Portwell FUDA2-S1x11 Series User Manual

Slim and fan-free 5-wire resistive touch panel pc powered by intel atom bay trail quad-core processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FUDA2-S1x11 Series Panel PC
(10.4"/12.1"/15"/17"/19")
Slim and Fan-free 5-wire Resistive Touch Panel PC
Powered by Intel® Atom™ Bay Trail Quad-core Processor
User's Manual
Version 1.1
Copyright © Portwell, Inc., 2015. All rights reserved.
All other brand names are registered trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUDA2-S1x11 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Portwell FUDA2-S1x11 Series

Summary of Contents for Portwell FUDA2-S1x11 Series

  • Page 1 (10.4”/12.1”/15”/17”/19”) Slim and Fan-free 5-wire Resistive Touch Panel PC Powered by Intel® Atom™ Bay Trail Quad-core Processor User's Manual Version 1.1 Copyright © Portwell, Inc., 2015. All rights reserved. All other brand names are registered trademarks of their respective owners.

  • Page 2: Table Of Contents

    Preface Table of Contents How to Use This Manual Chapter 1 System Overview ....................... 1-1 1.1 Introduction ....................... 1-1 1.2 Check List ......................1-2 1.3 Product Specification ..................1-3 1.4 Mechanical Dimension ..................1-4 Chapter 2 System Installation ....................2-1 2.1 Embedded Board H/W Jumper Setting Introduction .........

  • Page 3: How To Use This Manual

    Preface How to Use This Manual The manual describes how to configure your FUDA2-S1x11 Series Panel PC system to meet various operating requirements. It is divided into four chapters, with each chapter addressing a basic concept and operation of Fan-less Panel PC System.

  • Page 4: Chapter 1 System Overview

    1024 x 768 pixels, it is housed in an Aluminum bezel with anodizing coating that has a full IP65 rated front panel. This feature allows FUDA2-S1x11 Series Panel PC to be used extensively in harsh environments such as the operating temperature from -20 to 70 ℃...

  • Page 5: Check List

    System Overview Check List The FUDA2-S1x11 Series Panel PC package covers the following items: Essential One FUDA2-S1x11 Panel PC Panel Size Model Name 10.4” FUDA2-S1011 12.1” FUDA2-S1211 15” FUDA2-S1511 17” FUDA2-S1711 19” FUDA2-S1911 Panel Mount Kits Panel Size Kits (pcs) 10.4”...

  • Page 6: Product Specification

    Package with Carton from 96.5 cm (1-Corner, 3-Axis, 6-Face) Front Panel Protection Front Panel Protection IP65 (Front) / IP20 (Rear) (IEC 60529 Edition 2.1 Standard) Front Panel Protection Front Panel Protection Certif Certif Certif Certification ication ication ication CE/FCC Class A FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 7: Mechanical Dimension

    System Overview 1.4 Mechanical Dimension Front and side view of the FUDA2-S1011 system Back view of the FUDA2-S1011 system FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 8 System Overview Front and side view of the FUDA2-S1211 system Back view of the FUDA2-S1211 system FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 9 System Overview Front and side view of the FUDA2-S1511 system Back view of the FUDA2-S1511 system FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 10 System Overview Front and side view of the FUDA2-S1711 system Back view of the FUDA2-S1711 system FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 11 System Overview Front and side view of the FUDA2-S1911 system Back view of the FUDA2-S1911 system FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 12: Chapter 2 System Installation

