- Page 1 Contents Connections Playback Settings Tips Appendix CD Player HD-CD1 You can print more than one page of a PDF onto a single sheet of paper. Owner’s Manual Front panel Display Rear panel Remote Index...
-
Page 2: Table Of Contents
Contents Contents Connections Playback Settings Tips Appendix Playback Accessories Inserting the batteries Basic operation Operating range of the remote control unit Turning the power on Features Switching the display’s brightness High quality sound Playing CDs High performance Playing CDs Part names and functions A-B repeat playback Front panel Playing tracks in a specific order (Program playback) - Page 3 Contents Connections Playback Settings Tips Appendix Settings Appendix Menu map Playable media Menu operation Discs H/P AMP GAIN Files Digital Out Playback order of music files Timer Play About discs and files Quick Replay Cautions on using media Auto Standby Inserting a disc How to handle media Tips...
-
Page 4: Rear Panel
Playback Settings Tips Appendix Thank you for purchasing this Marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Accessories Check that the following parts are supplied with the product. -
Page 5: Inserting The Batteries 5
Contents Connections Playback Settings Tips Appendix Inserting the batteries NOTE 0 To prevent damage or leakage of battery fluid: 0 Do not use a new battery together with an old one. Remove the rear lid in the direction of the arrow and 0 Do not use two different types of batteries. - Page 6 The CS4398 Cirrus Logic D/A Converter, which has a reputation playback, and the track rewinds the set amount of time (setting range: for high precision and has been adopted for other Marantz Super Audio 5-60 seconds), and resumes playing from the rewind point.
-
Page 7: Part Names And Functions
Contents Connections Playback Settings Tips Appendix Part names and functions Front panel q w e A Power operation button (X) C Disc tray open/close button (5) This turns the power on/off (standby). (v p. 22) Opens and closes the disc tray. (v p. 23) B STANDBY indicator D Fast-reverse/Reverse-skip button (8) This is lit as follows according to the power status:... - Page 8 Contents Connections Playback Settings Tips Appendix I Stop button (2) Stops playback. J Pause button (3) Pauses playback. K Play button (1) Playback starts. L Remote control sensor This receives signals from the remote control unit. (v p. 5) M Headphones jack (PHONES) Used to connect headphones.
- Page 9 Contents Connections Playback Settings Tips Appendix Display A Information display D RANDOM indicator Displays various information or playback elapsed time and so on of the Lights during random playback. disc. E Repeat mode indicators B Playback mode indicators Lights to match the repeat mode settings. 1 : Lights up during playback.
- Page 10 Used to connect an Amplifier or D/A converter that has a digital input connectors. (v p. 16) Used to connect the power cord. (v p. 20) C REMOTE CONTROL jacks Used to connect to a Marantz amplifier that is compatible with the remote control function. (v p. 18) Front panel Display...
-
Page 11: Operating This Unit
Contents Connections Playback Settings Tips Appendix Remote control unit o Operating this unit To operate CD player, press REMOTE MODE CD button to switch the remote control to the CD operation mode. REMOTE MODE CD button lights for approximately two seconds. A Power operation button (CD POWER X) This turns the power on/off (standby). - Page 12 Contents Connections Playback Settings Tips Appendix E Playback mode switching button (MODE) This switches the playback mode. F Information button (INFO) This switches the track information shown in the display during playback. G Cursor buttons (uio p) These select items. H BACK button This returns to the previous item.
- Page 13 Contents Connections Playback Settings Tips Appendix L REPEAT button (L) Switches the repeat playback. M DIMMER button This switches the brightness of the display. (v p. 22) N ENTER button This determines the selection. O SETUP button This displays the setting menu on the display. (v p. 33) P CLEAR button This clears the program registration.
-
Page 14: Amplifier Operations
Connections Playback Settings Tips Appendix o Amplifier operations A Marantz amplifier can be operated. A Input source select buttons B MUTE button (:) C AMP POWER button (X) D Remote mode select button (REMOTE MODE AMP) E VOLUME buttons (df) -
Page 15: Index
Contents Connections Connections Playback Settings Tips Appendix o Contents o Cables used for connections Provide necessary cables according to the devices you want to connect. Connecting to a device with digital audio input connectors Connecting to a stereo audio amplifier Audio cable (Sold separately) Connecting devices with remote control connectors Connecting the timer device... -
Page 16: Connecting To A Device With Digital Audio Input Connectors
Contents Connections Playback Settings Tips Appendix Connecting to a device with digital audio input connectors You can enjoy digital audio playback by connecting an AV receiver or D/A converter that has a digital audio terminal to this unit. Amplifier / D/A converter COAXIAL OPTICAL... - Page 17 Contents Connections Playback Settings Tips Appendix Connecting to a stereo audio amplifier Use this connection for audio playback via an amplifier. Amplifier AUDIO Front panel Display Rear panel Remote Index...
