Clevo W24ACZ Service Manual page 14

Communication
10Mb/100Mb Ethernet LAN
(Factory Option) 2M HD PC Camera Module
(Factory Option) 3G Mini-Card Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Intel® Centrino® Wireless-N 105 Wireless
LAN (802.11b/g/n)
(Factory Option) Intel® Centrino® Wireless-N 135 Wireless
LAN (802.11b/g/n) + Bluetooth 3.0
(Factory Option) Third-Party Wireless LAN (802.11b/g/n)
(Factory Option) Third-Party Wireless LAN (802.11b/g/n) +
Bluetooth 4.0
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD
MS (Memory Stick) / MS Pro / MS Duo
Mini Card Slots
Slot 1 for WLAN Module or WLAN and Bluetooth Combo
Module
(Factory Option) Slot 2 for 3G Module
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 3.42A/18.5V, 3.5A (65W)
Removable 6 Cell Smart Lithium-Ion Battery Pack, 48.84WH
(Factory Option) Removable 3 Cell Smart Lithium-Ion Bat-
tery Pack, 24.42WH
(Factory Option) Removable 6 Cell Smart Lithium-Ion Bat-
tery Pack, 62.16WH
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
Design I:
340mm (w) * 238mm (d) * 25.05 - 33.5mm (h)
2.2kg with 48.84WH Battery & ODD
Design II:
340mm (w) * 238mm (d) * 13.9 - 31.8mm (h)
340mm (w) * 238mm (d) * 12 - 30.2mm (h)
2.2kg with 48.84WH Battery & ODD
Design III:
341mm (w) * 238.5mm (d) * 16 - 34mm (h) (h)
2.2kg with 48.84WH Battery & ODD
Introduction
Specifications 1 - 3
