Summary of Contents for Axis A4010-E
- Page 1 AXIS A4010–E Reader Installation Guide (English)
-
Page 2: Electromagnetic Compatibility (Emc)
This equipment has been designed and tested to fulfill Every care has been taken in the preparation of this applicable standards for: document. Please inform your local Axis office of any inaccuracies or omissions. Axis Communications • Radio frequency emission when installed... -
Page 3: Disposal And Recycling
Directive 1999/5/EC. This product complies with IEC/EN 60950-1 and IEC/EN 60950-22, Safety of Information Technology Equipment. Par la présente Axis Communications AB déclare que l’appareil ce produit est conforme aux exigences Disposal and Recycling essentielles et aux autres dispositions pertinentes de When this product has reached the end of its la directive 1999/5/CE. -
Page 4: Hazard Levels
Support Should you require any technical assistance, please Indicates useful information which helps contact your Axis reseller. If your questions cannot in getting the most out of the product. be answered immediately, your reseller will forward your queries through the appropriate channels to Safety Instructions ensure a rapid response. -
Page 5: Installation Steps
AXIS A4010–E Reader Installation Guide This Installation Guide provides instructions for connecting AXIS A4010-E Reader to a network door controller. AXIS A4010-E Reader is an OSDP reader that is designed to communicate with Axis network door controllers. Installation Steps Make sure the package contents, tools and other materials necessary for the installation are in order. -
Page 6: Hardware Overview
AXIS A4010–E Reader Hardware Overview Frontplate Core unit Cable Red LED Green LED Double sided tape Reader Feedback The table shows the feedback signals that are preconfigured in the reader when connected to an Axis network door controller. -
Page 7: Specifications
AXIS A4010–E Reader LED indicator Beeper pattern Event/state Door locked Silent Steady red Door unlocked Silent Steady green Access granted One short beep Steady green Access denied One long beep Steady red Pre-alarm warning Short beeps until Steady red entering new state... - Page 8 IEC/EN 60950-1, IEC/EN 60950-22 EN 50581 (RoHS) IEC/EN 60529 IP54 PVC free Dimensions 85 x 46 x 19 mm (3.35 x 1.8 x 0.75 in) (HxWxD) Weight 128 g (0.28 lb) Warranty Axis 3-year warranty and AXIS Extended Warranty option, see www.axis.com/warranty...
- Page 9 Use a Safety Extra Low Voltage (SELV) compliant limited power source (LPS) with a rated output current limited to ≤2 A. For example, AXIS A1001 Network Door Controller fulfills these requirements when powered by Power over Ethernet (PoE) or a SELV-compliant LPS.
- Page 10 • The recommended maximum cable length is up to 30 m (98.4 ft). Connection with AXIS A1001 To use the reader with AXIS A1001, connect the RS485 wires from A to B and from B to A. For more information about Axis network door controller connections, see the hardware pin chart, generated through the door controller’s hardware...
- Page 11 In the door controller, the alarm event can be used to trigger an action. For information, see the door controller’s User Manual. Note Mount the Axis product first and then connect the cable. The accelerometer (for tampering alarm) is calibrated at power on. RS485 Termination...
-
Page 12: Install The Hardware
AXIS A4010–E Reader Install the Hardware Remove the frontplate from the core unit. - Page 13 AXIS A4010–E Reader Hold the core unit against the wall and mark your holes with a pencil. Drill your holes in the wall and mount the core unit to the wall. Use drill bits, screws and plugs that are appropriate for...
-
Page 14: Further Information
Fasten the double sided tape onto the main unit. Position it carefully under the two LEDs. Push the frontplate onto the main unit. Further information • For the latest version of this document, see www.axis.com • To check if there is updated firmware available for your product, see www.axis.com/support •... -
Page 15: Warranty Information
AXIS A4010–E Reader Warranty Information For information about Axis’ product warranty and thereto related information, see www.axis.com/warranty/... - Page 16 Ver. M1.15 Installation Guide (English) AXIS A4010–E Reader Date: June 2016 © Axis Communications AB, 2016 Part No. 1594648...
