Yamaha GRIZZLY 125 YFM125GZ Owner's Manual page 80

may result.
[ECB00851]
6. Insert the dipstick into the oil filler hole, and
1
then tighten the engine oil filler cap.
To change the engine oil
2
1. Place the ATV on a level surface.
3
2. Start the engine, warm it up for several min-
utes, and then turn it off.
4
3. Place an oil pan under the engine to collect
the used oil.
5
4. Remove the engine oil filler cap, and then re-
move the engine oil drain bolt to drain the oil
6
from the crankcase. NOTICE: When remov-
ing the engine oil drain bolt, the compres-
7
sion spring, oil strainer and O-ring will fall
out. Take
8
parts.
[ECB00311]
9
10
11
care not to lose
1
1. Engine oil drain bolt
2. O-ring
3. Spring
4. Oil strainer
these
5. Clean the oil strainer with solvent.
6. Check the O-ring for damage and replace it if
necessary.
7. Install the O-ring, oil strainer, compression
spring and drain bolt. Tighten the engine oil
drain bolt to the specified torque. NOTICE:
Before installing the engine oil drain bolt,
be sure to install the O-ring, compression
spring and oil strainer.
8-11
4
3
2
[ECB00321]
1
