O w n e r ' s I n s t r u c t i o n s
SP-H700/H710/H500
Downloaded From projector-manual.com Samsung Manuals

Advertisement

Table of Contents
loading

Related Manuals for Samsung SP-H700

Summary of Contents for Samsung SP-H700

  • Page 1 O w n e r ' s I n s t r u c t i o n s SP-H700/H710/H500 Downloaded From projector-manual.com Samsung Manuals...

  • Page 2: Table Of Contents

    Restoring the Factory Default Settings ....48 Connecting to VCR/Camcorder/Cable Box ..23 Information ............49 Connecting to DVD ..........24 Connecting to the Digital TV Receiver....25 Setting up the External Input Source ....26 Naming the External Connections ....27 Downloaded From projector-manual.com Samsung Manuals...
  • Page 3 Setting up the PC Environment ......59 Connecting to PC..........60 Automatic Picture Adjustment ......62 Frequency Adjustment ........63 Fine Tuning with the Phase Adjustment ..64 Zooming the Screen ..........65 Reset the PC ............66 Troubleshooting Before Contacting Service Personnel ....68 Downloaded From projector-manual.com Samsung Manuals...

  • Page 4: Features And Design

    User adjustments This unit allows adjustment of each input port. The unit has a reference pattern that can be used for positioning and adjustment. The remote control is backlit to improve usability in a dark environment. Downloaded From projector-manual.com Samsung Manuals...

  • Page 5: Caution On Lamp Use And Replacement

    Caution on Lamp Use This projector produces intense light. Do not stare light source directly. Do not touch the exhaust vent during operation. It can be very hot. Do not expose the unit to rain or moisture. Downloaded From projector-manual.com Samsung Manuals...
  • Page 6 Downloaded From projector-manual.com Samsung Manuals...
  • Page 7 Preparation ......8 Projector and Accessories Installation and Basic Adjustments ..14 Downloaded From projector-manual.com Samsung Manuals...

  • Page 8: Projector And Accessories

    You can adjust screen images up and down within the lens range. 6 6 Zoom Knob Used to enlarge or reduce image size. Accessories Remote Control/ Power Cable Owner's Instructions 2 Batteries Downloaded From projector-manual.com Samsung Manuals...
  • Page 9 This Projector uses a cooling fan system to keep the unit from overheating. Operation of the cooling fan may cause noise, which does not affect the product performance. NOTE No exchange or refund for the noise concern. Downloaded From projector-manual.com Samsung Manuals...

  • Page 10: Rear Side And Cables

    Connected to the Connected to the Connected to the outlet ∏. connection port ˇ. connection port ´. connection port ’. PC Video Cable DVI-D Cable Connected to the Connected to the connection port Ø. connection port ˆ. Downloaded From projector-manual.com Samsung Manuals...

  • Page 11: Remote Control Buttons

    Used to flip or reverse the projected image. 1 1 9 9 INFO (Page 49) Used to check source signals, picture setup, PC screen adjustment and lamp lifespan. 2 2 0 0 EXIT Used to make Menu Screen disappear. Downloaded From projector-manual.com Samsung Manuals...

  • Page 12: Operating The Remote Control

    Select the current (left), or move to setting upper item Inserting Batteries into Remote Control Press on the part of the lid to remove it. Insert two AAA-sized 1.5V batteries by matching +/-. Close the lid. Downloaded From projector-manual.com Samsung Manuals...
  • Page 13 Using Remote Control in Dark Place (LIGHT) Press the LIGHT button of the remote controller for five seconds. The remote control buttons are lit for about 5 seconds and turn off automatically. LIGHT Downloaded From projector-manual.com Samsung Manuals...

  • Page 14: Installation And Basic Adjustments

    Installing Projector in Front of the Screen Install the projector at the viewers’ side. The projector may be installed on the ceiling in front / back side of the screen. NOTE When installing the projector on the ceiling, contact your dealer. Downloaded From projector-manual.com Samsung Manuals...

  • Page 15: Turning On Projector

    Screen display comes up in 30 seconds. When you turn off the projector, the cooling fan stops within 1 minute and 30 seconds. When the cooling fan stops, push the power switch toward "O" and unplug the power cord. NOTE Downloaded From projector-manual.com Samsung Manuals...

  • Page 16: Zooming And Focus Adjustment

    You can adjust the size of image within zoom range by manipulating the Zoom Knob. Focus the picture on the screen using the Focus Ring. Zoom Knob Focus Ring Focus may appear dim if the projector is installed at a shorter than recommended distance. (Page 20) NOTE Downloaded From projector-manual.com Samsung Manuals...

