  • Page 1 MULTIFUNCTION SYNTHESIZER WF1945B INSTRUCTION MANUAL NF Corporation...
  • Page 3 DA00012505-002 WF1945B MULTIFUNCTION SYNTHESIZER Instruction Manual...

  • Page 5: Foreword

    Foreword Thank you very much for procuring the WF1945B MULTIFUNCTION SYNTHESIZER. At the outset, please take a few minutes to read the Safety Precautions indicated in this manual in order to use this equipment safely and correctly. ● Warning and Caution notices The following Warning and Caution notices appear in this manual.

  • Page 6: Safety Precautions

    Do not use this equipment in the presence of flammable gas. There is danger of fire and explosion. ● Do not remove covers This equipment contains dangerously high voltages. Do not remove external covers. Refer all internal inspection and service to a qualified service technician who fully understands the hazards. WF1945B...
  • Page 7 Appears in the text and on the product to advise risk of damage to the product. Ground indication: Indicates connector housing and signal ground is connected to a chassis ground. Indicates power switch on state. Indicates power switch off state. WF1945B...

  • Page 9: Table Of Contents

    3.2 Input and output connectors···························································································· 3-5 Waveform output (FUNCTION OUT) ···································································· 3-5 Sync signal output (SYNC OUT)············································································ 3-6 Trigger/sweep input (TRIG/SWEEP IN)································································· 3-9 Sweep stop/restart input (SWEEP PAUSE IN) ······················································· 3-10 Sweep X-drive output (SWEEP X-DRIVE OUT) ··················································· 3-10 Contents 1 WF1945B...
  • Page 10 Sweep value and Z-MARKER/SYNC/X-DRIVE outputs ······································· 4-38 4.3 Modulation ····················································································································· 4-40 Frequency modulation (FM) ··················································································· 4-40 Amplitude modulation (AM)··················································································· 4-43 DC offset modulation (OFSM)················································································ 4-46 Phase modulation (PM)··························································································· 4-49 Pulse width modulation (PWM)·············································································· 4-52 4.4 Arbitrary Waveform········································································································ 4-55 Arbitrary waveform (ARB) ····················································································· 4-55 Contents 2 WF1945B...
  • Page 11 Output on/off at power on ······················································································· 5-19 LOAD function (equalize setting and output values) ·············································· 5-20 UNDO function······································································································· 5-21 Pulse generator function·························································································· 5-22 Phase sync··············································································································· 5-24 Section 6 Troubleshooting··················································································································· 6-1 6.1 Error message ················································································································· 6-2 Power on error ········································································································ 6-2 Operation error········································································································ 6-3 Contents 3 WF1945B...
  • Page 12 8.1 Waveform and output characteristics ·············································································· 8-2 8.2 Output voltage ················································································································ 8-4 8.3 Other functions ··············································································································· 8-5 8.4 Initialized settings··········································································································· 8-10 8.5 Remote control ··············································································································· 8-11 8.6 Options ··························································································································· 8-12 8.7 General items ·················································································································· 8-13 External drawing····································································································· 8-14 Index ······················································································································································ Index Contents 4 WF1945B...

  • Page 13: Section 1 Overview

    Section 1 Overview 1.1 Features ·····················································································································1-2 1.2 Operating principles···································································································1-3 Block diagram····································································································1-3 1.3 Function outline·········································································································1-4 Function tree ······································································································1-4 WF1945B...

  • Page 14: Features

    1.1 Features The WF1945B Wave Factory is a multifunctional synthesizer based on the direct digital synthesizer (DDS) system. The WF1945B is single channel, but the series also includes the 2-channel WF1946B, the single-channel WF1943B with basic functions, and the 2-channel WF1944B with basic functions.

  • Page 15: Operating Principles

    The lowpass filter (LPF) smoothes the stepped D/A output signal. Amplitude control is set by the gain control. DC offset is produced by the offset D/A converter and the output amplifier adds and amplifies the output signal. The attenuator (ATT) selects the output range by 1/10 attenuation on/off. WF1945B...

  • Page 16: Function Outline

    The amplitude can be set by the keypad or modify dial. • DC offset setting The DC offset can be set by the keypad or modify dial. • Phase setting Phase between channels and oscillation starting phase during burst oscillation can be set. WF1945B...
  • Page 17 The units can be expressed by up to 4 desired characters. • Setting store and recall The settings for frequency, amplitude, etc., can be stored and recalled. The WF1945B is capable of 10 combinations store/recall. • Computer control Remote control (GPIB or USB) enables external control from a personal computer.
  • Page 18 Linear, logarithmic Modulation Modulation type Frequency, amplitude, DC offset, phase, duty Modulation waveform Noise Waveform (50 % fixed duty), (variable duty), arbitrary waveform (ARB) Voltage Output range Gain setting DC offset setting High level setting Low level setting (continued) WF1945B...
  • Page 19 Output mode setting at power on Sync out, sweep period output Trigger, gate, sweep start input Sweep stop, restart input Sweep X-drive output Sweep marker output External add input External AM input 1991 synchronous operation option 1992A digital output option WF1945B...

  • Page 21: Section 2 Preparation

    2.1 Check before using ····································································································2-2 Safety check·······································································································2-2 Unpacking and repacking···················································································2-2 2.2 Power source and grounding······················································································2-4 Grounding··········································································································2-4 Line filter ···········································································································2-4 Power source······································································································2-4 Power supply fuse ······························································································2-6 2.3 Installation ·················································································································2-7 Cautions·············································································································2-7 Installation conditions ························································································2-7 Panel and case cleaning······················································································2-7 2.4 Conformable standards ······························································································2-8 2.5 Calibration ·················································································································2-9 WF1945B...

  • Page 22: Check Before Using

    2.1 Check before using Safety check Before using the WF1945B, refer to the Safety precautions of this manual and confirm safety. Also, before connecting the power, refer to Section 2.2 Power source and grounding and thoroughly check the safety. Unpacking and repacking First, inspect the equipment for possible damage in shipping.

  • Page 23: Check Before Using

    The required number of cables is one less than the total number of connected units. ■ 1992A digital output option If ordered, this option is installed at time of shipment. The following accessory cable is also provided. Supplied accessory Digital output cable (1 meter) ············································ 1 WF1945B...

  • Page 24: Power Source And Grounding

    For your safety, be sure to ground the device. Fuse To power switch Chassis Power source ! CAUTION Be sure to observe the following in order to prevent damage to the equipment. Confirm the power source voltage is within the range specified for the WF1945B. WF1945B...
  • Page 25 115V 230V Before using the WF1945B with a source voltage that differs from the factory setting, be sure to contact the sales representative of NF Corporation. Make sure that the power switch is off before connecting the power cable. Also, after switching power off, wait at least five seconds before switching the power on again.

  • Page 26: Power Supply Fuse

    There is risk of fire from an improperly rated fuse. Be sure to disconnect the power cable before replacing the fuse. Fuse: Time lag 1 A (100/115 V) or time lag 0.5 A (230 V) 250 V, φ5.2 × 20 mm The specified rating of a fuse changes depending on the power source voltage. WF1945B...

