Philips M38 107B4 Service Manual

Philips M38 107B4 Service Manual

17" auto scan colour monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

17" Auto scan Colour Monitor
Service
Service
Service
DDC/Power saving/MPR II/TCO
Description
Important Safety Notice ------------------------------- 2
Technical Data ------------------------------------------ 3
Front control & OSD------------------------------------ 4
OSD menu tree------------------------------------------ 5
OSD Adjustments-----------------------------------6~12
Troubleshooting----------------------------------------12
Warning and Notes ------------------------------------ 14
Mechanical Instructions ------------------------- 15~17
Wiring Diagram-----------------------------------------18
Hex Data of DDC2B--------------------------------19 ~21
DDC Instructions -----------------------------------22~26
Electrical Adjustments --------------------------- 27~ 29
Block Diagram ------------------------------------------31
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by BCU Monitors
Printed in Taiwan

TABLE OF CONTENTS

Page
SAFETY NOTICE
Copyright reserved
Subject to modification
Description
Video Panel C.B.A.(A) --------------------------------33
Main Panel-Deflection (B) Schematic Diagram --34
Main Panel C.B.A.(B,C)-------------------------------35
Key ControlPanel C.B.A. (D) ------------------------38
Repair Tips ----------------------------------------------39
Exploded View------------------------------------------40
parts list------------------------------41
Spare parts list------------------------------------- 42~44
Repair flow chart----------------------------------- 45~52
LightFrame for Windows--------------------------53~56
General Product Specification-------------------57~82
General Troubleshooting Guide----------------83~105
Sep 25 2002
Chassis : M38
M38 107B4
107B40/40C
Horizontal frequencies
30 - 86 kHz
Page
GB
3138 106 10232

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M38 107B4 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips M38 107B4

Summary of Contents for Philips M38 107B4

  • Page 1: Table Of Contents

    17" Auto scan Colour Monitor Chassis : M38 Service M38 107B4 Service Service DDC/Power saving/MPR II/TCO 107B40/40C Horizontal frequencies 30 - 86 kHz TABLE OF CONTENTS Description Page Description Page Video Panel (A) Schematic Diagram ---------------32 Important Safety Notice ------------------------------- 2 Video Panel C.B.A.(A) --------------------------------33...

  • Page 2: Important Safety Notice

    REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR evaluation. Accordingly, a servicer who uses a service PART NUMBERS IN THE PARTS LIST SECTION OF THIS procedure or tool which is not recommended by PHILIPS SERVICE MANUAL. must first satisfy himself thoroughly that neither his safety nor the safe operation of the equipment will be jeopardized by the service method selected.

  • Page 3: Technical Data

    Data Storage Factory preset modes: This monitor has 8 factory-preset modes as indicated in the This monitor is ENERGY STAR compliant. following table : As an ENERGY STAR Partner, PHILIPS has determined that Frequen Sync polarity Mode Resolution this product meets the ENERGY STAR guidelines for energy...

  • Page 4: Front Control & Osd

    Description of the On Screen Display What is the On-Screen Display? This is a feature in all Philips monitors which allows an end-user to adjust screen performance of monitors directly though an on-screen instruction window. The user interface provides user-friendliness and ease-of-use when operating the monitor.

  • Page 5: Osd Menu Tree

    OSD menu tree M38 107B4 Go to cover page The OSD Tree Below is an overall view of the structure of the On- Screen Display. You can use this as reference when you want to later on work your way around the different...