  • Page 17: Leveling With Adjustable Feet

    For level placing of the projector, adjust the Adjustable Feet of the projector. Adjustable Feet You may adjust the level of the projector up to 5 degrees. Depending on the position of the projector, Keystone distortion of image may appear. (Page 46) NOTE Downloaded From projector-manual.com Samsung Manuals...

  • Page 18: Using The Lens Shift Dial

    Using the Lens Shift Dial Move the picture projected on the screen up and down within the lens range by turning the Lens Shift Dial on the top side of the projector with your fingers. Lens Shift Dial DOWN Downloaded From projector-manual.com Samsung Manuals...

  • Page 19: Screen Size And Projection Distance

    1.4/4.5 3.2/1.3 This projector is designed to show images optimally on a 80 to 150 inch sized screen. NOTE Screen Screen Z : Throw Distance Z' : Distance from Lens Center to Image Bottom NOTE Downloaded From projector-manual.com Samsung Manuals...
  • Page 20 1.7/5.6 5.0/2.0 This projector is designed to show images optimally on a 80 to 150 inch sized screen. NOTE Screen Screen Z : Throw Distance Z' : Distance from Lens Center to Image Bottom NOTE Downloaded From projector-manual.com Samsung Manuals...

  • Page 21: Connections And Source Setup

    Connections and Source Setup ........22 Before Connections Connecting to Video Equipment ....23 Setting up the External Input Source ..26 Naming the External Connections ....27 Downloaded From projector-manual.com Samsung Manuals...

  • Page 22: Before Connections

    3. Check the type of ports the projector is connected to. Refer to "Rear Side and Cables" on page 10 for cables used for connection. Downloaded From projector-manual.com Samsung Manuals...

  • Page 23: Connecting To Video Equipment

    When Composite Mode is not available, check the video cables are in place. Check that the projector and the video equipment are turned off before connecting NOTE cables. This projector does not support sound. (Separate audio system is needed for sound.) Downloaded From projector-manual.com Samsung Manuals...

  • Page 24: Connecting To Dvd

    Component2 if COMPONENT2 is connected. When Component Mode is not available, check that the component cables are in place. Component Ports are marked as (Y, Pb,Pr), (Y, B-Y, R-Y) or (Y, Cb, Cr) depending on NOTE the manufacturer. Downloaded From projector-manual.com Samsung Manuals...

  • Page 25: Connecting To The Digital Tv Receiver

    If the receiver is connected to DVI or PC port, press the DVI or PC button to select DVI or PC respectively. When Component Mode is not available, check that the component cables are in place. Downloaded From projector-manual.com Samsung Manuals...

  • Page 26: Setting Up The External Input Source

    : - - - - : - - - - If the input mode is not selected, check that cables are in place. : - - - - Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 27: Naming The External Connections

    Cable √ Composite : - - - - √ : - - - - Satellite √ : - - - - AV Receiver † Press the EXIT button to exit the menu. Move Enter Return Downloaded From projector-manual.com Samsung Manuals...
  • Page 28 Downloaded From projector-manual.com Samsung Manuals...

  • Page 29: Picture Adjustment

    Changing the Color Standard ....32 Selecting and Adjusting Color Temperature ..........33 Gamma Correction ........34 Saving Custom Picture Settings ....35 Setting up DNIe ..........36 Selecting Picture Size........37 Screen Position Adjustment ......39 Film Mode ............40 Overscan ............41 Still Picture ..........42 Downloaded From projector-manual.com Samsung Manuals...

  • Page 30: Selecting Picture Mode

    Options are designed Gamma NOTE Modes Temperature for setup and storage of various users’ Dynamic 9300K Gamma Mode3: Graphic Mode customized picture Standard 8000K Gamma Mode2: Video Mode modes. Movie1 6500K Gamma Mode1: Film Mode Movie2 5500K Downloaded From projector-manual.com Samsung Manuals...

  • Page 31: Custom Settings Of The Picture

    NOTE COMPONENT1 and Color Used to adjust color lighter or deeper. COMPONENT2 are set Tint Used to obtain more natural color of objects at 480p, 720p and using Green or Red enhancement. 1080i. Downloaded From projector-manual.com Samsung Manuals...

