2.7

Ports

Ports allow you to connect peripheral devices to your notebook computer as
you would with a desktop PC. The ports are found on the left and rear panel.
The following sections discuss these ports and their functions.
2.7.1

Left Panel Ports

Multimedia ports and the PC card slots are found on the left panel. See
Figure 2-7.
1 PC Card Slots
2 Microphone-in/Line-in Port
3 Speaker-out/Line-out Port
Figure 2-7
System Tour
See Chapter 4 on how to connect external devices to the
notebook.
1 2 3

Left Panel Ports

2-23
