Summary of Contents for Hama DIT2010
- Page 1 00054833 (DIT2010) Digital Radio Digitalradio Bedienungsanleitung...
- Page 2 Technical Data / Technische Daten Radio Receiver/ DAB+ Internet Spotify Radio Empfänger Connectivity/ LAN (10/100), WIFI(b/g/n), USB (Play) Verbindungsfähigkeit Display/ 2.8“ Colour TFT Bildschirm Encryption/ WEP, WPA, WPA2, WPS Verschlüsselung Audio Output/ Audio Ausgang Power input/ 110-240 V ~ 50-60Hz Stromeingang Frequency range/ DAB/DAB+:...
-
Page 4: Operating Instructions
G Operating instructions Controls and Displays A: Front B: Rear [on / off] On/ off switch Mains power supply AUX IN socket Connection DAB/FM wire antenna* [volume] Rotate: Volume control Connection WiFi antenna* Rotate: Selection from Optical output favourites list [preset] Press: listing/ save/ confirm Coaxial output... - Page 5 C: Remote Control ▲ Up / ▼ Down / ◄ Back on menu level Navigation On/ off switch ≙ [back] / keys ≙ [on / off] ► Forward/ Confirm ≙ Press [tuning]/[OK] Mute Confirm Direct access to operating [OK] [IR] ≙...
-
Page 6: Table Of Contents
Content 10.3 Station list ........23 1. - Page 7 15.11 AUX: Auto-Standby ......36 16. Hama Smart Radio (Android / iOS) ....37 16.1 Preparation .
- Page 8 Icon overwiew Icon Meaning Icon Meaning Application failed Operating mode: Aux in See display for further information Operating mode: Muted Internet radio Operating mode: Shared Media Playback Spotify Connect Playback: Pause Operating mode: Music player Playback: Stop Operating mode: DAB RDS (Radio Data System) ...
-
Page 9: Menu Structure
Menu structure MAIN MENU INTERNET RADIO Last listened Station list My Favourites Local Stations Location Genre Search stations Popular stations New stations Podcasts Location Genre search podcasts My Added Stations Help Get access code System settings Main menu SPOTIFY System settings Main menu MUSIC PLAYER Shared media... - Page 10 Main menu AUXILIARY INPUT System settings Main menu SLEEP ALARMS SYSTEM SETTINGS Equaliser Normal Flat Jazz Rock Movie Classic News My EQ My EQ profile setup Bass Treble Network Network wizard PBC Wlan setup View settings Manual settings NetRemote PIN Setup Network profile Keep network connection Time/Date...
-
Page 11: Explanation Of Warning Symbols And Notes
Thank you for choosing a Hama product. 3. Safety Notes Take your time and read the following instructions and • The product is intended for private, non-commercial use information completely. Please keep these instructions in a only. safe place for future reference. If you sell the device, please •... -
Page 12: Informations And Notes Before Getting Started
4. Informations and notes before getting started 4.2 WLAN connection (wireless network) • Ensure that the router is switched on, is functioning Note – Optimal reception correctly and that there is a connection to the internet. • Activate the WLAN function of your router. •... -
Page 13: Radio - Connecting And Starting Up
You can find an appropriate selection of Hama products at • The buttons on the remote control – corresponding www.hama.com. to the control buttons on the device ( ≙ )- you will find under Controls and Displays. -
Page 14: Additional Information
Navigation and controls Additional information • Select among menu items by turning [tuning]. Press [info] to display context-dependent additional • Confirm the selection by pressing [tuning]. information. The information shown depends on the operating mode as well as the current selection of radio This procedure is indicated in these operating instructions station, music file, etc. -
Page 15: Initial Setup
5.4 Initial setup Date/ Time • 12/24 hours format The Setup Wizard starts up automatically when the radio • Auto update is turned on for the first time. The default used language • Update from DAB/ FM is English. You can skip the Setup Wizard and start up If automatic time and date adjustment is anytime in your language. -
Page 16: Main Menu / Modes
Once the network wizard has finished, the setup wizard Select amongst the available operating modes by is finished as well. The display shows a message to this repeatedly pressing [mode]. effect. Press [tuning] to enter the main menu. Proceed as follows to choose your desired language: [mode] [menu] 7. -
Page 17: Station Search
7.1 Station search 7.1.3 Search by name This radio offers various ways to search for stations. If you know the name of the desired station, you can search for it directly. • Use [tuning] to navigate through each search function and its options. -
Page 18: New Stations
