USER MANUAL

GE-Digital Camera
G Series G2
A Series A735
E Series E840s/E1035
A835
E1235

Downloaded From camera-usermanual.com General Electric Manuals

Advertisement

Table of Contents
loading

  Also See for GE G2

GE E1055W User Manual
GE E1055W User Manual 120 pages
GE A1030 User Manual
GE A1030 User Manual 115 pages
GE G Owner's Manual
GE G Owner's Manual 115 pages

  Related Manuals for GE G2

  Summary of Contents for GE G2

  • Page 1: User Manual

    USER MANUAL GE-Digital Camera G Series G2 A Series A735 E Series E840s/E1035 A835 E1235 Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 2 Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 3: Declaration Of Conformity

    FOR HOME OR OFFICE USE Declaration of Conformity FCC Statement Model Name : G2/A735/A835/ This device complies with part 15 of the FCC Rules. E840s/E1035/E1235 Operation is subject to the following two conditions: Trade Name : GE (1) This device may not cause harmful interference, Responsible Party : General Imaging Co.

  • Page 4: Safety Precautions

    In a place where the camera is subject to a high the batteries. magnetic field, e.g. near motors, transformers or • Use GE charger in the package to charge the magnets. lithium battery only (for G and E series). Do not place the camera on a wet surface or...

  • Page 5: Before You Start

    BEFORE YOU START Preface Safety information Thank you for purchasing GE digital cameras. Please read the following important information Please read this manual carefully and keep it in a carefully before using the product. safe place for future reference. • Do not take apart or attempt to service the camera yourself.

  • Page 6: About This Manual

    This manual provides you with instructions on batteries. how to use your GE digital camera. Every effort has been made to ensure that the contents of • Do not use or store the camera in dusty, dirty, or...

  • Page 7: Table Of Contents

    Using the zoom function ......28 GETTING READY ........7 Using the flash ..........29 Unpacking ............7 Using the self-timer........29 Camera Views: G2 ......... 8 Using Macro mode ........30 : A735/A835 .......10 Exposure compensation ......30 : E840s .........12 Advanced function menu ......31 : E1035/E1235 ....16...
  • Page 8 Quality .............33 Landscape ..........43 Size ............34 Night landscape ........43 Color ............35 Night portrait ........43 Return to the scene mode palette ..44 USING THE MODES .......38 Panorama mode..........44 LCD Screen display ........38 Image stabilization mode ......46 Still shooting mode display ....38 Face detection ..........47 Video shooting mode display .....40 PLAYBACK..........48...
  • Page 9 Expo Metering (Exposure Metering).. 56 Slide show ..........67 Cont.Shot (Continuous shot) ....57 Red-eye removal ........68 Grid ............57 Setup menu ..........69 Quick Review .........58 Format Memory ........69 Digital Zoom ..........58 Beep ............70 Histogram ..........59 LCD Brightness ........71 Slow shutter ...........59 Power Saver ...........71 Date Imprint ..........59 Date/Time ..........72 Movie menu ..........60...
  • Page 10 Connecting to a PC ........77 Appendices ..........86 Setting the USB mode ......78 Specifications: Transferring files to your PC ....78 G2 ...............86 Connecting to a PictBridge compatible A735/A835 ..........90 printer ............79 E840s/E1035/E1235 .......94 Setting the USB mode ......80 Error messages .........100 Using the PictBridge menu .......82...

  • Page 11: Getting Ready

    GETTING READY Unpacking Your package should contain the camera model you purchased along with the following items. If anything is missing or appears to be damaged, please contact your vendor. (The accessories will vary based on model purchased and are noted below.) Rechargeable AA-size alkaline User Manual...

  • Page 12: Camera Views: G2

    Camera views : G2 Front View Back View Right View Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 13 Top View Bottom View 13 Self-timer/ Down button Flash 14 Flash mode/ Left button Lens 15 Func/ok button AF assist beam/Timer indicator 16 Speaker LCD screen 17 Zoom scroll wheel Status LED 18 Shutter button Left View Mode dial 19 Power button Face detection AF button 20 Memory card/ Battery compartment...

