Summary of Contents for Dacor Discovery DYF42BSIWS
-
Page 1: Installation Instructions
Installation Instructions Discovery 42-inch Built-in Stainless Refrigerator ® Model DYF42BSIWS Document Number 109524 Rev. B MFL67410809... - Page 2 © 2016 Dacor, all rights reserved.
-
Page 3: Table Of Contents
Keep this Installation Instructions manual for future needs and for the local inspector’s reference. If you have questions or problems with installation, contact your Dacor dealer or the Customer Service Team at Dacor. Whenever you call, please have the model and serial number of the product(s) ready. -
Page 4: Refrigerator Safety
Also keep items that could explode, such as aerosol cans away from cooktop Always contact the Dacor Customer Service Team about burners, ovens and range hoods. Do not store flammable problems and conditions that you don’t understand. -
Page 5: Conservez Ces Instructions
Sécurité du réfrigérateur Sécurité du réfrigérateur DANGER Nous donnons de nombreux messages de sécurité importants dans ce manuel et sur votre appareil ménager. Assurez-vous de toujours lire tous les messages de sécurité et de vous y conformer. Ce guide contient plusieurs messages de sécurité très importants. -
Page 6: Installation Safety
Installation Safety DANGER Location and Installation Safety IMPORTANT WARNING If any doorways are too small for the refrigerator to pass through, the doors on the refrigerator can be removed. ■ Before installing the refrigerator, connect it to a power This refrigerator is a “built-in” style refrigerator, meaning outlet and turn the refrigerator ON to make sure the that the refrigerator requires installation inside a recess in refrigerator is working. - Page 7 Sécurité d’emplacement DANGER Exigences d’emplacement REMARQUE Si toutes les portes sont trop petites pour le réfrigérateur AVERTISSEMENT de passer à travers , les portes du réfrigérateur peuvent être enlevés. Observer les dispositions de tous les codes et règlements en vigueur. Installer le réfrigérateur de façon à...
-
Page 8: Specification Sheet
Specification Sheet Specifications Total Capacity (L) 25.6 cu.ft. (725 L) Freezer Capacity 9.4 cu.ft. (265 L) Refrigerator Capacity 16.2 cu.ft. (460 L) Dimensions 41”- 42” × 83 1 /2” × 25 3 /8” (106.7×212×64.5 cm) Outer Dimensions (W x H x D) 42”... -
Page 9: Tipping Radius
Tipping Radius Tipping Radius WARNING Because the refrigerator is top-heavy, it will tip easily when it is not permanently attached to the cabinet. AVERTISSIMENT For more on this, go to page 17 and see Attaching to the Cabinet. Below is the radius measurement from the top of the refrigerator to the floor: 92 13 /16 in 86 in... -
Page 10: Installation Requirements
Installation Requirements Tools and Parts Accessory Kit Images Gather the required tools and parts before starting the installation. Read and follow the instructions provided with the tools. All items that are included with the refrigerator are listed here in the Accessory Kit. WrenchTool Accessory Kit Water filter... -
Page 11: Cutout Requirements
Installation Requirements DANGER Cutout Requirements AVERTISSEMENT WARNING Cutout Dimensions ( 42” x 83 3 /4” x 24” (106.7 x 212.7 x 61 cm ) ƒ Make sure a dedicated, grounded, 3-prong outlet is ƒ Install the refrigerator so that it can be pulled away installed to supply electrical from the wall if service becomes necessary. -
Page 12: Product Specifications
Product Specifications Refrigerator Dimensions Outside Dimensions ( Rear Dimensions 42” x 83 1 /2” x 25 3 /8” 41 in (106.7 x 212. x 64.5 cm) (104.14 cm) 82 1 /2 in (209.55 cm) 83 1 /2 in (212.09 cm) 25 3 /8 in (64.50 cm) 42 in... -
Page 13: Refrigerator With Cabinet Dimensions
Product Specifications Refrigerator with Cabinet Dimensions Space Behind the Refrigerator 5 /32 in (0.4 cm) Floor to Top of Cabinet 83 3 /4 in (212.73 cm) 83 1 /2 in (212.09 cm) Floor to Handle 13 /16 in 27 5/8 in (88.48 cm) (70.2 cm) Bottom Section... -
Page 14: Door-Swing Radius