  • Page 6: Osd Adjustments

    OSD Adjustments M38 107B4 Go to cover page LANGUAGE The OSD Controls The ON SCREEN DISPLAY shows its settings in one of five languages. The default is English, but you can select French, Spanish, German, or Italian. BRIGHTNESS To adjust your screen's brightness, follow the steps below. Brightness is 1) Press the button on the monitor.
  • Page 7 OSD Adjustments (Continued) M38 107B4 Go to cover page ZOOM 3) Press the button. The ADJUST HORIZONTAL window appears. ADJUST POSITION should be highlighted. ZOOM increases or decreases the size of the images on your screen. To adjust the ZOOM follow the steps below.
  • Page 8 OSD Adjustments (Continued) M38 107B4 Go to cover page 2) Press the button until ADJUST SHAPE is highlighted. 2) Press the button until ADJUST VERTICAL is highlighted. 3) Press the button. The ADJUST SHAPE window appears. 3) Press the button. The ADJUST VERTICAL window appears.
  • Page 9 OSD Adjustments (Continued) M38 107B4 Go to cover page Smart Help After returning to MAIN CONTROLS . . . 7) When the trapezoid is adjusted, press the button to highlight ...to continue to ADJUST SIDE ANGLES, start with step 5 under...
  • Page 10 OSD Adjustments (Continued) M38 107B4 Go to cover page 4) Press the button to highlight 9300K for GENERAL USE, 5) Press the button. The ROTATE IMAGE window appears. ROTATE 6500K for GAMES, or USER PRESET. should be highlighted. 5) Once you have highlighted GENERAL USE or GAMES, press the button to confirm you selection and return to the MAIN CONTROLS window.
  • Page 11 OSD Adjustments (Continued) M38 107B4 Go to cover page 4) Press the button to select YES or NO. NO is the default. 4) Press the button. The ADJUST MOIRE window appears. YES returns all settings to their original factory adjustments.

  • Page 12: Troubleshooting

    OSD Adjustments (Continued), Troubleshooting M38 107B4 Go to cover page DEGAUSS Monitor Specific Troubleshooting EXTRA CONTROLS is a set of three features, including DEGAUSS. Self-Test Feature Check (STFC) Degaussing removes electromagnetic build up that may distort the color Your monitor provides a self-test feature that allows you to check on your screen.

  • Page 13: Lock/Unlock, Factory Mode & Service Mode

    Lock/Unlock, Factory Mode, Burn In, Service Mode M38 107B4 Go to cover page To access factory mode Front Control 1. Turn off monitor (don't turn off PC) 2. Press " " and " " simultaneously on the front control panel,then press "...

  • Page 14: Warning And Notes

    Warning and Notes M38 107B4 Go to cover page Warnings Notes . Safety regulations require that the unit should be returned The direct voltages and waveforms are average voltages. in its original condition and that components identical to They have been measured using the Service test software the original components are used.

  • Page 15: Mechanical Instructions

    Mechanical Instructions M38 107B4 Go to cover page 0. General To be able to perform measurements and repairs on the "circuit boards", these unit should placed in the service position first. 1.Remove the rear cover -Remove right and left lib (screw cover) on the back cover as shown in Fig.
  • Page 16 Mechanical Instructions M38 107B4 Go to cover page 4. Main panel with Bottom Tray - Disconnect the degaussing coil (1113)from Main panel as shown in Fig. 6. - Remove the video panel from CRT neck. - Remove the "screw" of I/F cable from Main panel, grounding screw , wire as shown in Fig.

  • Page 17: Mechanical Instructions

    Mechanical Instructions M38 107B4 Go to cover page 5. How to remove Main Panel (Chassis) After remove "Main panel with bottom tray": Fig. 18 - Remove a screw from back of bottom tray as shown in Fig. 15. - Remove Interface cable from bottom tray as shown in Fig. 16.

  • Page 18: Wiring Diagram

    Wiring Diagram M38 107B4 Go to cover page...

  • Page 19: Hex Data Of Ddc2B

    : TY 123456 Blue Y coordinate : 0.057 Monitor Descriptor #3 White X coordinate : 0.283 Monitor Name : PHILIPS 107B4 White Y coordinate : 0.297 Monitor Descriptor #4 Established Timings Established Timings I : 720 x 400 @70Hz (IBM,VGA)
  • Page 20 Hex Data of DDC2B M38 107B4 Go to cover page Standard Timing Identification #6 ********************************************************************** Horizontal active pixels : 1280 EDID log file for Philips Tube Aspect Ratio : 4:3 ********************************************************************** Vendor/Product Identification Refresh Rate : 85 ID Manufacturer Name...
  • Page 21 Hex Data of DDC2B M38 107B4 Go to cover page Standard Timing Identification #7 ********************************************************************** Horizontal active pixels : 1280 EDID log file for SAMSUNG CRT Aspect Ratio : 4:3 ********************************************************************* Refresh Rate : 60 Vendor/Product Identification Standard Timing Identification #8...

