Symbol Technologies WS 2000 with AP 300
VIEW Pre-Certified Configuration and Deployment Guide
SpectraLink's Voice Interoperability for Enterprise Wireless (VIEW) Certification
Program is designed to ensure interoperability and high performance between NetLink
Wireless Telephones and WLAN infrastructure products.
The products listed below have been thoroughly tested in Symbol Technologies' lab
using the VIEW Pre-Certification Test Plan. This document details how to configure the
WS 2000 Wireless Switch and the AP 300 access point (AP) with NetLink Wireless
Telephones.
Product Summary
Manufacturer:
Approved products:
RF technology:
Radio frequency:
Quality of Service:
Security:
Wireless Switch firmware version tested:
NetLink Wireless Telephone software version tested:
Maximum telephone calls per AP:
Recommended network topology:
Denotes products directly used in Pre-Certification Testing
†
Service Information
If you encounter difficulties or have questions regarding the configuration process,
please contact Symbol Technologies technical support at (800) 653-5350, or at
http://www.symbol.com/services/contactsupport.
© Copyright 2006 SpectraLink Corporation. All rights reserved
PN: 72-9954-00-A.doc
Symbol Technologies:
http://www.symbol.com/products/wireless/ws20
00_brochure.html
Wireless Switch
Access Point
WS 2000
AP 300
†
802.11b/g
2.4 – 2.484 GHz
SpectraLink Voice Priority (SVP)
WPA-TKIP (PSK), WPA2-CCMP (PSK)
2.1.1.0-009R
89.127
8
Switched Ethernet
†
Page 1
Advertisement
Table of Contents
Related Manuals for Symbol WS 2000
Summary of Contents for Symbol WS 2000
-
Page 1: Product Summary
The products listed below have been thoroughly tested in Symbol Technologies’ lab using the VIEW Pre-Certification Test Plan. This document details how to configure the WS 2000 Wireless Switch and the AP 300 access point (AP) with NetLink Wireless Telephones. -
Page 2: Network Topology
Network Topology The following topology was used during VIEW Pre-Certification testing. PN: 72-9954-00-A.doc Page 2... -
Page 3: Configuration Settings
The VIEW Pre-Certified firmware release can be obtained from Symbol Technologies ‘Dev Zone’. Upgrading the WS 2000 Wireless Switch to the new firmware can be done through the Web interface or through the command line interface (CLI). Place the image on the FTP server, TFTP server or through Compact Flash card, depending on the file transfer mechanism chosen. - Page 4 Installing Firmware through the Web Interface 1. Open the WS 2000 applet by entering the IP address of the wireless switch: http://192.168.0.1 2. From the menu on the left side of the screen, click . The Firmware Update Firmware page will appear.
- Page 5 Configuring the Wireless Switch from the Default Configuration Radio settings: The NetLink Wireless Telephones use an 802.11b radio, therefore VIEW Pre-Certification testing was done with the 802.11b mode only and not the b/g mode. Commands Default Settings Required Settings Beacon-interval DTIM-period BG mode B and G...
- Page 6 Configuring Radio Settings through the Web Interface 1. Go to the WS 2000 applet. 2. From the menu on the left side of the page, click AP1<index> [BG] 3. In the page, go to , and select from the dropdown list.
- Page 7 7. Go to the WS 2000 applet. 8. Click AP<index> [BG] 9. In the page, click Beacon Settings 10. In the dialog box, set the Beacon Settings DTIM Period 3 Beacons 11. Click 12. Click Apply PN: 72-9954-00-A.doc Page 7...
-
Page 8: Quality Of Service
Quality Of Service In the WS 2000 Wireless Switch, QoS is achieved by prioritizing voice traffic over data traffic. To prioritize voice traffic over data traffic in the Access Port traffic queues, enable voice prioritization in wireless QoS. Commands Default Settings... - Page 9 Configuring QoS through the Web Interface 1. In the WS 2000 applet, click . The page will Wireless QOS Wireless QoS Configuration appear. is enabled by default. Use Voice Prioritization PN: 72-9954-00-A.doc Page 9...
-
Page 10: Ssid Settings
Configure the SSID settings of the wireless switch using the following commands. admin> admin>network admin(network)>wlan admin(network.wlan)>set ess 1 spectralink Configuring SSID Settings through the Web Interface 1. In the WS 2000 applet, under , click Wireless WLAN1 2. Configure the ESSID (e.g. spectralink). 3. Click Apply PN: 72-9954-00-A.doc... -
Page 11: Security Settings
WPA/WPA2-TKIP WPA/WPA2-TKIP Settings dialog box will appear. WPA/WPA2-TKIP Settings The WS 2000 Wireless Switch supports mixed-mode operation of WPA- TKIP and WPA2-TKIP. The steps below enable WPA-TKIP by default. WPA-TKIP was used for VIEW Pre-Certification testing. PN: 72-9954-00-A.doc Page 11... - Page 12 3. In the page, under , click the WPA/WPA2-TKIP Settings Key Settings ASCII passphrase option to enter the ASCII passphrase. 4. A warning dialog box will appear while you are trying to enter the key. Click 5. Enter the ASCII passphrase. This will configure the WPA-TKIP (PSK) mode. Click 6.
- Page 13 To configure WPA2-CCMP as a security option, use the following commands. admin>network admin(network)>wlan admin(network.wlan)>set enc 1 ccmp admin(network.wlan)>set ccmp phrase 1 12345678 admin(network.wlan)>save Configuring WPA2-CCMP through the Web Interface 1. In the WS 2000 applet, double-click , and then click . The WLAN1 WLAN1 Security page will appear. WLAN1 Security 2.
- Page 14 3. In the dialog box, under , click the WPA2-CCMP Settings Key Settings ASCII passphrase option to enter the ASCII passphrase. 4. A warning dialog box will appear. Click 5. Enter the ASCII passphrase. Click 6. Click Apply PN: 72-9954-00-A.doc Page 14...
