satspeed V7621-A1 User Manual

Vdsl2/adsl2+ iad
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
satspeed V7621-A1
satspeed V7621-A1 User's Manual
VDSL2/ADSL2+ IAD
satspeed V7621-A1
VDSL2/ADSL2+ IAD
User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V7621-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for satspeed V7621-A1

  • Page 1 V7621-A1 satspeed V7621-A1 User’s Manual VDSL2/ADSL2+ IAD satspeed V7621-A1 VDSL2/ADSL2+ IAD User’s Manual...

  • Page 2: Table Of Contents

    V7621-A1 User’s Manual Table of Contents 1 Introduction ......................... 9 Features ..............................9 Device Requirements ..........................9 Using this Document ..........................10 Notational conventions ........................10 Typographical conventions ......................10 Special messages ..........................10 Getting Support ............................10 2 Getting to know the device ..................11 Computer / System requirements ......................
  • Page 3 V7621-A1 User’s Manual 10 Local Network Configuration .................. 79 Changing the LAN IP address and subnet mask ................79 Adding the Secondary LAN IP address and subnet mask ..............81 Change IP Pool Range and Subnet mask................... 82 11 Wireless Network ....................84 Basic Settings ............................
  • Page 4 V7621-A1 User’s Manual ATM Settings ............................144 DSL Settings ............................146 14 3G Settings ......................148 15 DHCP Settings ...................... 150 DHCP Server Configuration ....................... 150 DHCP Relay Configuration ......................... 152 DHCP None Configuration........................153 16 DHCPv6 Settings ....................154 DHCP Server (Manual) Configuration ....................
  • Page 5 V7621-A1 User’s Manual Port 1/ Port 2 configurations ....................... 201 SIP Account ............................ 207 SIP Advanced ..........................209 Forward Mode ..........................210 Speed Dial ............................211 Abbreviated (Phonebook) Dial ....................... 212 Dial plan ............................214 PSTN Routing Prefix ........................214 Codec ..............................
  • Page 6 V7621-A1 User’s Manual IPv6 ............................... 244 RADVD ..............................244 DHCPv6 ............................... 245 MLD Proxy ............................245 MLD Snooping ............................. 246 IPv6 Routing ............................247 IP/Port Filtering ............................ 248 37 Diagnostic ......................249 Ping ............................... 249 ATM Loopback ............................ 250 DSL Tone Diagnostics ........................
  • Page 7 V7621-A1 User’s Manual B IP Addresses, Network Masks, and Subnets ............280 IP Addresses ............................280 Structure of an IP address ......................280 Network classes ..........................280 Subnet masks ............................281 C Troubleshooting ..................... 283 Troubleshooting Suggestions ......................283 Diagnosing Problem using IP Utilities ....................
  • Page 8 V7621-A1 User’s Manual...

  • Page 9: Introduction

    V7621-A1 User’s Manual Introduction Congratulations on becoming the owner of the Wireless VDSL2 Router. You will now be able to access the Internet using your high-speed DSL connection. This User Guide will show you how to connect your Wireless VDSL2 Router, and how to customize its configuration to get the most out of your new product.

  • Page 10: Using This Document

    V7621-A1 User’s Manual Note up to four Ethernet PCs directly to your device using the ports labeled Ethernet on the rear panel. Using this Document Notational conventions  Acronyms are defined the first time they appear in the text and also in the glossary.

  • Page 11: Getting To Know The Device

    V7621-A1 User’s Manual Getting to know the device Computer / System requirements  1. Pentium 200MHZ processor or above  2. Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Vista, Windows 7 and Windows 8  3. 64MB of RAM or above ...

  • Page 12: Installation & Setup

    V7621-A1 User’s Manual Installation & Setup Follow each STEP carefully and only go to the next step once you have complete the previous STEP. Connection of Integrated Access Device If you have an ISDN telephone line connect the modem router as shown below: 1.
  • Page 13 V7621-A1 User’s Manual If you have a PSTN telephone line (normal analog line) connect the router as shown below: 1. Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to any of the 4 Integrated Access Device's LAN Ports.

  • Page 14: Led Meanings & Activations

    V7621-A1 User’s Manual LED meanings & activations Your Integrated Access Device has indicator lights on the front side. Please see below for an explanation of the function of each indicator light. Power indicator Internet Active indicator Ethernet Active indicator...

  • Page 15: Back Panel Connectors

    V7621-A1 User’s Manual Back Panel Connectors Table 2 shows the function of each connector and switch of the device. Table 2. Function / Description of Connectors Connector Description POWER Connects to your Integrated Access Device 12Vdc power adaptor SWITCH...

  • Page 16: Computer Configurations Under Different Os, To Obtain Ip Address Automatically

    V7621-A1 User’s Manual Computer configurations under different OS, to obtain IP address automatically Before starting the Integrated Access Device configuration, please kindly configure the PC computer as below, to have automatic IP address / DNS Server. For Windows 98SE / ME / 2000 / XP 1.
  • Page 17 V7621-A1 User’s Manual 3. Double click on "Internet Protocol (TCP/ IP)". 4. Check "Obtain an IP address automatically" and “Obtain DNS server address automatically” then click on "OK" to continue. 5. Click "Show icon in notification area when connected" (see screen...
  • Page 18 V7621-A1 User’s Manual For Windows Vista-32/64 1. Click on “Start” -> “Control Panel” -> “View network status and tasks”. 2. In the Manage network connections, click on “Manage network connections” to continue.
  • Page 19 V7621-A1 User’s Manual 3. Single RIGHT click on “Local Area connection", then click "Properties". 4. The screen will display the information “User Account Control” and click “Continue” to continue. 5. Double click on "Internet Protocol Version 4 (TCP/IPv4)".
  • Page 20 V7621-A1 User’s Manual 6. Check "Obtain an IP address automatically" and “Obtain DNS server address automatically” then click on "OK" to continue. For Windows 7-32/64 1. Click on “Start” -> “Control Panel” (in Category View) -> “View network status and tasks”.
  • Page 21 V7621-A1 User’s Manual 2. In the Control Panel Home, click on “Change adapter settings” to continue. 3. Single RIGHT click on “Local Area connection", then click "Properties".
  • Page 22 V7621-A1 User’s Manual 4. Double click on "Internet Protocol Version 4 (TCP/IPv4)". 5. Check "Obtain an IP address automatically" and “Obtain DNS server address automatically” then click on "OK" to continue.
  • Page 23 V7621-A1 User’s Manual For Windows 8-32/64 1. Move the mouse or tap to the upper right corner and click on “Settings”. 2. Click on “Control Panel”.
  • Page 24 V7621-A1 User’s Manual 3. Click on “View network status and tasks”. 4. In the Control Panel Home, click on “Change adapter settings” to continue.
  • Page 25 V7621-A1 User’s Manual 5. Single RIGHT click on “Ethernet", then click "Properties". 6. Double click on "Internet Protocol Version 4 (TCP/IPv4)".
  • Page 26 V7621-A1 User’s Manual 7. Check "Obtain an IP address automatically" and “Obtain DNS server address automatically” then click on "OK" to continue.

  • Page 27: Utility Cd Execution

    V7621-A1 User’s Manual Utility CD execution Connecting the Hardware This section describes how to connect the device to the wall phone port, the power outlet and your computer(s) or network. 1. Before you begin to execute utility CD Installations, please ensure the Integrated Access Device has been powered 2.

  • Page 28: Vdsl Wan Configuration (Vdsl Line User)

    V7621-A1 User’s Manual 5. Please enter the User Name: admin and Password: admin and then click on OK button. VDSL WAN Configuration (VDSL Line User) 6. From the left-hand menu, click on WAN -> PTM WAN.
  • Page 29 V7621-A1 User’s Manual Examples 8-1. PPPoE From the Channel Mode drop-down list, select PPPoE setting. Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting. From the IP Protocol drop-down list, select the IP Protocol, IPv4, IPv6 or dual stacks IPv4/IPv6 determined by your ISP.
  • Page 30 V7621-A1 User’s Manual...
  • Page 31 V7621-A1 User’s Manual 8-2. Bridged From the Channel Mode drop-down list, select Bridged setting. From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting. If you are happy with your settings, click Apply Changes Now you can load your PPPoE Client Software onto your PC.
  • Page 32 V7621-A1 User’s Manual 8-3. IPoE by DHCP From the Channel Mode drop-down list, select IPoE Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting. From the IP Protocol drop-down list, select the IP Protocol, IPv4, IPv6 or dual stacks IPv4/IPv6 determined by your ISP.
  • Page 33 V7621-A1 User’s Manual...
  • Page 34 V7621-A1 User’s Manual 8-4. IPoE by Fixed IP From the Channel Mode drop-down list, select IPoE setting. Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting. From the IP Protocol drop-down list, select the IP Protocol, IPv4, IPv6 or dual stacks IPv4/IPv6 determined by your ISP.
  • Page 35 V7621-A1 User’s Manual...
  • Page 36 V7621-A1 User’s Manual From the left-hand Service menu, click on Services -> DHCP. From the Type ratio, click Set Manually. Enter DNS setting determined by your ISP. If you are happy with your settings, click Apply Changes...
  • Page 37 V7621-A1 User’s Manual Click OK 7. From the left-hand menu, click on Admin -> Commit/Reboot. 8. Click on Commit and Reboot. 9. Click on OK.