Product Specifications Door-Swing Radius 41” Refrigerator Door Opening: Wide-Open (130°) Doors can be fully opened when the refrigerator is 39 3/8” 44 1/2” extended about 2 inches from the cabinet recess. (100 cm) (113 cm) 42” Cabinet This allows: • clearance between the cabinet and doors •... -
Page 15: Installation Instructions
Installation Instructions Inserting 90-Degree Door-Stops If the refrigerator is seated deeply within a cabinetry recess, stop-pins can be inserted in the doors to prevent them from opening fully outward and harming the surrounding cabinetry. Refer to the two images on the previous page that show the cabinet and the opened refrigerator doors. -
Page 16: Meeting Electrical Requirements
Installation Instructions Meeting Electrical Requirements WARNING Before you move your refrigerator into its final position, it is important to make sure you have the correct, legal Electrical Shock Hazard electrical connection. The following electrical specifications are required: 115 Volt, 60 Hz., with a 15 or 20 Amp. fused, grounded Plug into a grounded, dedicated 3-prong outlet. -
Page 17: Connecting To The Main Water Supply
Installation Instructions Connecting to the Main Water Supply Before connecting the refrigerator’s water line to the house’s main water supply, the house’s plumbing layout must be understood. 1. Decide the best way to utilize the plumbing layout, then 2. Tap into the main water line while following these requirements: •... -
Page 18: Connecting The Water Line
Installation Instructions Connecting the Water Line Finish the instructions on the previous page called “Connecting to the Main Water Supply.” The “water line” refers to the line or pipe that connects the refrigerator to the house’s main water supply. Check for and repair any water leaks at the main water supply valve before continuing. -
Page 19: Attaching To The Cabinet
Installation Instructions Attaching to the Cabinet Method #1 DANGER This refrigerator is top-heavy and MUST be attached to WARNING 1/4 in the surrounding cabinetry, otherwise it will fall forward 0.64 cm and could cause injury or death. WARNING L-Bracket AVERTISSIMENT M4 L12 M4*L12 screw x 6 Suspending L-Brackets Above the Refrigerator... -
Page 20: Removing / Attaching The Top Grill
Installation Instructions Removing / Attaching the Top Grill AVERTISSEMENT If the height of the doors needs to be adjusted, the top grill must be removed first. Risque de coupure de la mains Refer to the images at the right while following these steps. WARNING 1. -
Page 21: Adjusting The Height
Installation Instructions Adjusting the Height WARNING Refer to the images at the right while following these steps: The bolts that adjust the refrigerator’s height are near the front feet. They adjust both the rear and front of the refrigerator. Caution: If the doors are adjusted too far, the sensors can Tip Hazard fail to detect the doors. -
Page 22: Adjusting The Door Height
Installation Instructions Adjusting the Door Height WARNING AVERTISSEMENT Risque de basculement Tip Hazard Le réfrigérateur est lourd au sommet et bascule Refrigerator is top-heavy and tips easily when not facilement lorsqu'il n'est pas complètement installé. securely installed. Keep doors taped closed until refrigerator is in its final Garder les portes fermées avec un ruban adhésif position and ready to be secured in place. -
Page 23: Adjusting The Door Gap
Installation Instructions Adjusting the Door Gap The gap between the doors is factory set to 5/16 (8 mm) before shipping. If the doors get misaligned and this gap needs to be reset, follow these instructions to adjust the right-side, refrigerator door. Refrigerator Door 1. - Page 24 Installation Instructions Adjusting the Door Gap The gap between the doors is factory set to 5/16 (8 mm) before shipping. If the doors get misaligned and this gap needs to be reset, follow these instructions to adjust the left-side, freezer door. Freezer Door 1.
-
Page 25: Wiring Diagram
Wiring Diagram Printed Circuit Board (PCB) REFRIGERATOR MODEL# DYF42BSIWS PCB Assembly Board BOARD... - Page 28 Dacor ● 14425 Clark Avenue, City of Industry, CA 91745 ● Phone: (800) 793-0093 ● Fax: (626) 403-3130 ● www.dacor.com...
