Fender ROC PRO 1000 Service Manual

HEAD p/n 022-6807-000 (120V)
COMBO p/n 022-6808-000 (120V)
SERVICE MANUAL
Fender Musical Instruments Corp. 7975 North Hayden Road Scottsdale, AZ 85258
ROC PRO 1000
CONTENTS:
Notices
Specifications
Parts lists:
PCB assembly
Chassis assembly
Cabinet assembly
Footswitch assembly
Miscellaneous
Schematics
Service diagrams
(This is the model name for warranty claims)
SERVICE MANUAL
The information contained herein is CONFIDENTIAL and PROPRIETARY to Fender Musical Instruments Corp. It
is disclosed solely for use by qualified technicians for purposes of equipment maintenance and service. It is not to
be disclosed to others without the expressed permission of Fender Musical Instruments Co. All specifications
subject to change without notice.
For warranty repair service, only Fender specified part numbers are to be used. It is recommended they also be
used for post-warranty maintenance and repair.
*
Parts marked with an asterick ( ) indicate the required use of that specific part. This is necessary for RELIABILITY
and SAFETY requirements. DO NOT USE A SUBSTITUTE!
A coded naming convention is used in the description of certain parts. The codes and what they mean are as
follows:
CAPACITOR CODES
CAP AE = Aluminum Electrolytic
CAP CA = Ceramic Axial
CAP CD = Ceramic Disk
CAP MPF = Metalized Polyester Film
CAP MY = Mylar
CAP PFF = Polyester Film/Foil
RESISTOR CODES
RES CC = Carbon Comp
RES CF = Carbon Film
RES FP = Flame Proof
RES MF = Metal Film
RES WW = Wire Wound
1
ROC PRO 1000
MAY 1996

IMPORTANT NOTICE:

HARDWARE CODES
BLX = Black Oxide
CR = Chrome Plated
HWH = Hex Washer Head
M = Machine Screw
NI = Nickel Plated
OHP = Oval Head Phillips
PB = Particle Board
PHP = Pan Head Phillips
PHPS = Pan Head Phillips Sems
SMA = Sheet Metal "A" Point
SMB = Sheet Metal "B" Point
SS = Stainless Steel
TF = Thread Forming
ZI = Zinc Plated
