EisSound KBSound iSelect User Manual

Hide thumbs Also See for KBSound iSelect:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
USER'S MANUAL
SPACE
CC-1152ENG-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KBSound iSelect and is the answer not in the manual?

Questions and answers

Related Manuals for EisSound KBSound iSelect

Summary of Contents for EisSound KBSound iSelect

  • Page 1 USER’S MANUAL SPACE CC-1152ENG-03...

  • Page 2: Table Of Contents

    Important Safety Instructions Table of Contents Before installing the unit, please read and follow the instructions provided in the Installation Manual included Quick Reference Guide in this kit. 1. Introduction Before operating the unit, please read and follow the instructions provided in this User´s Manual thoroughly and save it for future reference.

  • Page 3: Quick Reference Guide

    Quick Reference Guide FM SENS 1-2-3 Automatic FM station search sensitivity 2” FM/DAB memory pre-sets Step forward and back for iPod® playing list. Delete all FM tuning pre-sets 6” Automatic FM station scan 1” Store all FM stations detected 6” Audio level adjustment volume/bass/treble/balance/loudness Delete individual FM tuning pre-sets...

  • Page 4: Introduction

    1. Introduction ® KBSOUND iSelect is a sound device specially designed for quick and easy installation. It fits discreetly into the decor of your kitchen, bathroom or anywhere in your home. ® The KBSOUND iSelect Kit comprises: Electronic module with built-in FM tuner and power supply. 1,5W + 1,5W stereo audio output.
  • Page 5 ® KBSOUND SPACE is a sound device specially designed for quick and easy installation. Is our new custom made audio solution. It´s open ended allowing you to choose your loudspeakers and amplifiers tu fulfill the specific design requirements of your dream project with superb sound. ®...

  • Page 6: General Operating Notes

    2. General Operating Notes 1.- None of the functions (except ON/OFF) work unless the remote control is in “on” mode. ® Once the KBSOUND or SPACE is connected to the mains, it will remain powered even it is in OFF state. That iSelect means that the OFF state (as indicated in this manual) really means a “standby”...

  • Page 7: Operating Audio Functions

    3. Operating Audio Functions Key Sequence Display If the electronic module is off, a brief press on the ON/OFF key will turn on the unit . The LED will display the word “ON” When the electronic module is off, the LED will be OFF. vol 58 Increase/decrease in the volume level: The LED will flash to indicate the desired change in volume.

  • Page 8: Operating The Fm Tuner

    4. Operating the FM Tuner Key Sequence Display 4.1 Station Scan SCAN While the search is taking place, the word “SCAN” will appear on the display screen. The screen will duly display the station frequency of the next station found. 1”...
  • Page 9 Key Sequence Display 4.3 Tuning to FM Memory Pre-Sets MEM 19 The UP/DOWN keys allow you to scroll through the stations stored in the memory (see Chapters 4.4 and 4.5, Storing and Clearing Stations in Memory). When stations are stored in the memory they are sorted in ascending order; that is, beginning 102.50 with 87.5 and ending with 108.0.
  • Page 10 Key Sequence Display Storing and Clearing Station Frequencies Automatically AUTO To activate the storing station frequencies automatically process, hold down key 6 for 6 seconds. 6’’ When the automatic programming begins the screen will display the word “AUTO”. The electronic module will store into the memory the stations that are received with the best reception, sequentially from lowest frequency (87.5 MHz) to highest frequency (108.0 MHz).

  • Page 11: Operating The Wireless Accessory

    KBSOUND DOCK can be linked iPod/iPhone. ® KBSOUND iSelect or SPACE are linked. ® ONLY WITH ONE KBSOUND iSelect IMPORTANT: use only the power supply or SPACE at any one time ® supplied with the KBSOUND DOCK The iPOD key on the remote control...

  • Page 12: Operating The Wireless Accessory

    Bluetooth sure that the Bluetooth device from ® ® through the KBSOUND iSelect 2.5", KBSOUND iSelect 5" or which you want to stream the music has ® ®...
  • Page 13 6.2.- Pairing (linking) a new Bluetooth device Access the Bluetooth menu of your Before being able to stream music from device ® a Bluetooth device to our KBSOUND kits it is necessary to link the In the device select the KBsoundXX ®...
  • Page 14 ® ® KBSOUND Bluetooth 6.3.- Transmit audio to a option from multiple Bluetooth devices ® Several Bluetooth devices can share the same KBSOUND If you want to transmit audio from a different Display ® Bluetooth option, although only one can transmit audio at any Bluetooth device, press the 5 key on the Sequence time.
  • Page 15 ® ® KBSOUND Bluetooth 6.4.- Transmit audio from one device to several options ® ® If there are several KBSOUND Bluetooth options in your installation, you will be able to transmit your music to any of them interchangeably from the ®...

  • Page 16: Selecting Turn-On Mode

    7. Selecting Turn-On Mode ® This function is designed for use in the event that the KBSOUND iSelect SPACE power supply is fed by a specifically designated switch. In this case, the automatic activation mode must be programmed in order to ®...

  • Page 17: Technical Specifications

    8. Technical specifications 52391/92 , 52398/93 NORMAL COMMENTS Measurements 200x53x56 Voltage 50Hz, terminal F,N (ref.52391,52398) 50/60Hz, terminal F,N (ref.52392,52393) Consumption demand terminals F,N Output signal (16 ohms) terminals L,R Passband 20.000 Aux.amplifier switch on signal terminals 62, 4 (ref.52398/93) Distortion Left/right channel separation FM Frequency range 87,5...
  • Page 18 Please note that the use of this accesory with iPhone may affect wireless performance. Polígono Malpica Calle F Oeste Grupo Gregorio Quejido, 87-88 50016 Zaragoza (SPAIN) Tel.: 34 976 465 550 Fax: 34 976 465 559 comercial@eissound.com www.eissound.com AENOR Empresa Registrada ER-0634/1998 CC-1152ENG-03...

This manual is also suitable for:

Kbsound space
