EBM 2.1
Spinnit
R
USER'S MANUAL
Before operating this equipment, please read these
instructions completely and keep these operating
instructions for future reference.
-
Manual Paper Drill
485 Hague Street, Rochester, NY 14606 U.S.A.
Tel: 585-436-1934
www.lasscowizer.com
Serial Number:
Date of Purchase:
Dealer:
Address:
Telephone Number:
Fax: 585-464-8665
info@lasscowizer.com
Advertisement
Table of Contents
Related Manuals for Lassco Spinnit EBM 2.1
Summary of Contents for Lassco Spinnit EBM 2.1
- Page 1 EBM 2.1 Spinnit Manual Paper Drill USER’S MANUAL Serial Number: Date of Purchase: Dealer: Address: Before operating this equipment, please read these instructions completely and keep these operating instructions for future reference. Telephone Number: 485 Hague Street, Rochester, NY 14606 U.S.A. Tel: 585-436-1934 Fax: 585-464-8665 www.lasscowizer.com...
-
Page 2: Table Of Contents
Page 03 future use. Grounding Instructions......Page 04 For parts and service, please contact the Lassco-Wizer Dealer from whom you purchased the machine. If you 3 - Setting Up Your Machine require assistance in locating a Lassco-Wizer Dealer Loose Items Inventory...... -
Page 3: Safety
2 - Safety 2.1 - Safety Instructions All operators must read and understand the Users KEEP CHILDREN AWAY. All visitors should be kept a safe Manual including all safety instructions before using this distance from the work area. equipment. Failure to fully understand the safety instructions can result in personal injury. -
Page 4: Warning Labels
2 - Safety 2.2 - Warning Labels English French WARNING: DO NOT EXPOSE TO RAIN AVERTISSEMENT: NE PAS EXPOSER OR USE IN DAMP LOCATIONS. À LA PLUIE ET NE PAS UTILISER DANS LES EMPLACEMENTS HUMIDES Page 03... -
Page 5: Grounding Instructions
2.3 - Grounding Instructions Diagram 2-10 METAL SCREW COVER OF GROUNDED OUTLET BOX GROUNDING In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conductor and a grounding plug. -
Page 6: Setting Up Your Machine
50-35: 5/16”-18 Elastic EBM-76: Black Fiber Stop Nut (1) Washer (1) 3.2 - Accessories Warning USE RECOMMENDED ACCESSORIES. Only use accessories approved by a Lassco-Wizer. The use of improper acces- sories may cause risk of injury to persons. Page 05... -
Page 7: Installing The Table Assembly
3 - Setting Up Your Machine 3.3 - Installing the Table Assembly 3.3.1 Grasping the Table and depressing the Release Handles to unlock Diagram 3-10 the Release Pin, slide the V-Bars located on the underside of the Table into the V-Rollers on the Base of the machine as shown. 3.3.2 Please note that one of the Table Stops (EZ-1014) comes in- stalled. -
Page 8: Assembly And Installation Of The Back-Gauge
3 - Setting Up Your Machine 3.4 - Assembly and Installation of the Back-gauge 3.4.1 Assemble the Backgauge by placing the Black Fiber Washer (EBM-76) over the Threaded Stud. Place the Clamp Bracket (EZ-1028) on the Threaded Stud with the knob end toward the center of the assembly. Tighten the Elastic Stop Nut on the Threaded Stud with a wrench until it is snug, allowing the Clamp Bracket to move with slight resis- tance. -
Page 9: Installing The Chip Bag
3 - Setting Up Your Machine 3.6 - Installing the Chip Bag 3.6.1 Attach the chip bag as shown by stretching the open end over the Diagram 3-90 top hook of the chip chute. Continue fitting it around the entire edge of the chip chute making sure it is snug. -
Page 10: Operation
4 - Operation 4.1 - Protective Guard 4.1.1 Your EBM-2.1 comes with a protective guard installed. DO NOT Diagram 4-10 operate this machine without the guard in place. 4.1.2 Please note that when you are performing certain operations such as removing and installing drill bits, you will need to move the guard out of the way. -
Page 11: Leveling The Drill Bits
4 - Operation 4.3 - Leveling the Drill Bits 4.3.1 We recommend using a piece of card stock on the Table when Diagram 4-40 leveling the drill bits to avoid drilling into the drill strip. This will lengthen the life of your drill bits and keep them sharper. 4.3.2 To level the drill bit to the Table follow steps 4.3.3 through 4.3.5. -
Page 12: Drilling Procedures
4 - Operation 4.5 - Drilling Procedures 4.5.1 When you are ready to drill, set the product to be drilled on the Diagram 4-60 table and make sure it is secure using the Paper Side Stops. Turn the machine on and holding the product firmly in place with one hand, pull down on the Handle raising the Table up to meet the drill bit. -
Page 13: Maintenance
5 - Maintenance 5.1 - Safety ALWAYS DISCONNECT THE POWER BEFORE PERFORMING MAINTENANCE ON THIS MACHINE. MAINTENANCE SHOULD ONLY BE PERFORMED BY A QUALIFIED TECHNICIAN. 5.2 - Annual Lubrication 5.2.1 Lubricating your EBM-2.1 should be done at least once every 12 months;... -
Page 14: Trouble Shooting Guide
6 - Trouble Shooting Guide 6.1 - Determining the Cause and Correction to Certain Problems Problem Cause Correction Drill bit not concentric. Foreign material in chuck or in Inspect and clean. drill plug. Drill bit is bent. Replace drill bit. Drill bit not seated in chuck Reinsert drill bit correctly. -
Page 15: Parts Diagrams
7 - Parts Diagrams 7.1 - Front, Rear, and Side Views Page 14... -
Page 16: Internal Views
7 - Parts Diagrams 7.2 - Internal Views Page 15... -
Page 17: Parts List
7 - Parts Diagrams 7.3 - Parts List EZ-108A: Handle Assembly FM5-5006: Rocker Switch (On/Off) EZ-117A: Shroud Assembly FMM5-5514: Chuck FM5-5011: Chuck Release Guard Hollow Drill Bit EBM2-0111A: Pressure Foot Assembly 3S-14: Table Scale EZ-1010L: Table Release Handle (Left) EZ-1010R: Table Release Handle (Right) EBM-44A: Channel Guard FM4-4007: Paper Side Stop Knob (Table Height Adjustment Knob) EZ-1034: Table Guide...