    System Installation Chapter 2 System Installation This chapter provides you with instructions to set up your FUDA2-S1x11 Series Panel PC. Definitions and locations of all the interfaces are described so that you can easily configure your system. 2.1 Embedded Board H/W Jumper Setting Introduction FUDA2-S1x11 Series Panel PC adopts PEB-99A4 mother board.
  • Page 13 LCD Inverter Power Connector. (1*5 Pin wafer/2mm) LCD LVDS Connector. (2*15 Pin Hirose/1.25mm) SD Card. Front Panel Connector. (1*5 Pin Wafer/2mm) Touch Panel Connector. (1*5 Pin Header/2.54mm) USB Port 3 Connector (1*4 Pin Wafer/2mm). Light sensor Connector (1*6 Pin Wafer/1mm). FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 14 J17: LCD Inverter Power Connector (1*5 Pin wafer/2mm) PIN NO. DESCRIPTION LCD_ENBLT +12V LCD_BLADJ J18: LCD LVDS Connector (2*15 Pin Hirose/1.25mm) PIN NO. Description PIN NO. Description YAP0 YAM0 YAP1 YAM1 YAP2 YAM2 YAP3 YAM3 CLKAP CLKAM YBP0 YBM0 FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 15 Normal (Keep CMOS Setup) ★ Default Clear CMOS Setup JP2: LCD Panel Inverter ON/OFF Signal Setup PIN NO. DESCRIPTION +5V High Active ★ Default Short Short PIN NO. DESCRIPTION Short Short +12V High Active FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 16 5V Level ★ Default 3.3V Level JP8: Internal Audio Connector PIN NO. DESCRIPTION Audio_R+ Audio_R- Audio_L+ Audio_L- JP9: LPC Debug Port Pin Assignment PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAD0 3.3V LAD1 LPC_RESET LAD2 LPC_FRAME LAD3 LPC_CLCOK FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 17 1280 x 960 (18bit) Single 1280 x 1024 (24bit) Dual 1366 x 768 (18bit) Single 1366 x 768 (24bit) Single 1440 x 900 (24bit) Dual 1400 x 1050 (24bit) Dual 1600 x 900 (24bit) Dual FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 18: Selectable I/O Kit Installation

    In addition to default I/O interfaces, including 1x DVI, 2x RS-232/422/485, 4x USB and 2x Gigabit Ethernet, to further enhance system flexibility as well as to increase the versatility in application fields, FUDA2 Series allows users to select different I/O combinations for various market demands. FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 19: Memory Installation

    1. Unscrew the back cover to detach it 2. Remove the IPC back cover 4. Press down the memory module and 3. Insert Memory module to the slot finish installation FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 20: Hdd Installation

    Unscrew and remove the side bracket. socket. CF card SD card 3. Complete insertion (Eject CF card by 4. Screw the side bracket and finish pressing the elastic stick on the right side) installation CF card SD card FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 21: Getting Started

    2.7 I/O Interfaces 2.7.1 Front View Ambient Light Sensor: The ambient light sensor can detect light intensity in the surrounding. This feature allows the Panel PC to adjust panel brightness accordingly. FUDA2-S1x11 Series Panel PC User’s Manual 2-10...

  • Page 22: Rear View

    It demonstrates the power in and HDD working status of the Panel PC. Status Power LED HDD LED Working Green Gigabit Ethernet: Two Gigabit Ethernet (10/100/1000 Mbits/sec) LAN ports by using dual Intel® I210IT GbE Ethernet Controller (Support Jumbo Frame) FUDA2-S1x11 Series Panel PC User’s Manual 2-11...

  • Page 23: Top View

    1x Line-out 2.7.3 Top View 2.5” HDD/SSD Cover: Remove the cover and install the 2.5” HDD/SSD. *Note: Refer to section 2.4 for installation guide. Antenna Hole: It is reserved for WiFi or 3G solution. FUDA2-S1x11 Series Panel PC User’s Manual 2-12...

  • Page 24: Side View

    Check the installation guide and cut-out dimension below. *Note: In order to ensure the Panel PC to be protected against dust and water, mount the system on a non-textured surface. Installation Guide 1. Hook Clip FUDA2-S1x11 Series Panel PC User’s Manual 2-13...

  • Page 25: Vesa® Mount

    10.4” <10.7 50.2 12.1” <10.9 53.2 X 12 15” <11.3 55.6 X 16 17” <12 58.6 <12 58.6 19” 2.8.2 VESA® Mount The Panel PC can install with VESA® 75x75/100x100 compliant adapter plate. FUDA2-S1x11 Series Panel PC User’s Manual 2-14...

  • Page 26: Chapter 3 Driver Installation And Touch Usage Guide

    2. Click [Start] to find the “eGalaxTocuh installed properly Configure Utility” 3. Click [About], you can see the 4. Click [General], the installed USB information and version of the “Touch touch screen controller is shown. Screen Utility” FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 27 6. Click [Tools] to align touch with the points or 25 points linearization style. display and verify touch accuracy. Click [4 Points Calibration] & [Linearization] to match display. Click [Draw Test], draw by touch pen or finger to determine touch accuracy FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 28: Light Sensor Function Setting

    3.3 Light Sensor Function Setting Facilitated with an ambient light sensor, FUDA2-S1x11 Series Panel PC is capable of automatically adjust panel brightness by sensing light intensity in the surroundings. The sensor can be detected by Windows 7 and Windows 8 without driver installation.