  • Page 14: A735/A835

    Camera views : A735/A835 Front View Back View Right View Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 15: Bottom View

    Top View Bottom View Flash Self-timer/ Down button Lens Func/ok button Flash mode/ Left button AF assist beam/Timer indicator USB/ AV port Status LED Power button LCD screen Shutter button Left View Face detection AF button Mode dial T&W button Speaker Menu button Tripod mount point...

  • Page 16: E840S

    Camera views : E840s Front View Back View Right View Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 17 Top View Bottom View Self-timer/ Down button Flash Flash mode/ Left button AF assist beam/Timer indicator Func/ok button Lens Speaker LCD screen Power button Face detection AF button Shutter button Left View Status LED Zoom scroll wheel Mode dial Tripod mount point Menu button USB/ AV port 10 Erase button...

  • Page 18: E1035/E1235

    Camera views : E1035/E1235 Front View Back View 10.1 E 1 0 3 5 megapix el Right View Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 19 Top View Bottom View Flash Self-timer/ Down button AF assist beam/Timer indicator Func/ok button Lens Flash mode/ Left button Power button LCD screen Shutter button Face detection AF button Zoom scroll wheel Left View Status LED Speaker Mode dial Tripod mount point Menu button USB/ AV port 10 Erase button...

  • Page 20: Charging The Battery

    2. Plug one end of the connecting cable into model as an example. the charger base. (G2, A735, A835, E840s, and E1235 3. Plug the other end of the connecting cable operate similarly.) into a wall outlet.

  • Page 21: Inserting The Battery

    Inserting the battery 2. Insert the battery while observing 1. Open the battery compartment. the correct polarity. Use the side of battery to press down the stopper as shown, allowing the battery to be inserted properly. Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 22 3. Close the battery compartment. Inserting the battery (A735/A835) 1. Open the battery compartment. Battery capacity decreases with usage. Downloaded From camera-usermanual.com General Electric Manuals...
  • Page 23 2. Insert the battery while observing 3. Close the battery compartment. the correct polarity. Use the side of battery to press down the stopper as shown, allowing the battery to be inserted properly. Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 24: Inserting An Optional Sd/Sdhc Card

    Inserting an optional SD/SDHC card 1. Open the battery compartment. 2. Insert an optional SD/SDHC card into the memory card slot as shown. Optional SD/SDHC cards are not included. The use of 64MB to 4GB memory cards from recognized manufacturers such as SanDisk, Panasonic and Toshiba is recommended for reliable data storage.

  • Page 25: Turning On And Off

    3. Close the battery compartment. Turning on and off Press the Power button to turn the camera on. To turn off the camera, press the Power button again. Power button When turned on, the camera will enter the mode according to the mode dial setting. You can also turn the mode dial to change the modes after the camera is turned on.

  • Page 26: Using The Mode Dial

    Using the Mode Dial The GE camera provides a convenient mode dial that allows you to switch between different modes with ease. All the available modes are listed as follows. Mode Name Icon Description Auto Switch to take still pictures. (The camera uses the default pro- grammed automatic settings.)

  • Page 27: Setting Display Language, Date, And Time

    Setting date/time and language To set the language, date, and time, the following settings need to be configured in the Setup menu. • Date / Time • Display language To access the Setup menu, do the following: 1 .Press Power to turn the camera on. button and use Up/Down/Left/ 2.

  • Page 28: Setting The Language

    2. Press the Left/Right to highlight each field and use the Up/Down to adjust the value. 3. Press the button to confirm the setting. Setting the Language 1. Use the Up/Down to select Language. Then press the Right to enter the setting. 2.

  • Page 29: About The Lcd Screen

    About the LCD screen When you turn the camera on, various icons If the LCD monitor is damaged, take are shown on the LCD screen to indicate the particular care with the liquid crystal in current camera settings and status. To learn the monitor.

  • Page 30: Basic Operation

    BASIC OPERATION Shooting in Auto mode Using the zoom function Auto mode is the easiest mode to take pho- Your camera is equipped with two types of zoom: optical zoom and digital zoom. Use the Zoom tos. While operating in this mode, the camera scroll wheel on the top of the camera to zoom automatically optimizes your photos for best results.