  • Page 38: Dsl Wan Configuration (Adsl Line User)

    V7621-A1 User’s Manual 10. System rebooting, Please wait ... DSL WAN Configuration (ADSL Line User) 11. From the left-hand menu, click on WAN -> ATM WAN. Examples 8-1. PPPoE Enter VCI and VPI setting determined by your ISP. Select the Encapsulation determined by your ISP.
  • Page 39 V7621-A1 User’s Manual...
  • Page 40 V7621-A1 User’s Manual 8-2. PPPoA Enter VCI and VPI setting determined by your ISP. Select the Encapsulation determined by your ISP. From the Channel Mode drop-down list, select PPPoA setting. Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting.
  • Page 41 V7621-A1 User’s Manual...
  • Page 42 V7621-A1 User’s Manual 8-3. Bridged Enter VCI and VPI setting determined by your ISP. Select the Encapsulation determined by your ISP. From the Channel Mode drop-down list, select 1483 Bridged setting. From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting.
  • Page 43 V7621-A1 User’s Manual 8-4. 1483 MER by DHCP Enter VCI and VPI setting determined by your ISP. Select the Encapsulation determined by your ISP. From the Channel Mode drop-down list, select 1483 MER Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting.
  • Page 44 V7621-A1 User’s Manual...
  • Page 45 V7621-A1 User’s Manual 8-5. 1483 MER by Fixed IP Enter VCI and VPI setting determined by your ISP. Select the Encapsulation determined by your ISP. Enable Enable NAPT From the Connection Type drop-down list, select VOICE_INTERNET_TR069 setting. From the Channel Mode drop-down list, select 1483 MER setting.
  • Page 46 V7621-A1 User’s Manual...
  • Page 47 V7621-A1 User’s Manual From the left-hand Service menu, click on Services -> DHCP. From the Type ratio, click Set Manually. Enter DNS setting determined by your ISP. If you are happy with your settings, click Apply Changes...
  • Page 48 V7621-A1 User’s Manual Click OK 12. From the left-hand menu, click on Admin -> Commit/Reboot. 13. Click on Commit and Reboot. 14. Click on OK.

  • Page 49: Voip Phone 1 Configuration

    V7621-A1 User’s Manual 15. System rebooting, Please wait ... VoIP PHONE 1 Configuration 16. From the left-hand menu, click on VoIP -> Port1.
  • Page 50 V7621-A1 User’s Manual 17. Enter Display Name, Number, Login ID and Password. 18. Enable Proxy. 19. Enter Proxy Server Address and Proxy Server Port of SIP Server for example 192.168.10.101 and 5060. 20. Enter SIP Domain Address of SIP Server for example 192.168.10.101.

  • Page 51: Voip Phone 2 Configuration

    V7621-A1 User’s Manual VoIP PHONE 2 Configuration 24. From the left-hand menu, click on VoIP -> Port2.
  • Page 52 V7621-A1 User’s Manual 25. Enter Display Name, Number, Login ID and Password. 26. Enable Proxy. 27. Enter Proxy Server Address and Proxy Server Port of SIP Server for example 192.168.10.101 and 5060. 28. Enter SIP Domain Address of SIP Server for example 192.168.10.101.

  • Page 53: Wireless Configuration

    V7621-A1 User’s Manual Wireless Configuration 32. From the left-hand menu, click on WLAN -> Basic Settings.
  • Page 54 V7621-A1 User’s Manual 33. From the Band drop-down list, select a Band. 34. From the Mode drop-down list, select AP setting. 35. Enter SSID for example VDSL-8673. (the default settings Radio On/Off = On, Network Name(SSID) = IAD-xxxx which could be found on the sticker of the bottom side of the device).
  • Page 55 V7621-A1 User’s Manual 42. From the left-hand menu, click on WLAN -> Security. 43. From the Encryption list, choose the Encryption type if necessary, as None / WEP / WPA / WPA2 and WPA2 Mixed Mode (the default settings Security Mode = WPA2 and passphrase is xxxxxxxx which could be found on the sticker of the bottom side of the device).
  • Page 56 V7621-A1 User’s Manual 47. Change setting successfully! 48. Click OK. 49. From the left-hand menu, click on Admin -> Commit/Reboot. 50. Click on Commit and Reboot. 51. Click on OK.
  • Page 57 V7621-A1 User’s Manual 52. System rebooting, Please wait ... 53. Click on " Exit " to exit this program. 54. Now, the Integrated Access Device has been configured completely, and suitable for Wireless and Internet Connections.

  • Page 58: Wireless Connection

    V7621-A1 User’s Manual Wireless Connection For easy installation it is saved to keep the settings. You can later change the wireless settings via the wireless configuration menu. (see user manual on the CD – Chapter 11 and other). 55. Double click on the wireless icon on your computer and search for the wireless network that you enter SSID name.
  • Page 59 V7621-A1 User’s Manual 57. If the wireless network isn’t encrypted, click on "Connect Anyway" to connect. 58. If the wireless network is encrypted, enter the network key that belongs to your authentication type and key. (the default settings Security Mode = Disable). You can later change this network key via the wireless configuration menu.

  • Page 60: Usb 3G Configuration (This Function May Vary Depending On Model)

    V7621-A1 User’s Manual USB 3G Configuration (This function may vary depending on model) Connecting the Hardware This section describes how to connect the device to the wall phone port, the power outlet and your computer(s) or network. Before you begin, turn the power off for all devices. These include your computer(s), your LAN hub/switch (if applicable), and the Wireless Gateway.

  • Page 61: Usb 3G Configuration

    V7621-A1 User’s Manual USB 3G Configuration 61. Visit web page http://192.168.1.1 and then enter the Login User Name: admin and Login Password: admin and then click on OK button. 62. From the left-hand menu, click on WAN -> 3G Settings.
  • Page 62 V7621-A1 User’s Manual 63. Click on the ratio of Enable from 3G WAN. 64. Enter PIN code provided by your ISP. Keep it empty if your ISP doesn't need it 65. Enter Access Point Name (APN) provided by your ISP.

  • Page 63: Wireless Configuration

    V7621-A1 User’s Manual Wireless Configuration 73. From the left-hand menu, click on WLAN -> Basic Settings.
  • Page 64 V7621-A1 User’s Manual 74. From the Band drop-down list, select a Band. 75. From the Mode drop-down list, select AP setting. 76. Enter SSID for example VDSL-8673. (the default settings Radio On/Off = On, Network Name(SSID) = IAD-xxxx which could be found on the sticker of the bottom side of the device).
  • Page 65 V7621-A1 User’s Manual 83. From the left-hand menu, click on WLAN -> Security. 84. From the Encryption list, choose the Encryption type if necessary, as None / WEP / WPA / WPA2 and WPA2 Mixed Mode (the default settings Security Mode = WPA2 and passphrase is xxxxxxxx which could be found on the sticker of the bottom side of the device).
  • Page 66 V7621-A1 User’s Manual 88. Change setting successfully! 89. Click OK. 90. From the left-hand menu, click on Admin -> Commit/Reboot. 91. Click on Commit and Reboot. 92. Click on OK.
  • Page 67 V7621-A1 User’s Manual 93. System rebooting, Please wait ... 94. Now you are ready to use the USB 3G to Internet.

  • Page 68: Samba- File Sharing With Usb Host

    V7621-A1 User’s Manual SAMBA- File Sharing with USB Host The device includes a USB Host let you sharing, read and write files on PEN Drive. You can have read and write access for FAT16/FAT32 format of PEN Drive. You can have only read access for NTFS format of PEN Drive.
  • Page 69 V7621-A1 User’s Manual 97. Fill in \\192.168.1.1\mnt\sda1 in Address field and then Samba Server press Enter key. You will see the below. 98. You can access the PEN Drive for reading and or writing files now.

  • Page 70: Getting Started With The Web Pages

    V7621-A1 User’s Manual Getting Started with the Web pages The Wireless VDSL2 Router includes a series of Web pages that provide an interface to the software installed on the device. It enables you to configure the device settings to meet the needs of your network.
  • Page 71 V7621-A1 User’s Manual Figure 1: Homepage The first time that you click on an entry from the left- hand menu, a login box is displayed. You must enter your username and password to access the pages. A login screen is displayed:...

  • Page 72: Testing Your Setup

    V7621-A1 User’s Manual Figure 2: Login screen 99. Enter your user name and password. The first time you log into the program, use these defaults: User Name: admin Password: admin You can change the password at any time or you can configure your device so that you do not need to enter a password.

  • Page 73: Default Device Settings

    V7621-A1 User’s Manual Table 1. LED Indicators Behavior POWER Solid green to indicate that the device is turned on. If this light is not on, check the power cable attachment. Flashing on/off while the device is booting. After about 10- 15 seconds, solid green to indicate that the device can communicate with your LAN.
  • Page 74 V7621-A1 User’s Manual Option Default Setting Explanation/Instructions LAN Port Assigned static IP address: This is the IP address of the LAN port on the device. IP Address 192.168.1.1 The LAN port connects the device to your Ethernet network. Typically, you will not need to change this address.

  • Page 75: Overview

    Satspeed V7621-A1 User’s Manual Configuring your Computers Overview The Overview page displays useful information about the setup of your device, including:  details of the device’s Internet access settings  version information about your device To display this page: From the left menu, click on Status - Device. The following page...

  • Page 76: Internet Access Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Internet access settings This section displays details of the settings that allow your device to access the Internet. These details include: IP address and The IP address and subnet mask subnet mask: assigned to your WAN interface. This...