  • Page 29: Chapter 4 Bios Setup Information

    Chapter 4 BIOS Setup Information FUDA2-S1x11 Series Panel PC adopts PEB-99A4 mother board. PEB-99A4 is equipped with the AMI BIOS stored in Flash ROM. These BIOS has a built-in Setup program that allows users to modify the basic system configuration easily.

  • Page 30: Main

    System Date The date format is <Day>, <Month> <Date> <Year>. Use [＋] or [－] to configure system Date. System Time The time format is <Hour> <Minute> <Second>. Use [＋] or [－] to configure system Time. FUDA2-S1x11 Series Panel PC User’s Manual...

  • Page 31: Configuration

    BIOS Setup Information 4.3 Configuration Use this menu to set up the items of special enhanced features. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 32 Vander pool Technology. The choice: Disabled. Enabled(Default). EIST Enable/Disable Intel Speed Step. The choice: Disabled. Enabled(Default). CPU C6 report Enable or Disable the CPU C6 (ACPI C3) report to OS. The choice: Disabled(Default). Enabled. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 33 Enable or Disable the High Precision Event Timer. The choice: Disabled. Enabled(Default). Audio Controller Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled. Enabled = Azalia will be unconditionally Enabled. The choice: Disabled. Enabled(Default). FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 34 Launch Legacy PXE Rom. [Disable] Not Launch Rom, [Enabled] Force Launch Rom. The choice: Disabled(Default). Enabled. Wake on LAN Controller Enable or Disable Intel LAN 0 and Intel LAN 1 WGI210AT wakeup function. The choice: Disabled. Enabled(Default). FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 35 Choices: Auto, IGD(Default), PCI, SG. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory sized used by the Internal Graphic Device Choices: 64M(Default), 96M, 128M, 160M, 192M, 224M, 256M, 288M, 320M, 352M, 384M,416M, 448M, 480M, 512M. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 36 Choices: PWM Inverted, PWM Normal(Default), GMBus Inverted, GMBus Normal. Active LFP Select the Active LEP Configuration. Mo LVDS: VBIOS does not enable LVDS. eDP Port-A: LFP driven by Int-DisplayPort encoder from Port-A. Choices: No LVDS, eDP Port-A(Default). FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 37 BIOS Setup Information PCI/PCIE Configuration PCI , PCI –X and PCI Express Setting. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 38 Enable or Disable the PCI Express Port 1 in the Chipset. Choices: Enable(Default), Disable. Speed Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. PCI Express Configuration Port 2 Enable or Disable the PCI Express Port 2 in the Chipset. Choices: Enable(Default), Disable. FUDA2-S1x11 Series Panel PC User’s Manual 4-10...
  • Page 39 Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. PCI Express Configuration Port 3 Enable or Disable the PCI Express Port 3 in the Chipset. Choices: Enable(Default), Disable. Speed Configuration PCIe Speed Choices: Auto(Default), Gen1, Gen2. FUDA2-S1x11 Series Panel PC User’s Manual 4-11...
  • Page 40 SATA Mode Select IDE / AHCI. Choices: Disabled, IDE, AHCI(Default). CF Device Enabled / Disabled CF Device. Choices: Disabled, Enabled(Default). Serial-ATA Port 0 Enable or Disable Serial ATA Port 0. Choices: Disabled, Enabled(Default). FUDA2-S1x11 Series Panel PC User’s Manual 4-12...
  • Page 41 XHCI driver. Choices: Enabled, Disabled(Default). EHCI Hand-off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. Choices: Enabled, Disabled(Default). FUDA2-S1x11 Series Panel PC User’s Manual 4-13...
  • Page 42 USB 2.0 (EHCI) Support Control the USB EHCI (USB2.0) functions. One EHCI controller must always be enabled. Choices: Enable, Disable(Default). USB Port 0 Enable/Disable USB Port 0: USB 3.0 port on Board. Choices: Enable(Default), Disable. FUDA2-S1x11 Series Panel PC User’s Manual 4-14...
  • Page 43 Enable/Disable USB Port 2: The USB port turn into a mini PCIE. Choices: Enable(Default), Disable. USB Port 3 Enable/Disable USB Port 3: The USB port as USB HUB have 2 USB Port in external cart. Choices: Enable(Default), Disable. FUDA2-S1x11 Series Panel PC User’s Manual 4-15...
  • Page 44 Enable / Disable GPIO wake on Ring function. Choices: Disabled(Default), Enabled. Wake System from S5 Enable or Disable System wake on alarm event, Select Enable, system will wake on the hr: mm: sec: specified. Choices: Disabled(Default), Enabled. FUDA2-S1x11 Series Panel PC User’s Manual 4-16...
  • Page 45 Set Termination Control Disabled/ Enabled. Choices: Disabled, Enabled(Default). Direction Control Set Direction Control set Enabled as Transceiver else; Disabled as Receiver. Choices: Disabled(Default), Enabled. Serial Port Enable or Disable Serial Port (COM) IO=2F8H; IRQ=3. Choices: Disabled, Enabled(Default). FUDA2-S1x11 Series Panel PC User’s Manual 4-17...
  • Page 46 Enable or Disable Watch Dog Timer. Choices: Disabled(Default), Enabled. Timer Unit (Watch Dog Timer Enabled) Select Timer count unit of WDT. Choices: Seconds(Default), Minutes. Timer value (Watch Dog Timer Enabled) Set WDT Timer value Seconds/minutes. Choices: Default [20]. FUDA2-S1x11 Series Panel PC User’s Manual 4-18...
  • Page 47 BIOS Setup Information Hardware Monitor Monitor hardware status. FUDA2-S1x11 Series Panel PC User’s Manual 4-19...