  • Page 31: Using The Flash

    Using the flash Using the self-timer/Multiple shots There are six flash modes. Press the Left/ To enable the self-timer function, press the Flash to cycle through the following flash Down/Self-timer to select 2-second timer modes. delay, 10-second timer delay, or a continuous shot.

  • Page 32: Using Macro Mode

    Using Macro mode Exposure compensation In Macro mode, you can capture tiny details The exposure compensation allows you to of the subject at a very close range. Press the adjust the background brightness to produce Right/Macro to take close-up shots. the best result of photos.

  • Page 33: Advanced Function Menu

    Advanced function menu (quick menu setup) WB (White Balance) 2. Use Up/Down navigation buttons to select the setting you want. The following The white balance allows the user to adjust options are available: the color temperature under different light source to ensure faithful color reproduction. •...

  • Page 34: Iso

    The ISO function allows you to set the camera sensor sensitivity to light. To improve the performance in darker environments, a higher ISO value is required. On the other hand, a lower ISO value is needed when in bright conditions. (The ISO setting is only available when the Manual mode).

  • Page 35: Quality

    Quality 3. Use the Up/Down navigation buttons to select a desired setting. Three options are The quality setting adjusts the compression available. ratio of the images. Higher quality settings give better photos, but will take up more • : Best quality (Standard compression) memory space.

  • Page 36: Size

    Please refer to page 34 for a list of image sizes that are available to the various GE digital camera models Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 37: Color

    Color The color setting allows you to add artistic effects directly when taking shots. You can try different color tones to alter the mood of your pictures. (The Color setting is only available when the Manual mode). camera is in the To set the image color, do the following: button to enter the Function 3.
  • Page 38 • Size settings in shooting mode. (•: available) Model name : Icon File size (Pixels) A735 A835 E840s E1035 E1235 0.3M: • • • • • • 640×480 • • • • • • 1024×768 • • • • • •...
  • Page 39 Model name : Icon File size (Pixels) A735 A835 E840s E1035 E1235 • 3072×2304 7M(3:2): • • • 3264×2176 7M(16:9): • 3648×2052 • • • 3264×2448 9M(3:2): • 3648×2432 9M(16:9): • 4032×2268 10M: • 3648×2736 10M(3:2): • 4032×2688 12M: • 4032×3024 Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 40: Using The Modes

    USING THE MODES LCD Screen display Still shooting mode display Scene 2 Scene icon (only available for mode) Mode: Fireworks Sport Children Glass Indoor Museum Leaf Landscape Snow Night landscape Night portrait Sunset 3 Light metering method Spot AE Center-Weight Ai AE 4 EV indicator 1 Shooting mode icon...
  • Page 41 6 Macro mode indicator Manual 14 ISO (only available for mode) Macro mode 15 Image quality 7 Flash mode indicator 16 Image size Auto flash Manual 17 Image color (only available for Red-eye reduction flash mode) 18 Slow shutter warning indicator Forced flash 19 Memory card/internal memory indicator Flash off...

  • Page 42: Video Shooting Mode Display

    Video shooting mode display 3 EV indicator 4 Self-timer indicator Mode: 10-second self-timer 5 Macro mode indicator Macro mode 6 Battery status 7 Movie recording “on” indicator 8 Remaining time for videos that can be taken. 9 Focus frame 10 Zoom indicator 11 Video resolution 12 Video quality 13 Memory card/built-in memory indicator...

  • Page 43: Playback Mode Display

    Playback mode display 1 Playback mode icon 11 Histogram 2 DPOF file icon 12 Aperture value Mode: 3 File protection icon 13 Shutter speed 4 Audio file icon 14 Exposure value 5 Video file icon 15 Memory capacity (current picture/ 6 Memory card/internal total picture number) memory indicator...

  • Page 44: Scene Mode

    Scene mode (SCN) In Scene mode, you can select from a total Use Up/Down/Left/Right to select a of 12 scene types to match your needs. You scene, and press the button. just need to select the right scene for the Sport occasion and the camera will automatically For shooting fast-moving objects.

