- Page 1 Installation and User Manual GN7A2IFXD Gas cooktop P/N : 50553-44070...
-
Page 2: Table Of Contents
Contents Preface ............4 Safety Warning ........5-10 - Safety Warning ......... 5 - Installation ..........6 - Child and People Safety ......7 - During Use ..........8 - Cleaning & Service ......... 10 - Environmental Information ..... 10 Instructions for use and maintenance ..11-19 - Description of the appliance .... -
Page 3: Preface
Preface Safety Warning ■ Your safety is of the utmost importance to Samsung. Thank you for choosing a Samsung gas cooktop. ■ You must read warnings carefully before installing or using the appliance. To use this appliance correctly and prevent any potential risk, read these instructions before ■... -
Page 4: Installation
Installation Child and People Safety Warning Warning ■ This appliance shall be installed in ■ Prior to installation, ensure that the ■ Do not allow children to play near or with the appliance. accordance with regulations in force gas and electrical supply complies The appliance gets hot when it is in use. -
Page 5: During Use
During Use During Use (Continued) Warning ■ Do not use or store flammable ■ Perishable food, plastic items and materials in the appliance storage aerosols may be affected by heat and should not stored above or below the drawer or near this appliance. appliance. -
Page 6: Cleaning & Service
Cleaning & Service Description of the appliance Warning ■ Never use abrasive or caustic ■ This appliance should only be cleaning agents. repaired or serviced by an authorised Service Engineer and only genuine approved spare parts should be used. Caution 1. -
Page 7: How To Use The Appliance
How to Use the Appliance How to Use the Appliance (Continued) Turn on Turn off Preparation Extinguishment The following symbols will appear on the control panel, next to each control handle : Circle : gas off Small flame : minimum setting Large flame : maximum setting Ignition position ■... -
Page 8: Safety And Energy Saving Advice
Safety and Energy saving advice Safety and Energy saving advice (Continued) - The diameter of the bottom of the pan should correspond to that of the burner. PANS BURNERS ■ Do not use cookware on the Φ min. Φ max. appliance that overlaps the Triple-Crown 200mm... -
Page 9: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance (Continued) BURNERS ■ Cleaning operations must only be carried out when the appliance is cool. ■ The appliance should be disconnected from your mains supply before commencing any cleaning process. ■ Remove the burner lids and Flame Spreaders by pulling them upwards and away ■... -
Page 10: Troubleshooting
Sentral 5, KL Sentral , 50470, Kuala Lumpur, Malaysia Asia Thai Samsung Electronics Co.,Ltd Service Department 1,6 Pacific floor Boonmitr Building 138 Silom Rd., Suriyawong ■ If problem is not solved, please contact the Samsung customer care Bangrak Bangkok 10500 1800-29-323202- www. THAILAND center. -
Page 11: Technical Instructions
■ The adjustment conditions for this appliance are stated on the label (or data plate). ■ This appliance is not connected to a combustion products evacuation Model GN7A2IFXD device. It shall be installed and connected in accordance with current installation regulations. Particular attention shall be given to the Pan Support Cast Iron relevant requirements regarding ventilaton. -
Page 12: Positioning
Positioning Installing the appliance 1. Remove the pan supports, the burner lid and ■ Clearance around the gas appliance must comply with the requirement flame spreader and carefully turn the of AS5601. appliance upside down and place it on a cushioned mat. -
Page 13: Gas Connection
Gas Connection Electrical Connection ■ This appliance must be earthed. ■ This appliance must be installed and connected in accordance with installa- ■ This appliance is designed to be connected to a 220~240V, 50/60Hz AC electricity supply. tion regulations in force in the country in which the appliance is to be used. ■... -
Page 14: Gas Conversion
Calibrated orifice 1/100mm on the right gas category Auxiliary to match with the setting 0063 Semi-rapid in rating plate. Remove the previous GN7A2IFXD S/N: Rapid setting “V” mark. G20/20mbar 220-240V 50/60Hz, Pmax 1W Triple-Crown ∑Qn G20: 11.3kW G30: 807g/h G31: 781g/h GB Cat.: II2H3+...