  • Page 22: Ddc Instructions

    DDC Instructions M38 107B4 Go to cover page 1. General 3. Pin assignment DDC Data Re-programming A. 15-pin D-Sub Connector In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect,repaired monitor the serial numbers have to be re-programmed.
  • Page 23 DDC Instructions (Continued) M38 107B4 Go to cover page 4. Configuration and procedure 3. At the submenu, type the letter of your computer's floppy disk drive followed by :EDID301 (for example, A:\EDID301, as shown in Fig. 5). There is no Hardware DDC (DDC IC) anymore. Main EEPROM stores all factory settings and DDC data (EDID code) which is so called Software DDC.
  • Page 24 DDC Instructions (Continued) M38 107B4 Go to cover page Re-programming EEPROM (Software DDC) 4. Click icon (Read EDID function) to read DDC EDID data from monitor. The EDID codes will display on screen as shown in Fig. 13. Step 1: After initialize alignment box, connecting all cables and box as shown in Fig.
  • Page 25 DDC Instructions (Continued) M38 107B4 Go to cover page Step 5: **Configuration Setup & Enter Factory Mode ** Step 6: Write DDC data for "write EDID data" Click (Write EDID) icon from the tool bar to write DDC data. Bring up "Writing 0%~100%, ready" a progressing bar on the left...

  • Page 26: Ddc Instructions

    DDC Instructions (Continued) M386 107B4 Go to cover page Step 9: Load DDC data Note 2 : In Factory Mode: Read/Write DDC data Before Read/Write EDID code, please confirm that the Software DDC only was enabled as shown in Fig. 23. Click from the tool bar.

  • Page 27: Electrical Adjustments

    Electrical Adjustments M38 107B4 Go to cover page 5. To access factory mode 0. General 5.1 Turn off monitor (don't turn off PC) 5.2 Press " " and " " simultaneously on the front control When carry-out the electrical settings in many cases a video signal panel,then press "...
  • Page 28 Gain. ( for ref.90,90,20,50) HEHT (for ref. 255) LF (BRIGH SHARP) OSD R/G/B cut-off and R/G/B gain can be accessed (for Philips ( for ref. 3,3) CRT), with initial data: EXIT 9300 K R cutoff = 62%, R gain = 71% (I C)

  • Page 29: Electrical Adjustments

    Electrical Adjustments (Continued) M38 107B4 Go to cover page 8. Focus adjustment Apply a signal of " @ " character. at 64 kHz/60 Hz mode set the brightness to mid-position , contrast to max - position and adjust the focus for optimal sharpness in the area within 2/3 from the screen center.

  • Page 30: Safety Test Requirements (Hipot & Ground)

    Safety test requirements M38 107B4 Go to cover page 3. Equipments and Connection All units that are returned for service or repair must pass the original manufactures safety tests. Safety testing requires both Hipot Ground Continuity testing. 3.1. Equipments For example :...

  • Page 31: Block Diagram

    M38 107B4 Block diagram Go to cover page FUNCTION BLOCK OF COCA+ M38 107B4 VIDEO VIDEO LIGHT & OUTPUT RESTOR. AMPLIFIER FRAME DEFLECTION UNIT STAGE BF422 x 6 TDA4886 TDA4822 LM2439 ROTATION LM358N OSD IC MYSON MTV030-19 Self- test S-CAP...

  • Page 32: Video Panel (A) Schematic Diagram

    Video Panel Schematic diagram M38 107B4 Go to cover page 7302-2 7301-18 1 V/div AC 1 V/div AC 5 mS/div 5 mS/div 7301-16 7302-4 1 V/div AC 1 V/div AC 5 mS/div 5 mS/div 7701-11 7302-6 20 V/div AC 1 V/div AC...

  • Page 33: Video Panel C.b.a

    Video Panel C.B.A.(A) - copper track side view M38 107B4 Go to cover page GRID BOARD 3340 B3 9712 A1 GRID BOARD # REF LABEL SIDE 3341 B3 9713 A1 # REF LABEL SIDE 1301 C3 3342 B3 9714 C1...
  • Page 34 Deflection - Main Panel Schematic diagram M38 107B4 Go to cover page B1 7503-C B8 7501-12 7262-D B22 7685-C B29 7621-1 50 V/div AC 0.5 V/div AC 50 V/div AC 100 V/div AC 2 V/div AC 5 mS/div 5mS/div 5 uS/div...