  • Page 45: Snow

    Snow Landscape Suitable for snowy landscape. Camera auto- For shooting landscapes. Vivid reproduction matically adjusts and corrects exposure value of green and blue. (EV). Night landscape Sunset For shooting night scenes. Use of tripod is For shooting sunsets. Vivid reproduction of recommended.

  • Page 46: Panorama Mode

    Returning to the Scene selection Panorama mode menu Panorama mode allows you create a pan- oramic picture. The camera will to automati- cally compose a panoramic picture using the individual shots that you take. Follow these steps to create a panoramic picture: 1.
  • Page 47 2. Use the Left/Right buttons to specify the direction of picture taking, and then in 2 seconds the panoramic sequence will commence automatically. 3. Compose your first view on the LCD screen and press the shutter button. 4. The frame record icon will display under the focus frame to indicate the number of photos you have taken.

  • Page 48: Image Stabilization Mode

    Image Stabilization mode The Image Stabilization mode combats the Setting the Image Stabilization function under effect of hand shake and allows you to take ) mode. pictures that would otherwise be blurred. (Stabilization during Movie mode is only available when the Frame Rate is set to 15 fps) 1.Switch the mode dial to ( ) mode.
  • Page 49 The stabilizer function is used for less blur picture caused by hand shake under a dark environment, the camera would increase the ISO level under the mode to have a higher shutter speed. This function may not help to take a clear picture of a fast moving target, such as a car passing by, etc.

  • Page 50: Face Detection

    Face Detection The Face Detection mode will detect faces of persons in a photo so that the faces will be as clear as possible. 1. While in photography mode, press the button to activate Face Detection. The indicator appears on the LCD. 2.

  • Page 51: Playback

    PLAYBACK Viewing photos and videos To view the captured photos and video clips on the LCD screen: 1. Turn your camera to Playback mode. The last recorded photo or video clip is displayed. 2. Use the Left/Right navigation buttons to scroll through the photos or video clips stored in the internal memory or memory card.
  • Page 52 During the video playback, an operation During the slow motion playback, you can use the Left/Right navigation buttons to adjust guide appears on the screen. You can use the navigation pad to perform the functions ac- the speed of playback. cordingly.

  • Page 53: Editing Video

    Editing video 3. To save the file, select the button and press the button. Press the Edit program button to enter the following screen and use the buttons on 4. Use the Up/Down navigation buttons to the left side to edit the playback. Use the Up/ select an option.

  • Page 54: Thumbnail View

    To exit the Edit screen, select the but- Thumbnail view ton and press the button. When in Playback mode, move the zoom Edited video must be at least 1 second scroll wheel to the Wide position ( ) once to display the thumbnail of photos and video long .

  • Page 55: Using Zoom Playback (For Still Pictures Only)

    Using zoom playback (for still pictures only) The zoom scroll wheel can also be used during playback. This allows you to magnify photos up to 8X. 1. Turn your camera to Playback mode. 2. Use the Left/Right navigation buttons to select a photo to magnify.

  • Page 56: Using The Delete Button

    Using the Delete button The camera is equipped with a quick Delete 4. Press the Up/Down navigation buttons button for you to delete photos or video- to select Yes or No. Then press the clips without entering the Playback menu. button to confirm.

  • Page 57: Using The Menus

    USING THE MENUS Still menu 3. Use the Up/Down navigation buttons to Mode: select an option. In still shooting modes, press the button 4. Press the button to confirm the setting to enter the Still menu. and exit the menu. Refer to the following sections for more de- tailed information on each setting.

  • Page 58: Af Mode (Auto-Focus Mode)

    AF mode (Auto-Focus mode) AF-assist beam Use this setting to control the auto-focus Use this setting to aid focus in dark condi- tions. Select On to turn on the AF assist mechanism while taking pictures. beam, or Off to disable the function. Two options are available: •...

  • Page 59: Expo Metering (Exposure Metering)

    Expo Metering (Exposure Metering) Cont. Shot (Continuous shot) Use this setting to select an area for the Use this setting to perform continuous shooting. exposure to be obtained. Once in this mode, you must continuously hold the shutter button to use this function. Four options are available: Three options are available: •...

