Page 1: Technical Data
Air Conditioning Technical Data Wall mounted unit EEDEN13-100 FTX-GV... -
Page 3: Table Of Contents
• Indoor Unit • Wall mounted unit • FTX-GV TABLE OF CONTENTS FTX-GV Features ............. 2 Specifications . - Page 4 • Indoor Unit • Wall mounted unit • FTX-GV Features U n i o o r - G V I n d F T X • Online controller (optional): control your indoor unit from any location • Home leave operation maintains the indoor temperature at your...
-
Page 5: Specifications
• Indoor Unit • Wall mounted unit • FTX-GV Specifications 2-1 Technical Specifications FTX50GV FTX60GV FTX71GV Power input Cooling Nom. 0.034 0.040 (2) / 0.040 (3) / 0.040 (4) 0.045 (2) / 0.045 (3) / 0.045 (4) Heating Nom. 0.036 0.045 (2) / 0.045 (3) / 0.045 (4) -
Page 6: Electrical Specifications
• Indoor Unit • Wall mounted unit • FTX-GV Specifications 2-2 Electrical Specifications FTX50GV FTX60GV FTX71GV Power supply Name Phase Frequency Voltage 220-240 Current Nominal running Cooling 0.16 (2) / 0.15 (3) / 0.15 (4) 0.19 (2) / 0.18 (3) / 0.17 (4) 0.21 (2) / 0.20 (3) / 0.19 (4) -
Page 7: Options
• Indoor Unit • Wall mounted unit • FTX-GV Options 3 - 1 Options • Split - Sky Air • Indoor Unit... -
Page 8: Dimensional Drawings
• Indoor Unit • Wall mounted unit • FTX-GV Dimensional drawings 4 - 1 Dimensional Drawings FTX50-60GV Air flow (indoor) (For performance and maintenance) The mark shows piping direction Rear Rear Left Right (Space for maintenance) Min. 50 Min. 50... -
Page 9: Centre Of Gravity
• Indoor Unit • Wall mounted unit • FTX-GV Centre of gravity 5 - 1 Centre of Gravity FTX50-71GV 4D065971B B B • Split - Sky Air • Indoor Unit... -
Page 10: Piping Diagrams
• Indoor Unit • Wall mounted unit • FTX-GV Piping diagrams 6 - 1 Piping Diagrams • Split - Sky Air • Indoor Unit... -
Page 11: Wiring Diagrams
• Indoor Unit • Wall mounted unit • FTX-GV Wiring diagrams 7 - 1 Wiring Diagrams - Single Phase FTX50-71GV Field wiring RECTIFIER Outdoor CAUTION Transmission Note that operation will restart circuit automatically if the main power supply is turned off and then back on again. -
Page 12: Sound Data
• Indoor Unit • Wall mounted unit • FTX-GV Sound data 8 - 1 Sound Pressure Spectrum FTX60GV Cooling Heating Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz) - Page 13 • Indoor Unit • Wall mounted unit • FTX-GV Sound data 8 - 1 Sound Pressure Spectrum FTX71GV Cooling Heating Approximate Approximate threshold hearing threshold hearing for continuous for continuous noise noise 3D051225D 3D051225D Octave band center frequency - IEC (Hz)
