- Page 1 CD Boombox with AM/FM Digital Readout Radio INSTRUCTION MANUAL CE2300 Thank you for purchasing this CD Boombox. Please read this instruction manual carefully before using this product to ensure proper use. Keep this manual in a safe place for future reference.
-
Page 2: What's In The Box
WHAT’S IN THE BOX Contents 1. CE2300 CD Boombox 2. AC Power Cord 3. Instruction Manual 4. Warranty Card If you are missing any parts above, please contact ADT Digital LLC. Tel: 561 922 6886 Fax: 561 922 6159... - Page 3 The CAUTION marking is located on the bottom panel. CD compartment. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
- Page 4 FCC AND CANADIAN ICES NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence in a residential installation.
- Page 5 WARNINGS: • To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Avertissement: pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité. •...
- Page 6 RADIO-CD-AUX FUNCTION SWITCH SKIP BUTTON VOLUME KNOB POWER INDICATOR PHONE JACK STOP BUTTON BASS BUTTON REPEAT BUTTON CD DOOR SKIP BUTTON OPEN AREA FM ST. INDICATOR TUNING KNOB PLAY/PAUSE BUTTON AM-FM-FM ST. BAND SWITCH ROD ANTENNA AUX IN JACK HANDLE POWER ON/OFF BUTTON AC SOCKET DISPLAY (POSITIVE LCD)
-
Page 7: Power Connection
POWER CONNECTION Connecting Power Plug the supplied AC power cord into the AC jack that located on the rear of the product and plug the other end into a standard AC socket. The unit is designed to operate from a main supply of AC120V ~ 60Hz. -
Page 8: Switching On For The First Time
SWITCHING ON FOR THE FIRST TIME Plug into AC power or install batteries by following instructions on the previous Power Connection section. Press the POWER button to ON position to turn on the unit. The POWER indicator will be lighted up. Switching between different sources (RADIO/CD/AUX) After turning on the unit, slide the FUNCTION switch to select different sound sources Adjusting sound volume level... -
Page 9: Stop Playback
Remark: • If there is no disc in the unit, “No” or “Er” will be indicated on the display. • If the CD cannot be read, “No” or “Er” will be indicated on the display. Play/Pause Control To pause playback temporarily by pressing the PLAY/PAUSE button. Music playback will be paused and the current elapsed track number will be shown on the display and the play icon will be blinking. -
Page 10: Radio Operation
RADIO OPERATION The unit is designed to receive FM Stereo/FM and AM radio bands. 1. Slide the FUNCTION switch on the top of the unit to select RADIO mode. 2. Slide the BAND switch on the side of the unit to select FM ST, FM or AM band. 3. -
Page 11: Troubleshooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Unit will not AC cord not Check AC cord turn on. connected. connection. Disc will not play. Disc Compartment Close Disc Compartment door not closed. door. Disc inserted Reinsert disc correctly. incorrectly. Dirty or defective CD. Try another disc. -
Page 12: Specifications
SPECIFICATIONS Power Output .............. 5 watts RMS x 2 Speakers ..............8 ohms, 8 W, 3 inches x 2, 2 inches x 2, 1.5 inches x 2 CD Disc- Disc Diameter ..........120mm / 80mm AC Power ..............AC120V ~ 60Hz Battery Size ..............