  • Page 77: Status

    Satspeed V7621-A1 User’s Manual Configuring your Computers Status You can view statistics on the processing of IP packets on the networking interfaces. You will not typically need to view this data, but you may find it helpful when working with your ISP to diagnose network and Internet data transmission problems.

  • Page 78: Ipv6

    Satspeed V7621-A1 User’s Manual Configuring your Computers IPv6 This page shows the DSL line statistic information. 103. From the left Status menu, click on IPv6 The following page is displayed: 104. To display updated statistics showing any new data since you opened this page, click Refresh.

  • Page 79: Local Network Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers Local Network Configuration The Addressing page displays information about your LAN IP address and allows you to change the address and subnet mask assigned to your device. You should only change the addressing details if your ISP asks you to, or if you are familiar with network configuration.
  • Page 80 Satspeed V7621-A1 User’s Manual Configuring your Computers 106. From the left-hand LAN menu, click on LAN. 107. Type a new IP Address and Subnet Mask. 108. Click Apply Changes. 109. The primary IP address is being changed to 10.0.0.2 netmask 255.255.255.0. Then please go to http://10.0.0.2 to continue.

  • Page 81: Adding The Secondary Lan Ip Address And Subnet Mask

    Satspeed V7621-A1 User’s Manual Configuring your Computers If you change the LAN IP address of the device while connected through your Web browser, you will be disconnected. You must open a new connection by entering your new LAN IP address as Note the URL.

  • Page 82: Change Ip Pool Range And Subnet Mask

    Satspeed V7621-A1 User’s Manual Configuring your Computers Change IP Pool Range and Subnet mask 116. From the left-hand Services menu, click on DHCP.
  • Page 83 Satspeed V7621-A1 User’s Manual Configuring your Computers 117. Change the IP Pool Range/Subnet Mask and then click Apply Changes button. 118. Change setting successfully! 119. Click OK.

  • Page 84: Wireless Network

    Satspeed V7621-A1 User’s Manual Configuring your Computers Wireless Network This chapter assumes that you have already set up your Wireless PCs and installed a compatible Wireless card on your device. See Configuring Wireless PCs. Basic Settings This page contains all of the wireless basic settings. Most users will be able to configure the wireless portion and get it working properly using the setting on this screen.
  • Page 85 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Disable Wireless Enable/Disable the Wireless LAN Interface. LAN Interface Band Select the appropriate band from the list provided to correspond with your network setting. Mode Configure the Wireless LAN Interface to mode...

  • Page 86: Advanced Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Advanced Settings These settings are only for more technically advanced users who have a sufficient knowledge about wireless LAN. These settings should not be changed unless you know what effect the changes will have on your Access Point. To access the Wireless Network Advanced Settings page: 120.
  • Page 87 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Fragment When transmitting a packet over a network medium, Threshold sometimes the packet is broken into several segments, if the size of packet exceeds that allowed by the network medium. The Fragmentation Threshold defines the number of bytes used for the fragmentation boundary for directed messages.
  • Page 88 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Broadcast SSID Broadcast or Hide SSID to your Network. Default: Enabled Relay Blocking Disable or Enable Relay Blocking Protection A protection mechanism prevents collisions among 802.11g nodes. Aggregation Disable or Enable Aggregation...

  • Page 89: Security

    Satspeed V7621-A1 User’s Manual Configuring your Computers Security This page allows you setup the wireless security. Turn on WEP or WPA by using Encryption Keys could prevent any unauthorized access to your wireless network. To access the Wireless Network Security page: From the left-hand WLAN menu, click on Security.
  • Page 90 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description SSID TYPE Select the SSID Encryption There are 4 types of security to be selected. To secure your WLAN, it’s strongly recommended to enable this feature. WEP: Make sure that all wireless devices on your network are using the same encryption level and key.

  • Page 91: Wep + Encryption Key

    Satspeed V7621-A1 User’s Manual Configuring your Computers Function Button Description Apply Changes Click to save the rule entry to the configuration. WEP + Encryption Key WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another.

  • Page 92: Wep + Use 802.1X Authentication

    Satspeed V7621-A1 User’s Manual Configuring your Computers 127. Change setting successfully! 128. Click OK. WEP + Use 802.1x Authentication WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another.

  • Page 93: Wpa/Wpa2/Wpa2 Mixed + Personal (Pre-Shared Key)

    Satspeed V7621-A1 User’s Manual Configuring your Computers 135. Change setting successfully! 136. Click OK. WPA/WPA2/WPA2 Mixed + Personal (Pre-Shared Key) Wi-Fi Protected Access (WPA) is a class of systems to secure wireless (Wi-Fi) computer networks. WPA/WPA2 implements the full standard, but will not work with some older network cards.

  • Page 94: Wpa/Wpa2/Wpa2 Mixed + Enterprise (Radius)

    Satspeed V7621-A1 User’s Manual Configuring your Computers 141. Enter the Pre-Shared Key depending on selected Passphrase or Hex (64 characters). 142. Click on Apply Changes button to confirm. 143. Click OK button. 144. Change setting successfully! 145. Click OK. WPA/WPA2/WPA2 Mixed + Enterprise (RADIUS) Wi-Fi Protected Access (WPA) is a class of systems to secure wireless (Wi-Fi) computer networks.
  • Page 95 Satspeed V7621-A1 User’s Manual Configuring your Computers 148. Check on the WPA Cipher Suite. 149. Enter the Port, IP Address and Password of RADIUS Server). 150. Click on Apply Changes button to confirm. 151. Click OK button. 152. Change setting successfully! 153.

  • Page 96: Access Control

    Satspeed V7621-A1 User’s Manual Configuring your Computers Access Control For security reason, using MAC ACL's (MAC Address Access List) creates another level of difficulty to hacking a network. A MAC ACL is created and distributed to AP so that only authorized NIC's can connect to the network.

  • Page 97: Allow Listed

    Satspeed V7621-A1 User’s Manual Configuring your Computers Allow Listed If you choose 'Allowed Listed', only those clients whose wireless MAC addresses are in the access control list will be able to connect to your Access Point. 155. From the Mode drop-down list, select Allowed Listed setting.
  • Page 98 Satspeed V7621-A1 User’s Manual Configuring your Computers 165. Click OK. 166. Enter the MAC Address. 167. Click Add button. 168. Change setting successfully! 169. Click OK. 170. The MAC Address that you created has been added in the Current Access Control List.

  • Page 99: Wps

    Satspeed V7621-A1 User’s Manual Configuring your Computers Introduction of WPS Although home Wi-Fi networks have become more and more popular, users still have trouble with the initial set up of network. This obstacle forces users to use the open security and increases the risk of eavesdropping.

  • Page 100: Ap Mode

    Satspeed V7621-A1 User’s Manual Configuring your Computers open security, WEP 64 bits, WEP 128 bits, WPA2-Personal TKIP, and WPA2-Personal AES. Users could choose either one of the methods at their convenience. AP mode For AP mode, Wireless Gateway supports three roles, registrar, proxy, and enrollee in registration protocol.

  • Page 101: Instructions Of Ap's And Client's Operations

    Satspeed V7621-A1 User’s Manual Configuring your Computers successfully doing the registration protocol. Then Wireless Gateway will associate with an AP. Instructions of AP’s and Client’s operations At this state, AP is transparent to users. If users want to configure a station or any device that is capable of being an enrollee, they have to enter device’s PIN into an external...
  • Page 102 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Disable WPS Check to disable the Wi-Fi protected Setup. When AP’s settings are factory default (out of box), it is WPS Status set to open security and un-configured state. “WPS Status” will display it as “UnConfigured”. If it already shows “Configured”, some registrars such as Vista...

  • Page 103: Operations Of Ap - Ap Being An Enrollee

    Satspeed V7621-A1 User’s Manual Configuring your Computers Operations of AP - AP being an enrollee In this case, AP will be configured by any registrar either through in-band EAP or UPnP. Here, users do not need to do any action on AP side. They just need AP’s device PIN and enter it into registrar.
  • Page 104 Satspeed V7621-A1 User’s Manual Configuring your Computers Plug the Ethernet cable into AP’s LAN port and make 173. sure the IP connection is valid with Vista. 174. Make sure WCN is enabled. Users may need to enable it at the first time. They could open the “Control Panel”, click “Classic View“, open “Administrative Tools”, double click...
  • Page 105 Satspeed V7621-A1 User’s Manual Configuring your Computers 175. If the previous steps are done, open Windows Explorer. Go to the Network section. Click on “Network discovery and file sharing are turned 176. off. Network computers and devices are not visible. Click to...
  • Page 106 Satspeed V7621-A1 User’s Manual Configuring your Computers Click on “Turn on network discovery and file sharing“ 177. Click on “No, make the network that I am connected to 178. a private network“...
  • Page 107 Satspeed V7621-A1 User’s Manual Configuring your Computers AP’s icon will show up. Double click on it. 179. Users could also Click “Add a wireless device” if the 180. icon is not there. Click “next”.
  • Page 108 Satspeed V7621-A1 User’s Manual Configuring your Computers Enter AP’s Self-PIN Number and click “next”. 181. 182. Choose a name that people who connect to your network will recognize.
  • Page 109 Satspeed V7621-A1 User’s Manual Configuring your Computers 183. Enter the Passphrase and then click Next. 184. A User Account Control screen pops up, click Continue. 185. AP is successfully configured by WCN.
  • Page 110 Satspeed V7621-A1 User’s Manual Configuring your Computers 186. Finally, AP will become configured (see WPS Status). The authentication algorithm, encryption algorithm, and key assigned by WCN will be displayed below “Current Key Info”. 187. The SSID field of Wireless Basic Settings page will also...