  • Page 35: Main Panel C.b.a.(B

    Main Panel C.B.A.(B,C) - copper track side view M38 107B4 Go to cover page 2611 B5 7262 A8 GRID BOARD GRID BOARD 3634 A3 5126 D3 9602 A2 3264 B8 2612 B4 7263 A8 # REF LABEL SIDE # REF LABEL SIDE...

  • Page 36: Power Supply (C) Schematic Diagram

    Power Supply - Main Panel Schematic diagram M38 107B4 Go to cover page 5113-1 5113-10 100 V/div AC 10 V/div AC 5 uS/div 5 uS/div 7102-3 5113-2 50 V/div AC 5 V/div AC 5 uS/div 5 uS/div 7102-4 5113-4 5 V/div AC...

  • Page 37: Key Control Panel (D) Schematic Diagram

    Key Control Schematic diagram M38 107B4 Go to cover page 1891 C2 1892 C2 1893 C3 1894 C4 1895 C4 3891 B2 CONTROL BOARD 3892 B3 3893 B3 3894 B4 SB: 53022 3895 B4 PB: 56701 6891 D1 8891 C1...

  • Page 38: Key Controlpanel C.b.a

    Key Control Panel C.B.A.(D) M38 107B4 Go to cover page 1891 A2 1892 A2 1893 A2 1894 A3 1895 A4 3891 A2 3892 A3 3893 A2 3894 A3 3895 A3 6891 A1 8891 A4 53022cus 53022hmc...

  • Page 39: Repair Tips

    Repair Tips M38 107B4 Go to cover page preferably be equipped with a thermal control (soldering 0. Warning temperature: 225 to 250 C). - The chip, once removed, must never be reused. All ICs and many other semi-conductors are susceptible to electrostatic discharges (ESD).

  • Page 40: Exploded View

    Exploded View M38 107B4 Go to cover page 3138 127 52031 BACK COVER ASSY 3138 188 71111 I/F CABLE 1151 3138 178 56211 VIDEO PCB ASSY (M38 for CPT CRT) 1153 3138 178 56201 MAIN PCB ASSY 1152 3138 168 78011...

  • Page 41: Recommended Parts List

    Recommended Parts List M38 107B4 Go to cover page Recommended parts list of 107B40/40C 0001 313812753041 FRONT CAINET ASSY 0002 313812752031 BACK COVER ASSY 0003 313810798401 PEDESTAL ASSY 0044 313810448612 BASE(CHEIL HR-1360) 0047 313810454231 BUTTON-POWER 0049 313810454211 BUTTON-FUNCTION 0053 313810448602 SWIVEL(CHEIL HR-1360)

  • Page 42: Spare Parts List

    Spare Parts List M38 107B4 Go to cover page Parts List 2411 203803511222 ELCAP REA 16V S 470U PM20 A 2501 203803511204 ELCAP REA 16V S 1U PM20 A CTV : 107B40/40C 2505 203803511222 ELCAP REA 16V S 470U PM20 A...
  • Page 43 Spare Parts List (Continued) M38 107B4 Go to cover page 3564 319802151230 RST SM 0805 12K PM5 COL R 6611 933493960683 DIO REC RGP10G A (GI) R 3567 213810113101 RST CRB CFR-12 A 1R PM5 A 6612 933957760683 DIO REC SB140...

  • Page 44: Spare Parts List

    Spare Parts List (Continued) M38 107B4 Go to cover page 1153 Video Panel 3703 213810113829 RST CRB CFR-12 A 82R PM5 A 1154 KEY CNTR PANEL 3711 319802151010 RST SM 0805 1R PM5 COL R 3712 212211000329 RST MFLM MF1/2WS A 1R PM1 A...

