- Page 1 NSX-DST717 SERVICE MANUAL COMPACT DISC BASIC CD MECHANISM: 6ZG-1 ZRNDM STEREO CASSETTE RECEIVER BASIC TAPE MECHANISM: 2ZM-3MK2 PR4NM • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-006-432-7T1...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST - 1/11 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 CAP,E 100-16 A....87-010-186-080 CAP,CHIP 4700P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-320-080 CHIP CAP 68P A.... - Page 3 ELECTRICAL MAIN PARTS LIST - 2/11 87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....87-A90-095-080 SW,TACT EVQ11G04M A....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3/11 87-010-260-080 CAP, ELECT 47-25V A....87-010-186-080 CAP,CHIP 4700P A....87-010-186-080 CAP,CHIP 4700P A....87-012-368-080 C-CAP,S 0.1-50 F A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-A10-119-080 CAP,E 10-100 REA A....87-A10-119-080 CAP,E 10-100 REA A....CNA 101 8A-NF8-652-010 CONN ASSY,7P TID-A(480) A....
- Page 5 ELECTRICAL MAIN PARTS LIST - 4/11 87-A40-488-080 DIODE,1SS244 A....87-A40-313-080 C-DIODE,MC 2840 A....87-A40-455-080 DIODE,RL203 GW A....87-A40-749-080 ZENER,UZ5.6BSB A....87-A40-749-080 ZENER,UZ5.6BSB A....87-A21-397-010 IC,STK490-070 A....87-A61-159-010 JACK,PIN 4P R/W/B/0 KM A....87-A50-610-010 COIL,1UH K(MDEC) A....87-A50-610-010 COIL,1UH K(MDEC) A....87-A50-610-010 COIL,1UH K(MDEC) A....
- Page 6 ELECTRICAL MAIN PARTS LIST - 5/11 8A-NFE-613-010 FL,BJ784GK-ANF14 A....87-A21-482-010 IC,RPM6938-H4 A....8A-NFE-635-010 C-IC,LC876596W-**** A....87-A21-577-040 C-IC,M61506FP A....87-A21-021-040 C-IC,BU2099FV A....87-A90-896-080 F-BEAD, 035600STY7 A....87-A90-896-080 F-BEAD, 035600STY7 A....87-A50-333-010 COIL,OSC 9.43MHZ A....LED 313 87-A40-380-180 LED,SEL6510C-TP5 GRN A....LED 315 87-A40-380-180 LED,SEL6510C-TP5 GRN A....
- Page 7 ELECTRICAL MAIN PARTS LIST - 6/11 87-007-342-010 COIL,OSC 85K BIAS A....87-026-609-080 TR,KTA1266GR A....87-A30-063-080 C-TR,KRA104S A....87-A30-087-080 C-FET,2SK2158 A....SFR 302 87-024-355-080 SFR,33K DIA6 H A....SFR 301 87-024-355-080 SFR,33K DIA6 H A....SFR 304 87-024-355-080 SFR,33K DIA6 H A....
- Page 8 ELECTRICAL MAIN PARTS LIST - 7/11 87-012-369-080 C-CAP,S 0.047-50F A....87-012-369-080 C-CAP,S 0.047-50F A....87-010-179-080 CAP,CHIP S B1200P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-197-080 CAP, CHIP 0.01 DM A....87-010-400-080 CAP, ELECT 0.47-50V A....87-010-400-080 CAP, ELECT 0.47-50V A....87-010-403-080 CAP, ELECT 3.3-50V A....
- Page 9 ELECTRICAL MAIN PARTS LIST - 8/11 87-010-318-080 C-CAP,S 47P-50 CH A....87-010-318-080 C-CAP,S 47P-50 CH A....87-010-318-080 C-CAP,S 47P-50 CH A....87-010-318-080 C-CAP,S 47P-50 CH A....87-010-180-080 C-CER 1500P A....87-010-197-080 CAP, CHIP 0.01 DM A....87-010-198-080 CAP, CHIP 0.022 A....
- Page 10 ELECTRICAL MAIN PARTS LIST - 9/11 87-010-154-080 CAP CHIP 10P A....87-010-154-080 CAP CHIP 10P A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-408-080 CAP, ELECT 47-50V A....87-010-408-080 CAP, ELECT 47-50V A....87-010-154-080 CAP CHIP 10P A....87-010-235-080 CAP,E 470-16 SME A....87-010-382-080 CAP, ELECT 22-25V A....
- Page 11 ELECTRICAL MAIN PARTS LIST - 10/11 87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-405-080 CAP, ELECT 10-50V A....87-010-405-080 CAP, ELECT 10-50V A....87-010-405-080 CAP, ELECT 10-50V A....87-010-405-080 CAP, ELECT 10-50V A....87-012-154-080 C-CAP,S 150P-50 CH A....87-A10-369-080 C-CAP,S 0.47-16 K B A....
- Page 12 ELECTRICAL MAIN PARTS LIST - 11/11 87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-374-080 CAP, ELECT 47-10V A....87-010-374-080 CAP, ELECT 47-10V A....87-010-374-080 CAP, ELECT 47-10V A....87-010-545-080 CAP, ELECT 0.22-50V A....87-012-393-080 C-CAP,S 0.22-16 R K A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-263-080 CAP, ELECT 100-10V A....
-
Page 13: Mechanical Parts List
MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF3-090-010 RING,FOOT A....8A-NF3-028-010 BOX,CASS L A....8A-NF3-029-010 BOX,CASS R A....8A-NF3-039-010 PANEL,CASS L A....8A-NF3-040-010 PANEL,CASS R A.... - Page 14 MECHANICAL PARTS LIST - 2/2 87-012-156-080 C-CAP,S 220P-50 CH A....87-018-123-080 CAP, CER 220P-50V A....87-A40-747-080 ZENER,UZ5.1BSB A....87-A91-422-010 BUSHING,AC CORD(U) A....87-A91-423-010 FAN,AD0612DS-D7OGL A....87-A91-711-010 FAN, 3110GL-B4W-B34-H02 -400MM A....88-905-081-110 FF-CABLE, 5P 1.25 A....88-906-481-110 FF-CABLE, 6P 1.25 480MM A....
-
Page 15: Accessories / Package List
ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. U ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-NFE-903-010 IB,U (ESF) M A....87-006-225-010 AM LOOP ANT NC2 A....87-043-115-010 ANT,FEEDER FM A....8Z-NFD-702-010 RC UNIT,RC- ZAS22 A.... - Page 16 SCHEMATIC DIAGRAM _ 1 (MAIN)
- Page 17 SCHEMATIC DIAGRAM _ 2 (DECK)
- Page 18 SCHEMATIC DIAGRAM _ 3 (TUNER)
- Page 19 SCHEMATIC DIAGRAM _ 4 (GEQ)
- Page 20 SCHEMATIC DIAGRAM _ 5 (DISPLAY)
- Page 21 SCHEMATIC DIAGRAM _ 6 (CONTROL)
- Page 22 SCHEMATIC DIAGRAM _ 7 (AMP1F)
- Page 23 SCHEMATIC DIAGRAM _ 8 (AMP2F)
- Page 24 SCHEMATIC DIAGRAM _ 9 (AC3)
- Page 25 SCHEMATIC DIAGRAM _ 10 (PT)
- Page 26 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9820572 Printed in Singapore...