  • Page 60: Grid

    Quick Review • Time-Lapse : Automatically capture pictures in at predefined intervals. This setting refers to the quick photo review immediately after taking a picture. The The flash is designed not to work in this picture stays on the LCD screen for an adjust- mode in order to enable quick succession of shots.

  • Page 61: Digital Zoom

    Digital Zoom Histogram Use this setting to enable or disable the The histogram is used for checking the expo- digital zoom function. When disabled, only the sure while taking pictures. Use this setting to optical zoom is enabled. enable or disable the histogram display on the LCD screen.

  • Page 62: Slow Shutter

    Slow Shutter Date Imprint In Slow shutter mode, the shutter will remain Include a date/time stamp in the photo image. open as long as the shutter button is pressed. This gives you complete control over the duration of exposure. (The slow shutter mode is available only in manual mode.

  • Page 63: Movie Menu

    Movie menu 3. Use the Up/Down navigation buttons to Mode: select an option. In movie shooting mode, press the button 4. Press the button to confirm the setting to enter the Movie menu. and exit the menu. Refer to the following sections for more de- tailed information on each setting.

  • Page 64: Expo Metering (Exposure Metering)

    Expo Metering (Exposure Metering) Stabilization Set metering mode for various lighting condi- Please refer to page 44 for instructions on tions. image stabilization. While in Movie mode, image stabilization can be activated and de-activated via the record- ing menu. Three options are available: •Spot metering •Center-weighted average meter- •Artificial intelligence automatic...

  • Page 65: Playback Menu

    Playback menu Protect Mode: To prevent pictures or videos being erased In playback mode, press the button to accidentally, you can use this setting to lock enter the Playback menu. one or all files. Please refer to the following sections for To protect/unprotect a picture or video: detailed instructions on the various menu 1.

  • Page 66: Delete

    Delete 2. Select the Protect setting from the Playback menu as described previously. There are three ways to delete files: (please 3. Use the Up/Down navigation buttons to note that a file cannot be recovered once it is select One to protect this picture/video, deleted.) or select All to protect all pictures/videos in the internal memory or memory card.

  • Page 67: Delete Selected

    the previous menu) using the Up/Down viewing.) buttons, then press the button to 3. Press the button to delete the selected confirm. files. Choose Yes to confirm file deletion or No to return to the previous menu. •Delete All: 1. On the Delete menu, select Delete All and The “...

  • Page 68: Dpof (Digital Print Order Format)

    Info. Box (Information Box) DPOF (Digital Print Order Format) Use this setting to enable or disable the text DPOF allows you to record your selection of display for taking pictures. The following pictures that you would like to print, and will information will be displayed on the screen: save your selection in the memory card, so histogram display, aperture value, shutter...

  • Page 69: Trim

    Trim The trim setting allows you select an area of the photo you want to keep and then save it as a new photo. To trim a picture: 1. Select the Trim setting from the Playback menu as described previously. 2.

  • Page 70: Rotate

    edited.” appears, it means that the current image cannot be resized. Rotate You can use this setting to change the picture orientation of the picture. 1. Select the Rotate setting from the Playback menu as described previously. 2. Use the Left/Right navigation buttons to 2.

  • Page 71: Slide Show

    cancel and return to the Playback menu. 4. Press the button to confirm the setting. The rotated image will be saved as a new file, and the original image will remain intact in memory. Slide show This setting allows you to view all the stored 3.

  • Page 72: Setup Menu

    Setup menu 2. Press the Right navigation button to enter Mode: the setting. The Setup menu is available in all modes. Press the button in any modes, then use Refer to the following sections for more de- the navigation buttons to select the Setup tailed information on each setting.

  • Page 73: Beep

    menu as described previously. 2. Use the Up/Down navigation buttons to switch between volume, shutter tone, key tone, self-timer tone, and power tone fields. 3. The current media is formatted. Beep Use this setting to adjust the volume of beep 3.