  • Page 27: Installation

    Near pulse type noise sources Also, when using, provide separation between the power cords and signal cables of the WF1945B and those of other equipment. Operating error can occur if the power cords and signal cables are too close. Cable routing requires particular attention when installing in a rack or other facility.

  • Page 28: Conformable Standards

    2.4 Conformable standards The WF1945B conforms to the following standards. Safety: EN 61010-1: 2001 EMC: EN 61326: 1997/A1: 1998/A2: 2001 However, the performance criteria for the following standards are as follows: EN61000-4-2(1995), EN61000-4-4(1995), EN61000-4-5(1995), and EN61000-4-11(1994):B The following cables are used for the test of EN 61326: 1997/A1: 1998/A2: 2001 •...

  • Page 29: Calibration

    2.5 Calibration Section 7.3 the Performance tests are recommended at least once a year. These should also be conducted before important tests and measurements. WF1945B...

  • Page 31: Section 3 Basic Operation

    Amplitude setting·······························································································3-24 DC offset setting ································································································3-25 Phase setting ······································································································3-26 Output on/off ·····································································································3-27 Operation tree ····································································································3-28 ・Following is an example of the display when using this section. Fully lighted (bold) Flashing ＰＲＥＳＥＴ ＳＹＳＴＥＭ：ＲＡＮＧＥ ＰＲＥＳＥＴ ＵＳＥＲ-ＵＮＩＴ Fully lighted (bold) Dimly lighted WF1945B...

  • Page 32: Panel Description

    3.1 Panel description This section describes the indications and functions of the front and rear panels of the WF1945B. WF1945B...

  • Page 33: Front Panel

    3.1 Panel description Front panel WF1945B...

  • Page 34: Rear Panel

    3.1 Panel description Rear panel WF1945B...

  • Page 35: Input And Output Connectors

    50 Ω input impedance or terminating the input at 50 Ω. ・Setting and output voltages The setting voltage display and actual output voltage (load terminal voltage) differ according to the load resistance. “5.4 Other settings (■LOAD function (equalize setting and output values))”, cf. WF1945B...

  • Page 36: Sync Signal Output (Sync Out)

    Although 50 Ω termination is possible, the high level voltage is reduced by about half. ・ Waveform and sync signal output relationship (Waveform phase definition) (1) Continuous oscillation mode (NORMAL) ① Sinewave WF1945B...
  • Page 37 FUNCTION OUT waveform when stop level is On or 100 kHz and below. ④ Squarewave (variable duty) (Phase definition) FUNCTION OUT Appendix. 14ns Jitter = 25ns p-p SYNC OUT Approximately 25 ns p-p jitter is also produced in the FUNCTION OUT waveform. WF1945B...
  • Page 38 High level when modulation waveform phase is above 0 and less than 180 degrees. Low level above 180 and below 360 degrees. FUNCTION OUT (Internal modulation waveform) SYNC OUT (5) Noise mode (NOISE) Digital (binary) noise source output. (6) DC mode (DC) Always high level. WF1945B...

  • Page 39: Trigger/Sweep Input (Trig/Sweep In)

    However, contact chatter from a mechanical switch or relay can prevent normal operation. Also, chattering will prevent normal operation when the oscillation mode is triggered gate. Avoid using a logic IC circuit having a power supply voltage higher than +5 V such as example (c) for the WF1945B input WF1945B...

  • Page 40: Sweep Stop/Restart Input (Sweep Pause In)

    0 to +5 V (open) Output impedance : Approx. 1 kΩ Recommended load : Above 10 kΩ Ground : Connected to chassis ground ! CAUTION Avoid shorting the output or applying an external signal. The unit can be damaged. 3-10 WF1945B...

  • Page 41: Sweep Marker Output (Sweep Z-Marker Out)

    50 Ω Input impedance : External add frequency : Up to 10 MHz Ground : Connected to signal ground (floating from chassis) ! CAUTION Do not apply a signal exceeding the above voltage. The unit can be damaged. 3-11 WF1945B...

  • Page 42: External Am Input (Ext Am In)

    25 ns (clock period) + 8 ns (phase sync pulse delay) = 33 ns. The WF1945B, WF1946B, WF1945A, WF1946A, WF1965, WF1966, WF1945 (1945), WF1946 (1946), and WF1956 (1956) equipped with the 1991 can be connected.
  • Page 43 (primary) side to the slave (secondary, tertiary) side. ・If possible, simultaneously switch off all products that are connected by the sync transfer cables. If simultaneous switch-off is not possible, switch off products in succession from the slave (secondary, tertiary) side to the master (primary) side. 3-13 WF1945B...

  • Page 44: Digital Output (Digital Out)

    Connect GND to all target signal grounds. Lease unused signal lines open. When the drain line is connected to the target signal ground, the WF1945B signal grounds (FUNCTION OUT, SYNC OUT, EXT ADD IN, EXT AM IN) are grounded to chassis.
  • Page 45 ・ Digital output is undefined when the oscillation mode is NOISE or DC. ・Except for the following cases, data corresponding to the waveform (FUNCTION) is output as digital output: (duty 50% fixed): Data corresponding to is output. (variable duty): Data to be output is undefined. 3-15 WF1945B...

  • Page 46: Basic Operation

    (lower PRESET flashes). ＰＲＥＳＥＴ ＳＹＳＴＥＭ：ＲＡＮＧＥ ＰＲＥＳＥＴ ＵＳＥＲ－ＵＮＩＴ 4 ENTER ② Press the key (upper PRESET flashes). ENTER ENTER ③ Again press the key to initialize. To return without initializing, before pressing EXIT press the key twice. 3-16 WF1945B...
  • Page 47 MODE → SWEEP, START TYPE=PHASE STOP 90 deg CENTER 0 deg SPAN 180 deg MARKER 0 deg MODE → SWEEP, START 40 % TYPE=DUTY STOP 60 % CENTER 50 % SPAN 20 % MARKER 50 % Continued next page 3-17 WF1945B...

  • Page 48: Basic Operation

    0.0005 s In case of FUNCTION= ENTRY→DUTY 50 % In case of FUNCTION= ENTRY→PERIOD 0.001 s ENTRY→HIGH 0.05 V −0.05 V ENTRY→LOW FUNCTION SYSTEM RANGE AUTO LOAD OPEN (50 ohms at SET) EXT-AM EXT-ADD DUTY-VALID IMMED SYNC-OUT STATE 3-18 WF1945B...

  • Page 49: Oscillation Mode Selection

    In this example, first set to DC, then to continuous (NORMAL). MODE ① Press the key, then the key to set the DC mode. The DC STATUS lamp lights. MODE NORMAL ② Press the key, then the key to set the NORMAL mode. The NORMAL STATUS lamp lights. 3-19 WF1945B...