  • Page 111: Operations Of Ap - Ap Being A Registrar

    Satspeed V7621-A1 User’s Manual Configuring your Computers Operations of AP - AP being a registrar AP mode Whenever users enter station’s PIN into AP’s Wi-Fi Protected Setup page and click “Start PIN”, AP will become a registrar. Users must start the PIN method on the station side within two minutes.
  • Page 112 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 113 Satspeed V7621-A1 User’s Manual Configuring your Computers 194. If the device PIN is correct and the WPS handshake is successfully done on the station side, User’s Wi-Fi Protected status will be shown as below.
  • Page 114 Satspeed V7621-A1 User’s Manual Configuring your Computers 195. If the device PIN is correct and the WPS handshake is successfully done, AP’s Wi-Fi Protected Setup page will be shown as below. Other pages such as Wireless Basic Settings page and Wireless Security Setup page will also be updated appropriately as described in previous sections.

  • Page 115: Push Button Method

    Satspeed V7621-A1 User’s Manual Configuring your Computers Push Button method Wireless Gateway supports a virtual button “Start PBC” on the Wi-Fi Protected Setup page for Push Button method. If users push a virtual button “Start PBC”, AP will initiate a WPS session and wait for any station to join.
  • Page 116 Satspeed V7621-A1 User’s Manual Configuring your Computers 200. Users must start the PBC method on the station side within two minutes.
  • Page 117 Satspeed V7621-A1 User’s Manual Configuring your Computers 201. If the device PCB and the WPS handshake is successfully done on the station side, User’s Wi-Fi Protected status will be shown as below.
  • Page 118 Satspeed V7621-A1 User’s Manual Configuring your Computers 202. If the device PIN is correct and the WPS handshake is successfully done, AP’s Wi-Fi Protected Setup page will be shown as below. Other pages such as Wireless Basic Settings page and Wireless Security Setup page will also be updated appropriately as described in previous sections.

  • Page 119: Wireless Multiple Bssid Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Wireless Multiple BSSID Settings This page allows you to set Virtual Access Points (VAP). Here you can enable/disable virtual APs and set the SSID and authentication type. Click "Apply Changes" for these settings to take effect.

  • Page 120: Wireless Status

    Satspeed V7621-A1 User’s Manual Configuring your Computers Wireless Status This page shows the WLAN current status. To access the Wireless Status page: 204. From the left-hand WLAN menu, click on Status The following page is displayed:...

  • Page 121: Ptm Wan

    Satspeed V7621-A1 User’s Manual Configuring your Computers PTM WAN This chapter describes how to configure the way that your device connects to the Internet. Your ISP determines what type of Internet access you should use and provides you with any information that you need in order to configure the Internet access to your device.
  • Page 122 Satspeed V7621-A1 User’s Manual Configuring your Computers 205. From the left-hand Network Settings -> PTM WAN menu. The following page is displayed: Option Description...
  • Page 123 Satspeed V7621-A1 User’s Manual Configuring your Computers Enable VLAN Enable or disable VLAN VLAN ID Enter the VLAN ID 802.1p_Mark Choose the 802.1p_Mark Channel Bridged Choose this option to have the device to be a AP Mode IPoE Fixed IP Choose this option if you are a leased line user with a fixed IP address.

  • Page 124: Configuring Ptm Wan Ipoe Static Ip Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring PTM WAN IPoE Static IP connection If you are a leased line user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS (domain name server) address(es) provided to you by your ISP.
  • Page 125 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 126 Satspeed V7621-A1 User’s Manual Configuring your Computers 213. From the left-hand menu, click on Services -> DHCP.
  • Page 127 Satspeed V7621-A1 User’s Manual Configuring your Computers 214. From the Type ratio, click Set Manually. 215. Enter DNS setting determined by your ISP. 216. If you are happy with your settings, click Apply Changes 217. Click OK.

  • Page 128: Configuring Ptm Wan Ipoe Dhcp Client Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring PTM WAN IPoE DHCP Client connection Dynamic Host Configuration Protocol (DHCP), Dynamic IP (Get WAN IP Address automatically). If you are connected to the Internet through a Cable modem line, then a dynamic IP will be assigned.

  • Page 129: Configuring Ptm Wan Pppoe Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring PTM WAN PPPoE connection If your ISP’s Internet service uses PPPoE you need to set up a PPP login account. The first time that you login to the Internet, your ISP will ask you to enter a username and password so they can check that you are a legitimate, registered Internet service user.
  • Page 130 Satspeed V7621-A1 User’s Manual Configuring your Computers 227. Select proper Connection Type 228. Enter User Name/Password provided by your ISP. Type them in the relevant boxes. 229. Click Apply Changes.

  • Page 131: Configuring Ptm Wan Ds-Lite Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring PTM WAN DS-Lite connection If you are a leased line with DS-Lite user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS (domain name server) address(es) provided to you by your ISP.

  • Page 132: Configuring Ptm Wan 6Rd Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring PTM WAN 6rd connection If you are a leased line with 6rd user with a fixed IP address, enter in the IP address, subnet mask, gateway address, and DNS (domain name server) address(es) provided to you by your ISP.
  • Page 133 Satspeed V7621-A1 User’s Manual Configuring your Computers...

  • Page 134: Atm Wan

    Satspeed V7621-A1 User’s Manual Configuring your Computers ATM WAN This chapter describes how to configure the way that your device connects to the Internet. Your ISP determines what type of Internet access you should use and provides you with any information that you need in order to configure the Internet access to your device.

  • Page 135: Types Of Dsl Wan Internet Access

    Satspeed V7621-A1 User’s Manual Configuring your Computers  Connect on demand. Enter the minutes after which the session must be disconnected, if no activity takes place.  Manual. Enter the minutes after which the session must be disconnected, if no activity takes place.

  • Page 136: Configuring Your Pppoe Dsl Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring your PPPoE DSL connection If your ISP’s Internet service uses PPPoE you need to set up a PPP login account. The first time that you login to the Internet, your ISP will ask you to enter a username and password so they can check that you are a legitimate, registered Internet service user.
  • Page 137 Satspeed V7621-A1 User’s Manual Configuring your Computers 242. From the left WAN menu, click on ATM WAN. The following page is displayed: 243. Enter VCI and VPI setting determined by your ISP. 244. Select the Encapsulation determined by your ISP.

  • Page 138: Configuring Your Pppoa Dsl Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers 253. Now you are ready to Surf the Internet !!! Configuring your PPPoA DSL connection If your ISP’s Internet service uses PPPoA you need to set up a PPP login account. The first time that you login to the Internet,...
  • Page 139 Satspeed V7621-A1 User’s Manual Configuring your Computers 254. From the left WAN menu, click on ATM WAN. The following page is displayed: 255. Enter VCI and VPI setting determined by your ISP. 256. Select the Encapsulation determined by your ISP.

  • Page 140: Configuring Your Bridged Dsl Connection

    Satspeed V7621-A1 User’s Manual Configuring your Computers 264. Your configuration is complete. 265. Now you are ready to Surf the Internet !!! Configuring your Bridged DSL connection 266. From the left WAN menu, click on ATM WAN. The following page is displayed: 267.

  • Page 141: Configuring Your 1483 Mer By Dhcp

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring your 1483 MER by DHCP 274. From the left WAN menu, click on ATM WAN. The following page is displayed: 275. Enter VCI and VPI setting determined by your ISP. 276. Select the Encapsulation determined by your ISP.

  • Page 142: Configuring Your 1483 Mer By Fixed Ip

    Satspeed V7621-A1 User’s Manual Configuring your Computers 285. Now you are ready to Surf the Internet !!! Configuring your 1483 MER by Fixed IP 286. From the left WAN menu, click on ATM WAN. The following page is displayed: 287.
  • Page 143 Satspeed V7621-A1 User’s Manual Configuring your Computers 297. From the left Service menu, click on DHCP. 298. Check on Set Manually ratio. 299. Enter DNS setting determined by your ISP. 300. Click Apply Changes button. 301. Click OK button. 302.

  • Page 144: Atm Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers ATM Settings The page is for ATM PVC QoS parameters setting. The DSL device support 4 QoS mode —CBR/rt-VBR/nrt-VBR/UBR. 304. From the left-hand WAN menu, click on ATM. The following page is displayed:...
  • Page 145 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Virtual Path Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table. Virtual Channel Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table.

  • Page 146: Dsl Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers DSL Settings The DSL setting page allows you to select any combination of DSL training modes. 305. From the left-hand WAN menu, click on DSL Settings. The following page is displayed:...
  • Page 147 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description ADSL modulation Choose prefered xdsl standard protocols. G.lite : G.992.2 Annex A G.dmt : G.992.1 Annex A T1.413 : T1.413 issue #2 ADSL2 : G.992.3 Annex A ADSL2+ : G.992.5 Annex A AnnexL Option Enable/Disable ADSL2/ADSL2+ Annex L capability.

  • Page 148: 3G Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers 3G Settings Please enter the APN, PIN code, user name, and password provided by your ISP. (Please note that some information might not be needed.) 306. From the left WAN menu, click on 3G Settings. The following page is displayed: 307.
  • Page 149 Satspeed V7621-A1 User’s Manual Configuring your Computers 313. Click OK button. 314. Your configuration is complete. 315. Now you are ready to Surf the Internet !!! Option Description 3G WAN Enable or Disable 3G WAN PIN code Enter PIN code determined by your ISP. Keep it empty if...