  • Page 32: Changing The Color Standard

    Save The Color Standard menu is displayed. Move Enter Return Press the œ or √ button to adjust the selected Color Standard item. SMPTE_C Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 33: Selecting And Adjusting Color Temperature

    Press the L or M buttons to select an option then button. Press the œ or √ buttons to press the … adjust the selected item. R-Gain † A separate adjustment window appears for making the adjustment. Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 34: Gamma Correction

    Gamma : Gamma Mode1 Gamma Mode1 Save Gamma Mode2 Gamma Mode3 Move Enter Return Press the EXIT button to exit the menu. Refer to page 30 for information on Gamma NOTE Mode1, 2, and 3. Downloaded From projector-manual.com Samsung Manuals...

  • Page 35: Saving Custom Picture Settings

    Save Current Setting to User1? Cancel Move Enter Return Press the EXIT button to exit the menu. The User1, User2 and User3 modes are saved differently according to external input sources (Component1/ Component2/ NOTE S-Video/Composite/PC/DVI). Downloaded From projector-manual.com Samsung Manuals...

  • Page 36: Setting Up Dnle

    Setting up DNIe DNIe (Digital Natural Image engine) is an image enhancing function developed by Samsung Electronics. It enables users to enjoy brighter, sharper and more dynamic pictures. MENU Select 2, 3, 4 …/† 2, 3, 4 EXIT Press the MENU button.

  • Page 37: Selecting Picture Size

    Full Setup is switched to the selected mode. Position Zoom1 Zoom2 DNIe : Off 4 : 3 Film Mode : On Overscan : On Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...
  • Page 38 Supported Picture Sizes O : Supported Modes X : Unsupported Modes Refer to page 58 for display modes supported. NOTE Downloaded From projector-manual.com Samsung Manuals...

  • Page 39: Screen Position Adjustment

    † Move Return Press the EXIT button to exit the menu. The respective position information is set and NOTE stored automatically to the corresponding external input modes (Component1,2 / S-Video, Composite / PC / DVI). Downloaded From projector-manual.com Samsung Manuals...

  • Page 40: Film Mode

    : Full Setup is switched to the selected mode. √ Position √ DNIe : Off √ Film Mode : On √ Overscan : On Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 41: Overscan

    : Full √ Position Setup is switched to the selected mode. √ DNIe : Off √ Film Mode : On √ Overscan : On Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 42: Still Picture

    Still Picture Used to pause playback to see a still picture. Press the STILL button. Each press of the button pauses and resumes play back. One Touch Downloaded From projector-manual.com Samsung Manuals...

  • Page 43: Setup

    Setup ..44 Flipping/Reversal of Projected Image Light Setting ..........45 Correcting Vertical Keystone ....46 Test Patterns ..........47 Restoring the Factory Default Settings..48 Information ..........49 Downloaded From projector-manual.com Samsung Manuals...

  • Page 44: Flipping/Reversing The Projected Image

    This function is used to Install Menu set up reversed image NOTE projection for ceiling Front-Floor Normal Image installation. To install Front-Ceiling Horizontally Reversed Image projector, refer to page Rear-Floor Vertically Reversed Image Rear-Ceiling Horizontal/Vertical Reversed Image Downloaded From projector-manual.com Samsung Manuals...

  • Page 45: Light Setting

    Used to reduce the brightness of the lamp in dark ambient light to prevent reflection in the eye. It also lowers power consumption and extends the life of the lamp. Bright Used to enhance the brightness in relatively bright ambient light. Downloaded From projector-manual.com Samsung Manuals...

  • Page 46: Correcting Vertical Keystone

    Press the EXIT button to exit the menu. V-Keystone V-Keystone corrects distortion of picture NOTE image by software. It is better to install the projector properly to avoid distortion instead of using the V-Keystone feature. Downloaded From projector-manual.com Samsung Manuals...

  • Page 47: Test Patterns

    Blue Screen, only for color adjustment. color adjustment White White Screen, only for color adjustment. procedures, and may 6500K_White White Screen, shows brightest white color possible. not comply with the actual colors displayed during video playback. Downloaded From projector-manual.com Samsung Manuals...

  • Page 48: Restoring The Factory Default Settings

    Back to Factory Default setting? press the button. Cancel Setting values are returned to factory defaults. Move Enter Return Press the EXIT button to exit the menu. User settings including Edit Name and Custom NOTE Picture will be reset. Downloaded From projector-manual.com Samsung Manuals...

