FR-DA400
EZ(S)

SERVICE MANUAL

RADIO RECEIVER
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-008-348-9T2).
S/M Code No. 09-008-348-9R2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-DA400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa FR-DA400

Summary of Contents for Aiwa FR-DA400

  • Page 1: Service Manual

    FR-DA400 EZ(S) SERVICE MANUAL RADIO RECEIVER This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-008-348-9T2). S/M Code No. 09-008-348-9R2...

  • Page 2: Specifications

    SPECIFICATIONS • Design and specifications are subject to change without notice ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 8A-RU5-905-010 IB,EZ(EGF)C 1 8A-RU5-907-010 IB,EZ(PHNCZ)C 1 8A-RU5-906-010 IB,EZ(SID)C...

  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C517 87-018-131-010 CAP,1000P C518 87-018-131-010 CAP,1000P 8A-RUA-605-010 IC,CXA1619BS C521 87-A11-144-080 CAP,TC U 0.1-50 K B S7-172-340-1A0 IC,LC72343G-9961 C523 87-018-131-010 CAP,1000P C524 87-018-131-010 CAP,1000P TRANSISTOR C526 87-015-683-080 CAP,E 33-16V...

  • Page 4: Chip Resistor Part Code

    • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor...
  • Page 5 BLOCK DIAGRAM-1 (MAIN) BLOCK DIAGRAM-2 (CPU)
  • Page 6 WIRING-1 (CONNECTION DIAGRAM) WIRING-2 (MAIN) TF401 MAIN C.B (PARTS SIDE) ACP401 6F22 R502 NOTE...
  • Page 7 SCHEMATIC DIAGRAM-1 (MAIN) T403 L403 L404 LW FREQ. RANGE ADJ. FM TRACKING ADJ. FM FREQ. RANGE ADJ. MAIN C.B C524 VOLUME SVC251 0.001 L402,TC402 LW TRACKING ADJ. L401,TC401 MW TRACKING ADJ. T401 SVC342 MW FREQ. RANGE ADJ. SVC251 FM ANT 14 13 12 11 10 2SC2001 AM/FM...
  • Page 8 WIRING-3 (LCD) WIRING-4 (KEY) KEY C.B (CONDUCTOR SIDE)
  • Page 9 SCHEMATIC DIAGRAM-2 (LCD/KEY) LCD C.B 220/6.3 LC72343 KEY C.B 47/6.3 NM : No Mount...

  • Page 10: Electrical Adjustment

    ELECTRICAL ADJUSTMENT VOLTAGE CHART...

  • Page 12: Transistor Illustration

    IC BLOCK DIAGRAM IC, CXA1619BS TRANSISTOR ILLUSTRATION E C B E C B E C B DTA114YS 2SC1923 2SC1740 2SK880 2SC1815 2SC2001 PE8050 PE8550 2SD1468 2SA1015 D G S DTC114YK DTC114ES 2SC4116 2SC2458 2SK118...
  • Page 13 IC DESCRIPTION IC, LC72343G Pin No. Pin Name Description XOUT Connections for a 75kHz crystal oscillator element. TEST2 IC test pins. These pins must be tied to ground. Special-purpose key return signal input port. Special-purpose key source signal output port. General-purpose I/O port.
  • Page 14 Pin No. Pin Name Description ________ System reset input. HCTR Universal counter dedicated input port. — Power supply pin. FMIN FM VCO (local oscillator) input. AMIN AM VCO (local oscillator) input. — Ground pin. The main charge pump output. AOUT Transistor used for the low-pass filter amplifier.

  • Page 15: Equipment Connection Diagrams

    EQUIPMENT CONNECTION DIAGRAMS LCD DISPLAY...
  • Page 16 MECHANICAL EXPLODED VIEW 1/1 PLATE, SILICON PLATE A PC 62-46-0.5 P.W.B SH, LCD FELT, LCD P.W.B BAR-ANT P.W.B...

  • Page 17: Mechanical Parts List

    MECHANICAL PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 8A-RU5-003-010 PANEL,FRONT EZ S 16 8A-RU3-201-010 HLDR,DIS 2 8A-RU3-013-010 WINDOW,LCD 17 8A-RU3-208-010 HLDR,BAR-ANT 3 8A-RU5-001-010 CABI,FRONT EZ S 18 8A-RU3-209-010 FOOT,RUBBER 4 8A-RU3-008-010 BTN,SUMMER 19 8A-RU3-206-010 PLATE,SW COVER...
  • Page 18 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 H251701 Printed in Singapore...

This manual is also suitable for:

Fr-da400 ez s

Table of Contents