  • Page 150: Dhcp Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCP Settings You can configure your network and DSL device to use the Dynamic Host Configuration Protocol (DHCP). This page provides DHCP instructions for implementing it on your network by selecting the role of DHCP protocol that this device wants to play.
  • Page 151 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description IP Pool Range Specify the lowest and highest addresses in the pool. Max Lease Time The Lease Time is the amount of time that a network user is allowed to maintain a network connection to the device using the current dynamic IP address.

  • Page 152: Dhcp Relay Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCP Relay Configuration 321. From the left-hand Services menu, click on DHCP. 322. From DHCP Mode check ratio, click on DHCP Relay. 323. Type DHCP server IP Addresses. 324. Click on Apply Changes.

  • Page 153: Dhcp None Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers b. Type ipconfig /release in the command window. c. Type ipconfig /renew. d. Type exit to close the command window. Linux a. Bring up a shell. b. Type pump -r to release the lease.

  • Page 154: Dhcpv6 Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCPv6 Settings You can configure your network and DSL device to use the Dynamic Host Configuration Protocol (DHCP). This page provides DHCP instructions for implementing it on your network by selecting the role of DHCP protocol that this device wants to play.
  • Page 155 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 156 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description IP Pool Range Specify the lowest and highest addresses in the pool. Prefix Length Configure Prefix Length Valid Lifetime Configure Valid Lifetime Preferred Configure Preferred Lifetime Lifetime Renew Time Configure Renew Time...

  • Page 157: Dhcp Server (Auto) Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCP Server (Auto) Configuration 336. From the left-hand Services menu, click on DHCPv6. 337. From DHCPv6 Mode check ratio, click on DHCP Server (Auto). 338. Click on Apply Changes. Function Button Description Apply Changes Set new DHCP server configuration.

  • Page 158: Dhcp Relay Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCP Relay Configuration 340. From the left-hand Services menu, click on DHCP. 341. From DHCPv6 Mode check ratio, click on DHCP Relay. 342. Configure the Upper Interface (server link). 343. Click on Apply Changes.

  • Page 159: Dhcp None Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers a. Bring up a command window. b. Type ipconfig /release in the command window. c. Type ipconfig /renew. d. Type exit to close the command window. Linux a. Bring up a shell. b. Type pump -r to release the lease.

  • Page 160: Dns Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers DNS Configuration This page is used to configure the DNS server ip addresses for DNS Relay. DHCP Server Configuration - Attain DNS Automatically 350. From the left Services menu, click on DNS -> DNS Server.

  • Page 161: Dhcp Server Configuration - Set Dns Manually

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCP Server Configuration - Set DNS Manually 354. From the left Services menu, click on DNS -> DNS Server. 355. From check ratio, click on Set DNS Manually. 356. Enter the IP Address of DNS.
  • Page 162 Satspeed V7621-A1 User’s Manual Configuring your Computers 358. Click OK button.

  • Page 163: Dynamic Dns Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers Dynamic DNS Configuration Overview of Dynamic DNS If some host has a dynamic IP address that keeps changing frequently, it is difficult to keep updating the IP record that is associated with the domain name of this host in the zone files.
  • Page 164 Satspeed V7621-A1 User’s Manual Configuring your Computers update request is sent. However, when the system comes up there is no way of knowing what was the IP address on last successful update before the system went down. You need to give the command “system config save“...

  • Page 165: Dynamic Dns Configuration - Dyndns.org

    Satspeed V7621-A1 User’s Manual Configuring your Computers Dynamic DNS Configuration – DynDNS.org 359. From the left Services menu, click on DNS -> Dynamic DNS. 360. Check the Enable check box. 361. From DDNS provider drop-down list, select DynDNS.org. 362. Enter the Hostname.

  • Page 166: Dynamic Dns Configuration - Tzo

    Satspeed V7621-A1 User’s Manual Configuring your Computers Function Button Description Click Add to add this registration into the configuration. Remove Select an existing DDNS registration by clicking the radio button at the Select column of the Dynamic DNS Table. Click Remove button to remove the selected registration from the configuration.
  • Page 167 Satspeed V7621-A1 User’s Manual Configuring your Computers Field Description Enable Check this item to enable this registration account for the DNS server. DDNS provider There are two DDNS providers to be selected in order to register your device with: DynDNS and TZO. A charge may occurs depends on the service you select.

  • Page 168: Ip/Port Filtering

    Satspeed V7621-A1 User’s Manual Configuring your Computers IP/Port Filtering Firewall contains several features that are used to deny or allow traffic from passing through the device. The IP/Port filtering feature allows you to deny/allow specific services or applications in the forwarding path.
  • Page 169 Satspeed V7621-A1 User’s Manual Configuring your Computers Rule Action Deny or allow traffic when matching this rule. Direction Traffic forwarding direction. Protocol There are 3 options available: TCP, UDP and ICMP. Source IP The source IP address assigned to the traffic on which Address filtering is applied.

  • Page 170: Mac Filtering

    Satspeed V7621-A1 User’s Manual Configuring your Computers MAC Filtering The MAC filtering feature allows you to define rules to allow or deny frames through the device based on source MAC address, destination MAC address, and traffic direction. Configuring MAC filtering to Deny for outgoing access 376.
  • Page 171 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block Outgoing Default Specify the default action on the LAN to WAN Action bridging/forwarding path. Incoming Default Specify the default action on the WAN to LAN Action bridging/forwarding path.

  • Page 172: Port Forwarding

    Satspeed V7621-A1 User’s Manual Configuring your Computers Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall. These settings are only necessary if you wish to host some sort of server like a web server or mail server on the private local network behind your Gateway's NAT firewall.
  • Page 173 Satspeed V7621-A1 User’s Manual Configuring your Computers...

  • Page 174: Port Forwarding For Tcp With Specified Ip

    Satspeed V7621-A1 User’s Manual Configuring your Computers Port Forwarding for TCP with specified IP Please follow example below to configure the Port Forwarding to Specified IP with TCP. 383. From the left Services menu, click on Firewall -> Port Forwarding.
  • Page 175 Satspeed V7621-A1 User’s Manual Configuring your Computers 384. Check the option Enable Port Forwarding to enable the Enable Port Forwarding. 385. Click Apply Changes. 386. Enter any comment in Comment field. 387. Enter the IP Address and port you want to be forwarded in IP Address / Local Port from / Local Port to field.

  • Page 176: Port Forwarding For Udp With Specified Ip

    Satspeed V7621-A1 User’s Manual Configuring your Computers Port Forwarding for UDP with specified IP Please follow example below to configure the Port Forwarding to Specified IP with UDP. 392. From the left Services menu, click on Firewall -> Port Forwarding.
  • Page 177 Satspeed V7621-A1 User’s Manual Configuring your Computers 393. Check the option Enable Port Forwarding to enable the Enable Port Forwarding. 394. Click Apply Changes. 395. Enter any comment in Comment field. 396. Enter the IP Address and port you want to be forwarded in IP Address / Local Port from / Local Port to field.

  • Page 178: Url Blocking

    Satspeed V7621-A1 User’s Manual Configuring your Computers URL Blocking The URL Blocking is the web filtering solution. The firewall includes the ability to block access to specific web URLs based on string matches. This can allow large numbers of URLs to be blocked by specifying a Keyword.
  • Page 179 Satspeed V7621-A1 User’s Manual Configuring your Computers Apply Changes Click to disable/enable the URL Blocking capability Add FQDN Add FQDN into URL Blocking table. Delete Selected Delete the selected FQDN from the URL Blocking FQDN table. You can click the checkbox at the Select column to select the Blocked FQDN.

  • Page 180: Configuring Url Blocking Of Keyword

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring URL Blocking of Keyword 407. From the left Services menu, click on Firewall -> URL Blocking. Fields on the Description first setting block URL Blocking Check this item to enable the URL Blocking feature.
  • Page 181 Satspeed V7621-A1 User’s Manual Configuring your Computers 408. From the URL Blocking check ratio, check on Enable 409. Click Apply Changes 410. Type the Keyword in the Keyword field. 411. Click Add 412. Configure URL Blocking of Keyword setting successfully!

  • Page 182: Domain Blocking

    Satspeed V7621-A1 User’s Manual Configuring your Computers Domain Blocking This page is used to configure the Blocked domain. Here you can add/delete the blocked domain. Configuring Domain Blocking 413. From the left Services menu, click on Firewall -> Domain Blocking.
  • Page 183 Satspeed V7621-A1 User’s Manual Configuring your Computers 414. From the Domain Blocking check ratio, check on Enable 415. Click Apply Changes 416. Type the Domain in the Domain field. 417. Click Add 418. Configure URL Blocking of FQDN setting successfully!

  • Page 184: Dmz

    Satspeed V7621-A1 User’s Manual Configuring your Computers A demilitarized zone (DMZ) is a host or small network that acts as neutral ground between the inside and outside network. It contains information that is useful to users of both the inside and outside network.
  • Page 185 Satspeed V7621-A1 User’s Manual Configuring your Computers 420. From the DMZ Host check ratio, check on Enable 421. Type the IP Address in the DMZ Host IP Address field. 422. Click Apply Changes 423. Click OK button.

  • Page 186: Upnp

    Satspeed V7621-A1 User’s Manual Configuring your Computers UPnP UPnP is an architecture for pervasive peer-to-peer network connectivity of intelligent appliances, Wireless devices, and PCs of all form factors. It is designed to bring easy-to-use, flexible, standards-based connectivity to ad-hoc or unmanaged networks whether in the home, in a small business, public spaces, or attached to the Internet.