  • Page 50: Waveform Selection

    When the pulse width is 100 ns or less, jitter becomes relatively larger compared with the pulse width, and a warning message is displayed. If the pulse width falls below 25 ns, pulses may disappear. If the pulse width falls below 100 ns, jitter becomes relatively larger compared with the pulse width. 3-20 WF1945B...
  • Page 51 Even though DUTY-VALID is set to CYCLE, extra pulses may be output if the frequency or phase is changed. Operation when DUTY-VALID: IMMED The setting will be reflected at the same time that the duty changes Operation when DUTY-VALID: CYCLE The setting will be reflected in the subsequent cycles Duty change 3-21 WF1945B...
  • Page 52 0.0100% to 99.9900%. The waveform cannot be selected in the following cases. ・ Oscillation mode is NOISE or DC. ・ TYPE is DUTY in SWEEP oscillation mode. ・ TYPE is PWM in MODU oscillation mode. 3-22 WF1945B...

  • Page 53: Frequency Setting

    (e.g., 50 Hz), press ENTER key directly after entering the frequency. “5.2 Units”, cf. ・ The frequency generating period can also be set. “5.1 Convenient Settings (■Frequency [Hz] setting by period [s])”, cf. 3-23 WF1945B...

  • Page 54: Amplitude Setting

    ・ Units other than Vp-p can also be set. “5.2 Units”, cf. ・ Can also be set by waveform high level and low level. “5.1 Convenient Settings (■Amplitude and DC offset setting by high and low level)”, cf. 3-24 WF1945B...

  • Page 55: Dc Offset Setting

    ④ After setting, press the key to release the setting mode. Other: ・ Can also be set by waveform high level and low level. “5.1 Convenient Settings (■Amplitude and DC offset setting by high and low level)”, cf. 3-25 WF1945B...

  • Page 56: Phase Setting

    ① Press the key, then the key. ② Select the digit to be changed with the keys. MODIFY ③ Turn the dial to set the flashing digit. EXIT ④ After setting, press the key to release the setting mode. 3-26 WF1945B...

  • Page 57: Output On/Off

    3.3 Basic operation Output on/off Output on/off setting is described. Operation: OUTPUT ① Press the key. The setting alternates between on and off each time the key is pressed. ON/OFF The lamp lights when on, extinguishes when off. 3-27 WF1945B...

  • Page 58: Operation Tree

    MARK (Number of cycles signal present) * For TYPE: BURST/TRIG SPACE (Number of cycles signal not present) * For TYPE: BURST STOP-LEVEL (Stop level) * When the same TYPE is set for both channels BURST Operation MAN TRIG 3-28 WF1945B...
  • Page 59 Menu (Internal modulation) TYPE (Modulation type) [FM/AM/OFSM/PM/PWM] DEVIATION * DEPTH for TYPE: AM FREQ (Modulation frequency) FUNCTION (Modulated waveform) [SIN/ MODU Operation START STOP ENTRY Main operation FREQ AMPTD OFFSET PHASE DUTY WIDTH PERIOD HIGH * DUTY/WIDTH for FUNCTION: 3-29 WF1945B...
  • Page 60 LOAD (LOAD function) EXT-AM (Selection of external AM) EXT-ADD (Selection of external addition) φ SYNC (Phase synchronization) DUTY-VALID (Duty) POWER-ON (Output state selection at power-on) REMOTE (Remote control menu) INTERFACE ADDRESS/ID (GPIB address/USB ID) DELIMITER (GPIB delimiter) OPTION (Option menu) 3-30 WF1945B...
  • Page 61 Setup memory menu STORE (Save setup memory) RECALL (Call setup memory) CLEAR (Clear setup memory) (Release remote state) LOCAL UNDO (Cancel setting) EXIT (Move to menu immediately above) ENTER (Accept input value) Numeric input (keypad) µ Numeric modification (Modify) MODIFY 3-31 WF1945B...

  • Page 63: Section 4 Applications

    4.6 Output waveforms for sweeping and modulation ·······················································4-63 4.7 Equivalent noise bandwidth ·······················································································4-65 ・Following is an example of the display when using this section. Fully lighted (bold) Dimly lighted ＢＵＲＳＴ ＴＲＩＧ ＧＡＴＥ 4 ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ Fully lighted Flashing Dimly lighted (bold) WF1945B...

  • Page 64: Burst Oscillation

    ③ Press the key, then produce the following display with the keys (BURST flashes). ＢＵＲＳＴ ＴＲＩＧ ＧＡＴＥ 4 ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ EXIT ④ This sets the burst oscillation type to burst. Press the key once to exit type setting. WF1945B...

  • Page 65: Burst Oscillation (Type: Burst)

    (0.5 cycles). In this example, the setting is 1.5 cycles. EXIT ④ After setting, press once to exit space cycle setting. (4) Set STOP-LEVEL ① Use the keys to produce the following display (STOP-LEVEL flashes). ＯＦＦ ＢＵＲＳＴ：ＴＹＰＥ ＭＡＲＫ ＳＰＡＣＥ ＳＴＯＰ―ＬＥＶＥＬ WF1945B...

  • Page 66: Burst Oscillation (Type: Trigger)

    Stop 1 wave Oscillation start Start phase: -90° • Burst oscillation setting items (BURST menu) TYPE: BURST MARK (oscillation cycle) [cycle] SPACE (cycle when oscillation stops) [cycle] STOP-LEVEL [OFF, ON[%]] PHASE (phase when oscillation starts) [deg] * ENTRY menu WF1945B...

  • Page 67: Burst Oscillation (Type: Trigger)

    ③ Press the key, then produce the following display with the keys (TRIG flashes). ＢＵＲＳＴ ＴＲＩＧ ＧＡＴＥ 4 ＴＲＩＧ：ＴＹＰＥ ＳＯＵＲＣＥ ＤＥＬＡＹ ＭＡＲＫ 4 EXIT ④ This sets the burst oscillation type to trigger. Press the key to exit type setting. WF1945B...

  • Page 68: Burst Oscillation (Type: Triggered Gate)

    ０．３μｓ ＴＲＩＧ：ＴＹＰＥ ＳＯＵＲＣＥ ＤＥＬＡＹ ＭＡＲＫ 4 ENTER ② Press the key. MODIFY ③ Set the delay time with the keypad or dial. For example, set to 1 ms. EXIT ④ After setting, press once to release delay time setting. WF1945B...
  • Page 69 In this example, the setting is -50 %. The stop level is the percentage with respect to the maximum positive (+100 %) and negative (-100 %) amplitude. EXIT ④ After setting, press the key to release the setting mode. WF1945B...
  • Page 70 • To generate the trigger signal via remote control (GPIB or USB), set the GET command or TRG command from the remote control interface. Also, set the trigger source to EXT “Remote Control Instruction Manual”, cf. For details of the remote control command, WF1945B...

  • Page 71: Burst Oscillation (Type: Gate)

    The example is a triangular waveform, DC offset 0 V, oscillation start phase 0 degrees, frequency and amplitude arbitrary. Oscillation stops at end of a half cycle, when gate signal is low level. WF1945B...
  • Page 72 (SOURCE flashes). ＥＸＴ Ｌ－ＯＮ ＧＡＴＥ：ＴＹＰＥ ＳＯＵＲＣＥ ＳＴＯＰ－ＬＥＶＥＬ ENTER ② Press the key. MODIFY ③ Press the key, then select positive logic (H-ON) with the dial. EXIT ④ After setting, press the key to release the setting mode. 4-10 WF1945B...
  • Page 73 (When stop level is off, the oscillation stops at either high or low level.) • Internal gate source : A 50 % duty gate signal is generated at the following period for oscillation start/stop. ＩＮＴ Ｈ－ＯＮ １．０００ｍｓ ＧＡＴＥ：ＴＹＰＥ ＳＯＵＲＣＥ ＳＴＯＰ－ＬＥＶＥＬ 4-11 WF1945B...
  • Page 74 “Remote Control Instruction Manual”, cf. • Burst oscillation (type: gate) setting items (BURST menu) TYPE: GATE SOURCE (trigger source) [EXT L-ON, EXT H-ON, INT [s] STOP-LEVEL [OFF, ON [%]] PHASE (phase when oscillation starts) [deg] * ENTRY menu 4-12 WF1945B...