7.1.5 New stations 7.2 Podcasts Stations that have recently been added to the database Podcasts are programs on various topics and include, can be found as follows: for example, talk shows, news and much more. Podcasts can be downloaded from the Internet. There are normally approximately 10,000 programs available. -
Page 19: Search By Name
7.2.3 Search by name 7.4.1 Save favourites If you know the name of the desired Podcasts, you can • Set the station that you would like to save as a favourite search for it directly. station preset. • If the station is received, press and hold [preset] on front of the radio. -
Page 20: Management Of Favourites With The Remote Control
7.4.3 Management of favourites with 7.5.1 First use – Registering your radio the remote control In order to be able to use this function you have to register Favourites 1-10 at www.wifiradio-frontier.com. You need a valid email address and an access code which will be generated by The remote control enclosed has number keys 1-0 your radio. -
Page 21: Managing Favourites Online (Vtuner - Http://Www.wifiradio-Frontier.com)
• During registration, the radio’s ID is associated with your 7.5.4 My Added Stations e-mail address and saved in the web interface. If a station you desire is not yet available, you can add it • If multiple radios are registered to you and you wish to manually to the portal, or suggest a station be added to delete one of those registrations or just compare them, the database (Recommend station). - Page 22 Use: • Choose Available devices to access an overview of • In the Spotify app, start playback of a playlist or title as all devices available on the network. usual. • Select the radio. The audio is now played back on the •...
-
Page 23: Music Player (Upnp, Usb)
9. Music player (UPNP, USB) 9.2 Playback from a computer (streaming) This operating mode enables the playback of MP3, WMA You can manage the radio and stream music to it from your or FlAC files that are saved on a PC, data storage medium computer. -
Page 24: Playback From The Network - Accessing Files Using The Radio
9.3 Playback from the network – Accessing files 9.4 Playback of playlist using the radio You can create a local playlist on the radio, in which you To access one of the existing network shared files directly save files shared on the network or from connected data from the radio, proceed as follows: storage devices. -
Page 25: General Playback Options
• To delete the entire playlist, proceed as follows: 10. DAB The radio receives all established digital radio frequencies in the range of 174 MHz to 240 MHz (band III, channel [menu] 5A to 13F). • From the main menu or after pressing [mode] repeatedly, activate operating mode DAB (DAB Radio): Main menu ... -
Page 26: Manual Station Search
10.2 Manual station search 10.3 Station list With the manual station search function you can search You can access the station list in DAB mode at any time via through individual frequencies and channels. If you know two methods: the frequency of the desired station and the automatic a) If a station is already playing, simply turn station search failed to find it, use this feature to set the [tuning]. -
Page 27: Slideshow/Station Information (Picture With Text/Full Screen)
10.5 Slideshow/Station information 10.7 Favourites (Picture with text/full screen) You can save up to 30 of your favourite stations for quick Many digital radio stations in the DAB+ network provide and direct access. additional information, which can be displayed on a colour screen. -
Page 28: Access Favourites
10.7.2 Access favourites 10.8 DRC (Dynamic Range Control) Press [preset] to open the overview window with the list Some radio stations in the DAB network support an audio of saved stations. level control that is activated at varying volumes during playback. -
Page 29: Scan Setting
11. FM 11.2 Automatic station search From the main menu or after pressing [mode] repeatedly, • Press and hold [tuning] until the automatic station activate operating mode FM (FM Radio): search starts. • The radio stops the search and starts playback when it finds a station. -
Page 30: Access Favourites
11.4.2 Access favourites Favourites 1-30 (alternative to number keys) • Press and hold [FAVORITES] approx. 3 seconds to save Press [preset] to open the overview window with the list a station on one of the 1-30 favourite station presets. of saved stations. An overview window with the station presets should open after approx. -
Page 31: Auxiliary Input
12. Auxiliary Input 13. Sleep Via the analogue audio input (AUX IN socket) you can The radio has a sleep function, after a defined time the connect mobile devices (for example smartphone, tablet radio switches to standby mode. PC, M3 player etc.) to the radio and play the audio files •... -
Page 32: Alarms
