- Page 1 RANGE HOODS E-250 - E-260 - E-270 INSTALLATION GUIDE...
- Page 3 INSTALLATION GUIDE E-250, E-260, E-270. 1 - MINIMUM DISTANCE Before to install the hood , please, ensure, that there is a minimum distance of 210 mm bet- ween the CEILING and the false ceiling. Please note that the maximum distance between the FALSE CEILING and the FLOOR should be no more than 2.40 m.
- Page 4 On the solid ceiling , draw the outline of the hole required to house the extractor hood based in the chosen model. The models E-250,E-260, E-270 are supplied with threaded rods which screw into the frame. The adjusting nuts can be used to set the required height for the extractor hood ( between 210mm and 370mm).
- Page 5 (Ø200) outlets , one on the front and other on the side. It also has Ø150 or Ø200 outlet on the top of the extractor hood for vertical pipe installations. Power connection: The model E-250, E-260, E-270 has one cable for the mains power con- nection and another cable to connect the motor.
- Page 6 INSTALLATION GUIDE E-250, E-260, E-270. 5– POSITIONING AND SECURING THE EXTRACTOR HOOD Once the connections are completed, we can then lift the hood and insert it in the correct posi- tion inside the hole. Before doing so, we must open the doors of the hood and remove the filters.
- Page 7 INSTALLATION GUIDE E-250, E-260, E-270. COMMISSIONING: After opening the doors and removing the filters, we can see the connection box. The ON switch for the extractor hood is opposite the connection box. If all the ceiling connections with the external or roof motor have been completed, we may start up the hood.
- Page 8 E-220 INSTALLATION GUIDE SYNCRONIZATION OF THE REMOTE CONTROL (ceiling hoods E-200/210 series) Light * switch/ diferencial case ¡¡¡Important!!! When the hood is installed and the differencial case is switched on, before 20 seconds pass, please keep pressed the button “light” until the lights of the hood swith on. This way the hood records the operating frequency of the remote control and toperating of the hood is correct.
- Page 9 The ceiling where the extractor hood is to be installed must be completely flat, with no uneeven • areas of any kind. For optional operation of the models E-250,E-260, E-270 , ventilation grilles must be installed at • ground level to ensure a continious flow of air..
- Page 10 Corian version remote control. User Instructions. 4 5 6 1. Hood motor on and off. 2. Reduce motor speed. 3. Increase motor speed. 4. Motor timer, keeps the hood on for 10 minutes and then switches it off. 5. Led indicator of control key pressed. Also indicates programming process. 6.
- Page 11 INSTALLATION GUIDE E-250, E-260, E-270. APPENDIX (EXTERNAL MOTORS DEMENSIONS)
- Page 12 Página 10...
