Summary of Contents for Rear view safety RVS-250C
-
Page 2: Table Of Contents
Taking Pictures .......................9 g) Playback Mode ......................10 Menu Setting........................11 a) Video Mode........................11 b) Playback Mode......................12 Connection........................13 a) Connect to TV......................13 b) Connect to Computer ....................13 DVR Player ........................14 Product Specification .....................15-16 Other Information......................17 Warranty ...........................18 Disclaimer .........................19 Rear View Safety... -
Page 3: Product Picture & Function
Product Picture & Function a) Device Introduction 1. SD Card Slot 11. LCD Display 2. HDMI Port 12. Up Button 3. LED Light 13. OK Button 4. Lens 14. Down Button 5. Speaker 15. Power Button 6. Status Light (Blue) 16. -
Page 4: B) Button Function
In playback mode, press this button to lock or unlock the video file. When file protection is active, the icon will appear Rear View Safety... - Page 5 Product Picture & Function on LCD display. Mode Button The device only has two modes, video mode and playback mode. Pressing this button during standby will switch device to recording mode. When the device is recording, pressing this button will have no effect. Up Button In video mode, press this button to turn on/off LCD display.
-
Page 6: C) Led Light Status List
Device is in standby or Playback Mode Device is off Charging Battery Charging Light (Red) Charging complete Basic Operation a) SD Card Installation Install the Micro SD into the Micro SD card slot as shown in the picture. Rear View Safety... -
Page 7: B) Gps Installation
Product Picture & Function b) GPS Installation Insert GPS into camera mount as shown in the image below. Install the device on the windshield with adhesive pad or suction cup mount. When the power is on, the device will automatically start to catch GPS signal. -
Page 8: C) Power Supply
The G-sensor will detect any abrupt movements or stops to the vehicle. When it senses a sudden stop or an impact on the vehicle, it will activate "protection mode". This will protect the video files from being over-written by the loop-recording, saving the most important video. Rear View Safety... -
Page 9: E) Video Mode
Camera Dimensions e) Video Mode In video mode, in standby status, LCD display will be shown as below: In video mode, in recording status, LCD display will be shown as below: f) Taking Pictures In video mode, at any time, press photo button to take picture. Reverse With Confidence... -
Page 10: G) Playback Mode
Up Button Previous file Down Button Next file OK Button Confirm Menu Button Enter menu list File Protection Button Lock/unlock video/picture file Mode Button Change mode Play OK Button Play/pause Mode Button Back to six grids preview Rear View Safety... -
Page 11: Menu Setting
Menu Setting The device has two mode, Video Mode and Playback Mode. a) In Video Mode: Setup Menu Item 2560x1080@30fps/ 2304x1296@30fps/ Video Resolution 1920x1080@45fps/ 1920x1080@30fps/ 1280x720@60fps Loop Setting Off/1min/3min/5min Motion Detect Off/On Sensor Flip Off/On Flicker Auto/50Hz/60Hz White Balance Auto/sunny/cloudy/tungsten/flourescent Contrast Standard/High/Low Sharpness... -
Page 12: B) Playback Mode
Back to Previous Level File Protection Operation Protect Current File/Protect All File/Unprotect Current File/ Unprotect All File Auto Play Video Play One/Video Play All/Video Repeat One/ Video Repeat All Delete file No/Delete this file/Delete All files Format No/Yes REAR VIEW SAFETY... -
Page 13: Connection
Connection a) Connect to TV The device can output the video to video equipment (TV or Monitor) to playback the data or adjust the settings. 1. Insert Micro SD card into device. 2. Connect HDMI cable to the video equipment (TV or Monitor) and to the device. -
Page 14: Dvr Player
The camera software comes preloaded onto the microSD card. Simply inser SD card into computer to install software. The DVR player will be shown as- below. Pressing this button, video file can copy to any folder means video is locked REAR VIEW SAFETY... -
Page 15: Product Specification
Product Specification Resolution 1/3” 4.0 Mega CMOS Sensor, OV4689, good night Camera vision performance Lens F/NO=2.0, 110° Horizon Angle in 1080P Standard Mov file, H.264 Compression Resolution 2560x1080@30fps/2304x1296@30fps/1920x10 Video 80@45fps/ 1920x1080@30fps/1280x720@60fps WDR Function Wide Dynamic Range, Good Night Recording Audio Built-in Microphone, can be turned off in menu Still Image 2688x1512 (4M) -
Page 16: Product Specification
Other Function Uniterrupted Recording: Over-writes first file if memory is full, no interruption between Video File File Protection Function: Once File is pro- tected, it wont be deleted during cycle recording Automatically starts recording when car starts. REAR VIEW SAFETY... -
Page 17: Other Information
Rear View Safety, Inc. system after partial failure or use with im- proper accessories. - Page 18 In no event shall Rear View Safety and/or its affiliates have any liability for any losses (whether direct...
-
Page 19: Disclaimer
If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 BETTER CAMERAS. BETTER SERVICE. IT’S OUR GUARANTEE. Reverse With Confidence...