14. Alarms Volume: You can set the volume at which the alarm sound should The Radio has two individually adjustable alarm times. be played. This setting makes it irrelevant how loud you last listened to the radio. 14.1 Alarm settings •... -
Page 33: System Settings
15. System settings 15.2 Network You can modify all settings and access important 15.2.1 Network wizard – Configuration of internet information about the radio in the System settings. connection / Automatic search The Network wizard supports you to set up a 15.1 Equaliser connection between the radio and internet. -
Page 34: Wireless Network Connection (Wlan)
15.2.2 Wireless network connection (WLAN) • Alternatively, PBC setup can be initiated from the internet settings of the radio: Depending on the network, there are a number of ways to connect to it. Networks that support connection via WPS (Wi-Fi Protected [menu] Setup) are identified in the list as [WPS]. -
Page 35: Wired Network Connection (Lan)
Open network Manual configuration wired (LAN) – DHCP enable • Select the option Wired. Note • Select the option DHCP enable. • The connection is now established. No further setting • We recommend against establishing unsecured adjustments are required. connections and advise you to always protect your network against unauthorised access. -
Page 36: View Settings
Network profile 15.2.6 NetRemote PIN Setup / Smart Radio-App The radio can be controlled using the application Hama Smart Radio. • Select a network profile and press [tuning] to delete it. For this, you have to have installed the app on your •... -
Page 37: Keep Network Connected
15.2.8 Keep network connected Auto update • Update from Network This setting is a radio energy-saving function. Choose this option to set the time and date automatically from the internet. Set the timezone of your current location (Set timezone) and, if desired, turn on [menu] automatic adjustment between summer time and winter time (Daylight savings ... -
Page 38: Factory Reset
15.5 Factory Reset • Set Auto-check setting to YES to have the radio automatically check for new software updates at regular To reset the radio to the factory default settings, proceed intervals. (Recommendation) as follows: • Choose Check now to manually start a check for software updates. -
Page 39: Backlight
15.9 Backlight 15.10 Color theme The backlight can be configured for each operating To change the color scheme of the display (Color of text mode (Operation Mode, Standby Mode, Slumber Mode) and background), proceed as follows: separately. • Proceed as follows: [menu] [menu] System settings... -
Page 40: Hama Smart Radio (Android / Ios)
16. Hama Smart Radio (Android / iOS) 16.2 First startup The Hama Smart Radio app allows you to access and control many features of the radio from your tablet computer or smartphone, without using the remote control. The current version of the app can be found here: For iPhone and iPad http://www.hama.com/hama-smart-radio-apple-itunes... -
Page 41: Source Selection
16.4 Source selection Source selection / active device Settings Playback source (DAB, FM, Internet, etc.) Playback window Search (stations or directories) Manage favourites Shuffle / Mix Share Repeat (function mode-dependent) Station information Navigation buttons (function mode- dependent) Navigation buttons (function mode- dependent) Navigation buttons (function mode- dependent) -
Page 42: Station Search And Favourites
16.5 Station search and favourites 16.5.2 Searching for stations / station lists 16.5.1 Managing favourites You can also search for stations using the app. Tap any of the search results to open it. To access favourites management, tap this button in the playback window (6). -
Page 43: Settings And Standby
18. Warranty Disclaimer Hama GmbH & Co. KG assumes no liability and provides no warranty for damage resulting from improper installation/ mounting, improper use of the product or from failure to observe the operating instructions and/ or safety notes. -
Page 44: Service And Support
19. Service and Support Please contact Hama Product Consulting if you have any questions about this product Hotline: +49 9091 502-115 (German/English) Further support information can be found here: www.hama.com 20. Recycling Information Note on environmental protection: After the implementation of the European Directive... - Page 45 Hama GmbH & Co KG 86652 Monheim / Germany www.hama.com The Spotify software is subject to third party licenses found here: www.spotify.com/connect/third-party-licenses All listed brands are trademarks of the corresponding companies. Errors and omissions excepted, and subject to technical changes. Our general terms of delivery and payment are applied.