  • Page 187: Configuring Upnp

    Satspeed V7621-A1 User’s Manual Configuring your Computers From the web page you can enable or disable UPnP. Configuring UPnP 424. From the left Services menu, click on UPnP. The following page is displayed: Fields on the Description first setting block UPnP Enable/disable UPnP feature.

  • Page 188: Upnp Control Point Software On Windows Me

    Satspeed V7621-A1 User’s Manual Configuring your Computers 428. Click OK button. UPnP Control Point Software on Windows ME To install the control point software on Windows ME: 1. In the Control Panel, select "Add/Remove Programs". 2. In the "Add/Remove Programs Properties" dialog box, select the "Windows Setup"...

  • Page 189: Ssdp Requirements

    Satspeed V7621-A1 User’s Manual Configuring your Computers 4. In the "Local Area Connection Properties" dialog box, select the "Advanced" tab. Disable the Internet Connection Firewall by de-selecting the entry with the following label: "Protect my computer and network by limiting or preventing access to the computer from the Internet".
  • Page 190 Satspeed V7621-A1 User’s Manual Configuring your Computers Installation procedure To install the Control point software on Windows XP, follow the steps below: 1. In the Control Panel, select "Add/Remove Programs". 2. In the "Add or Remove Programs" dialog box, click the "Add / Remove Windows Components"...
  • Page 191 Satspeed V7621-A1 User’s Manual Configuring your Computers 5. Select the following entries from the “Networking Services” window and then click "OK": If you are using Windows XP, select: • "Universal Plug and Play". If you are using Windows XP SP1, select: •...

  • Page 192: Rip

    Satspeed V7621-A1 User’s Manual Configuring your Computers RIP is an Internet protocol you can set up to share routing table information with other routing devices on your LAN, at your ISP’s location, or on remote networks connected to your network via the DSL line.
  • Page 193 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block Enable/disable RIP feature. Fields on the Description second setting block: Interface The name of the interface on which you want to enable RIP. Receive Mode Indicate the RIP version in which information must be passed to the DSL device in order for it to be accepted into its routing table.

  • Page 194: Samba

    Satspeed V7621-A1 User’s Manual Configuring your Computers Samba This page let user to config Samba. Samba 430. From the left Services menu, click on Samba. Fields on the Description first setting block Digital Media Enable/disable the Digital Media Server Server...

  • Page 195: Voip Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers VoIP Configuration Introduction The Wireless VoIP Gateway Voice software release provides a software architecture for telephony applications. The software consists of real-time voice and signal processing software that perform many of the required telephony data processing functions.
  • Page 196 Satspeed V7621-A1 User’s Manual Configuring your Computers For FXS ports the SLIC generates FXS signalling. For example, telephone line events are generated when picking up or hanging up a telephone. Commanding a phone to ring is an example of telephone line signalling.
  • Page 197 Satspeed V7621-A1 User’s Manual Configuring your Computers Voice processing software Voice protocol software • Health Monitor to monitor the state of the IP connection and indicate this status to on-board LEDs. Telephony data processing features The main telephony data processing functions supported in the...
  • Page 198 Satspeed V7621-A1 User’s Manual Configuring your Computers SIP features SIP stands for Session Initiation Protocol (SIP), an application- layer control (signalling) protocol for creating, modifying, and terminating sessions with one or more participants. These sessions can include Internet telephone calls, multimedia distribution, and multimedia conferences.
  • Page 199 Satspeed V7621-A1 User’s Manual Configuring your Computers SIP Features not supported As SIP is an emerging standard, it is also worth noting the features which are not supported in the current Wireless VoIP Gateway implementation of SIP. • Dynamic mapping of users to endpoints.
  • Page 200 Satspeed V7621-A1 User’s Manual Configuring your Computers c. A party dials the C party, C party receives a ring tone and A party receives ringback d. A party press hook flash button to complete the conference, each of the three parties can hear the other two parties in the conference e.

  • Page 201: Port 1/ Port 2 Configurations

    Satspeed V7621-A1 User’s Manual Configuring your Computers Port 1/ Port 2 configurations 1. From the left-hand menu, click on VoIP Settings -> Port1 or Port2. The following page is displayed:...
  • Page 202 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 203 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 204 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 205 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 206 Satspeed V7621-A1 User’s Manual Configuring your Computers...

  • Page 207: Sip Account

    Satspeed V7621-A1 User’s Manual Configuring your Computers SIP Account Set account for the port (lines) individually. Option Description Display Name Enter user name to be displayed. Number Enter user name (or phone number) of the user. Login ID Enter user name for authentication, maximum 39 characters.
  • Page 208 Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description Proxy Addr The IP address of SIP proxy Proxy Port The port number used by SIP Proxy Default: 5060 SIP Domain Assign domain name for the URL to be registered. SIP registration expired time. Assigns the time interval from 1 – 65535,...

  • Page 209: Sip Advanced

    Satspeed V7621-A1 User’s Manual Configuring your Computers SIP Advanced Prompts for SIP Advanced Setting Option Description SIP Port Assign the SIP port number of terminal adapter. Its range is 1024 to 65535, default setting is 5060 for FX0 and 5061 for FXS1.

  • Page 210: Forward Mode

    Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description RFC2833 Specify the Out-band 2833 payload type value. Payload Type Default: 96 SIP INFO The Duration (ms) SIP INFO Duration (ms) Call Waiting Enable/Disable Call Waiting. Default: Enable Call Waiting Enable/Disable Call Waiting Caller ID.

  • Page 211: Speed Dial

    Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description No Answer Enable/Disable No Answer Forward to. Forward to Default: Disable No Answer When the port is no answer, the incoming call will be redirected to the Number specified phone number.

  • Page 212: Abbreviated (Phonebook) Dial

    Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description Position There are 10 Speed Dial number from 0 to 9. Just pick up the phone and dial the speed dial number for example 5 and then dial # to make the call for the Phone Number in Speed dial number 5.
  • Page 213 Satspeed V7621-A1 User’s Manual Configuring your Computers Examples Example 1: Abbreviated Name: 001, Phone Number: 2222 When the user dials the Abbreviated Number 001, it will dial to the VoIP User whose phone number is 2222. Example 2: Abbreviated Name: 002, Phone Number: 192.168.10.222 When the user dials the Number 002, it will dial to the VoIP Device whose WAN IP Address is 192.168.10.222.

  • Page 214: Dial Plan

    Satspeed V7621-A1 User’s Manual Configuring your Computers Example 5: Abbreviated Name: 005, Phone Number: voipuser When the user dials the Number 005, it will dial to the VoIP User whose phone number is voipuser. Dial plan Dial plan Configuration. PSTN Routing Prefix...

  • Page 215: Fax)

    Satspeed V7621-A1 User’s Manual Configuring your Computers V.152 V.152 Configuration. T.38(FAX) The T.38 FAX procedure is used for the changeover from VoIP to fax mode during a call. The SIP will establish a normal VoIP call using INVITEs with SDP field to support T.38 detail.

  • Page 216: Customize Parameters)

    Satspeed V7621-A1 User’s Manual Configuring your Computers T.38(customize parameters) T.38(customize parameters) Configuration. Hot Line Hot Line provides a way for a user to call a designated phone number without dialing any number. Once the user picks up the handset of the line which is setup as a “Hot Line”, the system will automatically dial the pre-set number and connect the caller to the pre-set place.

  • Page 217: Dnd (Don't Disturb)

    Satspeed V7621-A1 User’s Manual Configuring your Computers DND (Don't Disturb) The Do Not Disturb function allows a caller to listen to a standard voicemail message, which simply states you are away from your desk or the office at this time. The caller is never aware that you have Do Not Disturb activated on your phone, so they will not be offended.

  • Page 218: Alarm

    Satspeed V7621-A1 User’s Manual Configuring your Computers Alarm Provide the alarm function. The alarm will sound when it reached the Alarm Time that you configured. Option Description Enable Enable/Disable Alarm. Time Default is 0:0 (hh:mm). Set the Alarm Time. (24 hours format, hh:mm) Example 1: Alarm: Enable, Alarm Time: 1:14 (hh:mm) The alarm will sound when it reached the current time 1:14.

  • Page 219: Dsp

    Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 220 Satspeed V7621-A1 User’s Manual Configuring your Computers...
  • Page 221 Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description Jitter Buffer Min delay (ms): 40-100. Control Max delay (ms): 130-300. Optimization factor: 1-13 Enable/Disable this function. There are three types of silence suppression: Silence Suppression Enabled - NO CNG Silence Suppression Enabled - Only G.711 Annex II type Silence Suppression Enabled - Codec Specific CN.
  • Page 222 Satspeed V7621-A1 User’s Manual Configuring your Computers Option Description Reverse Polarity Reversal is enabled to inform the charge/billing system. Polarity Enable/Disable this function. before Caller Default: Disable. Short Ring Enable/Disable this function. before Caller Default: Disable. Dual Tone Enable/Disable this function.

  • Page 223: Tone Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Tone Settings This page is used to configure the parameters for tone settings. 1. From the left-hand menu, click on VoIP Settings -> Tone. The following page is displayed:...