  • Page 75: Burst Oscillation (Type: Triggered Gate)

    ③ Press key, then use the keys to produce the following display (T-GATE flashes). Ｔ－ＧＡＴＥ Ｔ－ＧＡＴＥ：ＴＹＰＥ ＳＯＵＲＣＥ ＳＴＯＰ―ＬＥＶＥＬ EXIT ④ This sets the burst oscillation type for triggered gate. Press the key once to release the type setting mode. 4-13 WF1945B...
  • Page 76 ⑤ After setting, press the key to release the setting mode. The above sets the burst oscillation (type: triggered gate). Oscillation alternates between start and stop each time a signal ( ) is applied to the TRIG/SWEEP IN connector. 4-14 WF1945B...
  • Page 77 “Remote Control Instruction Manual”, cf. For details of the remote control command, • Burst oscillation (type: triggered gate) setting items (BURST menu) TYPE: T-GATE SOURCE (trigger source) [ EXT , EXT STOP-LEVEL [OFF, ON[%]] PHASE (phase when oscillation starts) * ENTRY menu 4-15 WF1945B...

  • Page 78: Sweep

    ENTER ③ Press , then use the keys to produce the following display (SINGLE flashes). ＳＩＮＧＬＥ ＣＯＮＴ ＧＡＴＥＤ Ｆ－ＳＷＰ：ＴＹＰＥ ＳＯＵＲＣＥ ＭＯＤＥ EXIT ④ This sets the sweep mode for single. Press the key once to release mode select. 4-16 WF1945B...
  • Page 79 (FUNCTION flashes). ＬＩＮ Ｆ－ＳＷＰ： ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ ＳＴＯＰ 4 ENTER ② Press the key. MODIFY ③ Press the key, then select with the dial. EXIT ④ After selecting, press the key once to release the function select mode. 4-17 WF1945B...
  • Page 80 ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ ＳＴＯＰ ENTER ② Press key. MODIFY ③ Set the stop frequency with the keypad or dial. For example, set to 1000 Hz. EXIT ④ After setting, press the key once to release the stop frequency setting mode. 4-18 WF1945B...
  • Page 81 The output quickly changes to the start frequency, then sweeps to the stop frequency in 3 seconds (in this example). Oscillation then continues at the stop frequency. When the key is again pressed, sweep begins at the stop frequency and ends at the start START frequency. 4-19 WF1945B...
  • Page 82 During a sweep, the sweep restarts if a trigger is input. ＥＸＴ Ｆ－ＳＷＰ：ＴＹＰＥ ＳＯＵＲＣＥ ＭＯＤＥ 4 •External sweep pause : Supply a low level signal to the rear panel SWEEP PAUSE IN connector. Note that sweep restarts at high level or open input. 4-20 WF1945B...

  • Page 83: Sweep (Mode: Continuous)

    During sweep, multiple pulses may be produced within 1 period output as indicated in the figure. • To generate the trigger signal via remote control (GPIB or USB), set the TRG command from the remote control interface. For details of the remote control command, “Remote Control Instruction Manual”, cf. 4-21 WF1945B...

  • Page 84: Sweep (Mode: Continuous)

    (CONT flashes). ＳＩＮＧＬＥ ＣＯＮＴ ＧＡＴＥＤ Ｆ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ 4 EXIT ④ This completes setting the sweep mode to continuous. Press the key once to release the setting mode. 4-22 WF1945B...
  • Page 85 (FUNCTION flashes). ＬＩＮ Ａ－ＳＷＰ：ＴＹＰＥ ＭＯＤＥ ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ 4 ENTER ② Press the key. MODIFY ③ Press the key, then turn the dial to select EXIT ④ After selecting, press the key once to release the function select mode. 4-23 WF1945B...
  • Page 86 ＴＩＭＥ ＣＥＮＴＥＲ ＳＰＡＮ 4 ENTER ② Press the key. MODIFY ③ Set the stop amplitude with the key pad or dial. For example, set to 2Vp-p. EXIT ④ After setting, press the key once to release the stop setting mode. 4-24 WF1945B...
  • Page 87 : The function determines the sweep type. For example, provides step-type change of output (e.g., frequency) at the sweep time halfway point. LIN/LOG provides linear or logarithmic variation of the output with respect to the time axis. iSIN ( 4-25 WF1945B...

  • Page 88: Sweep (Mode: Gated)

    X- DRIVE outputs)", cf. • Sweep type set to duty : Output waveform fixed to squarewave (variable duty) and waveform (Function) cannot be selected. During sweep, multiple pulses may be produced within 1 period output as indicated in the figure. 4-26 WF1945B...

  • Page 89: Sweep (Mode: Gated)

    ③ Press the key, then use the keys to produce the following display (GATED flashes). ＳＩＮＧＬＥ ＣＯＮＴ ＧＡＴＥＤ Ｆ－ＳＷＰ：ＴＹＰＥ ＳＯＵＲＣＥ ＭＯＤＥ EXIT ④ This completes setting the sweep mode to gated. Press the key once to release the setting mode. 4-27 WF1945B...
  • Page 90 (FUNCTION flashes). ＬＩＮ Ｆ－ＳＷＰ： ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ ＳＴＯＰ 4 ENTER ② Press the key. MODIFY ③ Press the key, then select with the dial EXIT ④ After selecting, press the key once to release the function select mode. 4-28 WF1945B...
  • Page 91 3 ＦＵＮＣＴＩＯＮ ＳＴＡＲＴ ＳＴＯＰ ENTER ② Press the key. MODIFY ③ Set the frequency with the keypad or dial. For example, set to 200 Hz. EXIT ④ After setting, press the key once to release the stop frequency setting mode. 4-29 WF1945B...
  • Page 92 For example, set to 50 %. The stop level is a percentage with respect to the maximum positive and negative amplitudes taken respectively as +100 % and -100 %. EXIT ⑤ After setting, press the key to exit stop level setting. 4-30 WF1945B...
  • Page 93 4.2 Sweep (8) Start sweep ① Press the key. START In this example, sweep ends after 3 seconds and oscillation stops. Again press the key to START sweep from the stop to the start frequency. 4-31 WF1945B...
  • Page 94 : The function determines the sweep type. For example, provides step-type change of output (e.g., frequency) at the sweep time halfway point. LIN/LOG provides linear or logarithmic variation of the output with respect to the time axis. iSIN ( 4-32 WF1945B...
  • Page 95 / LOG / LOG , "SETTING CONFLICT 001" is displayed continuously during a short trigger cycle and the menu may not be displayed. In such cases, switch the trigger source, or stop input to the SWEEP PAUSE IN connector. 4-33 WF1945B...

