Time in Minutes Setting Conventional Bake First Courses Lasagne 2 - 3 210 - 230 Oven Baked Pasta 2 - 3 210 - 230 Meat Roast Veal 175 - 200 30 –... -
Page 21: Care And Maintenance
There is a seal surrounding the oven opening which guarantees its optimum performance. Check the condition of this seal on a regular basis. Should it become damaged, please contact Parmco Appliances. This may or may not be covered under warranty. - Page 22 Cleaning the Gas Cooktop Before cleaning the cooktop, make sure all burners are “OFF” and that the appliance is cooled down. To keep the stainless steel in a good condition, it must be cleaned regularly after each use. The stainless steel parts should be washed with lukewarm water without using any abrasive powders or corrosive substances.
- Page 23 How to remove the Oven Door Hinge Style 1 Open the door fully (1). Lift up and turn the small hooks located on the two hinges (2). Grip the door on the two external sides and close it approximately half way. Unlock the door panel by pressing on the two small plastic buttons (3).
- Page 24 Parmco Appliances. Disposal Parmco has a commitment to being environmentally responsible. To avoid potential negative impacts on the environment, please ensure that this appliance is disposed of correctly. This product must not be treated as household waste. Instead, it should be handed over to an appropriate collection point for recycling of electrical and steel components.
- Page 25 Requirements with particular reference to the New Zealand Electrical and Gas Standards. Any attempt to install this or any other Parmco products without an authorized person could result in damage to the product and possible health hazards. Not having an authorized person install this appliance may result in all associated warranties from Parmco Appliances being made null and void.
-
Page 26: Installation Instructions
Before any procedure, it is important to check that the appliance is DISCONNECTED from the electrical mains. Parmco declines all responsibilities for any damage deriving from installations that are in breach of the regulations in force or from failure to comply with these installation... - Page 27 Installing Units on a Plinth It is possible to install the AR 600, AR 900, AR 600-LEG, AR 600-OBS, AR 600-WHT, AR 900-LEG, AR 600-CER, AR 900-CER and AR 900-OBS units on a “plinth” if required. Special ventilation is required in this application.
- Page 28 MAKE SURE THE ANTI-TILTING CHAINS ARE TAUT WHEN ANCHORED TO PREVENT THE APPLIANCE FROM TILTING. AR 600-LEG and AR 900-LEG Models These models have extendable legs that you can use to raise and lower the appliance to the desired installation height. It is important not to over extend these legs as the appliance can become unstable.
- Page 29 3 Catalytic Liners NOTE: If your oven does not have catalytic liners and you wish to purchase them, they are available from your retailer or Parmco. Operation The catalytic liners are coated with a specially formulated enamel coating, over a base of regular enamel.
- Page 30 Cleaning Cleaning by hand. Make sure the oven is cool before cleaning. The catalytic liners should be cleaned using a solution of hot water and washing-up liquid applied with a soft nylon brush. Do not wash these liners in the dishwasher. Do not use abrasive cleaning agents, hard brushes, scouring pads or cloths, steel wool, knives or other abrasive materials.
- Page 31 Removing and installing the catalytic fan cover Remove the 4 retaining screws on the top and bottom edge of the rear fan cover. Remove cover Note: The fan cover must be replaced after cleaning To refit, place the fan cover back into position by lining up the screw holes in each corner. ...
-
Page 32: Electrical Connection
This appliance is not intended to be operated by means of an external timer of separate remote- control system. It is essential that this unit is operated in conjunction with some form of ventilation/extraction system. Parmco has a wide range of kitchen ventilation solutions available. -
Page 33: Technical Data
Nominal Gas consumption per burner 3.6 MJ/h 6.3 MJ/h 10.08 MJ/h 13.7 MJ/h Product Code Max power consumption AR 600, AR 600-LEG, AR 600-WHT, AR 600-OBS 2.65KW AR 900, AR 900-LEG, AR 900-OBS 3.5KW AR 600-CER 10.4KW AR 900-CER 12.65KW FS9S-5-2 4.35KW... -
Page 34: Warranty
Please retain this Warranty card together with receipt or other proof of purchase date when seeking service during the warranty period • Normal or scheduled maintenance including blocked filters or ducting. • Consumable items such as light bulbs. • Any damage to hobs caused by spills when cooking. • Any breakage or damage of glass items. Please contact Parmco at 09 573 5678 if your • Any damage caused by non recommended product used for cleaning, appliance needs servicing under warranty. Please maintaining, lubricating or similar. have your model number and proof of purchase ready. • Any aspect relating to the installation of the product, or damage caused Warranty repairs must be authorized by Parmco. during installation including blocked access for repair. • Any third party (including reseller) or consequential loss or damage (direct or indirect) however arising. Subject to updates without prior notice, please visit www.parmco.co.nz for E & O.E. 727626022015 the latest version.