  • Page 45: Repair Flow Chart

    Repair Flow Chart M38 107B4 Go to cover page A. Power Supply Failure check 7105 1. Symptom : check 7105 pin8 check 7105 no startup sound pin 1=11V 140V<pin8<360V Pin6 output ? LED light off check check replace 7105 6108/3125/...
  • Page 46 Repair Flow Chart (Continued) M38 107B4 Go to cover page rough check for R,G, B B.Video 1. video input= 0.7V check blanking Repair Flow 2. 7301video output =2.5V 7501 pin16 3. 7701 video output > 35Vpp check 1.Sympton : R,G,B output...
  • Page 47 Repair Flow Chart (Continued) M38 107B4 Go to cover page C. Horizontal deflection output repair flow : 1. Sympton : check Hsync check Hsync check Hsync without 7606 base 7605 base 7501 pin8 H-deflection. check check Hsync check Hsync replace 5612...
  • Page 48 Repair Flow Chart (Continued) M38 107B4 Go to cover page basic check D. Vertical Deflection Failure +12/-12V/+80V Sympton : check check one horizontal line 3401,3402 6405,6402 V_size is abnormal 3407,3408 good? too large/small good check check 7401 7401 check 7501...
  • Page 49 Repair Flow Chart (Continued) M38 107B4 Go to cover page check cpu pin6/ pin32= 5V E. CPU Basic Check pin9/pin8=12MhZ check list pin7=gnd H size compensation for 86K S-CAPACITOR SWITCH TABLE 31. H-EHT the load variance Hor. Freq.(KHz) < 27.50 27.5 ~ 33.24...
  • Page 50 Repair Flow Chart (Continued) M38 107B4 Go to cover page check 38. Rotation output from 0V to 5V check 3. ABL-CON output from 0V to 5V check key check 3836, 2821 23. Keypad Enter,Up,Down,Left,Right keys 3871~3875 check pin34 1.no H/V sync & IF cable pin5 floating - show msg.
  • Page 51 Repair Flow Chart (Continued) M38 107B4 Go to cover page Basic check F. TDA4841 Vcc=pin9=pin10=12V Vcc > 9V Check List gnd =pin7=pin25=0v during startup 1. HFLB pin16 if no exist (from H.defl) CLBL=hi pin17 = Hunlock = floating pin30 = Hpll2 = 0V pin6 = HDRV = floating 2.
  • Page 52 Repair Flow Chart (Continued) M38 107B4 Go to cover page Hunlock pin is floating while pll1(pin26) is 17. Hunlock unlock in searching mode 18. IIC scl = hi the initial sequence of IIC IC 19 IIC sda = hi 7501,7301,7304 compensate for the V_size 21 EHT_compen.

  • Page 53: Lightframe For Windows

    Earlier Philips monitors or other manufacturers monitors will not work with this special software. It is recommended that you install this software only on a Philips monitor designed to use it. These monitors can be identified by the LightFrame logo on the front of the monitor.
  • Page 54 LightFrame for Windows (Continued) M30 107S2 GS_3 M38 107B4 Go to cover page 5. Click Yes, bring up Fig.5 Fig 9 9. Click Finish, Fig 5 bring up LightFrame 3, Fig. 10 on the desktop. 6. Click Next, bring up Fig.6 Fig 6 7.
  • Page 55 LightFrame for Windows (Continued) M38 107B4 Go to cover page Operating LightFrame 3b) If you want to highlight only an area of a window, click on the left mouse button and drag the cursor over the area to be highlighted while After installation, LightFrame starts up automatically whenever the holding the mouse button.
  • Page 56 LightFrame for Windows (Continued) M38 107B4 Go to cover page On button LightFrame 3 State and transition diagram Combined with Control bar appearance Add/remove button Off button Full screen button Help button LF Idle User clicks off or full screen...