  • Page 74: Lcd Brightness

    LCD Brightness Power Saver Use this setting to adjust the brightness of This setting allows you to save power and get your LCD screen. the maximum possible running time for your battery. Follow the steps below to turn off the 1.

  • Page 75: Date/Time

    to specify the idle period before automatic while you are overseas. power-off. The level bars correspond to the 1. Select the World time setting from the following idle periods. Setup menu as described previously. The world time screen appears. • LCD off: 2.

  • Page 76: File Numbering

    File Numbering Language See “Setting the Language“ section on After capturing photos or videos, the camera will automatically save the file with a numeric page 26. suffix. Video system Use this setting to determine your video system in the current area. 1.

  • Page 77: Copy To Card (Copy Internal Memory To Memory Card)

    Copy to Card (Copy internal memory NTSC: USA, Canada, Taiwan, Japan, etc. to memory card) PAL : Europe, Asia (excluding Taiwan), Oceania, etc. Use this setting to copy the files stored in the Note: The TV output will not display properly if internal memory to the memory card.

  • Page 78: Reset Settings

    Reset Settings FW Ver. (Firmware version) Use this setting to restore the camera to its Use this setting to view the current camera default settings. firmware version. 1. Select the Reset setting from the Setup 1. Select the FW Ver. setting from the Setup menu as described previously.

  • Page 79: Connections

    CONNECTIONS Connecting to a TV You can connect your camera to your Video Audio television, computer, or printer to view picture you have taken. By using the AV cable, you can view the captured images on a TV. Follow the steps below to connect the supplied AV cable to a TV.

  • Page 80: Connecting To A Pc

    Connecting to a PC Use the USB cable and ArcSoft software (CD- ROM) supplied with your camera to copy (transfer) pictures to a computer. Setting the USB mode Since the camera’s USB port can be set to connect with either a PC or a Printer, the following steps will allow you to ensure that the camera is correctly configured to connect with a PC.
  • Page 81 5. Disconnect the camera once transfer is By using the USB cable, you can transfer the completed. captured photos and videos to a PC. Follow the steps below to connect the camera to a If the USB option is set to [PC] : Turn the camera off and disconnect the USB 1.
  • Page 82 Window 2000 Professional Click the [Unplug or Eject Hardware] icon ( in the taskbar and select [Stop USB Mass Storage Device] from the menu displayed. Macintosh Drag the untitled icon to the Trash. ("Untitled") Downloaded From camera-usermanual.com General Electric Manuals...

  • Page 83: Connecting To A Pictbridge Compatible Printer

    Connecting to a PictBridge compatible printer PictBridge allows printing images button and use Up/Down to 1. Press the from a memory card in a digital select USB Connect, and then press the camera directly to a printer, Right navigation button. regardless of brand.

  • Page 84: Connecting The Camera And Printer

    Connecting the camera and printer. If the camera is not connected to a PictBridge compatible printer, the following error 1. Make sure both the camera and printer are message appears on the LCD screen. turned on. 2. Connect one end of the supplied USB cable to the USB port on your camera.

  • Page 85: Using The Pictbridge Menu

    Using the PictBridge menu Print with date After setting the USB mode to Printer, the PictBridge menu appears. If you have set the date and time of your camera, the date record would be saved with the photos you take. You can print the photos with date by following the steps below.

  • Page 86: Print Without Date

    Print without date 2. Use the Left/Right navigation buttons to scroll through the photos. Use this setting to print the photos without 3. Use the Up/Down navigation buttons to dates on them. select the number of prints for the current 1.

  • Page 87: Print Index

    Print index displayed image. You can use this setting to print all indexes to 4. Press the button and the following show all the photos currently in your camera. screen appears. 1. Select Print index from the PictBridge menu. The following screen appears. 5.

  • Page 88: Print Dpof

    Print DPOF (Digital Print Order Format) Exit To exit the PictBridge menu, select Exit. To use DPOF printing, you must make the The “Remove USB cable” message will be selection of photos for printing using the DPOF displayed. settings before hand. See “DPOF” section on page 64.