  • Page 224: Select Country

    Satspeed V7621-A1 User’s Manual Configuring your Computers Select Country Wireless VoIP Gateway supports configuration of pre- configured audible tones based on the geographical location. Adjust the tone frequency according to each country. Telephony developers working in VoIP, PBXs, VoIP gateways,...
  • Page 225 Satspeed V7621-A1 User’s Manual Configuring your Computers 4. To custom the call progress tones, you should search on a specific call progress tone (e.g. dial tone, busy tone, call waiting tone..etc.) for their frequency, wavelength, period, amplitude, speed, and candence.

  • Page 226: Ring Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Ring Settings This page is used to configure the parameters for ring settings. 1. From the left-hand menu, click on VoIP Settings -> Ring. The following page is displayed:...

  • Page 227: Other Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Other Settings This page is used to configure the parameters for other settings. From the left-hand menu, click on VoIP Settings -> Other. The following page is displayed:...

  • Page 228: Auto Provision Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Auto Provision Settings This page is used to configure the parameters for Auto Provision and Firmware update. 2. From the left-hand menu, click on VoIP Settings -> Config. The following page is displayed:...

  • Page 229: Network Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Network Settings This page is used to configure the parameters for Network settings. 3. From the left-hand menu, click on VoIP Settings -> Network. The following page is displayed:...

  • Page 230: Arp Table

    Satspeed V7621-A1 User’s Manual Configuring your Computers ARP Table This ARP Table shows a list of learned MAC addresses. ARP Table 4. From the left Advance menu, click on ARP Table.

  • Page 231: Bridging

    Satspeed V7621-A1 User’s Manual Configuring your Computers Bridging You can enable/disable Spanning Tree Protocol and set MAC address aging time in this page. Bridging 5. From the left Advance menu, click on Bridging. Fields on the Description first setting block Ageing Time Set the Ethernet address ageing time, in seconds.

  • Page 232: Routing

    Satspeed V7621-A1 User’s Manual Configuring your Computers Routing The Routing page enables you to define specific route for your Internet and network data. Most users do not need to define routes. On a typical small home or office LAN, the existing routes that set up the default gateways for your LAN hosts and for the DSL device provide the most appropriate path for all your Internet traffic.
  • Page 233 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block Enable Check to enable the selected route or route to be added. Destination The network IP address of the subnet. The destination can be specified as the IP address of a subnet or a specific host in the subnet.

  • Page 234: Snmp

    Satspeed V7621-A1 User’s Manual Configuring your Computers SNMP Simple Network Management Protocol (SNMP) is a troubleshooting and management protocol that uses the UDP protocol on port 161 to communicate between clients and servers. The DSL device can be managed locally or remotely by SNMP protocol.
  • Page 235 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block System System description of the DSL device. Description System Contact Contact person and/or contact information for the DSL device. System Name An administratively assigned name for the DSL device.

  • Page 236: Ip Qos

    Satspeed V7621-A1 User’s Manual Configuring your Computers IP QoS Entries in this table are used to assign the precedence for each incoming packet based on specified policy. Config Procedure: 1: set traffic rule. 2: assign the precedence or add marker for different stream.

  • Page 237: Qos Classification

    Satspeed V7621-A1 User’s Manual Configuring your Computers 9. Click on Enable. The following page is displayed: This page is used to configure the QoS policy and Queue. If select PRIO of policy, the lower numbers imply greater precedence. If select WRR of policy, please input the weight of this queue.
  • Page 238 Satspeed V7621-A1 User’s Manual Configuring your Computers 11. Click on Add. The following page is displayed:...
  • Page 239 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block IP Version Select the IP Version Rule Name Configure the Rule Name Precedence Select this field to mark the IP precedence bits in the packet that match this classification rule.

  • Page 240: Traffic Shaping

    Satspeed V7621-A1 User’s Manual Configuring your Computers Traffic Shaping 12. From the left Advance menu, click on IP QoS -> Traffic Shaping. The following page is displayed: 13. Click on Add. The following page is displayed:...
  • Page 241 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields on the Description first setting block IP Version Select the IP Version Interface Select the Interface Protocol The selections are TCP, UDP, ICMP and the blank for none. This field is required if the source port or destination port has been entered.

  • Page 242: Remote Access

    Satspeed V7621-A1 User’s Manual Configuring your Computers Remote Access This page is used to enable/disable management services for the LAN and WAN. Remote Access 14. From the left Advance menu, click on Remote Access. The following page is displayed:...

  • Page 243: Others

    Satspeed V7621-A1 User’s Manual Configuring your Computers Others Here you can set some other advanced settings. Others 15. From the left Advance menu, click on Others. The following page is displayed:...

  • Page 244: Ipv6

    Satspeed V7621-A1 User’s Manual Configuring your Computers IPv6 This page is used to configure IPv6 IPv6 This page is used to configure IPv6 enable/disable 16. From the left Advance menu, click on IPv6 -> IPv6. The following page is displayed:...

  • Page 245: Dhcpv6

    Satspeed V7621-A1 User’s Manual Configuring your Computers DHCPv6 This page is used to configure DHCPv6 Server and DHCPv6 Relay. 18. From the left Advance menu, click on IPv6 -> DHCPv6. The following page is displayed: MLD Proxy This page is used to configure MLD Proxy.

  • Page 246: Mld Snooping

    Satspeed V7621-A1 User’s Manual Configuring your Computers 20. Click OK button. MLD Snooping This page is used to configure MLD Snooping. 21. From the left Advance menu, click on IPv6 -> MLD Snooping. Fields on the Description first setting block...

  • Page 247: Ipv6 Routing

    Satspeed V7621-A1 User’s Manual Configuring your Computers IPv6 Routing This page is used to configure the IPv6 static routing information. Here you can add/delete static IP routes. 23. From the left Advance menu, click on IPv6 -> IPv6 Routing.

  • Page 248: Ip/Port Filtering

    Satspeed V7621-A1 User’s Manual Configuring your Computers IP/Port Filtering Entries in this table are used to restrict certain types of data packets through the Gateway. Use of such filters can be helpful in securing or restricting your local network. 24. From the left Advance menu, click on IPv6 -> IP/Port...

  • Page 249: Diagnostic

    Satspeed V7621-A1 User’s Manual Configuring your Computers Diagnostic The DSL device supports some useful diagnostic tools. Ping Once you have your DSL device configured, it is a good idea to make sure you can ping the network. A ping command sends a message to the host you specify.

  • Page 250: Atm Loopback

    Satspeed V7621-A1 User’s Manual Configuring your Computers 28. Now you could see the result below: ATM Loopback In order to isolate the ATM interface problems, you can use ATM OAM loopback cells to verify connectivity between VP/VC endpoints, as well as segment endpoints within the VP/VC.

  • Page 251: Dsl Tone Diagnostics

    Satspeed V7621-A1 User’s Manual Configuring your Computers DSL Tone Diagnostics This page displays the DSL Tone Diagnostic performance. Click Start button to start the DSL diagnostic. 30. From the left Maintenance menu, click on Diagnostic -> DSL Tone. The following page is displayed:...

  • Page 252: Adsl Connection Diagnostics

    Satspeed V7621-A1 User’s Manual Configuring your Computers ADSL Connection Diagnostics The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. 32. From the left Maintenance menu, click on Diagnostic ->...

  • Page 253: Commit/Reboot

    Satspeed V7621-A1 User’s Manual Configuring your Computers Commit/Reboot Whenever you use the web console to change system settings, the changes are initially placed in temporary storage. To save your changes for future use, you can use the Commit/Reboot function. This function saves your changes from RAM to flash memory and reboot the system.

  • Page 254: Backup/Restore

    Satspeed V7621-A1 User’s Manual Configuring your Computers Backup/Restore You can save the current configuration of your Router to a file on your computer. This is highly recommended before you change any configuration settings on the Router or before you upgrade your firmware.

  • Page 255: Restore Settings

    Satspeed V7621-A1 User’s Manual Configuring your Computers Restore settings 42. From the left Maintenance menu, click on Update -> Backup/Restore. The following page is displayed: 43. Click Browse... and browse to the location of your backup file 44. Click Upload Figure 6: Backup &...
  • Page 256 Satspeed V7621-A1 User’s Manual Configuring your Computers Software Reset: 47. From the left Admin menu, click on Commit/Reboot. The following page is displayed: Reset 48. Click on 49. Click on OK. 50. System rebooting, Please wait ... 60 seconds.

  • Page 257: System Log

    Satspeed V7621-A1 User’s Manual Configuring your Computers System Log This page can be used to set remote log server and show the system log. System Log 51. From the left-hand Admin menu, click on System Log. The following page is displayed:...
  • Page 258 Satspeed V7621-A1 User’s Manual Configuring your Computers 52. Check the option Enable. 53. From the Log Level drop-down list, select a Log Level. 54. From the Display Level drop-down list, select a Display Level. 55. Click Apply Changes. 56. Change setting successfully! Click on OK to confirm.

  • Page 259: Password

    Satspeed V7621-A1 User’s Manual Configuring your Computers Password You can restrict access to your device’s web pages using password protection. With password protection enabled, users must enter a username and password before gaining access to the web pages. By default, password protection is enabled on your device, and...
  • Page 260 Satspeed V7621-A1 User’s Manual Configuring your Computers 58. This page displays the current username and password settings. Change your own unique password in the relevant boxes. They can be any combination of letters or numbers with a maximum of 30 characters. The default setting uses admin for the username and admin for password.

