Related Manuals for lavatools javelin pro duo
Summary of Contents for lavatools javelin pro duo
- Page 1 j av e li n D U O P R O Q U A L I T Y T H E R M O M E T E R S C A L I F O R N I A U S A...
- Page 2 YO U R JAVE LI N P RO...
- Page 3 TOUCH PAD PROBE for backlight & functions 18/8 stainless steel MAGNET FOOD SAFE convenient storage antimicrobial coating LANYARD HOLE 2-INCH DISPLAY simple portability antifog & ambidextrous...
- Page 4 STA B ILIZATI O N AL ERT Insert the probe into your food and hold the icon. The word HOLD will blink and after several seconds, a “beep” will sound to indicate the stabilized temperature. Reading is held as long as you are holding icon.
- Page 5 M AX / MI N Double tap the icon to display the maximum temperature for current session. Tap again for the minimum temperature. To exit, tap again. Hold the icon during MAX/MIN to clear values.
- Page 6 A M BIDEX TR OU S D I SPLAY Built in motion sensors detect when the device is upside-down and rotates the display accordingly. A simple solution for awkward angles and left-handers alike.
- Page 7 C HANGING T H E B AT T E RY When the display shows “LO” and the icon, it’s time to switch out your battery. Fully retract the probe and twist open the battery door with a coin. Carefully remove existing battery and insert a new CR2032 with the positive (+) pole up.
- Page 8 A D D IT I O N AL INFO RM AT I ON Sleep Mode If left on and idle for more than 60 minutes, the Javelin PRO will automatically go to sleep. Simply tap the touch pad or move the device to wake.
- Page 9 Magnetic Backing The Javelin PRO has a built-in magnetic backing to allow for convenient storage. Magnetic backing may not work on stainless steel surfaces. Antimicrobial Coating Silver-based antimicrobial additive is impregnated into the plastic shell to inhibit pathogen growth. E cacy is rated at 99% or greater. Tapered Sensor Tip The ultra-sensitive thermistor sensor is located at the tip of the probe, requiring a minimum insertion distance of 0.25”...
- Page 10 PE R SO N ALIZAT I ON Toggle various functions on your Javelin PRO using switches found inside the battery bay. You must restart the device to have these changes apply. toggle toggle toggle toggle C°/ F° auto sleep stabilization alert tenth degree...
- Page 11 ACC U R ACY T EST To check the accuracy of your Javelin PRO, we recommend using an ice bath test. Fully pack a large cup with crushed ice and fill up to 3/4 with purified water. Let the slurry sit for a brief moment, then give it a quick stir to allow the temperature to equalize throughout.
- Page 12 T R O UB L ES H OOT I NG WON’T DISPLAYING CHANGE SWITCH ON ACCURATE LO BATT C°/ F° retract and extend Test accuracy in battery is running use switch 1 to probe or change crushed ice bath low, change switch between battery or contact...
- Page 13 RESTORE “HOLD” DEVICE FACTORY DON’T HEAR DOESN’T ASLEEP SETTINGS “BEEP” BLINK tap on touch pad turn o device make sure to hold use switch 3 to or move device to and position all the touch pad activate wake personalization long enough stabilization alert (see page 10) switches...
- Page 14 U S E & M AI NT E NANC E • Always measure at the center of the meat, avoid hitting bone or hard cartilage. • Prevent build up of grime; always clean the body with soft damp cloth. • Do not clean with solvents or scouring agents. •...
- Page 15 Damage resulting from normal wear and tear, water entry, abuse, misuse, accidental breakage, negligence, defects caused by modifications, repair and servicing not made or authorized by Lavatools will void all warranty. Lavatools reserves the right to make the final judgment on all claims.
- Page 16 LAVATOOLS.CO come visit us for more info Lavatools, Javelin, and Javelin PRO are registered trademarks of Lavatools, LLC., v1.2 registered in the U.S. and other countries. 692-7884-K...