  • Page 48: Security

    Password Check Mode [Setup] check password when enter setup screen, [Power On] check password on every time system power on. Choices: Setup(Default), Power On. Administrator Password Set Administrator Password User Password Set User Password. FUDA2-S1x11 Series Panel PC User’s Manual 4-20...

  • Page 49: Boot

    Choices: Default [5]. Bootup NumLock state Select the keyboard NumLock state. Choices: On(Default), Off. Post Report Post Report Support Enabled/Disabled. Choices: Disabled(Default), Enabled. Summary Screen Summary Screen Support Enabled/Disabled. Choices: Disabled(Default), Enabled. FUDA2-S1x11 Series Panel PC User’s Manual 4-21...
  • Page 50 Enables or Disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. Choices: Disable(Default), Enabled. Boot Option #1 Sets the system boot order Choices: UEFI: Built-in EFI Shell, Disabled. FUDA2-S1x11 Series Panel PC User’s Manual 4-22...

  • Page 51: Save And Exit

    BIOS Setup Information 4.6 Save and Exit Save Changes and Reset Reset the system after saving the changes. Pressing <Enter> on this item asks for confirmation: Save configuration and reset. FUDA2-S1x11 Series Panel PC User’s Manual 4-23...
  • Page 52 Reset system setup without saving any changes. Pressing <Enter> on this item asks for confirmation: Reset without saving. Restore Defaults Restore/Load Default values for all the setup options. Pressing <Enter> on this item asks for confirmation: Load Optimized Default. FUDA2-S1x11 Series Panel PC User’s Manual 4-24...

  • Page 53: Chapter 5 Important Instructions

    5.2 Exclusion of Accident Liability Obligation Portwell, Inc. shall be exempt from the statutory accident liability obligation if users fail to abide by the safety instructions. 5.3 Liability Limitations / Exemption from the Warranty Obligation In the event of damage to the system unit caused by failure to abide by the hints in this manual and on the unit (especially the safety instructions), Portwell, Inc.

  • Page 54: Chapter 6 Frequent Asked Questions

    Methanol Antibreeze Animalistic fat Normal Saline Salad oil Q2: How to enable/disable Light Sensor function in Windows 7? Answer: Light Sensor function can be turned on/off in Windows 7. Step 1: Open “Control Panel” FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 55 Frequent Asked Questions Step 2: Select “Location and Other Sensors” Step 3: Check and Apply to enable/disable Light Sensor function. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 56 When the message appears on the screen, press <Del> key and enter BIOS setup screen. Step2. In page “Boot”, you can find OS Selection and choose the corresponding OS. Note: For Linux OS, please choose Windows 7. FUDA2-S1x11 Series Panel PC User’s Manual...
  • Page 57 AT mode. SW2: AT/ATX & BIOS recovery Setup PIN NO. DESCRIPTION ON: AT Mode 1-4(Port1) OFF:ATX Mode ★ Default *Note: Diagram ATX mode setting *Note: Diagram AT mode setting FUDA2-S1x11 Series Panel PC User’s Manual...