  • Page 96: Center, Span, Marker, Mkr → Ctr

    START = CENTER − /+ (SPAN ÷ 2) STOP = CENTER +/− (SPAN ÷ 2) • A value that changes the SWEEP Z-MARKER OUT signal is set for MARKER. • MKR→CTR copies the marker value to the center value. 4-34 WF1945B...

  • Page 97: Summary Of The Sweep Setting Items

    STOP (sweep end/sweep start state) *For subsequent operation when the sweep has been completed, the state is reset to the sweep start state. PAUSE (sweep pause/restart) In the SWEEP menu • START-STATE (sweep start state) STOP-STATE (sweep stop state) 4-35 WF1945B...

  • Page 98: Sweep (Modulation) Steps And Step Width

    ② Sweep time is more than 50 to 62.5 ms and below: Step number = 250 (fixed) ③ Sweep time is more than 62.5 ms: Step number = Sweep time [s] × 8000 *1: If raising up results in odd number, -1. 4-36 WF1945B...
  • Page 99 During logarithmic sweep, step width = log [log start Step width during log sweep changes with step progression. The marker output is synchronized with the sweep step output. The difference between marker setting and actual output is ± step width. 4-37 WF1945B...

  • Page 100: Sweep Value And Z-Marker/Sync/X-Drive Outputs

    4.2 Sweep Sweep value and Z-MARKER/SYNC/X-DRIVE outputs ◆ is approx. 100 to 125 µ s 4-38 WF1945B...
  • Page 101 4.2 Sweep 4-39 WF1945B...

  • Page 102: Modulation

    (FM flashes). ＦＭ ＡＭ ＯＦＳＭ ＰＭ ＰＷＭ ＦＭ：ＴＹＰＥ ＤＥＶＩＡＴＩＯＮ ＦＲＥＱ ＦＵＮＣＴＩＯＮ EXIT ④ This sets the modulation type for frequency. Press the key once to release the type setting mode. 4-40 WF1945B...
  • Page 103 For example, set to 50 Hz (20 ms). EXIT ④ After setting, press the key once to release the modulation setting mode. (4) Select the modulation waveform (FUNCTION) ① Use the keys to produce the following display (FUNCTION flashes). ＳＩＮ ＦＭ：ＴＹＰＥ ＤＥＶＩＡＴＩＯＮ ＦＲＥＱ ＦＵＮＣＴＩＯＮ 4-41 WF1945B...
  • Page 104 To stop modulation: Press the key. Resume modulation by pressing the key. STOP START • Setting items at frequency modulation (MODU menu) TYPE: FM DEVIATION (frequency deviation) [Hz] FREQ (modulation frequency) [Hz] FUNCTION (modulation waveform) [SIN, 4-42 WF1945B...

  • Page 105: Amplitude Modulation (Am)

    (AM flashes). ＦＭ ＡＭ ＯＦＳＭ ＰＭ ＰＷＭ ＦＭ：ＴＹＰＥ ＤＥＰＴＨ ＦＲＥＱ ＦＵＮＣＴＩＯＮ EXIT ④ This sets the modulation type for amplitude. Press the key once to release the type setting mode. 4-43 WF1945B...
  • Page 106 ② Press the key. MODIFY ③ Use the keypad or dial to set the modulation frequency. For example, set to 200 Hz (5ms). EXIT ④ After setting, press the key once to release the modulation frequency setting mode. 4-44 WF1945B...
  • Page 107 • At 0 % depth, the output amplitude is 1/2 the setting. At 100 % depth, the output amplitude is the same as the setting. • Setting items at amplitude modulation (MODU menu) TYPE: AM DEPTH (modulation depth) [%] FREQ (modulation frequency) [Hz] FUNCTION (modulation waveform) [SIN, 4-45 WF1945B...

  • Page 108: Dc Offset Modulation (Ofsm)

    (OFSM flashes). ＦＭ ＡＭ ＯＦＳＭ ＰＭ ＰＷＭ ＯＦＳＭ：ＴＹＰＥ ＤＥＶＩＡＴＩＯＮ ＦＲＥＱ 4 EXIT ④ This sets the modulation type for DC offset. Press the key once to release the type setting mode. 4-46 WF1945B...
  • Page 109 ENTER ② Press the key. MODIFY ③ Set the frequency with the keypad or dial. For example, set to 250 Hz (4 ms). EXIT ④ After setting, press the key once to release the modulation frequency setting mode. 4-47 WF1945B...
  • Page 110 To stop modulation : Press the key. Resume modulation by pressing the key. STOP START • Setting items at DC offset deviation (MODU menu) TYPE: OFSM DEVIATION (dc offset deviation) [V] FREQ (modulation frequency) [Hz] FUNCTION (modulation waveform) [SIN, 4-48 WF1945B...

  • Page 111: Phase Modulation (Pm)

    (PM flashes). ＦＭ ＡＭ ＯＦＳＭ ＰＭ ＰＷＭ ＰＭ：ＴＹＰＥ ＤＥＶＩＡＴＩＯＮ ＦＲＥＱ ＦＵＮＣＴＩＯＮ EXIT ④ This sets the modulation type for phase. Press the key once to release the type setting mode. 4-49 WF1945B...
  • Page 112 ENTER ② Press the key. MODIFY ③ Set the frequency with the keypad or dial. For example, set to 200 Hz (5 ms). EXIT ④ After setting, press the key once to release the modulation frequency setting mode. 4-50 WF1945B...
  • Page 113 To stop modulation : Press the key. Resume modulation by pressing the key. STOP START • Setting items at phase modulation (MODU menu) TYPE: PM DEVIATION (phase deviation) [deg] FREQ (modulation frequency) [Hz] FUNCTION (modulation waveform) [SIN, 4-51 WF1945B...

  • Page 114: Pulse Width Modulation (Pwm)

    ＤＥＶＩＡＴＩＯＮ ＦＲＥＱ ＦＵＮＣＴＩＯＮ EXIT ④ This sets the modulation type for pulse width. Press the key once to release the type setting mode. The waveform is automatically set to squarewave (variable duty) during PWM. The waveform (FUNCTION) cannot be selected. 4-52 WF1945B...
  • Page 115 ＦＵＮＣＴＩＯＮ ENTER ② Press the key. MODIFY Set the frequency with the keypad or dial. For example, set to 50 Hz (20 ms). EXIT ③ After setting, press the key once to release the modulation frequency setting mode. 4-53 WF1945B...
  • Page 116 • During sweep, multiple pulses may be produced within 1 period output as indicated in the figure. • Setting items at pulse width modulation (MODU menu) TYPE: PWM DEVIATION (pulse width deviation) [%] FREQ (modulation frequency) [Hz] FUNCTION (modulation waveform) [SIN, 4-54 WF1945B...

