Cleaning the Dust Filter

5
6
Fig. 5 Press the release button and remove the dirt cup from cleaner.
Fig. 6 Empty the dirt cup.
Fig. 7 It is also recommended to empty and clean the filter after each
use. To remove debris from the filter, tap it on a hard surface or brush it
with a soft brush. The filter can be washed in warm soapy water using a
soft brush if necessary. Dry it completely before replacing it into the dirt
cup.

Power Brush

8
Important: Disconnect cleaner from electrical outlet.
Fig. 8 To maintain cleaning effectiveness, regularly remove hair, lint, strings,
threads, etc. from the brush roll with a knife or scissors. If a blockage
resulting from hair, lint, strings, etc. is caught in the brush roll, the
cleaner will stop automatically for safety purposes. After removing the
blockage, push the "reset button" on the brush assembly. A green light
will appear in the brush lamp next to the reset button and the cleaner
should run normally.