  • Page 261: Firmware Update

    Satspeed V7621-A1 User’s Manual Configuring your Computers Firmware Update The Firmware Update page allows you to:  manually download the latest firmware version from website and manually update your firmware. See Manually updating firmware. About firmware versions Firmware is a software program. It is stored as read-only memory on your device.
  • Page 262 Satspeed V7621-A1 User’s Manual Configuring your Computers 65. Use the Choose file box to navigate to the relevant directory where the firmware version is saved. 66. Once you have selected the file to be installed, click Open. The file’s directory path is displayed in the Select File: text box.
  • Page 263 Satspeed V7621-A1 User’s Manual Configuring your Computers 69. Firmware update has been update complete and it will bring you to the home page of the device:...
  • Page 264 Satspeed V7621-A1 User’s Manual Configuring your Computers 70. From the left Admin menu, click on Commit/Reboot. The following page is displayed: Reset 71. Click on 72. Click on OK. 73. System rebooting, Please wait ... 60 seconds.

  • Page 265: Acl Configuration

    Satspeed V7621-A1 User’s Manual Configuring your Computers ACL Configuration You can specify which services are accessable form LAN or WAN side. Entries in this ACL table are used to permit certain types of data packets from your local network or Internet network to the Gateway.

  • Page 266: Time Zone

    Satspeed V7621-A1 User’s Manual Configuring your Computers Time Zone Certain systems may not have a date or time mechanism or may be using inaccurate time/day information. the Simple Network Time Protocol feature provides a way to synchronize the device’s own time of day setting with a remote time server as described in RFC 2030 (SNTP) and RFC 1305 (NTP).
  • Page 267 Satspeed V7621-A1 User’s Manual Configuring your Computers Fields Description Current Time The current time of the specified time zone. You can set the current time by yourself or configured by SNTP. Interval The Interval of SNTP client to update the system clock Time Zone The time zone in which the DSL device resides.
  • Page 268 Satspeed V7621-A1 User’s Manual Configuring your Computers Time GMT +/- Description Daylight Saving Daylight Saving Start Zone offset IDLW -1200 International Date Line West Not applicable Not applicable -1100 Nome Not applicable Not applicable -1000 Hawaii Standard Not applicable Not applicable...
  • Page 269 Satspeed V7621-A1 User’s Manual Configuring your Computers Time GMT +/- Description Daylight Saving Daylight Saving Start Zone offset +100 Central European Last Sunday March at Last Sunday 2:00am October at 2:00am +100 Middle European Last Sunday March at Last Sunday...
  • Page 270 Satspeed V7621-A1 User’s Manual Configuring your Computers Time GMT +/- Description Daylight Saving Daylight Saving Start Zone offset +900 Korean Standard Not applicable Not applicable +900 Japan Standard Not applicable Not applicable CAST +930 Central Australian Standard Last Sunday October...

  • Page 271: 271

    Satspeed V7621-A1 User’s Manual Configuring your Computers TR-069 TR-069 is a protocol for communication between a CPE and Auto-Configuration Server (ACS). The CPE TR-069 configuration should be well defined to be able to communicate with the remote ACS. TR-069 Configuration 81.
  • Page 272 Satspeed V7621-A1 User’s Manual Configuring your Computers Figure 12: TR-069 Configuration page ACS Field Description ACS URL. For example, http://10.0.0.1:80 https://10.0.0.1:443 User Name The username the DSL device should use when connecting to the ACS. Password The password the DSL device should use when connecting to the ACS.

  • Page 273: Statistics

    Satspeed V7621-A1 User’s Manual Configuring your Computers Statistics This page shows the packet statistics for transmission and reception regarding to network interface. Statistics - Interface 82. From the left Statistics menu, click on Interface The following page is displayed: 83. To display updated statistics showing any new data since...

  • Page 274: Statistics - Dsl

    Satspeed V7621-A1 User’s Manual Configuring your Computers Statistics - DSL This page shows the packet statistics for transmission and reception regarding to network interface. 84. From the left Statistics menu, click on DSL The following page is displayed: 85. To display updated statistics showing any new data since...

  • Page 275: A Configuring Your Computers

    Satspeed V7621-A1 User’s Manual Configuring your Computers Configuring your Computers This appendix provides instructions for configuring the Internet settings on your computers to work with the Wireless VDSL2 Router. Configuring Ethernet PCs Before you begin By default, the Wireless VDSL2 Router automatically assigns the required Internet settings to your PCs.
  • Page 276 Satspeed V7621-A1 User’s Manual Configuring your Computers 94. In the Network and Dial-up Connections window, right-click the Local Area Connection icon, and then select Properties. The Local Area Connection Properties dialog box is displayed with a list of currently installed network components.

  • Page 277: Windows Me Pcs

    Satspeed V7621-A1 User’s Manual Configuring your Computers Windows Me PCs 104. In the Windows task bar, click the Start button, point to Settings, and then click Control Panel. 105. Double-click the Network and Dial-up Connections icon. 106. In the Network and Dial-up Connections window, right- click the Network icon, and then select Properties.

  • Page 278: Windows Nt 4.0 Workstations

    Satspeed V7621-A1 User’s Manual Configuring your Computers 121. Click on Microsoft in the Manufacturers list box, and then click TCP/IP in the Network Protocols list box. 122. Click OK to return to the Network dialog box, and then click OK again.

  • Page 279: Assigning Static Internet Information To Your Pcs

    Satspeed V7621-A1 User’s Manual Configuring your Computers 137. Open the Control Panel window, and then double-click the Network icon. 138. In the Network dialog box, click the Protocols tab. 139. In the Protocols tab, select TCP/IP, and then click Properties.

  • Page 280: B Ip Addresses, Network Masks, And Subnets

    Satspeed V7621-A1 User’s Manual IP Addresses, Network Masks, and Subnets IP Addresses, Network Masks, and Subnets IP Addresses This section refers only to IP addresses for IPv4 (version 4 of the Internet Protocol). IPv6 addresses are not covered. This section assumes basic knowledge of binary numbers, bits, Note and bytes.

  • Page 281: Subnet Masks

    Satspeed V7621-A1 User’s Manual IP Addresses, Network Masks, and Subnets scope of this discussion.) These classes have different uses and characteristics. Class A networks are the Internet's largest networks, each with room for over 16 million hosts. Up to 126 of these huge networks can exist, for a total of over 2 billion hosts.
  • Page 282 Satspeed V7621-A1 User’s Manual IP Addresses, Network Masks, and Subnets 255.255.255.192 or 11111111. 11111111. 11111111.11000000 The two extra bits in field4 can have four values (00, 01, 10, 11), so there are four subnets. Each subnet uses the remaining six bits in field4 for its host IDs, ranging from 1 to 62.

  • Page 283: C Troubleshooting

    User’s Guide Troubleshooting Troubleshooting This appendix suggests solutions for problems you may encounter in installing or using the Wireless VDSL2 Router, and provides instructions for using several IP utilities to diagnose problems. Contact Customer Support if these suggestions do not resolve the problem.
  • Page 284 Satspeed V7621-A1 User’s Manual Troubleshooting Problem Troubleshooting Suggestion My LAN PCs cannot Verify that the DNS server IP address display web pages specified on the PCs is correct for your ISP, on the Internet. as discussed in the item above. If you...

  • Page 285: Diagnosing Problem Using Ip Utilities

    Satspeed V7621-A1 User’s Manual Troubleshooting Diagnosing Problem using IP Utilities ping Ping is a command you can use to check whether your PC can recognize other computers on your network and the Internet. A ping command sends a message to the computer you specify. If the computer receives the message, it sends messages in reply.

  • Page 286: Nslookup

    Satspeed V7621-A1 User’s Manual Troubleshooting nslookup You can use the nslookup command to determine the IP address associated with an Internet site name. You specify the common name, and the nslookup command looks up the name in on your DNS server (usually located with your ISP). If that name is not an entry in your ISP’s DNS table, the request is...

  • Page 287: D Glossary

    Satspeed V7621-A1 User’s Manual Glossary 10BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 10 Mbps. Also known as Category 3 (CAT 3) wiring. See data rate, Ethernet. 100BASE-T A designation for the type of wiring used by Ethernet networks with a data rate of 100 Mbps.
  • Page 288 Satspeed V7621-A1 User’s Manual DHCP Dynamic Host Configuration Protocol DHCP automates address assignment and management. When a computer connects to the LAN, DHCP assigns it an IP address from a shared pool of IP addresses; after a specified time limit, DHCP returns the address to the pool.
  • Page 289 Satspeed V7621-A1 User’s Manual HTTP Hyper-Text Transfer Protocol HTTP is the main protocol used to transfer data from web sites so that it can be displayed by web browsers. See web browser, web site. A hub is a place of convergence where data arrives from one or more directions and is forwarded out in one or more directions.
  • Page 290 Satspeed V7621-A1 User’s Manual LAN know these addresses; the outside world sees only the public IP address when talking to a computer on your LAN. network A group of computers that are connected together, allowing them to communicate with each other and share resources, such as software, files, etc.
  • Page 291 Satspeed V7621-A1 User’s Manual machines, modems, etc. to a telephone port. It is a 6-pin connector usually containing four wires. RJ-45 Registered Jack Standard-45 The 8-pin plug used in transmitting data over phone lines. Ethernet cabling usually uses this type of connector.
  • Page 292 Satspeed V7621-A1 User’s Manual twisted pair The ordinary copper telephone wiring used by telephone companies. It contains one or more wire pairs twisted together to reduce inductance and noise. Each telephone line uses one pair. In homes, it is most often installed with two pairs.
  • Page 293 Satspeed V7621-A1 User’s Manual World Wide Web Also called (the) Web. Collective term for all web sites anywhere in the world that can be accessed via the Internet.

Table of Contents