-
Page 18: Connecting Devices With Remote Control Connectors
Settings Tips Appendix Connecting devices with remote control connectors When you use this unit connected to a Marantz amplifier, this unit receives operation signals sent from the amplifier and operates accordingly. Next, configure the “Connection” and “Setting”. Connection This unit... -
Page 19: Connecting The Timer Device
Contents Connections Playback Settings Tips Appendix Connecting the timer device This unit can perform timer play when an amplifier and timer device are connected to this unit. (“Timer Play” (v p. 35)) This unit Amplifier To household power outlet (AC 120V, 60Hz) Timer device Front panel Display... -
Page 20: Connecting The Power Cord
Contents Connections Playback Settings Tips Appendix Connecting the power cord After completing all the connections, insert the power plug into the power outlet. To household power outlet (AC 120 V, 60 Hz) Power cord (supplied) Front panel Display Rear panel Remote Index... - Page 21 Contents Connections Playback Playback Settings Tips Appendix o Contents Basic operation Playing CDs Playing DATA CDs (MP3, WMA and AAC files) Front panel Display Rear panel Remote Index...
-
Page 22: Basic Operation
Contents Connections Playback Settings Tips Appendix Basic operation Turning the power on CD POWER X Press CD POWER X to turn on power to the unit. The power indicator turns off. 0 You can also press X on the main unit to turn the power on. DIMMER o When power is switched to standby Press CD POWER X. -
Page 23: Discs
Contents Connections Playback Settings Tips Appendix Playing CDs Playing CDs Insert a disc. (v p. 45) Press 5 on the unit to open/close the disc tray. 1 / 3 Press 1/3. The 1 indicator lights on the display. Playback starts. RANDOM REPEAT NOTE... -
Page 24: A-B Repeat Playback
Contents Connections Playback Settings Tips Appendix o Playing a specific track (Direct searching) Operation buttons Function Playback / Pause Use 0 – 9 and +10 to select the tracks. Stop Skip to previous track / Skip to next track GExampleH (Press and hold) Fast-reverse / Fast-forward Track 4 : 0 –... - Page 25 Contents Connections Playback Settings Tips Appendix A-B repeat playback Playing tracks in a specific order (Program playback) You can specify the section within a track that you want to hear, and play it back repeatedly. Up to 25 tracks can be programmed. During playback, press REPEAT A-B at the point where In the stop mode, press PROGRAM.
- Page 26 Contents Connections Playback Settings Tips Appendix o Checking the order of the programmed tracks Skipping tracks you don’t want to hear In the stop mode, press 9. (Delete program playback) The tracks are shown in the programmed order in the display each time 9 is pressed.
- Page 27 Contents Connections Playback Settings Tips Appendix o To clear the last delete program track Rewinding tracks slightly to listen In the stop mode, press CLEAR. again (Quick replay) The last track set in the delete program is cleared in order each time CLEAR is pressed.
- Page 28 Contents Connections Playback Settings Tips Appendix Switching the display (CD-TEXT) You can view text information stored on a disc as CD-TEXT on this unit. Mainly, information on the current track being played is displayed. A maximum of 32 characters can be displayed. During playback, press INFO.
-
Page 29: Files
Contents Connections Playback Settings Tips Appendix Playing DATA CDs (MP3, WMA and AAC files) This section explains how to playback MP3, WMA and AAC files that are recorded onto a CD-R or CD-RW. For details on how to playback files recorded onto media other than CD-R or CD-RW, see the following sections. -
Page 30: Random Playback
Contents Connections Playback Settings Tips Appendix Playing files Operation buttons Function Playback / Pause Stop Load a CD-R or CD-RW disc containing music files in the MP3, WMA or AAC formats into the disc tray. Skip to previous track / Skip to next track (v p. -
Page 31: Switching The Display
Contents Connections Playback Settings Tips Appendix o Switching the display NOTE 0 Programmed playback is not possible with MP3/WMA/AAC discs. During playback, press INFO. 0 Copyright-protected files cannot be played. Switching between the file name, title name, artist name and album (The “Not Support”... -
Page 32: Menu Map
Contents Connections Playback Settings Settings Tips Appendix Menu map By default, this unit has recommended settings defined. You can customize this unit based on your existing system and your preferences. Setting items Description Page H/P AMP GAIN Set the gain of the headphone amplifier. Digital Out Switched the digital audio output on/off. - Page 33 Contents Connections Playback Settings Tips Appendix Menu operation Press SETUP while playback is stopped. The menu is displayed on the display. Use ui to select the menu to be set or operated, then press ENTER. Use ui to change to desired setting. Press p or ENTER to enter the setting.
-
Page 34: Rear Panel
Contents Connections Playback Settings Tips Appendix H/P AMP GAIN Digital Out Set the gain of the headphone amplifier. Set this according to the Switched the digital audio output on/off. impedance of the connected headphones. It is recommended that this is set on the “LOW”... -
Page 35: Timer Device
Contents Connections Playback Settings Tips Appendix Timer Play Quick Replay This unit can perform timer play by cooperating with your timer device. You can set how many seconds a track is rewound when Q.REPLAY P is (“Connecting the timer device” (v p. 19)) pressed. -
Page 36: Tips
Contents Connections Playback Settings Tips Tips Appendix o Contents Tips Troubleshooting I want to display CD-TEXT Power does not turn on / Power is turned off I want to skip tracks on a CD Operations cannot be performed through the remote control unit I want to repeatedly listen to a specific section Display on this unit shows nothing I want to playback just the specified folder... - Page 37 Contents Connections Playback Settings Tips Appendix Tips I want to display CD-TEXT This unit is compatible with CD-TEXT. Press the INFO button to switch the displayed information. (v p. 28) I want to skip tracks on a CD Select the tracks that you want to skip in delete program playback mode. (v p. 26) I want to repeatedly listen to a specific section Set A-B repeat playback.