  • Page 49: Information

    Color Temperature : 6500K Coarse : 1344 R-Gain : 50 Fine : 101 G-Gain : 50 Resolution : 1024X768 B-Gain : 50 H-Frequency : 31KHz R-Offset V-Frequency : 70Hz G-Offset Lamp Time : 0 Hour B-Offset Downloaded From projector-manual.com Samsung Manuals...
  • Page 50 Downloaded From projector-manual.com Samsung Manuals...
  • Page 51 Menu Option Setting the Language........52 Setting the Menu Position......53 Setting the Menu Translucency ....54 Setting the Menu Display Time....55 Selecting the Quick Menu ......56 Downloaded From projector-manual.com Samsung Manuals...

  • Page 52: Menu Option

    Menu Translucency : Opaque Español language, then press the button. Menu Display Time : 120 Sec Français Italiano Setup is switched to the selected language. Svenska † Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 53: Setting The Menu Position

    Press the L, M, œ, or √ button to move to … desired position. œ √ The menu screen is displayed on the given position. † Move Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 54: Setting The Menu Translucency

    Menu Position Menu Translucency : Opaque Opaque Setup is switched to the selected mode. Menu Display Time : 120 Sec High Medium Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 55: Setting The Menu Display Time

    Menu Position Menu Translucency : Opaque Setup is switched to the selected time. Menu Display Time : 120 Sec Stay On Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 56: Selecting Quick Menu

    Selecting the Quick Menu Press the QUICK button. The menu you used previously will appear. One Touch Downloaded From projector-manual.com Samsung Manuals...

  • Page 57: Connecting To Pc

    ......58 Before Connecting to PC Setting up the PC Environment....59 Connecting to PC ........60 Automatic Picture Adjustment ....62 Frequency Adjustment ........63 Fine Tuning with the Phase Adjustment..64 Zooming the Screen ........65 Reset the PC ..........66 Downloaded From projector-manual.com Samsung Manuals...

  • Page 58: Before Connecting To Pc

    720 x 576i 864 x 625 15.625 13.5 The table complies to IBM/VESA requirements and is based on analog signal input. NOTE Refer to "Rear Side and Cables" on page 10 for cables used for connection. Downloaded From projector-manual.com Samsung Manuals...

  • Page 59: Setting Up The Pc Environment

    SOURCE button or check that PC is properly connected. When connecting the projector to PC (including DVI connection), check that PC setup complies to display settings supported by this projector. If not, there may be signal problems. Downloaded From projector-manual.com Samsung Manuals...

  • Page 60: Connecting To Pc

    Enjoy better picture quality by using DVI-D cable (supports digital signals only) instead of PC Video cable. NOTE DVI-I cable (supports analog signals) is not supported. Use DVD-D cable. Sound comes out from PC speakers. Downloaded From projector-manual.com Samsung Manuals...
  • Page 61 T.M.D.S. DATA3- T.M.D.S. Clock- Horizontal Sync Vertical Sync Clock (DDC) DVI-D cable does not support VESA Plug & Play analog RGB signals. CAUTION This appliance supports VESA Plug & Play and recognizes connection to PC automatically. Downloaded From projector-manual.com Samsung Manuals...

  • Page 62: Automatic Picture Adjustment

    Auto Adjustment in progress message is displayed and PC Fine screen is adjusted automatically. √ Zoom √ Reset Move Enter Return Press the EXIT button to exit the menu. Auto Adjustment in Progress.. Please Wait Downloaded From projector-manual.com Samsung Manuals...

  • Page 63: Frequency Adjustment

    Press the L or M button to move to Coarse, then Coarse 1344 Fine press the button. √ Zoom Press the œ or √ button to adjust. √ Reset Move Enter Return Press the EXIT button to exit the menu. … Coarse 1344 † Downloaded From projector-manual.com Samsung Manuals...

  • Page 64: Fine Tuning With The Phase Adjustment

    Press the L or M button to move to Fine, then Coarse 1344 Fine press the button. √ Zoom Press the œ or √ button to adjust. √ Reset Move Enter Return Press the EXIT button to exit the menu. … Fine † Downloaded From projector-manual.com Samsung Manuals...

  • Page 65: Zooming The Screen

    Press the L, M, œ, or √ button to move to desired position, then press the button to extend as you want. The screen can be extended by 1, 2, 4, or 8 times. Move Zoom Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 66: Reset The Pc

    Press the œ or √ button to move to OK, then Back to Default Settings? press the button. Cancel The PC is reset to the time of purchasing. Move Enter Return Press the EXIT button to exit the menu. Downloaded From projector-manual.com Samsung Manuals...

  • Page 67: Troubleshooting

    Troubleshooting Before Contacting Service Personnel..68 Downloaded From projector-manual.com Samsung Manuals...

