2.7.2

Rear Panel Ports

The rear panel includes the notebook's main ports and connectors. See
Figure 2-8.
1
1 DC-in Port
2 PS/2 Port
3 Serial Port
4 Parallel Port
Figure 2-8
2-26
2
3
4
5

Rear Panel Ports

6
7
8
5 Mini Dock Connector
6 External CRT Port
7 RJ-11 Phone Jack
8 Infrared Port