  • Page 57: General Product Specification

    GENERAL PRODUCT SPECIFICATION M38 107B4 Go to cover page M38 107B4 86KHz General Specification (Sheet 590) ======================================== FEATURES / BENEFITS - EXTREMELY HIGH MTBF (OVER 75K HRS, EXCLUDING CRT) - PROFESSIONAL LOOK, WITH NON-FLAMMABLE CABINET (94V-0) - USER'S CONTROLS . FRONT MOUNTED CONTROLS FOR EASY ACCESS - BETTER DISPLAY PERFORMANCE .
  • Page 58 Image non-linearity Mis-covergence Focus check 4.10 Luminance uniformity 4.11 White color adjustment 4.12 Color tracking on full white pattern 4.13 Purity 4.14 Moire 4.15 Blemish 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 59 Leakage current Grounding Certifications Safety Fulfil approbation requirements Reliability Mean time between failures 10.0 Quality assurance requirements 10.1 Acceptance test 11.0 Service ability 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 60 (between 0 and 0.6 V to be considered as low level ,between 2.3 and 5.0 V as high level) C. Impedance Video : Terminated with 75 ohms Sync : Terminated with 4.7K ohms pull down resistors. 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang...
  • Page 61 75Hz (VESA) 6. 1024 x 768 68.7 85Hz (VESA) 7. 1280 x 1024 80.0 75Hz (VESA) 8. 640 x 480 43.3 85Hz (VESA) 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 62 Timing requirements The AUTOSCAN color monitor must be capable of displaying standard resolutions within the vertical(refresh) frequency range of 50 to 160 Hz and horizontal scan range of 30 - 86KHz. 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552...
  • Page 63 = 12.800 ms Rear porch 3.232 us Rear porch 0.448 ms Sync width 1.616 us Sync width 0.064 ms Sync.polarity = Sync.polarity = 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 64 Display size = 12.804 ms Rear porch = 1.837 us Rear porch 0.475 ms Sync width 1.067 us Sync width 0.037 ms Sync.polarity = Sync.polarity 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 65 Active Mandatory Inactive Inactive Blanked Mandatory <=2w(TCO) Normal Remark: Transition time from ON to any power saving mode will have 5 seconds delay. 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 66 < 1.20mm for C and Due to aging (25 C, 300 hrs) : 1.0 % Due to mains voltage variation ( 10% ) : 1.0 % 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 67 (preset modes only, refer to fig. 1) Width : 306 +/- 3 mm Height : 230 +/- 3 mm 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 68 The maximum convergence error to be measured on a white spot or white display line to represents the maximum distance between the energy centers of any two primary colors. (See Fig. 6) 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552...
  • Page 69 : As stated in item 4.0, the purity must be checked under specific destinations of earth magnetic environments and the monitor to be well degaussed. After warming-up time of 30 min. , no color stains may occur in above four patterns. 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552...
  • Page 70 : 1.5 m +/- 50 mm flying with 15 pin PS/2 D-shell socket Tilt and swivel base Tilt angle : 5 forward and 15 backward Swivel rotation : 90 leftward or rightward 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang...
  • Page 71 B-1 Container loading (separated pedestal) Container size Q'ty W/ palette W/ palette Layers Sets per layer Sets per block Blocks per container Total sets 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 72 The disturbances induced by the display and tolerated by the environment are defined as follows : 6.3.1 Radiation Completely fulfilled International Commission of Radio logical Protection (ICRP) requirement 0.5 mR/Hr. 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang...
  • Page 73 Sweden SEMKO ---- Norway NEMKO ---- Denmark DEMKO ---- Finland FIMKO ---- Spain HOMOLOGATION BEAB U.S.A. UL , DHHS Canada Japan ---- VCCI 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 74 Service ability The service ability of this monitor should fulfil the requirements which are prescribed in UAW-0346 and must be checked with the check list UAT - 0361 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang...
  • Page 75 GENERAL PRODUCT SPECIFICATION M38 107B4 Go to cover page 303 mm 306 mm 309 mm FIG-1 IMAGE DIMENSION 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 76 M38 107B4 GENERAL PRODUCT SPECIFICATION Go to cover page 306 mm |A-B| AND |C-D| < 5 mm FIG-2 IMAGE CENTERING 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 77 GENERAL PRODUCT SPECIFICATION M38 107B4 Go to cover page 306 mm < 2 mm FIG-3 IMAGE ROTATION 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 78 M38 107B4 GENERAL PRODUCT SPECIFICATION Go to cover page 306 mm A=B=C=D < 2.0 mm FIG-4 IMAGE GEOMETRY 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 79 GENERAL PRODUCT SPECIFICATION M38 107B4 Go to cover page 306 mm A=B=C=D < 2.0 mm FIG-4 IMAGE GEOMETRY 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 80 M38 107B4 GENERAL PRODUCT SPECIFICATION Go to cover page ZONE B ZONE A ZONE C 306 mm FIG-6 MISCONVERGENCE 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...
  • Page 81 DC < 1.20 mm DD < 1.20 mm (D measured between flash on / off) Figure 7 Dynamic and Static EHT regulation distortion pattern 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS (86K)(TCO99) 2002-07-12 WR.Huang...
  • Page 82 GENERAL PRODUCT SPECIFICATION Go to cover page 1 BYTE = 8BITS LINE HEX.DATA 0 0 0 0 Fig 7 CHARACTER FORMAT FOR FOCUS CHECK 17" M38 107B4 86K TYPE : 107B40/40C 8639 000 12552 BRAND : PHILIPS(86K)(TCO99) 2002-07-12 WR.Huang 2002-07-12...

Table of Contents