  • Page 68: Before Contacting Service Personnel

    Some of Menu functions Refer to the user manual. Some functions are locked Pages do not work. depending on sources and type of the input signal. 23~26 Downloaded From projector-manual.com Samsung Manuals...
  • Page 69 Adjustable items of the Custom Picture Menu are Page 31 black and white or properly set. odd color/screen is too Execute Factory Default if you want to restore the factory Page 48 dark or bright. default setting values. Downloaded From projector-manual.com Samsung Manuals...
  • Page 70 Downloaded From projector-manual.com Samsung Manuals...

  • Page 71: Other Information

    Other Information ......72 Storage and Maintenance Purchasing Optional Parts ......73 Structure of Screen Menu ......74 Lamp Replacement ........77 RS-232C Connection and Control ....78 Specifications ..........80 Remote Control Specifications ....81 Downloaded From projector-manual.com Samsung Manuals...

  • Page 72: Storage And Maintenance

    It may leave scratches. Cleaning the Inside of the Projector Contact your dealer or service personnel to clean the inside of the projector. Contact your dealer if particles or other objects are stuck inside of the projector. Downloaded From projector-manual.com Samsung Manuals...

  • Page 73: Purchasing Optional Parts

    You can purchase at electronics shops or over the Internet. Video (Composite) Cable S-Video Cable Component Cable PC Video Cable 1.5V AAA Batteries You can purchase at electronics shops or over the Internet. Or you can call your dealer or service center. Downloaded From projector-manual.com Samsung Manuals...

  • Page 74: Structure Of Screen Menu

    0 ~ 100 (Not supported in 480p mode or above) Color Standard SMPTE_C/HD/EBU Color Temperature 5500K / 6500K / 8000K / 9300K Gamma Gamma Mode1 / Gamma Mode2 / Gamma Mode3 Save User1 / User2 / User3 Downloaded From projector-manual.com Samsung Manuals...
  • Page 75 Front-Floor / Front-Ceiling / Rear-Floor / Rear-Ceiling Light Setting Theater Bright V-Keystone -50 ~ 50 Test Pattern Crosshatch Screen Size Color Standard Green Blue White 6500K_White Auto Adjustment Coarse Fine Zoom Reset OK / Cancel Factory Default OK / Cancel Information Downloaded From projector-manual.com Samsung Manuals...
  • Page 76 English / Deutsch / Nederlands / Español / Français / Italiano / Svenska / Português / Menu Position Menu Translucency Opaque / High / Medium / Low Menu Display Time 5 / 10 / 30 / 60 / 90 / 120 / Stay On Downloaded From projector-manual.com Samsung Manuals...

  • Page 77: Lamp Replacement

    NOTE pressure product. Wait for at least 30 minutes to proceed after disconnecting power. Be sure that the power cord is disconnected before proceeding. Downloaded From projector-manual.com Samsung Manuals...

  • Page 78: Rs-232C Connection And Control

    Computer nor will it be displayed on the Projector’s screen. Transmit the INFORMATION command to display the current information on the Projector’s screen. All the control commands apply to the input source and the Projector’s status currently displayed. Downloaded From projector-manual.com Samsung Manuals...
  • Page 79 Menu Display Time Stay On 10,3,6 Picture Size Full 2,9,0 10,3,0 Zoom1 2,9,2 10,3,1 Zoom2 2,9,3 10,3,2 10,3,3 2,9,4 10,3,4 Position 2,13,0 10,3,5 Down 2,13,1 Menu EXIT Left 2,13,2 Right 2,13,3 DNIe 0,1,1 0,1,0 Demo 0,1,2 Downloaded From projector-manual.com Samsung Manuals...

  • Page 80: Specifications

    The DMD Panel used in DLP Projectors consists of several hundred thousand micro mirrors. As with other visual display elements, the DMD Panel may include a few bad pixels. Samsung and the DMD Panel manufacturer have a rigid, bad pixel identification and limitation procedure in place and products will not exceed the maximum number of bad pixels set by our standards.

  • Page 81: Remote Control Specifications

    Remote Control Specifications Function and Transmission Codes Remote Control Signal Format /Data Code LEADER PULSE System Code System Code Data Code (Reverse Data Code) 4.5msec 4.5msec Data /Data (Reverse Data) Downloaded From projector-manual.com Samsung Manuals...
  • Page 82 Memo Downloaded From projector-manual.com Samsung Manuals...
  • Page 83 Memo Downloaded From projector-manual.com Samsung Manuals...
