- Page 1 Digital Photo Printer CHC-S9045 Operation Manual First version April 19, 2004 Revision date Revision code Shinko Electric Co., Ltd.
- Page 2 About the Handling of This Manual １ ． All copyright for this manual is preserved by the Shinko Electric Co., Ltd. No parts of this manual may be reproduced in any form without prior written permission from the Shinko Electric Co., Ltd., by the Japanese Copyright Law.
- Page 3 PREFACE This manual describes the operating precautions and basic operations relating to the CHC-S9045 digital photo printer. In the remainder of this manual, the digital photo printer is called the machine. Before operating the machine, read this manual and thoroughly understand the proper methods of installing and operating the machine.
-
Page 4: Table Of Contents
CONTENTS PREFACE SECTION 1. FOR SAFE MACHINE USAGE ………………… 1-1 Operating Environment and Installation ………………………………… 1-2 Handling the Printer ………………………………………………………… Handling the Consumable Parts/Materials and Printed Photos ……… 1-5 SECTION 2. INSTALLATION AND SETUP ………………… 2-1 Procedure from Unpacking to Setup ……………………………………… Checking the Accessories …………………………………………………… Names and Functions of the Printer Components ……………………… Functions of Each Section …………………………………………………... - Page 5 SECTION 5. TROUBLESHOOTING ………………………… In Case of the Red LEDs Lighting ………………………………………… In Case of Paper Congestion ……………………………………………… In Case of a Power Interruption during Printing ……………………… In Case of a Paper-Loading Failure ……………………………………… In Case the ribbon has been torn ………………………………………… 5-10 SECTION 6. AFTER-SALE SERVICE ……………………… (ii)
-
Page 6: Section 1. For Safe Machine Usage
SECTION 1. FOR SAFE MACHINE USAGE This operating manual is intended for the user to operate the machine safely. Before operating the machine, read this operating manual and the manual accompanying the machine and thoroughly understand its proper installing and operating methods. ◆This operating manual includes the precautions for avoiding the possible hazards. -
Page 7: Operating Environment And Installation
SECTION 1. FOR SAFE MACHINE USAGE Operating Environment and Installation Strictly observe the following precautions to ensure safe use of this color printer: CAUTION: Do not allow children to touch the machine or to tamper with any cables. Failure to observe this precaution could result in injury and/or electrical shock. -
Page 8: Handling The Printer
After this, please contact your product dealer or Shinko Electric's product maintenance service or sales representative. Continued use of the dropped or damaged product may result in fire and/or electrical shock. - Page 9 If the proper grounding connection is not possible, please consult with your product dealer or Shinko Electric's product maintenance service or sales representative.
-
Page 10: Handling The Consumable Parts/Materials And Printed Photos
SECTION 1. FOR SAFE MACHINE USAGE Handling the Consumable Parts/Materials and Printed Photos Observe the following precautions when handling ink ribbons, print paper, and printed photos: NOTICE: When handling print paper ･Use the manufacturer-specified paper. ･Store the paper in a horizontal position. ･Avoid exposure to moisture, and store paper horizontally in a place free from direct sunlight. - Page 11 SECTION 1. FOR SAFE MACHINE USAGE （ MEMO）...
-
Page 12: Section 2. Installation And Setup
SECTION 2. INSTALLATION AND SETUP Procedure from Unpacking to Setup This section lays down the procedure from unpacking this product to setting it up for operation. If you have not yet read Section 1, FOR SAFE MACHINE USAGE, first return to Section 1 and read it before going into this section (Section 2). -
Page 13: Checking The Accessories
SECTION 2. INSTALLATION AND SETUP Checking the Accessories After removing the accessories from the package, make sure that there are no missing accessories. The printer comes with the following accessories: Ink ribbon cassette Trim Box Paper flange assembly This operating manual Instruction sheet Power cable... -
Page 14: Names And Functions Of The Printer Components
SECTION 2. INSTALLATION AND SETUP Names and Functions of the Printer Components Front view Operations panel Ribbon cassette cover Paper storage unit Lever Rear view USB connector Power switch Power connector... -
Page 15: Internal View
SECTION 2. INSTALLATION AND SETUP Internal view Ink ribbon Ink ribbon cassette Paper flange assembly Ink ribbon identification Paper card insertion slot Trim Box... -
Page 16: Functions Of Each Section
SECTION 2. INSTALLATION AND SETUP Functions of Each Section Name of component Function When the cover of this storage unit is open, it is possible to replace the paper with new paper, or Paper storage unit in case of paper congestion, to remove any fragments of the paper, or to conduct other maintenance operations. -
Page 17: Setting An Ink Ribbon
SECTION 2. INSTALLATION AND SETUP Setting an Ink Ribbon １ ．Open the ribbon cassette cover by holding the upper corners with both hands and pulling the top downward to the front. NOTICE: Do not abruptly open the ribbon cassette cover or open it to an angle of 90 degrees or ２... - Page 18 SECTION 2. INSTALLATION AND SETUP Supply side ４ ． Set a new ink ribbon in the ink ribbon cassette that supply side of the ribbon (that is, the side where the new ribbon is wound) and the geared side face in the directions shown in the photo.