  • Page 89: Appendices

    Appendices Specifications : G2 "Design and specifications are subject to change without notice." Effective Image Sensor Pixels 8.0 Megapixels Image Sensor 8.31 Megapixels [1/2.35” Charge Coupled Device (CCD)] Focal Length F = 6.75mm (Wide) ~ 27mm (Tele) [35mm film equivalent] [38mm (Wide) ~ 152mm (Tele)] F number F3.5 (Wide) ~ F5.15 (Tele)
  • Page 90 Image Compression Best, Fine, Normal DCF, DPOF (Ver1.1) Support Still Image Exif 2.2 (JPEG) File Format Movie Image Compression: MPEG4, Audio: G.711 [Monaural] Audio WAVE [Monaural] (Max 60 seconds) Auto, Manual, Image Stabilization, Movie, Scene (Sport, Children, Indoor, Leaf, Snow, Sunset, Fireworks, Glass, Shooting Modes Museum, Landscape, Night Landscape, Night Portrait), Panorama, Portrait...
  • Page 91 Single AF, Multi-AF (TTL 9-point), Face-Detection, AF AF Method Assist Light (On/Off) Artificial Intelligence AE (Ai AE), Center-weighted Light Metering Method Average, Spot (Fixed to center of frame) Exposure Control Method ProgramAE (AE-lock available) Exposure Compensation ±2 EV in 1/3 steps Shutter Speed 4 ~ 1/2000 second (Manual 30 seconds) Continuous Shooting...
  • Page 92 Internal Memory: 26MB Recording Media SD Card/SDHC Card (Up to 4GB support) PictBridge, Exif Print Support, Other Features Multi-language Support (11 languages) Jacks USB2.0/AV-OUT (Integrated Proprietary Connector) Power Rechargeable Lithium-ion Battery GB-20, 3.7V 750mAh Battery Charger Input Voltage : AC 100 to 240V, 50/60Hz, 100mA Output Voltage : DC 4.2V, 500mA"...

  • Page 93: A735/A835

    Appendices Specifications : A735/A835 "Design and specifications are subject to change without notice." Effective Image Sensor Pixels 7.07 /8.0 Megapixels Image Sensor 7.40 /8.5 Megapixels [1/2.5” (CCD)] Focal Length F = 6.1mm (Wide) ~ 18.3mm (Tele) [35mm film equivalent] [36mm (Wide) ~ 108mm (Tele)] F number F2.8 (Wide) ~ F4.8 (Tele) Lens...
  • Page 94 A735: 7MP:(3072x2304), (3:2)6MP: (3072x2048), (16:9)5MP:(3072x1728), 3MP, 2MP, 1MP, 0.3MP Number of Still Image 8MP:(3264x2448),(3:2)7MP:(3264x2176), A835: Recording (16:9)6MP:(3264x1836), 5MP: (2560x1920), Pixels 3MP, 2MP, 1MP, 0.3MP Movie 640x480pixels: 30fps/15fps, 320x240pixels: 30fps/15fps Image Compression Best, Fine, Normal DCF, DPOF (Ver1.1) Support Still Image Exif 2.21 (JPEG) File Movie...
  • Page 95 Panorama Stitching 2.5 inch LTPS (low-temperature polycrystalline silicon) TFT LCD Display color LCD (153,600 pixels) ISO Sensitivity Auto, ISO 80/100/200/400/800/1600 AF Method Single AF, Multi-AF (TTL 9-point), AF Assist Light (On/Off) Light Metering Method Artificial Intelligence AE (Ai AE), Center-weighted Average, Spot (Fixed to center of frame) Exposure Control Method ProgramAE (AE-lock available)
  • Page 96 Auto/Red-Eye Reduction/Forced Flash/No Flash/ Slow Synchro/Red-Eye Reduction+Slow Synchro Internal Flash (Shooting Gno. 6.5 (ISO 100) Range) Shooting Range Wide: Approx. 0.3m~4.6m / Tele: Approx. 0.3m~2.7m (ISO 400) Internal Memory: 32MB Recording Media SD Card/SDHC Card (Up to 4GB support) PictBridge, ExifPrint Support, Other Features Multi-language Support (20 languages) Jacks...

