ENGLISH
o Press the SETUP button to load the factory settings. The display shows
"OK! Setting is done"

STANDALONE MODE:

This is the simplest way to operate the TUBELED™ system.
Use the MODE button to select the desired mode or patterns from the list below:
Number PATTERN / MODE
1 BLACKOUT
2 STATIC RED
3 STATIC GREEN
4 STATIC YELLOW
5 STATIC BLUE
6 STATIC PURPLE
7 STATIC CYAN
8 STATIC WHITE
9 FAST CHANGE
10 SLOW FLOW 1
11 FAST FLOW 1
12 FAST FLOW 2
13 BLACK RUN 1
14 ROLL CHASE
15 ROLL COLOR
16 COLOR 1/4
17 COLOR1 1/4
18 COLOR 1/2
19 COLOR FLASH
20 B & W FLOW
21 R & G FLOW
22 G & B FLOW
23 R & B FLOW
24 R & G CHASE 1
25 R & G CHASE 2
26 R & B CHASE 1
27 R & B CHASE 2
28 R & W CHASE 1
29 R & W CHASE 2
30 B & G CHASE 1
31 B & G CHASE 2
32 W &G CHASE 1
33 W &G CHASE 2
34 RAINBOW CHASE 1
35 RAINBOW CHASE 2
36 RAINBOW CHASE 3
37 RAINBOW CHASE 4
38 RAINBOW CHASE 8
39 AUTO MODE
40 TEST MODE
41 ADDRESS MODE
42 Factory settings load
43 DMX512 MODE
Use the SETUP and UP/DOWN buttons to change the values of the pattern
parameters. Refer to the "CONTROLS (front)" section to read more about how to use
these buttons.
JB SYSTEMS
OPERATION MANUAL
5/29 TUBELED™ CONTROLLER
ENGLISH

DMX-512 MODE:

Before using the DMX capabilities you have to set the start address. See "installation
steps". There are two different ways to control the controller by DMX:
MODE1 – DMX PATTERN SELECTION:
Mode1 is active when the DMX value of channel1 is not zero!
• Channel1 is used select one of the preprogrammed patterns:
DMX Value
1~5
6~11
12~17
18~23
24~29
30~35
36~41
42~47
48~53
54~59
60~65
66~71
72~77
78~83
84~89
90~95
96~101
102~107
108~113
114~119
120~125
126~131
132~137
138~143
144~149
150~155
156~161
162~167
168~173
174~179
180~185
186~191
192~197
198~203
204~209
210~215
216~221
222~255
• Channel2 is used to control the pattern speed:
DMX value = 000
DMX value = 255
JB SYSTEMS
OPERATION MANUAL
Pattern
BLACKOUT
STATIC RED
STATIC GREEN
STATIC YELLOW
STATIC BLUE
STATIC PURPLE
STATIC CYAN
STATIC WHITE
FAST CHANGE
SLOW FLOW1
FAST FLOWI
FAST FLOW2
BLACK RUNT
ROLL CHASE
ROLL COLOR
COLOR 1/4
COLOR1 1/4
COLOR1 ½
COLOR FLASH
B & W FLOW
R & G FLOW
G & B FLOW
R & B FLOW
R & G CHASE 1
R & G CHASE 2
R & B CHASE 1
R & B CHASE 2
R & W CHASE 1
R & W CHASE 2
B & G CHASE 1
B & G CHASE 2
W &G CHASE 1
W &G CHASE 2
RAINBOW CHASE 1
RAINBOW CHASE 2
RAINBOW CHASE 3
RAINBOW CHASE 4
RAINBOW CHASE 8
Speed = 0
Speed = maximum
6/29 TUBELED™ CONTROLLER
