- Page 1 Quick Installation Guide TE100-P21 3.01...
-
Page 2: Table Of Contents
Table of Contents English 1. Before You Start 2. How to Install 3. Configure the Printer Server 4. Add the Printer to your computer Troubleshooting Version 02.28.2011... -
Page 3: English
1. Before You Start Package Contents Ÿ TE100-P21 Ÿ Utility CD-ROM Ÿ Multi-Language Quick Installation Guide Ÿ AC Power Adapter (5V DC, 2.5A) System Requirements Ÿ CD-ROM Drive Ÿ Router Ÿ An available DHCP Server – routers usually have a built-in DHCP server... -
Page 4: How To Install
2. Hardware to Install Note: Please power off all printers before connecting them to the print server. Then turn on each printer after you make your hardware connections. 1. Connect a RJ-45 network cable from a Switch/ Router to the LAN port of the Print Server. 2. -
Page 5: Configure The Printer Server
3. Configure the Print Server Note: The Print Server can be managed using the PS-Utility or a web browser. For Mac users, change your computers IP address to 192.168.0.X (where X is an available number from 2-254). Since the Print Server's default IP address is 192.168.0.1, make sure no other network devices are assigned an IP address of 192.168.0.1. - Page 6 5. Click the Print Server and click Change IP Address. Manually assign the IP Address of the Print Server and then click OK. Note: The IP Address must match the network segment of your network. 6. Click OK. 7. Click Show Web Setup. Print Server configuration is now complete.
-
Page 7: Add The Printer To Your Computer
4. Add the Printer to your computer Note: For printing instructions for Windows ME, 98SE, and Mac OS X, please consult the User's Guide included on the Utility CD-ROM. Windows 7/Vista/2003 Server/XP/2000 1. Click PS Wizard and then click Win 7/Vista/2003/XP/2000. 2. - Page 8 4. Click Next. 5. Click Print Test Page. 6. Click OK.
- Page 9 Add Printer is now complete For detailed information regarding the TE100-P21 configuration and advanced settings, please refer to User's Guide on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register...
-
Page 10: Troubleshooting
Troubleshooting 1. I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu does not appear automatically. What should I do? For Windows 2000/2003 Server/XP, if the window does not appear automatically, click Start, click Run and type D:\autorun.exe where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard. - Page 11 1. Open PS Wizard (See 4. Add the Printer to your PC) to locate your print server's IP Address. 2. For MAC users, press the Reset button at the back of the TE100-P21, hold the button for 15 seconds, release the button, and enter http://192.168.0.1...
- Page 14 Copyright © 2011. All Rights Reserved. TRENDnet.
