Section 5 – Recorder Setup
Alarms: When the Active box is checked the alarms are active for this channel (2) provided the
Enable
is set. When not checked the alarms are deactivated for this channel. Pressing the Alarms button
opens the
Alarm Setup
which will affect ALL widgets using this channel. This is a protected option.
Apply: Pressing this button will exit and save any changes made.
Exit: Pressing this button will exit without saving any changes made in THIS dialog box ONLY. If you
used the Setup or Alarms buttons to make changes to the channel information, these are Global and
WILL be saved.
Setup: Pressing this button opens the
made to the channel settings which will affect ALL widgets using this channel. This is a
protected option.
Delete:
the display.
Displaying Min, Max or Average Values
5.3.1.2
The Digital Display widgets show the instantaneous channel value but can be
changed at any time to display minimum, maximum or average values. To
change the reading double tap in the lower line of the digital display widget
indicated right.
This will pop up a drop down menu that allows the user to select the display
mode as follows.
INST. =
display)
MIN.
Maximum – will display the maximum (highest) value ever measured
MAX.
Average – will perform a weighted average on all input samples at 10
AVG.
samples/sec and average them as (last value + current value)/2 and display this.
Note – you can use the
The display indicated the current display mode in the lower left of the display
widget using the characters above -
is shown for real time (instantaneous) value. Maximum value is shown displayed
right.
dialog window. This allows changes to be made to the channel alarm settings
Pressing this button will DELETE the Digital Display Widget. This will remove it from
Instantaneous – display the data as it is read – default (real time
Minimum - will display the minimum (lowest) value ever measured.
Filter
on each channel to provide additional averaging.
Channel Setup
with the exception that NO indicator
Page 53
window. This allows changes to be
Master
09/11/2008 REV 0.99