  • Page 117: Arbitrary Waveform

    (1:ARB_01 flashes). ０：ＡＲＢ＿００ １：ＡＲＢ＿０１ ＡＲＢ：ＳＥＬＥＣＴ ＮＡＭＥ ＥＤＩＴ ＣＯＰＹ 4 EXIT ③ This completes the selection of an arbitrary waveform (No. 1 is selected here). Press the key one time to release the arbitrary waveform selection mode. 4-55 WF1945B...
  • Page 118 (COPY flashes). ＳＩＮ ＡＲＢ：ＳＥＬＥＣＴ ＮＡＭＥ ＥＤＩＴ ＣＯＰＹ ENTER ② Press key, then use the keys to produce the following display (SIN flashes). ＳＩＮ ＡＲＢ：ＳＥＬＥＣＴ ＮＡＭＥ ＥＤＩＴ ＣＯＰＹ ENTER ③ Press key to copy the sinewave. 4-56 WF1945B...
  • Page 119 * is interpolation type mark and indicates the linear interpolation type address. The mark appears and extinguishes each time the key is pressed. ⑤ Next, use above steps ③ and ④ to set the interpolation mark (*) to waveform address 3072. 4-57 WF1945B...
  • Page 120 1024 and 3072. ⑧ In the same manner as above steps ① to ⑥, clip the first half of a sinewave (set interpolation marks at 5120 and 7168). The above completes arbitrary waveform setting. 4-58 WF1945B...
  • Page 121 The output waveform changes as described below when the waveform data size is changed. If, for example, the waveform data size is changed from 16 KB to 8 KB when there is a waveform like for waveform number 0, is assigned to waveform number 0 and to waveform number 1. 4-59 WF1945B...
  • Page 122 For other cases, high level while between 0 and 180 degrees of the waveform in the oscillation period, and low level while between 180 and 360 degrees. Oscillating Stopped FUNCTION OUT SYNC OUT SYNC OUT: STATE SYNC OUT SYNC OUT: PHASE 4-60 WF1945B...
  • Page 123 (variable duty), the same waveform as that for FUNCTION OUT. Otherwise, high level while between 0 and 180 degrees of the modulated waves, and low level while between 180 and 360 degrees. Modulation execution FUNCTION OUT SYNC OUT SYNC OUT: STATE SYNC OUT SYNC OUT: PHASE 4-61 WF1945B...
  • Page 124 + 90 degrees shifts the output level to the high level while oscillation is stopped. SYNC OUT The shaded sections represent an undefined output level. Approximately ±2 degrees Phase 0° 180° 360° (=0°) (ideal value) 4-62 WF1945B...
  • Page 125 , but also by , and Since the phase changes at intervals of 100 to 252 µs, discontinuities are generated The phase is swept Waveform when swept Update interval 100 to 252 µs Waveform when not swept 4-63 WF1945B...
  • Page 126 360 × oscillation frequency [Hz] × sweep time [s] If, for example, the frequency is 1 kHz, the phase span is 90 degrees, and the sweep time is 100 ms, an extra pulse is generated every 400 cycles on average. 4-64 WF1945B...
  • Page 127 4.7 Equivalent noise bandwidth The density of noise generated by the WF1945B is as shown in the following figure (a) "Frequency characteristics of noise generated by the WF1945B." The effective values (rms) of (a) are equal to those of white noise in the figure (b) "Frequency characteristics of white noise,"...
  • Page 129 UNDO function··································································································5-21 Pulse generator function·····················································································5-22 Phase sync··········································································································5-24 ・Following is a typical example of the display panel indications used in this Section. Fully lighted(bold) Dimly lighted ＦＲＥＱ ＰＥＲＩＯＤ ＡＭＰＴＤ 4 ＵＳＥＲ ＵＮＩＴ：ＴＹＰＥ ＮＡＭＥ ＦＯＲＭＵＬＡ 4 Fully lighted(bold) Flashing Dimly lighted WF1945B...

  • Page 130: Convenient Settings

    Thus, the setting tolerance is large when the frequency setting digits are fewer (period longer). MODIFY In this situation, even if setting is changed by the keypad or dial, the actual oscillation period does not change in some cases. WF1945B...

  • Page 131: Squarewave Duty Setting

    • The actual waveform duty resolution is [oscillation frequency] [approx. 40 MHz] (0.00001 % at minimum). When the stop level is on, the minimum actual waveform duty resolution is approximately 0.003 %. • For other notes, see "■Waveform selection " in Section 3.3, "Basic operation." WF1945B...

  • Page 132: Squarewave Pulse Width Setting

    • Due to the oscillation period and duty relationship, the pulse can be lost when the actual pulse width is less than 25 ns. An error message is displayed at this type of setting. Also, jitter increases when the pulse width is less than 100 ns. A warning message is displayed at this type of setting. WF1945B...

  • Page 133: Amplitude And Dc Offset Setting By High And Low Level

    For example, set to +5 V. EXIT ③ Press the key, then the key to produce the following display. ＬＯＷ －０．０５００ Ｖ １０００．０００００００Ｈｚ Ｈ＋５．００００Ｖ ／ＯＰＥＮ MODIFY ④ Set the Low level with the keypad or dial. For example, set to +0 V. WF1945B...
  • Page 134 AM, when the output voltage exceeds the following values, the Over lamp flashes and the output is clipped in some cases. 10 V range: Approx. 11 V peak/open time 1 V range: Approx. 1.1 V peak/open time WF1945B...

  • Page 135: Units

    ② Press the key to change the display as follows. １．０００００００００００ｋＨｚ Ａ０．１０００Ｖｐ－ｐ Ｏ＋０．００００Ｖ ／ＯＰＥＮ Other: • Unit change enable: Only when the key is lighted. µ ENTER • Initializing units (e.g., from kHz to Hz): At above step②, press the key. WF1945B...

  • Page 136: Amplitude Units Change

    Notes: Only Vp-p and USER can be selected when the oscillation mode is NOISE. Only Vp-p and USER can be selected when the selected waveform is ARB. • Even if the amplitude units are changed, the actual output voltage does not change. WF1945B...

  • Page 137: User-Unit Setting

    (FREQ flashes). ＦＲＥＱ ＰＥＲＩＯＤ ＡＭＰＴＤ 4 ＵＳＥＲ ＵＮＩＴ：ＴＹＰＥ ＮＡＭＥ ＦＯＲＭＵＬＡ 4 EXIT ④ This selects the setting type to frequency. Press the key once to release the type select mode. WF1945B...
  • Page 138 ② Press the key, then use the keys to produce the following display [(h+n)*m flash]. （ｈ＋ｎ）＊ｍ （Ｌｏｇ（ｈ）＋ｎ）＊ｍ ＵＳＥＲ ＵＮＩＴ：ＴＹＰＥ ＮＡＭＥ ＦＯＲＭＵＬＡ EXIT ③ This sets the formula to (h+n)*m. Press the key once to release the formula setting mode. 5-10 WF1945B...
  • Page 139 ① Press the key, then the key. ② Press the key to produce the following display (Hz flashes). １０００．００００００００ Ｈｚ Ａ０．１０００Ｖｐ－ｐ Ｏ＋０．００００Ｖ ／ＯＰＥＮ MODIFY ③ Turn the dial to produce the following display. ６００００．０００００００ ｒｐｍ Ａ０．１０００Ｖｐ－ｐ Ｏ＋０．００００Ｖ ／ＯＰＥＮ 5-11 WF1945B...
  • Page 140 Since the logarithm of a negative value cannot be a real number, "OVER" is displayed. Thereafter, user setup values can be arbitrarily changed. However, the DC offset and phase cannot be converted to a negative value while user units are being used. 5-12 WF1945B...