- Page 19 SECTION 2. INSTALLATION AND SETUP ６ ． While holding the grip of the ink ribbon cassette, fully set the cassette in the printer with the supply side of the ink ribbon facing toward you. ７ ． Close the ribbon cassette cover by holding the center top edge of the cover and fully pushing the top edge upward.
- Page 20 SECTION 2. INSTALLATION AND SETUP Setting Flange Size １ ． By pulling the knob (green) on of the gray Knob flange, the lock will be released. After releasing the lock, remove the gray flange. Flange ２ ． Push the stopper of the black flange with shaft inside and remove the core flange.
- Page 21 SECTION 2. INSTALLATION AND SETUP ４ ． Push the stopper of the gray flange inside and remove the core flange. ５ ． Set the size indication (L, PC) on the core flange to the arrow on the flange and insert the core flange until it clicks.
-
Page 22: Setting Print Paper And The Ink Ribbon Identification Card
SECTION 2. INSTALLATION AND SETUP Setting Print Paper and the Ink Ribbon Identification Card １．First, collect paper into the paper supply section of the printer as follows: If the printer contains paper, press the PAPER REWIND button operations panel. The paper will be collected automat- ically. - Page 23 SECTION 2. INSTALLATION AND SETUP ４ ．Remove the paper flange assembly with the used paper remaining mountedc Knob Pulling the knob at one end of the gray ５． flange releases the lock. Unlock the other end of the flange in the same manner.
- Page 24 SECTION 2. INSTALLATION AND SETUP ７ ． Thread the paper onto the shaft of the black flange (match the direction of the paper flange assembly to the label on the flange.) label ８ ． Thread the gray flange onto the other s aide.
- Page 25 SECTION 2. INSTALLATION AND SETUP １ ０ ． Holding the geared section of the gray flange, push the shaft knob of the black flange until you have heard a “click “sound. Shaft knob Flange (Gray) １ １ ． Set the new paper in the direction shown int the photo.
- Page 26 SECTION 2. INSTALLATION AND SETUP １ ３ ． Detach the label holding the leading end of the paper. Print side １ ４ ． Remove the ink ribbon identification card mounted ribbon wrapping plastic bag. Hold removed ribbon identification card so that the printed surface of the card faces to the left, and insert the card in the direction of the arrow.
-
Page 27: Connecting The Power Cable
If the proper grounding connection is not possible, please consult with your product dealer or Shinko Electric's product maintenance service or sales representative. WARNING: Connect the power plug properly. - Page 28 SECTION 2. INSTALLATION AND SETUP WARNING: If this product is not to be used for a long period, be sure to disconnect the power cord from the power outlet to ensure safety. WARNING: Avoid connecting the power cord to any power outlet being used for other purposes.
-
Page 29: Connecting The Usb Cable
SECTION 2. INSTALLATION AND SETUP Connecting the USB Cable Connect the USB cable between your personal computer and the USB connector at the rear left of the printer. Connect the USB cable properly. NOTICE: Before disconnecting the USB cable from the printer, make sure that the printer is in a ready status for printing. - Page 30 SECTION 2. INSTALLATION AND SETUP （MEMO） 2-19...
-
Page 31: Section 3. Operations Panel Usage
SECTION 3. OPERATIONS PANEL USAGE Power Switch The power switch is located at the rear left of the printer. A press of the "|" section turns power on, and a press of the "o" section turns power off. ○ ｜ Operations Panel As shown below, one button and five LED indicators are arranged on the operations panel. -
Page 32: Led Indicators
SECTION 3. OPERATIONS PANEL USAGE LED Indicators The LED indicators light to indicate the states listed below. Name of the Color Description POWER Orange Lights to indicate that power is on. Lights to indicate that printing is READY Green possible. PAPER Lights to indicate that a printer error has occurred. - Page 33 SECTION 3. OPERATIONS PANEL USAGE （ MEMO）...