  • Page 97: E840S/E1035/E1235

    Appendices Specifications : E840s/E1035/E1235 "Design and specifications are subject to change without notice." Model name E840s E1035 E1235 Effective Image 8.0 Megapixels 10.1 Megapixels 12.1 Megapixels Sensor Pixels 10.54 Megapixels 12.40 Megapixels 8.53 Megapixels Image Sensor 1/2.5" CCD 1/1.7" CCD 1/1.72"...
  • Page 98 Model name E840s E1035 E1235 Anti-Handshake Electronic Image Stabilization 4.5X digital zoom 4.5X digital zoom 4.5X digital zoom Digital Zoom (Combined Zoom: 22.5X) (Combined Zoom: 13.5X) (Combined Zoom: 13.5X) Number of Re- 8MP, 7MP(3:2), 10MP, 9MP(3:2), 12MP(4:3), 10MP(3:2), cording Pixels : 6MP(16:9), 5MP, 7MP(16:9), 5MP, 9MP(16:9), 6MP,...
  • Page 99 Model name E840s E1035 E1235 File Format : Image Compression: MPEG4, Audio: G.711 [Monaural] Movie File Format : WAVE [Monaural] (Max 60 seconds) Audio Auto, Manual, Image Stabilization, Movie, Scene (Sport, Children, Indoor, Leaf, Shooting Modes Snow, Sunset, Fireworks, Glass, Museum, Landscape, Night Landscape, Night Portrait), Panorama, Portrait Face-Detection Red-eye Removal Yes...
  • Page 100 Model name E840s E1035 E1235 Auto, ISO 80/100/200 Auto, ISO 64/100/200/ Auto, ISO 64/100/200/ ISO Sensitivity /400/800/1600 400/800/1600/3200 400/800/1600/3200 (3M) AF Method Single AF, Multi-AF (TTL 9-point), Face-Detection, AF Assist Light (On/Off) Light Metering Artificial Intelligence AE (Ai AE), Center-weighted Average, Spot (Fixed to center Method of frame) Exposure Control...
  • Page 101 Model name E840s E1035 E1235 Auto/Red-Eye Reduction/Forced Flash/No Flash/Slow Synchro/Red-Eye Reduction+Slow Synchro Gno. 5.9 (ISO 100) Gno. 5.7±0.5EV (ISO 100) Gno. 5.7±0.5EV (ISO 100 Internal Flash (Shooting Range) (Shooting Range) (Shooting Range) (Shooting Range) (Wide): Approx. (Wide): Approx. (Wide): Approx. 0.3m~3.3m (Tele) : Ap- 0.3m~4.1m (Tele) : 0.3m~3.2m (Tele) :...
  • Page 102 Model name E840s E1035 E1235 Shooting Approx. 210 shots Approx. 200 shots Approx. 210 shots Capability (based on CIPA (based on CIPA (based on CIPA (Battery standards) standards) standards) Performance) Operation Temperature: 0~40 C, Humidity: 0~90% Environment Dimensions 95.7 x 56 x 19.5 mm 103 x 56 x 24 mm 103 x 56 x 24 mm (W x H x D)

  • Page 103: Error Messages

    Error messages Messages Explanation No card • The memory card is not inserted. Card error • The memory card is not formatted. (See P.68) Card full • The memory card is full and cannot store any new images. Write protect •...
  • Page 104 Messages Explanation Card is not formatted, format? • Confirm whether the memory card should be formatted. This image cannot be deleted • The picture or video you are trying to delete is protected. Cannot record movie • The write protection switch in the memory card is set to the “LOCK”...

  • Page 105: Troubleshooting

    Troubleshooting Problem Possible causes Solution Camera does not turn on. • The battery has run out. • Charge the battery or replace with a fully charged battery. • The battery is not in- serted correctly. • Re-insert the battery observing the correct polarity.
  • Page 106 Problem Possible causes Solution No picture is taken when • The memory card is full. • Replace the memory card with pressing the shutter but- a new one or clean off current • No available space to ton. memory card. store the files.