  • Page 141: Setting Memory

    EXIT The above completes memory storage. Press the key to release the storage mode. Other: • By pressing the keypad at above step ②, name input is omitted and storage is at the memory of the depressed number. 5-13 WF1945B...

  • Page 142: Setting Recall

    • Items stored in the setting memory and user unit settings are noted in Section [3.3 Basic operation, Setting initialize]. The following items do not change before and after recall. • Output on/off • Output on/off state at power on • Arbitrary waveform parameter • Type of remote control • GPIB parameter • USB ID 5-14 WF1945B...

  • Page 143: Setting Memory Clear

    １ ２ ３ ４ ５ ６ ７ ８ ９ ENTER ③ Press key to clear the memory recall. Other: • At above step ②, pressing the keypad clears the corresponding memory number. Only the stored numbers of the keypad light. 5-15 WF1945B...

  • Page 144: External Input

    External add (EXT-ADD) ( : EXT-ADD) Operation is described for adding an external signal to the WF1945B output. The external signal is connected to the rear panel EXT ADD IN connector. Refer to External add input (EXT ADD IN) on page 28.

  • Page 145: External Am (Ext

    External AM (EXT-AM) ( : EXT-AM) Operation to modulate the WF1945B output with an external AM signal is described. The external signal is applied to the rear panel EXT AM IN connector. For details on connectors, “3.2 Input and output connectors ( External add input (EXT ADD IN)”, cf.

  • Page 146: Other Settings

    • If the output range is set as 1 V when the amplitude setting is larger than 2 Vp-p (open), the amplitude is automatically changed to 1/10 since voltage exceeding 2 Vp-p (open) cannot be output in the 1 V range. 5-18 WF1945B...

  • Page 147: Output On/Off At Power

    (POWER-ON flashes). ＬＡＳＴ－ＳＴＡＴＥ ＯＦＦ ＯＮ ＳＹＳＴＥＭ： 3 ＳＹＮＣＯＵＴ ＰＯＷＥＲ－ＯＮ ENTER ② Press the key, then use the keys to produce the following display (OFF flashes). ＬＡＳＴ－ＳＴＡＴＥ ＯＦＦ ＯＮ ＳＹＳＴＥＭ： 3 ＳＹＮＣＯＵＴ ＰＯＷＥＲ－ＯＮ 5-19 WF1945B...

  • Page 148: Load Function (Equalize Setting And Output Values)

    100 Ω. ③ Press the key, then turn the The above setting calculates the actual voltage of FUNCTION OUT connector from the WF1945B output impedance (50 Ω) and the load impedance for automatically changing the indicated value. Other: •...

  • Page 149: Undo Function

    (ineffective when UNDO is extinguished). Other: • Undo enabled: Directly after changing frequency, amplitude, etc., with the keypad or MODIFY dial. MEMORY UNDO Directly after setting recall ( → RECALL). Press the key to return the state prior to recall. 5-21 WF1945B...

  • Page 150: Pulse Generator Function

    5.5 Other settings Pulse generator function Operation of the WF1945B as a pulse generator is described. Operation: (1) Set for continuous pulse output Period: 2 ms Pulse width: 0.2 ms FUNCTION ① Set the waveform to squarewave (variable duty), ( →...
  • Page 151 • Double pulse output: At above step ④, set MARK = 2.0 cycles. • Manual trigger: At above step ④, set SOURCE = EXT and press the key. MAN TRIG (Do not connect anything to the TRIG/SWEEP IN connector.) 5-23 WF1945B...

  • Page 152: Phase Sync

    • φ sync is effective in Normal oscillation mode. In other modes, the phase may shift 180 degrees and the values of the mark cycle and space cycle settings may change. • The phase between outputs of units (channels) in synchronous operation is the difference between the phase settings (PHASE) set for each unit (channel). 5-24 WF1945B...
  • Page 153 Section 6 Troubleshooting 6.1 Error message ············································································································6-2 Power on error ···································································································6-2 Operation error···································································································6-3 6.2 Suspected failure········································································································6-5 In case of abnormality························································································6-5 WF1945B...

  • Page 154: Error Message

    Calibration data Contact dealer. Although possible to start destroyed. by pressing the ENTER key, accuracy cannot be guaranteed. SYSTEM TEST FAILED 001 Internal ROM sum Contact dealer. check error. SYSTEM TEST FAILED 002 Internal RAM Contact dealer. read/write error. WF1945B...

  • Page 155: Operation Error

    Combined period and pulse width exceed the permissible duty setting range. Since the mode is SWEEP or MODU for (variable duty), SETTINGS CONFLICT 010 DUTY VALID cannot be set. STORE/RECALL MEMORY Setting storage memory contents destroyed and settings cannot be LOST recalled. Contact dealer. continued next page WF1945B...
  • Page 156 WARNING 015 Because of DUTY VALID change, the duty was changed to 0.01% or 99.99%. WARNING 016 Because of a mode change, DUTY VALID was changed to IMMED. WF1945B...

  • Page 157: Suspected Failure

    Set the address and USB ID so that they do not to that of another device match those of other devices. Does not operate Settings have been initialized The instruction manual presumes the settings have (PRESET). been initialized. according to instruction manual WF1945B...
  • Page 159 Preparatory checks ·····························································································7-3 Function checks ·································································································7-3 7.3 Performance tests·······································································································7-5 Performance tests ·······························································································7-5 Preparatory checks ·····························································································7-5 Test preparation ·································································································7-5 Frequency accuracy ···························································································7-5 Amplitude accuracy ···························································································7-6 DC offset accuracy·····························································································7-6 Amplitude vs. frequency characteristics·····························································7-7 Sinewave distortion····························································································7-7 Squarewave response ·························································································7-8 Duty factor ·········································································································7-8 WF1945B...

  • Page 160: Outline

    AC voltmeter 2 True rms, accuracy better than 1 %, bandwidth at least 20MHz, recommended: Boonton Model 9200C+952016+952002 Distortion meter Full scale 0.1 %, frequency up to 100 kHz 50 Ω feed through terminator 50 Ω 20 dB attenuator WF1945B...

  • Page 161: Operation Checks

    ・Frequency ( → ENTRY AMPTD ・Amplitude ( → ENTRY OFFSET ・DC offset ( → FUNCTION ・Waveform ( Duty fixed 50 %， → ， ， ， FUNCTION ENTRY DUTY ・Duty ( Variable duty， → → OUTPUT ・Output on/off ( ON/OFF WF1945B...
  • Page 162 Conduct some of the main function checks via GPIB/USB and confirm the same output variations. Also note that the remote (REM) indicator lights. Press the LOCAL key and confirm the remote indicator extinguishes and the local mode is returned (not local lock out). WF1945B...