-
Page 34: Section 4. Routine Maintenance
In such a case, immediately turn off the power switch and after disconnecting the power cable from the power outlet, please contact your product dealer or Shinko Electric's product maintenance service or sales representative. CAUTION: Wiping with a volatile solvent such as benzene or thinner, or the application of an insecticide causes discoloration, cracking, or other defects. - Page 35 SECTION 4. ROUTINE MAINTENANCE （ MEMO）...
-
Page 36: Section 5. Troubleshooting
○ ＊ ○ is not set. The movable section or Repairing is likely to be control circuit board of required. the printer is abnormal. Please contact your Shinko ○ ○ ● Electric product service representative. The ribbon cassette cover or... -
Page 37: In Case Of Paper Congestion
SECTION 5. TROUBLESHOOTING In Case of Paper Congestion １ ． Turn off the power switch. ２ ． Open the paper storage unit at the front bottom of the printer by lifting the lever at the bottom of the storage unit and pulling the unit out to the front. - Page 38 SECTION 5. TROUBLESHOOTING ４ ． Cut any wrinkled or printed sections of the paper using scissors. If wrinkled or printed paper is used as it is, paper congestion will recur or the ribbon will break. ５ ．Remove the paper from the paper flange assembly as directed in Section 2, INSTALLATION AND SETUP.
- Page 39 SECTION 5. TROUBLESHOOTING ７ ．Set the paper in the paper flange assembly as directed in Section 2, INSTALLATION AND SETUP. ８ ． Once again, set the paper as directed in Section 2, INSTALLATION AND SETUP. NOTICE: When setting the paper again, securely hold down the leading end of the paper by hand so that no take-up slack occurs.
-
Page 40: In Case Of A Power Interruption During Printing
SECTION 5. TROUBLESHOOTING In Case of a Power Interruption during Printing If power is interrupted during printing, the thermal head will remain pressed against the rubber platen roller and if this state is maintained for a long time, the platen roller may deform. - Page 41 SECTION 5. TROUBLESHOOTING ４ ． Remove the clogging paper. Use the troubleshooting procedure in this section (Section 5) to remove the paper. ５ ． Close the paper storage unit by inserting it into the printer until you have heard a "click" sound. NOTICE: Do not open the ribbon cassette cover with power turned off during printing.
-
Page 42: In Case Of A Paper-Loading Failure
SECTION 5. TROUBLESHOOTING In Case of a Paper-Loading Failure If a small deal of paper is set, it may not be loaded into the printer properly. In this case, troubleshoot using the following procedure: １ ． Open the paper storage unit at the front bottom of the printer by pulling the storage unit out to the front while lifting the lever at the bottom of the... - Page 43 SECTION 5. TROUBLESHOOTING ４．Remove any take-up slack of the paper. ５ ． Set the paper in the paper flange assembly as directed in Section 2, INSTALLATION AND SETUP. ６ ． Once again, set the paper as directed in Section 2, INSTALLATION AND SETUP.
- Page 44 SECTION 5. TROUBLESHOOTING 7． Turn the tip (about 10cm) of the paper toward the direction of the arrow and pull it tight. 8． Close the paper storage unit by inserting it into the printer until you have heard a "click" sound.
-
Page 45: In Case The Ribbon Has Been Torn
SECTION 5. TROUBLESHOOTING In case, the Ink ribbon has been torn 1. Open the ribbon cassette cover and, remove the Ink ribbon cassette from the printer. Cut the edge of the Ink ribbon at the geared side (gray color) by scissors. Geared bobbin (gray) 3. - Page 46 SECTION 5. TROUBLESHOOTING 4. Stick the Ink ribbon at the supply side to the geared side ribbon by the tape. Notice: Make sure to stick the Ink ribbon straightly without any rumple. If not, it can be the cause of the problem during printing.
- Page 47 SECTION 5. TROUBLESHOOTING 7. Holding the knob of the ink ribbon cassette, set the cassette into the printer properly with the supply side of the ink ribbon at the front side. 8. Close the ribbon cassette cover by holding the center top edge of the cover. 5-12...
-
Page 48: Section 6. After-Sale Service
SECTION 6. AFTER-SALE SERVICE Please contact your product dealer for repair of the product or for other information. - Page 49 YTE8-J0101E Revision：...