- Page 38 Contents Connections Playback Settings Tips Appendix Troubleshooting If a problem should arise, first check the following. 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? If this unit does not operate properly, check the items listed in the table below.
- Page 39 Contents Connections Playback Settings Tips Appendix o Operations cannot be performed through the remote control unit Symptom Cause / Solution Page Operations cannot be Batteries are worn out. Replace with new batteries. performed through the Operate the remote control unit within a distance of about 23 ft/7 m from this unit and at an angle of within remote control unit.
- Page 40 Contents Connections Playback Settings Tips Appendix o No sound comes out Symptom Cause / Solution Page No sound is produced. Or Check the connections for all devices. sound is distorted. Insert connection cables all the way in. － Check cables for damage. －...
- Page 41 Contents Connections Playback Settings Tips Appendix o Cannot playback Discs Symptom Cause / Solution Page Cannot playback when the The disc is dirty or scratched. Either clean the disc, or insert a different disc. play button is pressed, or cannot correctly play back a specific part of the disc.
-
Page 42: Playable Media
Contents Connections Playback Settings Tips Appendix Appendix Playable media Discs Files CD-R and CD-RW discs created in the format described below can be Playable media played. o Writing software format ISO9660 level 1, 2 CD-R Expansion format (Juliet.Romeo) When written in other formats, it may not be possible to play the disc properly. -
Page 43: Compatible Formats
Contents Connections Playback Settings Tips Appendix o Compatible formats Playback order of music files Sampling Bit rate Extension When there are multiple folders containing music files, the playback order frequency length of folders is automatically set when this unit reads the media. The files in 32 –... -
Page 44: About Discs And Files
Contents Connections Playback Settings Tips Appendix About discs and files Music files recorded on CD-R/-RW are divided into large segments (folders) and small segments (files). Files are stored in folders, and folders can be placed for storage in a hierarchy. The unit can recognize up to 8 levels of folders. -
Page 45: Cautions On Using Media
Contents Connections Playback Settings Tips Appendix Cautions on using media Inserting a disc NOTE Set the disc in the tray label side up. 0 Only load one disc at a time. Loading two or more discs can damage the unit or scratch the discs. -
Page 46: How To Handle Media
Contents Connections Playback Settings Tips Appendix How to handle media Cleaning discs Do not get fingerprints, oil or dirt on discs. If there are fingerprints or dirt on a disc, wipe them off before using the disc. Take special care not to scratch discs when removing them from their cases. -
Page 47: Explanation Of Terms
Contents Connections Playback Settings Tips Appendix Explanation of terms MP3 (MPEG Audio Layer-3) Dynamic range This is an internationally standardized audio data compression scheme, The difference between the maximum undistorted sound level and the using the “MPEG-1” video compression standard. It compresses the data minimum discernible level above the noise emitted by the device. -
Page 48: Trademark Information
Contents Connections Playback Settings Tips Appendix Trademark information Adobe, the Adobe logo and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Front panel Display Rear panel Remote Index... -
Page 49: Specifications
Contents Connections Playback Settings Tips Appendix Specifications o Audio performance Analog output Channels: 2-channels Playable frequency range: 2 Hz – 20 kHz Playable frequency response: 2 Hz – 20 kHz (±0.5 dB) S/N: 110 dB Dynamic range: 100 dB Harmonic distortion: 0.002 % (1 kHz) Wow &... - Page 50 Contents Connections Playback Settings Tips Appendix o General Power supply: AC 120 V, 60 Hz Power consumption: 14 W Power consumption in standby mode: 0.3 W or less Operating temperatures: +5 ℃ - +35 ℃ Operating humidity: 5 – 90 % (without dew) For the purpose of improvement, the specifications and design are subject to change without notice.
- Page 51 Contents Connections Playback Settings Tips Appendix Dimensions (Unit : in. (mm)) 5 3/8 (134) 12 (304) 1 7/8 (47) 8 3/8 (210) 1 7/8 (47) Weight : 12 lbs 13 oz (5.7 kg) Front panel Display Rear panel Remote Index...
- Page 52 Contents Connections Playback Settings Tips Appendix Index Front panel ............7 Timer device ..........19 Tips ..............37 Troubleshooting ..........38 A-B repeat playback ........25 Menu map ............32 Amplifier ........... 16, 17 Auto Standby ..........35 Program playback .......... 25 CD ............
- Page 53 3520 10478 00AM Copyright © 2016 D&M Holdings Inc. All Rights Reserved.