  • Page 163: Performance Tests

    Normal if within ±5 ppm (999.995 to 1.000005 MHz) (when shipped) Judgment: However, since aging may occur with up to ±3 ppm/year, deterioration up to ±8 ppm (999.992 to 1.000008 MHz) may have occurred if one year has passed since shipment. WF1945B...

  • Page 164: Amplitude Accuracy

    ±4.905 to ±5.095 V 10 V ±2.000 V/open ±1.920 to ±2.080 V 10 V ±1.000 V/open ±0.925 to ±1.075 V 10 V −0.070 to +0.070 V 10 V 0.000 V/open ±1.0000 V/open ±0.985 to ±1.015 V −0.010 to +0.010 V 0.0000 V/open WF1945B...

  • Page 165: Amplitude Vs. Frequency Characteristics

    Initialize, then set the amplitude to 20 Vp-p/open and the frequency as indicated in the table. Measurement: Measure the distortion Judgment: The normal range is indicated in the table. Frequency Normal range (Bandwidth 500 kHz) 10 Hz to 100 kHz 0.2 % or less WF1945B...

  • Page 166: Squarewave Response

    Rated range (duty 50 % fixed) 1 MHz 490 to 510 ns (duty 50 % fixed) 10 MHz 47.0 to 53.0 ns (duty 50 % fixed) 15 MHz 30.0 to 36.7 ns (duty variable) 100 kHz 4.90 to 5.10µ s WF1945B...
  • Page 167 8.1 Waveform and output characteristics ·········································································8-2 8.2 Output voltage ···········································································································8-4 8.3 Other functions ··········································································································8-5 8.4 Initialized settings······································································································8-10 8.5 Remote control ··········································································································8-11 8.6 Options ······················································································································8-12 8.7 General items ·············································································································8-13 External drawing································································································8-14 Guaranteed values are shown with tolerance, values without tolerance are for reference. WF1945B...
  • Page 168 Point specification and linear interpolation by the panel operation origination or data writing by GPIB or USB Arbitrary waveform data 16 bits (-32768 to 0 to +32767) resolution The 1992A digital output option outputs all 15 bits and clock. WF1945B...
  • Page 169 Up to 1 MHz: ±1 % of the period 1 MHz to 10 MHz: ±3 % of the period 10 MHz to 15 MHz: ±5 % of the period (duty variable) Up to 100 kHz: ±1 % of the period Jitter: 30 nsp-p and below WF1945B...

  • Page 170: Output Voltage

    Output voltage can be set with high and low level buttons. SYNC OUT Output voltage (SYNC OUT) Output voltage 0/+5V (open) Output waveform Rise/fall time 2.5 ns 50 Ω, unbalanced Output impedance 45 Ω and more Load impedance Output connector Front panel BNC receptacle (SYNC OUT) WF1945B...

  • Page 171: Other Functions

    Trigger jitter Less than 50 ns Oscillation stop level On and off settable Off: stops at set phase. On: stops at set stop level. −100.0 % (maximum negative output) to +100.0 % (maximum Range positive output), Resolution 0.01 % WF1945B...
  • Page 172 On/off setting effective during gated sweep. (However, ineffective and fixed at off if the sweep item is duty) Off: stop at set phase. On: stop at set stop level. −100.00 %（maximum negative output) to +100.00 % (maximum Range positive output) Resolution 0.01 % WF1945B...
  • Page 173 0 V to +5 V/open Signal characteristics 0 V→+5 V: sweep value is increasing, +5 V→+0 V: sweep value is decreasing. Output impedance 1 kΩ, unbalanced Load impedance 10 kΩ and more Output connector Rear panel, BNC receptacle (SWEEP X-DRIVE OUT) WF1945B...
  • Page 174 1 V range: × 0.2 ±5 V Input voltage range 50 Ω Input impedance Input connector Rear panel BNC receptacle (EXT ADD IN) Setting initialization Functions Initializes nearly all setting contents. Initialization settings, “3.3 Basic operation (Initialization table) ”, WF1945B...
  • Page 175 Battery back up for nearly all settings prior to power off. Backup period Three years and more under normal temperature. Battery Lithium cell Operation when battery depleted Error at power on and settings are initialized. Setting memory and arbitrary waveform memory are initialized. Battery needs replacement (fee charged) WF1945B...

  • Page 176: Initialized Settings

    User unit computation formula (h+n)*m User unit coefficient User unit offset Arbitrary waveform selection ARB_00 Arbitrary waveform name ARB_00 ~ ARB_11 Arbitrary waveform data size Arbitrary waveform data All 0 Remote control interface GPIB GPIB address GPIB delimiter CR+LF USB ID 8-10 WF1945B...

  • Page 177: Remote Control

    GPIB parameters GPIB address (0 to 30), delimiter in transmission (CR/LF+EOI, CR+EOI, LF+EOI) Remote release Remote condition can be canceled by LOCAL key. (Except for Local Lockout) Connector Rear panel, IEEE 488 (24-pins) connector USB interface USB1.1 full speed 8-11 WF1945B...

  • Page 178: Options

    4001H 0、+1 4000H -2、-1 3FFFH -4、-3 3FFEH -32764、-32763 -16382 0002H -32766、-32765 -16383 0001H -32768、-32767 -16384 0000H Accessory Digital output cable: One *1: The following products: 1945, 1946, 1956, WF1945, WF1946, WF1956, WF1945A, WF1946A, WF1965, WF1966, WF1945B, and WF1946B 8-12 WF1945B...

  • Page 179: General Items

    216(W) × 132.5(H) × 290(D) mm (Excluding protrusions). Mass Mainframe excluding attachments, options, etc. Approx. 4.3 kg Safety EN 61010-1: 2001 EN 61326: 1997/A1: 1998/A2: 2001 However, the performance criteria for the following standards are as follows: EN61000-4-2(1995), EN61000-4-4(1995), EN61000-4-5(1995), and EN61000-4-11(1994):B 8-13 WF1945B...

  • Page 180: External Drawing

    General items External drawing 8-14 WF1945B...
  • Page 181 4-57, 5-7 TRIG/SWEEP IN ·················· 3-9, 4-8, 4-11, 4-14, M ····································································· 5-7 4-20, 4-32, 5-23 MAN TRIG ··························4-8, 4-12, 4-15, 5-23 UNDO ··························································· 5-21 MEMORY ····················································· 5-13 WIDTH ···················································· 5-3, 5-4 φ-SYNC IN,OUT·································· 3-12, 5-24 µ ······································································ 5-7 Index 1 WF1945B...
  • Page 183 All NF products are warranted against defects in materials and workmanship for a period of one year from the date of shipment. During the warranty period of, NF will, at its option, either will repair the defective product without any charge for the parts and labor, or either repair or replace products which prove to be defective.
  • Page 185 • We assume no responsibility for influences resulting from the operations in this manual. Copyright 2005, NF Corporation WF1945B MULTIFUNCTION SYNTHESIZER Instruction Manual NF Corporation 3-20 Tsunashima Higashi 6-chome, Kohoku-ku. Yokohama-shi...
  • Page 188 NF Corporation 6-3-20, Tsunashima-higashi, Kohoku-ku,Yokohama 223-8508 JAPAN...

Table of Contents
