Release Button - Oreck MODEL AV-701B User Manual

Release Button

2
Fig. 2 To remove the hand held unit, push the release button. When finished
cleaning, align the hand held unit against the wall bracket of the stick
broom and snap it into place.
Hand Held Unit ON/OFF Switch & Charging Indication Lamp
3
Fig. 3 A red lamp indicates the unit is charging. A green lamp indicates the unit
is fully charged.
Adjustable Handle Control Lever
4
Fig. 4 The handle can be set to desired working position. Loosen the handle by
turning the control lever to the center position, then pull the handle to the
desired length and secure it by turning it to the locked position.
