Rear Panel - Manley Stereo Variable MU Owner's Manual

I
N
E
P
U
T
A
O
D
U
T
P
U
T
A
FUSE HOLDER
B IEC MAINS SOCKET
C GROUND TERMINALS
D OUTPUT XLR
E INPUT XLR
METER
OUTPUT
TRANSFORMER
5687/
7044
BALANCE
GAIN
TRIM
12AX7
COMPRESS
ZERO TRIM
DC BALANCE
ADJUST

REAR PANEL

TRANSFORMER
FUSEHOLDER
IEC RECEPTACLE
TUBES and TRIMS
REG
12AL5
CH1 INPUT
TRANSFORMER
5670
LIMIT ZERO
TRIM
FUSE 2A SLOBLO
IEC POWER CONNECTOR
Houses a standard 2 Amp SLO-BLO fuse. Replace only with the
same type and size.
Standard 3 pin AC mains socket. See the section MAINS
CONNECTIONS for more details.
Use these terminals to help with hum problems. Normally the
two terminals are connected together.
3 Pin XLR BALANCED.
3 Pin XLR BALANCED.
POWER
12 VDC
REGULATOR
REG
12AL5
CH2 INPUT
TRANSFORMER
LIMIT ZERO
TRIM
7
A C
CIRCUIT
CHASSIS
B
Pin 1 - Ground
Pin 2 - Positive going phase (+)
Pin 3 - Negative going phase (-)
Pin 1 - Ground
Pin 2 - Positive going phase (+)
Pin 3 - Negative going phase (-)
12 VDC
REGULATOR
METER
OUTPUT
TRANSFORMER
5687/
7044
BALANCE
5670
12AX7
COMPRESS
ZERO TRIM
DC BALANCE
ADJUST
I
N E
P
U
T
B
O
U
D
T
P
U
T
